ZiLOG Zdots eZ80AcclaimPlus Manual de usuario

www.zilog.com

UM022403-1008

User Manual

Wireless Zdots®Single

Board Computer

Development Kit

Wireless Zdots® SBC Development Kit

User Manual

UM022403-1008 Revision History

Revision History

Each instance in Revision History reflects a change to this document from its previous

revision. For more details, refer to the corresponding pages and appropriate links in the

table below.

Date

Revision

Level Description Page Number

October

2008

03 Replaced WiFi with Wireless. All

October

2008

02 Updated Wireless Zdots® SBC Development Kit

Overview, Wireless Zdots® SBC Development Kit

Connectors/Jumper, Physical Dimensions

(Figure 6 Title) sections.

2, 5, 6

October

2008

01 Original issue. All

Wireless Zdots® SBC Development Kit

User Manual

UM022403-1008 Safeguards

iii

Safeguards

The following precautions must be observed when working with the devices described in

this document.

Always use a grounding strap to prevent damage resulting from electrostatic discharge

(ESD).

Caution:

Wireless Zdots® SBC Development Kit

User Manual

UM022403-1008 Table of Contents

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Kit Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Wireless Zdots®SBC Development Kit Overview. . . . . . . . . . . . . . . . . . . . . . . . . . 2

Wireless Zdots®SBC Development Kit Boards . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Wireless Zdots®SBC Development Kit Connectors/Jumper. . . . . . . . . . . . . . . . . 5

Physical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Flash Loader Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Mounting the Wireless Zdots®SBC to the Base Board . . . . . . . . . . . . . . . . . . . . . 7

Changing the Power Supply Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Wireless Zdots® SBC Development Kit

User Manual

UM022403-1008 Introduction

Introduction

Zilog’s Wireless Zdots®Single Board Computer (SBC) Development Kit provides a gen-

eral-purpose platform to evaluate the capabilities and operation of Zilog’s eZ80F91 micro-

controller unit (MCU) and the Realtek 8711 Wireless Transceiver. The eZ80F91 is a

member of eZ80AcclaimPlus!™product family, which offers on-chip Flash capability.

The Wireless Zdots SBC Development Kit features two primary boards— the

eZ80AcclaimPlus! Wireless Zdots SBC and a base board. The Wireless Zdots SBC Devel-

opment Kit provides a full development platform when using both the boards. It can also

provide a smaller-sized reference platform with the Wireless Zdots SBC as a stand-alone

development tool.

Kit Features

The key features of eZ80AcclaimPlus! Wireless Zdots SBC Development Kit include:

•

eZ80AcclaimPlus! Wireless Zdots SBC

– 1 MB fast SRAM (12 ns access time)

– 4 MB NOR Flash (70 ns access time)

– Realtek RTL8711 Wireless 802.11 b/g transceiver

– On-board antenna, option for external antenna

– Two Optional headers for connection to RS-232, General-Purpose Input/Output

(GPIO), I2C, MII interface

– Programmable power switch

– Small footprint

– Standard operating Temperature range: 0 ºC to 70 ºC

•

eZ80AcclaimPlus! Wireless Zdots SBC Development Kit Base Board

– Zilog Debug Interface (ZDI)

– Supported by Zilog Developer Studio II (ZDS II) and the eZ80®C-Compiler

– Plug-in headers for the Wireless Zdots SBC and test points

– Prototype area

–Powersupply

Wireless Zdots® SBC Development Kit

User Manual

UM022403-1008 Wireless Zdots® SBC Development Kit Overview

Wireless Zdots®SBC Development Kit

Overview

The Wireless Zdots SBC Development Kit provides a set of tools to evaluate the features

of eZ80F91 MCU and the Realtek 8711 Wireless transceiver to develop a new application

before building the application hardware. The eZ80AcclaimPlus!™Wireless Zdots SBC

Development Kit, together with its plugged-in Wireless Zdots SBC, can operate in stand-

alone mode with Flash Memory, or interface via USB Smart Cable (or any Zilog®debug

tool) to a host PC running ZDS II Integrated Development Environment (IDE) software. A

block diagram of the eZ80AcclaimPlus! Wireless Zdots SBC Development Kit and the

Wireless Zdots SBC is displayed in Figure 1.

Figure 1. Wireless Zdots®SBC Development Kit Block Diagram

Wireless Zdots®SBC

Base Board

(Power Supply, Connectors, ZDI)

RS-232

Adapter

USB

Smart Cable

Power

Input 5 V

DB9

5 V

ZDI

RS-232,GPIO,I2C,MII

USB

Wireless Zdots® SBC Development Kit

User Manual

UM022403-1008 Wireless Zdots® SBC Development Kit Overview

Wireless Zdots®SBC Development Kit Boards

Figure 2 displays Wireless Zdots SBC Development Kit.

Figure 2. Wireless Zdots®SBC Development Kit

Figure 3 displays RS-232 Adapter.

Figure 3. RS-232 Adapter

Wireless

Prototype

Area

Zdots SBC

Wireless Zdots SBC Development

RS-232

Adapter

ZDI

Interface

Kit Base Board

RS-232 Driver

RS-232 DB9

6-Pin TTL Level

TX, TX, RTS, CTS,

3.3 V and Ground

Wireless Zdots® SBC Development Kit

User Manual

UM022403-1008 Wireless Zdots® SBC Development Kit Overview

Figure 4 displays Wireless Base Board.

Figure 4. Wireless Base Board

Figure 5 displays Wireless Zdots SBC.

Figure 5. Wireless Zdots®SBC

Prototype

Wireless Zdots SBC Plug-in Headers

DC Power Input

ZDI

Test Poi n ts

Interface

Area

On-Board Antenna

MII Input/Output

eZ80F91

NOR Flash

SRAM

RS-232/PWR

Input/Output

Wireless Zdots® SBC Development Kit

User Manual

UM022403-1008 Wireless Zdots® SBC Development Kit Connectors/Jumper

Wireless Zdots®SBC Development Kit

Connectors/Jumper

The Wireless Base Board include:

•

J4 DC Input 5 V

•

J6 3 pins Ground test points

•

J7 3 pins Voltage Select:

– Pins 1:2, 5.0 V connects to Wireless Zdots SBC

– Pins 2:3, 3.3 V connects to Wireless Zdots SBC1

•

J3 ZDI Interface

•

J8 2 pin Wireless Zdots SBC power input2

•

J1 Wireless Zdots SBC Main GPIO I/O connector

•

J2 Wireless MII I/O pins

•

J5 General Test points

1. The default jumper setting is 2:3 CLOSE (jumper is placed near 3.3 V label)

2. The default jumper setting is 1:2 CLOSE

Wireless Zdots® SBC Development Kit

User Manual

UM022403-1008 Physical Dimensions

Physical Dimensions

The dimensions of the Wireless Zdots SBC (see Figure 6) are 2.20 inches x 3.50 inches

(55.88 mm x 88.90 mm).

Figure 6. Physical Dimensions of the Wireless Zdots®SBC

Flash Loader Utility

The Flash Loader utility integrated within ZDS II provides a convenient way to program

on-chip and off-chip Flash Memory. For more details, refer to Zilog Developer Studio II-

eZ80Acclaim!®User Manual (UM0144).
