Yeastar Technology NeoGate TA1600 Manual de usuario

Sales Tel: +86-592-5503309

E-mail: sales@yeastar.com

Support Tel: +86-592-5503301

E-mail: support@yeastar.com

Web: http://www.yeastar.com

Version: 47.0.0.49

Revised: September 17, 2019

TA1600/2400/3200 User Manual

2/87

No parts of this publication may be reproduced or transmitted in any form or by any

means, electronic or mechanical, photocopying, recording, or otherwise, for any

purpose, without the express written permission of Yeastar Information Technology

Co., Ltd. Under the law, reproducing includes translating into another language or

format.

Declaration of Conformity

Hereby, Yeastar Information Technology Co., Ltd. declares

that TA1600/2400/3200 is in conformity with the essential

requirements and other relevant provisions of the CE, FCC.

Warranty

The information in this document is subject to change without notice.

Yeastar Information Technology Co., Ltd. makes no warranty of any kind with regard

to this guide, including, but not limited to, the implied warranties of merchantability

and fitness for a particular purpose. Yeastar Information Technology Co., Ltd. shall not

be liable for errors contained herein nor for incidental or consequential damages in

connection with the furnishing, performance or use of this guide.

WEEE Warning

In accordance with the requirements of council directive 2002/96/EC on

Waste of Electrical and Electronic Equipment (WEEE), ensure that at

end-of-life you separate this product from other waste and scrap and

deliver to the WEEE collection system in your country for recycling.



TA1600/2400/3200  User  Manual

3/87
Contents

About This Guide................................................................................................6
Getting Started....................................................................................................8
Accessing Web GUI..........................................................................................................8
Web Configuration Panel ................................................................................................10
Making and Receiving Calls............................................................................................10
Basic Operations .............................................................................................. 11
Voice Menu.....................................................................................................................11
Call Hold.........................................................................................................................12
Call Waiting ....................................................................................................................12
Call Transfer ...................................................................................................................13
Three-party Conference..................................................................................................14
Direct IP Call ..................................................................................................................14
Change TA1600/2400/3200’s IP Address Using Analog Phones......................................14
FXS Port Settings .............................................................................................16
General Settings.............................................................................................................16
Other Settings ................................................................................................................19
Hunt Group.....................................................................................................................21
VoIP Settings.....................................................................................................24
VoIP Server Settings.......................................................................................................24
Dial Pattern Template......................................................................................................27
SIP Settings....................................................................................................................28
IAX Settings....................................................................................................................35
Gateway Settings..............................................................................................37
Basic Preferences...........................................................................................................37



TA1600/2400/3200  User  Manual

4/87
Feature Codes................................................................................................................38
Speed Dial......................................................................................................................42
Prompt Settings................................................................................................43
Custom Prompts.............................................................................................................43
Music on Hold Prompts...................................................................................................44
System Prompts .............................................................................................................45
Advanced Settings............................................................................................46
Distinctive Ringtones ......................................................................................................46
Tone Zone Settings.........................................................................................................46
RADIUS Settings............................................................................................................48
Network Preferences ........................................................................................50
LAN Settings ..................................................................................................................50
WAN Settings .................................................................................................................52
Service ...........................................................................................................................54
VLAN Settings ................................................................................................................54
VPN Settings..................................................................................................................55
DDNS Settings ...............................................................................................................56
Static Route....................................................................................................................57
SNMP Settings ...............................................................................................................59
TR-069 Settings..............................................................................................................59
Remote Management .....................................................................................................61
Security Center.................................................................................................63
Security Center...............................................................................................................63
Alert Settings..................................................................................................................65
AMI Settings...................................................................................................................67
Certificates .....................................................................................................................68
Firewall Rules.................................................................................................................69



TA1600/2400/3200  User  Manual

5/87
IP Blocklist......................................................................................................................71
System Preferences..........................................................................................73
Password Settings..........................................................................................................73
Date and Time ................................................................................................................74
Auto Provision Settings...................................................................................................74
Firmware Upgrade..........................................................................................................77
Upgrade through HTTP................................................................................................78
Upgrade through TFTP ................................................................................................78
Backup and Restore .......................................................................................................80
Reset and Reboot...........................................................................................................81
Status................................................................................................................82
FXS Port Status..............................................................................................................82
Network status................................................................................................................83
System Info ....................................................................................................................84
Reports .............................................................................................................85
Call Logs ........................................................................................................................85
System Logs...................................................................................................................85
Packet Tool.....................................................................................................................86
Port Monitor Tool.............................................................................................................87








TA1600/2400/3200 User Manual

6/87

About This Guide

YeastarTA1600/2400/3200 FXS Analog VoIP Gateways are cutting-edge products

that connect legacy telephones, fax machines and PBX systems with IP telephony

networks and IP-based PBX systems. Featuring rich functionalities and easy

configuration, Yeastar TA is ideal for small and medium enterprises that wish to

integrate a traditional phone system into IP-based system. Yeastar TA helps them to

preserve previous investment on legacy telephone system and reduce

communication costs significantly with the true benefits of VoIP.

Audience

This manual will help you learn how to operate and manage your TA1600/2400/3200

FXS Analog VoIP Gateway. In this guide, we describe every detail on the functionality

and configuration of TA1600/2400/3200. We begin by assuming that you are

interested in TA1600/2400/3200 and familiar with networking and other IT

disciplines.

Safety when working with electricity

Features Highlights

16/24/32 FXS ports

Fully compliant with SIP and IAX2

Hunt Group

Configurable VoIP Server templates

Reliable FAX performance with T.38

3-party conference

Direct IP Calling

Inter-port Calling

Do not open the device when the device is powered on.

Do not work on the device, connect or disconnect cables when

lightning strikes.

