YOKOGAWA FA-M3 FA Link H Module Manual de usuario

Applicable Modules:

Model Code Model Name

F3LP02-0N FA Link H Module

F3LP12-0N Fiber-optic FA Link H Module

User’s

Manual

IM 34M06 H43-01E

FA Link H Module

Fiber-optic FA Link H Module

Model: F3LP02-0N, F3LP12-0N

IM 34M06 H43-01E

6th Edition

Yokogawa Electric Corporation

Blank Page

IM 34M06H43-01E

6th Edition : Aug.30, 2019-00

Applicable Product

Range-free Controller FA-M3

- Model : F3LP02-0N

- Name : FA Link H Module

- Model : F3LP12-0N

- Name : Fiber-optic FA Link H Module

The document number for this manual is given below.

Refer to the document number in all communications, including when purchasing

additional copies of this manual.

- Document No.: IM 34M06H43-01E

IM 34M06H43-01E

6th Edition : Aug.30, 2019-00

Precautions

About This Manual

- This Manual should be passed on to the end user.

- This manual is an essential part of the product; keep it in a safe place for future

reference.

- This product is designed to be used by a person with specialized knowledge.

- Before using the product, read this manual thoroughly to have a clear understanding

of the product.

- This manual explains the functions of this product, but there is no guarantee that

they will suit the particular purpose of the user.

- Under absolutely no circumstances may the contents of this manual be transcribed

or copied, in part or in whole, without permission.

- The contents of this manual are subject to change without prior notice.

- Every effort has been made to ensure accuracy in the preparation of this manual.

However, should any errors or omissions come to the attention of the user, please

contact the nearest Yokogawa Electric representative or sales office.

Safety Symbols

- ”Handle with care.” This symbol on the product indicates that the operator must

follow the instructions laid out in this user's manual to avoid the risk of personnel

injuries, fatalities, or damage to the instrument.

- Protective Conductor Terminal

This terminal is to prevent electric shock. Before using the instrument, connect to

the Protective earth (Comply with the regulation of each country.), and route the line

through the shortest path possible.

- Functional Earth Terminal

This terminal is for stable operation. Before using the instrument, be sure to ground

this terminal.

- Alternating current. Indicates alternating current.

- Direct current. Indicates direct current.

iii

IM 34M06H43-01E

6th Edition : Aug.30, 2019-00

The following symbols are used only in the user's manual.

WARNING

- Draws attention to information essential to prevent electrical shock or other dangers

that may result in injury or the loss of life.

CAUTION

- Draws attention to information essential to prevent hardware damage, software

damage or system failure.

NOTE

- Draws attention to information essential to the understanding of operation and

functions.

Safety Precautions when Using/Maintaining the Product

- For the protection and safe use of the product and the system controlled by it, be

sure to follow the instructions and precautions on safety stated in this manual

whenever handling the product. Take special note that if you handle the product in

a manner other than prescribed in these instructions, the protection feature of the

product may be damaged or impaired. In such cases, Yokogawa cannot guarantee

the quality, performance, function and safety of the product.

- When installing protection and/or safety circuits such as lightning protection devices

and equipment for the product and control system as well as designing or installing

separate protection and/or safety circuits for fool-proof design and fail-safe design of

processes and lines using the product and the system controlled by it, the user

should implement it using devices and equipment, additional to this product.

- If component parts or consumable are to be replaced, be sure to use parts specified

by the company.

- This product is not designed or manufactured to be used in critical applications

which directly affect or threaten human lives and safety — such as nuclear power

equipment, devices using radioactivity, railway facilities, aviation equipment,

shipboard equipment, aviation facilities or medical equipment. If so used, it is the

user’s responsibility to include in the system additional equipment and devices that

ensure personnel safety.

- Do not attempt to modify the product.

- To avoid electrical shock, turn off the power before wiring.

- This product is classified as Class A for use in industrial environments. If used in a

residential environment, it may cause electromagnetic interference (EMI).

In such situations, it is the user's responsibility to adopt the necessary measures

against EMI.

Exemption from Responsibility

- Yokogawa Electric Corporation (hereinafter simply referred to as Yokogawa Electric)

makes no warranties regarding the product except those stated in the WARRANTY

that is provided separately.

- Yokogawa Electric assumes no liability to any party for any loss or damage, direct or

indirect, caused by the use or any unpredictable defect of the product.

