Yealink W56B Manual de usuario

Quick Start Guide(V80.15)

IP DECT Phone

W56P & W56H

www.yealink.com Applies to firmware version 25.80.0.15 or later.

The following items are included in your W56P package:

Packaging Contents

Base for W52P/W56P USB Charger Cradle

Belt Clip

W56H Handset

Ethernet Cable

The following items are included in your W56H package:

USB Charger Cradle

Power Adapter Rechargeable Battery

Belt Clip

Rechargeable Battery

Two Power Adapters

Quick Start Guide

Packaging Contents

Note: We recommend that you use the accessories provided or approved by Yealink. The use

of unapproved third-party accessories may result in reduced performance.

Note: Yealink W56P IP DECT phone consists of one Base for W52P/W56P and one W56H

Handset.

1. Connect the network and power for the base station in one of the following ways,

as shown below:

Assembling the Phone

a. AC Power Option

The following item is optional accessory:

W56P Handset Protective Case

2. Insert the battery into the handset, as shown below:

b. PoE (Power over Ethernet) Option

Assembling the DECT Phone

Note:

If inline power (PoE) is provided, you do not need to connect the power adapter. Make

sure the hub/switch is PoE-compliant. The base station should be used with original

power adapter (5V/600mA) only. The use of the third-party power adapter may cause

the damage to the base station.

Note: You need to purchase separately if required.

battery

IEEE 802.3af compliant

PoE Hub/Switch

3. Connect the charger cradle and charge the handset, as shown below:

5. Attach the Belt Clip, as shown below:

4. (Optional) Mount the charger cradle on the wall, as shown below:

Note:

The handset should be used with original power adapter (5V/600mA) only. The use of the

third-party power adapter may cause the damage to the handset.

The charging status of the handset is indicated in the top right-hand corner of the LCD

screen.

36.00mm

1:1

36mm

Shortcuts

1.Do one of the following to register your handset manually:

Handset Registration

This helps you get quick access to features by pressing the shortcut keys directly without

having to scroll through the menu.You can press the following predefined shortcut keys to

access some frequently used features when the handset is idle:

Press the left soft key to access the call history.

Press the right soft key to check the line status.

Press to place an internal call.

Press to increase the ringer volume.

Press to access the directory.

Press to decrease the ringer volume.

Long press on the base station till the registration LED slow flashes. Then press

the OK key to enter the main menu on the handset, select Settings->Registration->Register

Handset.

If the handset LCD screen prompts “Press base page 2s then press OK”, long press

on the base station till the registration LED slow flashes. Then press the OK soft key on

the handset, select Register Handset.

Press one or more times to switch among input modes or enter “#”.

Press to select the special characters or enter “*”.

Press a digit key one or more times to enter the desired character or digit.

Press the Del soft key to delete entered characters.

Press the Save soft key to accept the change or to cancel.

Getting Started

You can register up to 5 handsets to one base station. Each handset can be registered to 4

different base stations.

Entering and Editing Data

Network Settings

DHCP: By default, the base station attempts to contact a DHCP server in your network to

obtain the valid network settings, e.g., IP address, subnet mask, gateway address

and DNS address.

Static IP Address: If the base station cannot contact a DHCP server for any reason, you need

to configure the IP address, subnet mask, gateway address, primary DNS

address and secondary DNS address for the base station manually.

You can configure the base station to obtain network settings in one of the following ways:

To configure the network parameters for the base station manually:

1.Press the OK key to enter the main menu, and then select Settings->System Settings ->Network.

4.Press to select the corresponding IP address mode.

3.Select the desired IP address mode from the IP Mode field.

2.Enter the system PIN (default: 0000), and then press the Done soft key.

5.Make the desired changes.

2.Select the desired base and press the OK soft key. The handset begins searching the base.

3.Press the OK soft key after searching a base successfully.

4.Enter the base PIN (default: 0000), and then press the Done soft key to complete

registeration.

6.Press the Save soft key to accept the change.

PPPoE: If you are using an xDSL modem, you can connect your base station to the Internet

via PPPoE mode. Contact the ITSP for the account and password.

Note:

The IP DECT phone supports either or both IPv4 and IPv6 addresses mode, but IPv6 is

disabled by default.

