Zennio MINiBOX 45v2 Manual de usuario

➢

MINiBOX 45 v2 / MINiBOX 25 v2

Multifunction Actuator with 4 or 5 Outputs and 5 Inputs

ZIOMN45V2

USER MANUAL

ZIOMN25V2

Application program version: [1.1]

User manual edition: [1.1]_a

www.zennio.com

 MINiBOX 45 v2/MINiBOX 25 v2
http://www.zennio.com Technical Support: http://support.zennio.com


CONTENTS
Contents........................................................................................................................................ 2
Introduction .......................................................................................................................... 3
1 MINiBOX 25 v2 / MINiBOX 45 v2 ..................................................................................... 4
2 Installation........................................................................................................................ 6
3 Start-Up and Power Loss.................................................................................................. 7
Configuration......................................................................................................................... 8
1 General............................................................................................................................. 8
2 Inputs ............................................................................................................................. 11
2.1 Binary Input............................................................................................................ 11
2.2 Temperature Probe................................................................................................ 11
2.3 Motion Detector .................................................................................................... 11
3 Outputs........................................................................................................................... 13
4 Logic Functions............................................................................................................... 14
5 Thermostats ................................................................................................................... 15
6 Master Light ................................................................................................................... 16
7 Scene Temporisation...................................................................................................... 19
8 Manual Control .............................................................................................................. 21
ANNEX I. Communication Objects............................................................................................... 26

MINiBOX 45 v2/MINiBOX 25 v2

http://www.zennio.com Technical Support: http://support.zennio.com

DOCUMENT UPDATES

Version

Changes

Page(s)

[1.1_a]

Changes in the application program of MINiBOX 45 / 25 v2:

•Internal optimisation.

MINiBOX 45 v2/MINiBOX 25 v2

http://www.zennio.com Technical Support: http://support.zennio.com

1INTRODUCTION

1.1 MINiBOX 25 v2 / MINiBOX 45 v2

MINiBOX 45 v2 and MINiBOX 25 v2 from Zennio are two versatile KNX actuators

featuring a wide variety of functions, being both of them entirelyequivalent except for the

number of individualbinary outputs available (four in MINiBOX 45 v2 and two in MINiBOX

25 v2) and by the incorporation of the functional block fancoil in the MINiBOX 45 v2.

The most outstanding features are:

4 / 2 relay outputs, respectively, configurable as:

➢Up to 4 / 2 individual ON/OFF output,

➢Up to 2 / 1 independent shutter channels (with or without slats),

➢Up to 1 two-pipe fan coil modules where both the fan speed control and

the valve control are performed through relays,

➢A combination of the above.

5 multi-purpose inputs, configurable as:

•Temperature probes, (with the possibility to parameterize a personalized

probe),

•Binary inputs (i.e., pushbuttons, switches, sensors),

•Motion detectors.

10 customisable, multi-operation logic functions.

4 independent thermostats.

Scene-triggered action control, with an optional delay in the execution.

Master light control for an easy, out-of-the-box control of a set of luminaires

(or functionally equivalent devices) one of which acts as a general lamp and

the others as secondary lamps.

MINiBOX 45 v2/MINiBOX 25 v2

http://www.zennio.com Technical Support: http://support.zennio.com

Manual operation / supervision of the 2 or 4 relay outputs through the on-

board pushbuttons and LEDs.

Heartbeat or periodical “still-alive”notification.

Relay Switches Counter.

MINiBOX 45 v2/MINiBOX 25 v2

http://www.zennio.com Technical Support: http://support.zennio.com

1.2 INSTALLATION

MINiBOX 45 / 25 v2 connects to the KNX bus through the on-board KNX connector.

Once the device is provided with power from the KNX bus, both the individual address

and the associated application program may be downloaded.

This device does not need any additional external power since it is entirely powered

through the KNX bus.

Figure 1. MINiBOX 45 v2. Elements

Note: the above element diagram is slightly different for MINiBOX 25 v2, although

entirely analogous.

The main elements of the device are described next.

Test/Prog. Pushbutton (6): a short press on this button sets the device into

the programming mode, making the associated LED (5) light in red.

Note: if this button is held while plugging the device into the KNX bus, the

device will enter into safe mode. In such case, the LED will blink in red every

0.5 seconds.

Outputs (7): output ports for the insertion of the stripped cables of the systems

being controlled by the actuator (see section 2.3). Please secure the

connection by means of the on-board screws.