IM 34M06H43-01E

6th Edition : Aug.30, 2019-00

Software Supplied by the Company

- Yokogawa Electric makes no other warranties expressed or implied except as

provided in its warranty clause for software supplied by the company.

- Use the software with one computer only. You must purchase another copy of the

software for use with each additional computer.

- Copying the software for any purposes other than backup is strictly prohibited.

- Store the original media that contain the software in a safe place.

- Reverse engineering, such as decompiling of the software, is strictly prohibited.

- Under absolutely no circumstances may the software supplied by Yokogawa Electric

be transferred, exchanged, or sublet or leased, in part or as a whole, for use by any

third party without prior permission by Yokogawa Electric.

IM 34M06H43-01E

6th Edition : Aug.30, 2019-00

General Requirements for Using the FA-M3 / e-RT3 Controller

Set the product in a location that fulfills the following requirements:

- INDOOR USE ONLY

- This product is an open equipment. The product must be installed in a metallic

panel enclosure with an impact rating IK08 or more.

- Where the product will not be exposed to direct sunlight, and where the operating

surrounding air temperature is from 0°C to 55°C (32°F to 131°F).

There are modules that must be used in an environment where the operating

surrounding air temperature is in a range smaller than 0°C to 55°C (32°F to 131°F).

Refer to “Hardware Manual” (IM 34M06C11-01E) or the applicable user's manual. In

case of attaching such a module, the entire system's operating surrounding air

temperature is limited to the module's individual operating surrounding air

temperature.

- Where the relative humidity is from 10 to 90%.

In places where there is a chance of condensation, use a space heater or the like to

constantly keep the product warm and prevent condensation.

- For use in Pollution Degree 2 Environment.

- Where there are no corrosive or flammable gases.

- Where the product will not be exposed to mechanical vibration or shock that exceed

specifications.

- Where there is no chance the product may be exposed to radioactivity.

Use the correct types of wire for external wiring:

- USE COPPER CONDUCTORS ONLY.

- Use conductors with temperature rating above 75°C.

Securely tighten screws:

- Securely tighten module mounting screws and terminal screws to avoid problems

such as faulty operation.

- Tighten terminal block screws with the correct tightening torque as given in this

manual. Refer to the “Hardware Manual” (IM 34M06C11-01E) or the applicable

user's manual for the appropriate tightening torque.

Securely lock connecting cables:

- Securely lock the connectors of cables, and check them thoroughly before turning

on the power.

Interlock with emergency-stop circuitry using external relays:

- Equipment incorporating the FA-M3 / e-RT3 controller must be furnished with

emergency-stop circuitry that uses external relays. This circuitry should be set up to

interlock correctly with controller status (stop/run).

Ground for low impedance:

- For safety reasons, connect the [FG] grounding terminal to a protective earth

(Comply with the regulation of each country.). For compliance to CE Marking, use

braided or other wires that can ensure low impedance even at high frequencies for

grounding.



IM 34M06H43-01E

6th Edition : Aug.30, 2019-00

Configure and route cables with noise control considerations:

- Perform installation and wiring that segregates system parts that may likely become

noise sources and system parts that are susceptible to noise. Segregation can be

achieved by measures such as segregating by distance, installing a filter or

segregating the grounding system.

Configure for CE Marking Conformance:

-For compliance to CE Marking, perform installation and cable routing according to

the description on compliance to CE Marking in the “Hardware Manual” (IM

34M06C11-01E).

-The list of CE conforming models is available in Appendix A2. of “Hardware

Manual”.

Keep spare parts on hand:

- We recommend that you stock up on maintenance parts, including spare modules,

in advance.

- Preventive maintenance (replacement of the module) is required for using the

module beyond 10 years.

Discharge static electricity before touching the system:

- Because static charge can accumulate in dry conditions, first touch grounded metal

to discharge any static electricity before touching the system.

Wipe off dirt with a soft cloth:

- Gently wipe off dirt on the product's surfaces with a soft cloth.

- If you soak the cloth in water or a neutral detergent, tightly wring it out before wiping

the product. Letting water enter the module interior can cause malfunctions.

- Do not use volatile solvents such as benzine or paint thinner or chemicals for

cleaning, as they may cause deformity, discoloration, or malfunctioning.

Avoid storing the FA-M3 /e-RT3 controller in places with high

temperature or humidity:

- Since the CPU module has a built-in battery, avoid storage in places with high

temperature or humidity.