Wrong network settings may result in inaccessibility of your DECT phone and may have

an impact on the network performance. For more information on these parameters,

contact your system administrator.

Note:

After the success of registration, the handset LCD screen prompts “Handset subscribed”.

If the handset LCD screen prompts “Searching for Base”, please check your base station

if powered on.

Basic Operations

Turning Handset On/Off

To turn the handset on, do one of the following:

Place the handset in the charger cradle. The handset will be turned on automatically.

To turn the handset off:

Locking/Unlocking Keypad

Handset Name

1.Press the OK key to enter the main menu, and then select Settings->Handset Name

3.Press the Save soft key to accept the change.

Silent Mode

Press or when the handset is idle to adjust the ringer volume.

Volume Adjustment

Press or during a call to adjust the receiver volume of speakerphone/earpiece.

Press , then the LCD screen lights up.

Long press to turn the handset off.

Long press when the handset is idle to switch the silent mode to On.

Long press when the handset is idle to lock the keypad.

Long press again to switch the silent mode to Off.

Long press again to unlock the keypad.

To rename the handset:

2.Edit the value in the Rename field.

Basic Operations

Handset Settings

Ring Tones

4.Press the Save soft key to accept the change.

Local Directory

To add a contact:

1.Press the OK key to enter the main menu, and then select Directory.

3.Enter the desired value in the Name, Number and Mobile field respectively.

2.Press the Options soft key, and then select New Contact.

4.Press the Save soft key to accept the change.

To edit a contact:

1.Press the OK key to enter the main menu, and then select Directory.

3.Press or to select the desired ring tone.

2.Press or to highlight the desired entry.

3.Press the Options soft key, and then select Edit.

4.Edit the value in the Name, Number and Mobile field respectively.

5.Press the Save soft key to accept the change.

To delete a contact:

1.Press the OK key to enter the main menu, and then select Directory.

3.Press the Options soft key, and then select Delete to delete the selected entry.

To assign a speed dial number:

1.Press the OK key to enter the main menu, and then select Settings->Telephony->Speed Dial.

2.Press or to highlight the desired entry.

2.Press or to highlight the desired digit key, and then press the Assign soft key.

3.Press or to highlight the desired entry, and then press the OK soft key.

If both the office number and mobile number are stored, press or to highlight the

desired number, and then press the OK soft key again.

2.Press or to highlight the Intercom Call option or the desired line.

1.Press the OK key to enter the main menu, and then select Settings->Audio->Ring Tones

->Melodies.

Placing Calls

To place a call from the local directory:

To place a call from the call history:

1.Press the History soft key when the handset is idle, and then select the desired call history

list.

To place a call directly:

To place a call using the speed dial key:

Long press the speed dial key to place a call to preset number directly.

1.Press when the handset is idle.

Enter the desired number when the handset is idle.

2.Press or to highlight the desired entry, and then press or to dial out using

the default line.

To place a call from the redial list:

1.Press or when the handset is idle.

2.Press or to highlight the desired entry, and then press or .

If multiple numbers for the contact are stored, press or to highlight the desired

number, and then press or again to dial out using the default line.

2.Press or to highlight the desired entry, and then press or to dial out using

the default line.

Basic Call Features

Press to enter the pre-dialing screen.

Enter the desired number using the keypad.

If there are multiple lines assigned to your handset as outgoing lines, press the Line soft

key to select the desired line. If you do not select a line, the handset uses the default

outgoing line to dial out.

2.Press , or to dial out.

1.Do one of the following:

Answering Calls

To answer a call, do one of the following:

Press the Accept soft key.

Ending Calls

Press .

Call Hold and Resume

To place a call on hold:

To resume a call, do one of the following:

If there is only a call on hold, press the Resume soft key.

Press the Options soft key during a call, and then select Hold.

If there are two calls on hold, press the Resume soft key to resume the current call.

Press the Swap soft key to swap between calls.

Blind Transfer

Call Transfer

You can transfer a call in the following ways:

1.Press the Options soft key during a call, and then select Transfer.

Call Mute

Press again to un-mute the call.

Press during a call to mute the call.

Press .

Note:

You can ignore an incoming call by pressing the Silence soft key or reject an incoming call by

pressing .
