Zanussi ZMSN5S Manual de usuario

User Manual

GETTING

STARTED?

EASY.

EN User manual

Microwave Oven

ZMSN5S

ZANUSSI_EN240_UKCA_17LSOLO_SBI_BASE_AE31UICTO_Layout 1 24/01/2022 08:46 Page 1

CONTENTS

1. SAFETY INFORMATION...........................................................................................................3

2. INSTALLATION ..........................................................................................................................7

3. PRODUCT DESCRIPTION .....................................................................................................11

4. OPERATION.............................................................................................................................13

5. HINTS AND TIPS ....................................................................................................................14

6. TROUBLESHOOTING.............................................................................................................16

7. TECHNICAL INFORMATION .................................................................................................17

8. ENVIRONMENT CONCERNS ................................................................................................17

ZANUSSI_EN240_UKCA_17LSOLO_SBI_BASE_AE31UICTO_Layout 1 24/01/2022 08:46 Page 2

SAFETY INFORMATION

This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

Children should be supervised to ensure that they do not play

with the appliance. Cleaning and user maintenance shall not be

made by children unless they are aged from 8 years and above

and supervised.

This appliance is not intended for use at altitudes above 2000m.

IMPORTANT! IMPORTANT SAFETY INSTRUCTIONS:

READ CAREFULLY AND KEEP FOR FUTURE

REFERENCE.

WARNING!

Do not use the appliance without the turntable and turntable

support. Do not use the appliance when empty.

WARNING!

If the door or door seals are damaged, the oven must not be

operated until it has been repaired by a competent person.

WARNING!

It is hazardous for anyone other than a competent person to

carry out any service or repair operation that involves the

removal of a cover which gives protection against exposure

to microwave energy.

WARNING!

Liquids and other foods must not be heated in sealed

containers since they are liable to explode.

ZANUSSI_EN240_UKCA_17LSOLO_SBI_BASE_AE31UICTO_Layout 1 24/01/2022 08:46 Page 3

This appliance is intended to be used in household and similar

applications such as: staff kitchen areas in shops, offices and

other working environments; farm houses; by clients in hotels,

motels and other residential environments; bed and breakfast

type environments.

Only use microwave-safe containers and utensils.

Metallic containers for food and beverages are not allowed during

microwave cooking.

Do not leave the oven unattended when using disposable plastic,

paper or other combustible food containers.

The microwave oven is intended for heating food and beverages.

Drying of food or clothing and heating of warming pads, slippers,

sponges, damp cloth and similar may lead to risk of injury,

ignition or fire.

If food being heated begins to smoke, DO NOT OPEN THE

DOOR. Turn off and unplug the oven and wait until the food has

stopped smoking. Opening the door while food is smoking may

cause a fire.

Microwave heating of beverages can result in delayed eruptive

boiling, therefore care has to be taken when handling the

container.

The contents of feeding bottles and baby food jars shall be stirred

or shaken and the temperature checked before consumption, in

order to avoid burns.

Do not cook eggs in their shells and whole hard boiled eggs

should not be heated in microwave ovens since they may

explode even after microwave cooking has ended.

ZANUSSI_EN240_UKCA_17LSOLO_SBI_BASE_AE31UICTO_Layout 1 24/01/2022 08:46 Page 4

CARE AND CLEANING

Door:

To remove all trace of dirt, regularly clean both sides of the

door, the door seals and sealing surfaces with a soft, damp

cloth. Do not use harsh abrasive cleaners or sharp metal

scrapers to clean the oven door glass since they can scratch

the surface, which may result in shattering of the glass.

Oven interior:

For cleaning, wipe any splatters or spills with a soft damp cloth

or sponge after each use while the oven is still warm. For

heavier spills, use a mild soap and wipe several times with a

damp cloth until all residues are removed. Do not remove the

waveguide cover. Make sure that mild soap or water does not

penetrate the small vents in the walls which may cause damage

to the oven.

Do not use spray type cleaners on the oven interior.

Clean the

waveguide cover, the oven cavity, the turntable and turntable

support after use. These must be dry and free from grease. Built-

up grease may overheat and begin to smoke or catch fire.

Oven exterior:

The outside of your oven can be cleaned easily with mild soap

and water. Make sure the soap is wiped off with a moist cloth,

and dry the exterior with a soft towel.