1. Output Control Pushbutton.

2. Output LED Indicator.

3. Analogue-Digital Inputs.

4. KNX Bus Connector.

5. Prog./Test LED.

6. Prog./Test Pushbutton.

7. Relay Outputs.

MINiBOX 45 v2/MINiBOX 25 v2

http://www.zennio.com Technical Support: http://support.zennio.com

Inputs (3): input ports for the insertion of the stripped cables of external

elements such as switches / motion detectors / temperature probes, etc. One

of the two cables of each element need to be connected to one of the slots

labelled “1” to “6”, while the other cable should be connected to the slot labelled

as “C”. Note that all the external input devices share the “C” slot for one of the

two cables. Please secure the connection by means of the on-board screws.

To get detailed information about the technical features of this device, as well as on the

installation and security procedures, please refer to the corresponding Datasheet,

bundled with the original package of the device and also available at www.zennio.com.

1.3 START-UP AND POWER LOSS

During the start-up of the device, the Test/Prog. LED will blink in blue colour for a few

seconds before the device is ready. External orders will not be executed during this time,

but afterwards.

Depending on the configuration, some specific actions will also be performed during the

start-up. For example, the integrator can set whether the output channels should switch

to a particular state and whether the device should send certain objects to the bus after

the power recovery. Please consult the next sections of this document for further details.

On the other hand, when a bus power failure takes place, the device will interrupt any

pending actions, and will save its state so it can be recovered once the power supply is

restored. For safety reasons, all shutter channels will be stopped (i.e., the relays will

open) if a power loss takes place, while the individual outputs and fan coil contacts will

switch to the specific state configured in ETS (if any).

MINiBOX 45 v2/MINiBOX 25 v2

http://www.zennio.com Technical Support: http://support.zennio.com

2CONFIGURATION

2.1 GENERAL

After importing the corresponding database in ETS and adding the device into the

topology of the project, the configuration process begins by entering the Parameters tab

of the device.

ETS PARAMETERISATION

The only parameterisable screen that is always available is General. From this screen it

is possible to activate/deactivate all the required functionality.

Figure 2. Default screen

Inputs [disabled/enabled]

: enables o disables the “Inputs” tab on the left

menu. See section 2.2 for more details.

Outputs [disabled/enabled]: enables o disables the “Outputs” tab on the left

menu. See section 2.3 for more details.

Logic Functions [disabled/enabled]: enables o disables the “Logic Functions”

tab on the left menu. See section 2.4 for more details.

The default values of each parameter will be highlighted in this document, as follows:

[default/rest of options].

MINiBOX 45 v2/MINiBOX 25 v2

http://www.zennio.com Technical Support: http://support.zennio.com

Thermostats [disabled/enabled]: enables o disables the “Thermostats” tab

on the left menu. See section 2.5 for more details.

Master Light [disabled/enabled]: enables o disables the “Master Light” tab on

the left menu. See section 2.6 for more details.

Scene Temporization [disabled/enabled]: enables o disables the “Scene

Temporization” tab on the left menu. See section 2.7 for more details.

Manual Control [disabled/enabled]: enables o disables the “Manual Control”

tab on the left menu. See section 2.8 for more details.

Sending of Indication Objects (0 and 1) on Bus Voltage Recovery

[disabled/enabled]: this parameter lets the integrator activate two new

communication objects (“Reset 0” and “Reset 1”), which will be sent to the KNX

bus with values “0” and “1” respectively whenever the device begins operation

(for example, after a bus power failure). It is possible to parameterise a certain

delay [0…255] to this sending.

Figure 3. Sending of Indication objects on bus voltage recovery

Heartbeat (Periodical Alive Notification) [disabled/enabled]: this parameter

lets the integrator incorporate a one-bit object to the project (“[Heartbeat]

Object to Send ‘1’”) that will be sent periodically with value “1” to notify that

the device is still working (still alive).

Figure 4. Heartbeat (Periodical Alive Notification).

MINiBOX 45 v2/MINiBOX 25 v2

http://www.zennio.com Technical Support: http://support.zennio.com

Note: The first sending after download or bus failure takes place with a delay of

up to 255 seconds, to prevent bus overload. The following sendings match the

period set.

Show Relay Switches Counter Objects [disabled/enabled]: enables two

communication objects to keep track of the number of switches performed by

each of the relays (“[Relay X] Number of Switches”) and the maximum

number of switches carried out in a minute (“[Relay X] Maximum Switches

per Minute”)