- Since the service life of the battery is drastically reduced by exposure to high

temperatures, take special care (storage surrounding air temperature should be

from -20°C to 75°C).

- There is a built-in lithium battery in a Sequence CPU module which serves as backup

power supply for programs, device information and configuration information.

The service life of this battery is more than 10 years in standby mode at room

temperature. Take note that the service life of the battery may be shortened when

installed or stored at locations of extreme low or high temperatures. Therefore, we

recommend that modules with built-in batteries be stored at room temperature.

Always turn off the power before installing or removing modules:

- Failing to turn off the power supply when installing or removing modules, may result

in damage.

Do not touch components in the module:

- In some modules you can remove the right-side cover and install ROM packs or

change switch settings. While doing this, do not touch any components on the

printed-circuit board, otherwise components may be damaged and modules may fail

to work.

vii

IM 34M06H43-01E

6th Edition : Aug.30, 2019-00

Do not use unused terminals:

- Do not connect wires to unused terminals on a terminal block or in a connector.

Doing so may adversely affect the functions of the module.

Use the following power source:

- Use only F3PU- as the power supply module.

- If using this product as a UL-approved product, for the external power supply, use a

limited voltage / current circuit power source or a Class 2 power source.

- If using this product as a CE-complied product, for the external power supply, use a

SELV and limited-energy circuit separated by reinforced insulation or double

insulation from hazardous voltage.

Refer to the user's manual before connecting wires:

- Refer to the “Hardware Manual” (IM 34M06C11-01E) or the applicable user’s

manual for the external wiring drawing.

- Refer to “A3.6.5 Connecting Output Devices” in the “Hardware Manual” before

connecting the wiring for the output signal.

- Refer to “A3.5.4 Grounding Procedure” in the “Hardware Manual” for attaching the

grounding wiring.

Authorized Representative:

- The Authorized Representative for this product in the EEA is:

Yokogawa Europe B. V.

Euroweg 2, 3825 HD Amersfoort, The Netherlands



viii

IM 34M06H43-01E

6th Edition : Aug.30, 2019-00

General Requirements for Using the FA-M3 Slave Units (TAH Series)

Connect YHLS cable to SHIELD terminal:

- Connect the DRAIN line of the YHLS cable to the SHIELD terminal of the YHLS

master module securely. Failing to do so may affect the performance of the YHLS

system.

Do not touch components in the unit:

- Do not remove the back cover of the unit. Doing so may cause a failure.



Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Unidad de control de YOKOGAWA

YOKOGAWA

YOKOGAWA FA Link H2 Manual de usuario

YOKOGAWA

YOKOGAWA FN310 Manual de usuario

YOKOGAWA

YOKOGAWA YFGW410 Manual de usuario

YOKOGAWA

YOKOGAWA FA-M3 Vitesse Manual de usuario

YOKOGAWA

YOKOGAWA F3LR02-0N Manual de usuario

YOKOGAWA

YOKOGAWA Stardom FCN-100 Manual

YOKOGAWA

YOKOGAWA F3LH02-0N Manual de usuario

YOKOGAWA

YOKOGAWA YS80 Series Manual de usuario

YOKOGAWA

YOKOGAWA F3YP14-0N Manual de usuario

YOKOGAWA

YOKOGAWA FN120 Manual de usuario

YOKOGAWA

YOKOGAWA SL1000 Manual de usuario

YOKOGAWA

YOKOGAWA F3RS22-0N Manual de usuario

YOKOGAWA

YOKOGAWA FA-M3 VITESSE F3CX04-0N Manual de usuario

YOKOGAWA

YOKOGAWA FA-M3 YHLS Master Module Manual de usuario

YOKOGAWA

YOKOGAWA WE7031 Manual de usuario

YOKOGAWA

YOKOGAWA Exner RF20C Manual de usuario

YOKOGAWA

YOKOGAWA FA-M3 Vitesse Manual de usuario

YOKOGAWA

YOKOGAWA WE7231 Manual de usuario

YOKOGAWA

YOKOGAWA FA-M3 F3YP22-0P Manual de usuario

YOKOGAWA

YOKOGAWA YPPA1004 Manual de usuario

YOKOGAWA

YOKOGAWA YS80 Series Manual de usuario

YOKOGAWA

YOKOGAWA YFGW410 Manual de usuario

YOKOGAWA

YOKOGAWA FN510 Manual de usuario

YOKOGAWA

YOKOGAWA F3CU04-0S Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