Control panel:

Open the door before cleaning to de-activate the control panel.

Care should be taken when cleaning the control panel. Using a

cloth dampened with water only, gently wipe the panel until it

becomes clean. Avoid using excessive amounts of water. Do

not use any sort of chemical or abrasive cleaner.

Turntable and turntable support:

Remove the turntable and turntable support from the oven.

Wash the turntable and turntable support in mild soapy water.

Dry with a soft cloth. Both the turntable and the turntable

support are dishwasher safe.

ZANUSSI_EN240_UKCA_17LSOLO_SBI_BASE_AE31UICTO_Layout 1 24/01/2022 08:46 Page 5

IMPORTANT!

Clean the oven at regular intervals and remove any food

deposits. Failure to maintain the oven in a clean condition

could lead to a deterioration of the surface that could

adversely affect the life of the appliance and possibly result

in a hazardous situation.

Care should be taken not to displace the turntable when

removing containers from the appliance.

IMPORTANT!

A steam cleaner should not be used.

The microwave oven is intended to be used built-in.

The appliance and its accessible parts become hot during use.

WARNING!

Children should be kept away to prevent them burning

themselves.

IMPORTANT!

Do not use commercial oven cleaners, steam cleaners,

abrasive, harsh cleaners, any that contain sodium

hydroxide or scouring pads on any part of your microwave

oven.

ZANUSSI_EN240_UKCA_17LSOLO_SBI_BASE_AE31UICTO_Layout 1 24/01/2022 08:46 Page 6

INSTALLING THE APPLIANCE

1. Remove all packaging and check carefully for

any signs of damage.

2. Fit the fixing bracket to the right hand side of

the kitchen cupboard using the installation

sheet and two screws supplied.

3. Fit the appliance into the kitchen cupboard

slowly and without force until it clips into the

brackets. Ensure the appliance is stable and

centralised.

4. Fix the oven on the left hand side using the two

screws supplied.

5. The front frame of the appliance should seal

against the front opening of the cupboard.

IMPORTANT!

Do not install this appliance in kitchen

cupboards without the specified 45mm rear

chimney. Inadequate ventilation could

adversely affect the performance and life of

the appliance.

Do not install this appliance in kitchen

cupboards that are adjacent to sources of

heat and steam such as hobs and cook

tops. Such sources could adversely affect

the performance and life of the appliance.

4,5

5,5

595

390

min.

380

292

352

452

min.560

min.

300

380

560

350

600

INSTALLATION

ZANUSSI_EN240_UKCA_17LSOLO_SBI_BASE_AE31UICTO_Layout 1 24/01/2022 08:46 Page 7

ZANUSSI_EN240_UKCA_17LSOLO_SBI_BASE_AE31UICTO_Layout 1 24/01/2022 08:46 Page 8

• The electrical outlet should be readily

accessible so that the unit can be unplugged

easily in an emergency. Or it should be

possible to isolate the oven from the supply by

incorporating a switch in the fixed wiring in

accordance with the wiring rules.

• The power supply cord may only be replaced

by an electrician.

• If the supply cord is damaged it must be

replaced by the manufacturer, its service agent

or similarly qualified persons in order to avoid a

hazard.

• The socket should not be positioned behind the

cupboard.

• The best position is above the cupboard, see

(A).

• Connect the appliance to a single phase

230-240 V/50 Hz alternating current via a

correctly installed earth socket.

• If the appliance is to be operated in a non-

European country, the supply voltage, current

type and frequency of the appliance indicated

on the rating plate must correspond with the

specification of your power supply. The rating

plate can be found on the inside face of the

control panel.

• Before installing, tie a piece of string to the

power supply cord to facilitate connection to

point (A) when the appliance is being installed.

• When inserting the appliance into the high-

sided cupboard, DO NOT crush the power

supply cord.

• Do not immerse the power supply cord or plug

in water or any other liquid.

• Do not allow the power supply cord to run over

any hot or sharp surfaces, such as the hot air

vent area at the top rear of the oven.

CONNECTING THE APPLIANCE TO THE

POWER SUPPLY

(A)

ZANUSSI_EN240_UKCA_17LSOLO_SBI_BASE_AE31UICTO_Layout 1 24/01/2022 08:46 Page 9

Do not use the microwave oven to heat oil for deep

frying. The temperature cannot be controlled and

the oil may catch fire. To make popcorn, only use

special microwave popcorn makers.

