Zapi SMART CONSOLE Manual de usuario
ZAPI SMART CONSOLE
Introduction for WRT60
Location of CAN Connection
Traction VACC
Turn on ZAPI Handset
Push and hold the power button for 3s
The Display will show: Cons AFG ZP021*
The Display will show : Cons AFG ZP021*
CAN CONSOLE
Press or button until CAN
CONSOLE shows on the display
Press OK to go into the
CANCONSOLE Menu
The Display will show:
The Display will show:
CANCONSOLE
SELECT NODE
Push , or
To select Node 2
SELECT NODE
NODE 2
Press OK to go into the
Traction controller
The Display will show: AD0T2B WF6EP1.11
24V 320A 0H
Press OK to go into the
Main Menu
The Display will show: Main Menu
Press or button until
PROGRAM VACC shows on the display
The Display will show: MAIN MENU
PROGRAM VACC
Press ENTER to go into the PROGRAM
VACC function
The Display will show the minimum and
maximum values of throttle voltage. Both
directions are shown
VACC SETTING
CURRENT VALUE
Press ENTER to clear these values.
Display will show 0.0
Select Forward Direction FORWARD x.xV x.xV
Slowly depress the accelerator to its
maximum value. The new minimum
and maximum voltages will be displayed on
the Console.
Select the Reverse Direction and
repeat the item above BACKWARD x.xV x.xV
When finished , press ESC
The Display will ask : APPLY
CHANGES ? APPLY CHANGES?
YES= OK NO=ESC
Press OK for yes
When finished, the Console shows : Main Menu
Press and hold power button 3s to
turn off the Console