TA1600/2400/3200 User Manual

7/87

Attended Transfer

Blind Transfer

Support RADIUS protocol

Support SNMP

Support TR-069

Check the TA1600/2400/3200 Installation Guide here:

www.yeastar.com/download/TAXX00/Yeastar_TA1600&2400&3200_V3_Installation_

Guide_en.pdf

For more information, please click:

https://www.yeastar.com/fxs-voip-gateways/

TA1600/2400/3200 User Manual

8/87

Getting Started

In this chapter, we guide you through the basic steps to start with a new

TA1600/2400/3200:

Accessing Web GUI

Web Configuration Panel

Making and Receiving Calls

Accessing Web GUI

The TA1600/2400/3200 attempts to contact a DHCP server in your network to obtain

valid network settings (e.g., the IP address, subnet mask, default gateway address

and DNS address) by default.

Please enable DHCP Server in your network to obtain the TA1600/2400/3200 IP

address.

How to check TA1600/2400/3200 IP address:

1. Pick up the analog phone, then access the voice menu prompt by dialing “***”.

2. Dial "1" to check the IP address.

3. Dial "2" for web access address.

After entering the IP address in the web browser, users will see a log-in screen.

Check the default settings below:

Username: admin

Password: password

TA1600/2400/3200 User Manual

9/87

Figure 2-1 TA1600/2400/3200 Login page

TA1600/2400/3200 User Manual

10/87

Web Configuration Panel

There are 4 main sections on the Web Configuration Panel for users to check the

TA1600/2400/3200’s status and configure it.

Status: check System Status, Port Status, Trunk Status, Network Status and

check call logs, system logs.

System: configure Network Settings, Security related Settings, System Date and

Time, Password, Backup and Restore, etc.

Gateway: configure FXS ports, gateway settings and SIP settings, etc.

Logout: log out TA1600/2400/3200.

Note: After saving the changes, remember to click the “Apply changes” button on the

upper right corner of the Web GUI to make the changes take effect.

Making and Receiving Calls

You will need an active VoIP account from a VoIP service provider or PBX, which

provides a VoIP telephone number to allow you to make and receive calls.

Making internal calls

To place an internal call, pick up the analog phone and dial the other port’s caller

ID number or dial *99 followed by the port number.

For example, to reach the other port with caller ID number 300, dial “300”.

To reach port 2, you can dial *9902 to ring the phone connected to port 2.

Making outbound calls

To make an outbound call, you need to dial according to the FXS port dial pattern.

By the default dial pattern, you can dial the desired outgoing number directly.

Answering calls

To answer a call, pick up the handset as you usually do.

Otros manuales para NeoGate TA1600

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Puerta de Yeastar Technology

Yeastar Technology

Yeastar Technology TA1610 Manual de usuario

Yeastar Technology

Yeastar Technology NeoGate TG Series Manual de usuario

Yeastar Technology

Yeastar Technology NeoGate Manual de usuario

Yeastar Technology

Yeastar Technology NeoGate TG100 Manual de usuario

Yeastar Technology

Yeastar Technology NeoGate TB400 Manual de usuario

Yeastar Technology

Yeastar Technology NeoGate TG100 Manual de usuario

Yeastar Technology

Yeastar Technology NeoGate TB400 Manual de usuario

Yeastar Technology

Yeastar Technology MyPBX-SOHO Manual de usuario

Yeastar Technology

Yeastar Technology NeoGate TA800 Manual de usuario

Yeastar Technology

Yeastar Technology TB200 Manual de usuario

Yeastar Technology

Yeastar Technology TA100 ATA Manual de usuario

Yeastar Technology

Yeastar Technology TG400G Manual de usuario

Yeastar Technology

Yeastar Technology TA Series Manual de usuario

Yeastar Technology

Yeastar Technology TG Series Manual de usuario

Yeastar Technology

Yeastar Technology NeoGate TA3200 Guía de seguridad

Yeastar Technology

Yeastar Technology NeoGate TA1600 Manual de usuario

Yeastar Technology

Yeastar Technology NeoGate TA400 Manual de usuario

Yeastar Technology

Yeastar Technology NeoGate TA1600 Manual de usuario

Yeastar Technology

Yeastar Technology TA Series Guía de seguridad

Yeastar Technology

Yeastar Technology Elastix Guía de seguridad

Yeastar Technology

Yeastar Technology NeoGate TA400 Manual de usuario

Yeastar Technology

Yeastar Technology NeoGate TA410 Manual de usuario

Yeastar Technology

Yeastar Technology NeoGate TG200 Manual de usuario

Yeastar Technology

Yeastar Technology Yeastar TE200 Manual de usuario

Manuales populares de Puerta de otras marcas

LST

LST M500RFE-AS Manual de usuario

Kinnex

Kinnex Media Gateway Manual de usuario

2N Telekomunikace

2N Telekomunikace 2N StarGate Manual de usuario

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manual de usuario

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manual de usuario

Telsey

Telsey CPVA 500 - SIP Manual de usuario

RTA

RTA 460A-NNA4 Hoja de especificaciones

Shaw

Shaw Gateway HDPVR Manual de usuario

ABB

ABB VSN900 Guía de inicio rápido

Commander

Commander Pulse Manual de usuario

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manual de usuario

NETGEAR

NETGEAR C6300BD Manual de usuario

Amit

Amit CDW531AM Manual de usuario

HMS

HMS Netbiter EasyConnect EC150 Manual de usuario

Huawei

Huawei EchoLife HG620 Manual de usuario

AT&T

AT&T U-verse 3801 Manual de uso y cuidado

Logic IO

Logic IO RTCU MX2 turbo Manual de usuario

Suttle

Suttle MediaMAX MXM-521 Manual de usuario