Individuals with PACEMAKERS should check with

their doctor or the manufacturer of the pacemaker

for precautions regarding microwave ovens.

Never spill or insert any objects into the door lock

openings or ventilation openings. In the event of a

spill, turn off and unplug the oven immediately and

call an authorised ELECTROLUX service agent.

Never modify the oven in any way.

Only use the turntable and the turntable support

designed for this oven. Do not operate the oven

without the turntable.

To prevent the turntable from breaking:

• Before cleaning the turntable with water, leave

the turntable to cool.

• Do not put hot foods or hot utensils on a cold

turntable.

• Do not put cold foods or cold utensils on a hot

turntable.

Neither the manufacturer nor the dealer can

accept any liability for damage to the oven or

personal injury resulting from failure to observe the

correct electrical connection procedure. Water

vapour or drops may occasionally form on the

oven walls or around the door seals and sealing

surfaces. This is a normal occurrence and is not an

indication of microwave leakage or a malfunction.

Concerning the lamp(s) inside this product and

spare part lamps sold separately: These lamps are

intended to withstand extreme physical conditions

in household appliances, such as temperature,

vibration, humidity, or are intended to signal

information about the operational status of the

appliance. They are not intended to be used in

other applications and are not suitable for

household room illumination.

ADDITIONAL ADVICE

ZANUSSI_EN240_UKCA_17LSOLO_SBI_BASE_AE31UICTO_Layout 1 24/01/2022 08:46 Page 10

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Microondas de Zanussi

Zanussi

Zanussi ZM27T Manual de usuario

Zanussi

Zanussi ZMF32E8 Manual de usuario

Zanussi

Zanussi ZNF21X Manual de usuario

Zanussi

Zanussi ZKC44510X Manual de usuario

Zanussi

Zanussi ZSC25259 Manual de usuario

Zanussi

Zanussi zm21mg Manual de usuario

Zanussi

Zanussi ZSG25224 Manual de usuario

Zanussi

Zanussi MW155 Guía de referencia rápida

Zanussi

Zanussi ZBM17542XA Manual de usuario

Zanussi

Zanussi ZM30 TH Manual de usuario

Zanussi

Zanussi ZBG26542XA Manual de usuario

Zanussi

Zanussi ZMF32E8 Manual de usuario

Zanussi

Zanussi ZKC44500XA Manual de usuario

Zanussi

Zanussi ZNF51X Manual de usuario

Zanussi

Zanussi ZMO19M Manual de usuario

Zanussi

Zanussi MW 2732 Manual de usuario

Zanussi

Zanussi ZMB 30 CST Manual de usuario

Zanussi

Zanussi ZSC25225 Manual de usuario

Zanussi

Zanussi MW600 Instrucciones de funcionamiento y seguridad

Zanussi

Zanussi ZNF21X Manual de usuario

Zanussi

Zanussi ZMD30STQ Manual de usuario

Zanussi

Zanussi MM1200B Instrucciones de montaje

Zanussi

Zanussi ME965 Instrucciones de montaje

Zanussi

Zanussi MW530D Guía de referencia rápida

Manuales populares de Microondas de otras marcas

Daewoo

Daewoo KOG-574R0S Manual de usuario

LG MH7040SS Manual de usuario

Sharp

Sharp R-895(AL)M Manual de usuario

Dometic

Dometic DOTRM13W Manual de usuario

Sanyo

Sanyo EM-X680 Manual de usuario

Sharp

Sharp R-393M Manual de usuario

KitchenAid

KitchenAid KMCX4510 Instrucciones de instalación

Smeg

Smeg S45MCX1 Manual de usuario

Russell Hobbs

Russell Hobbs RHM2044 Manual de usuario

Sunbeam

Sunbeam SMW759 Manual de usuario

Gallet

Gallet FMOE230S Manual de usuario

Bosch

Bosch CEG732X.1B Manual de usuario

Dometic

Dometic Roadmate 230 Manual de usuario

Samsung

Samsung SJ0396W Manual de usuario

Sanyo

Sanyo EM-P494WS Manual de usuario

Sharp

Sharp R-240 Manual de usuario

Electrolux

Electrolux EMS2840 Manual de usuario

Daewoo

Daewoo KOC-984T2S13 Manual de usuario
