YASKAWA JEPMC-BU3301-E Manual de usuario

MANUAL NO. TOMP C880725 22A

製品を安全にお使いいただくために，本書を必ずお読みください。

また，本書をお手元に保管していただくとともに，最終的に本製品をご使用になる

ユーザー様のお手元に確実に届けられるよう，お取り計らい願います。

To properly use the product, read this manual thoroughly and retain

for easy reference, inspection, and maintenance. Ensure the end user

receives this manual.

MP3300 Base Unit

Machine Controller MP3000 Series

INSTRUCTIONS

Unité de Base MP3300

Contrôleur de Machine Série MP3000

INSTRUCTIONS

MP3300 ベースユニット

マシンコントローラMP3000シリーズ

取扱説明書

Model: JEPMC-BU3301-E，-BU3302-E，-BU3303-E，-BU3304-E

Modèle: JEPMC-BU3301-E，-BU3302-E，-BU3303-E，-BU3304-E

形式：JEPMC-BU3301-E，-BU3302-E，-BU3303-E，-BU3304-E

Pour utiliser correctement le produit, lisez attentivement ce manuel.

Conservez-le comme références et pour les cas d’inspections et de

maintenance. Assurez-vous que l’utilisateur final reçoive ce manuel.

in a retrieval system, or transmitted, in any form, or by any means,

mechanical, electronic, photocopying, recording, or otherwise, without the

prior written permission of Yaskawa. No patent liability is assumed with

respect to the use of the information contained herein. Moreover, because

Yaskawa is constantly striving to improve its high-quality products, the

information contained in this manual is subject to change without notice.

Every precaution has been taken in the preparation of this manual. Never-

theless, Yaskawa assumes no responsibility for errors or omissions. Nei-

ther is any liability assumed for damages resulting from the use of the

information contained in this publication.

E-1

Safety Precautions

Safety Information

To prevent personal injury and equipment damage in advance, the following sig-

nal words are used to indicate safety precautions in this document. The signal

words are used to classify the hazards and the degree of damage or injury that

may occur if a product is used incorrectly. Information marked as shown below is

important for safety. Always read this information and heed the precautions that

are provided.

DANGER

• Indicates precautions that, if not heeded, are likely to result in loss of

life, serious injury, or fire.

WARNING

• Indicates precautions that, if not heeded, could result in loss of life,

serious injury, or fire.

CAUTION

• Indicates precautions that, if not heeded, could result in relatively seri-

ous or minor injury, or in fire.

NOTICE

• Indicates precautions that, if not heeded, could result in property dam-

age.

E-2

Safety Precautions That Must Always Be Observed



General Precautions

WARNING

• Read and understand this manual to ensure the safe usage of the

product.

• Keep this manual in a safe, convenient place so that it can be referred

to whenever necessary. Make sure that it is delivered to the final user

of the product.

• The installation must be suitable and it must be performed only by an

experienced technician.

There is a risk of electrical shock or injury.

• Before connecting the machine and starting operation, make sure that

an emergency stop procedure has been provided and is working cor-

rectly.

There is a risk of injury.

• Do not approach the machine after a momentary interruption to the

power supply. When power is restored, the product and the device

connected to it may start operation suddenly. Provide safety measures

in advance to ensure human safety when operation restarts.

There is a risk of injury.

• Do not touch anything inside the product.

There is a risk of electrical shock.

• Do not remove the front cover, cables, connector, or options while

power is being supplied.

There is a risk of electrical shock, malfunction, or damage.

• Do not damage, pull on, apply excessive force to, place heavy objects

on, or pinch the cables.

There is a risk of electrical shock, operational failure of the product, or

burning.

• Do not attempt to modify the product in any way.

There is a risk of injury or device damage.

E-3



Storage and Transportation Precautions

CAUTION

• Do not store the product in any of the following locations.

•Locations that are subject to direct sunlight

•Locations that are subject to ambient temperatures that exceed the

storage conditions

•Locations that are subject to ambient humidity that exceeds the storage

conditions

•Locations that are subject to rapid temperature changes and condensa-

tion

•Locations that are subject to corrosive or inflammable gas

•Locations that are subject to excessive dust, dirt, salt, or metallic pow-

der

•Locations that are subject to water, oil, or chemicals

•Locations that are subject to vibration or shock

There is a risk of fire, electrical shock, or device damage.

• Hold onto the main body of the product when transporting it.

Holding the cables or connectors may damage them or result in injury.

• Do not overload the product during transportation. (Follow all instruc-

tions.)

There is a risk of injury or an accident.

• Never subject the product to an atmosphere containing halogen (fluo-

rine, chlorine, bromine, or iodine) during transportation.

There is a risk of malfunction or damage.

• If disinfectants or insecticides must be used to treat packing materials

such as wooden frames, pallets, or plywood, the packing materials

must be treated before the product is packaged, and methods other

than fumigation must be used.

Example: Heat treatment, where materials are kiln-dried to a core tem-

perature of 56°C for 30 minutes or more.

If the electronic products, which include stand-alone products and prod-

ucts installed in machines, are packed with fumigated wooden materials,

the electrical components may be greatly damaged by the gases or

fumes resulting from the fumigation process. In particular, disinfectants

containing halogen, which includes chlorine, fluorine, bromine, or iodine

can contribute to the erosion of the capacitors.

E-4



Installation Precautions

CAUTION

• Do not install the product in any of the following locations.

•Locations that are subject to direct sunlight

•Locations that are subject to ambient temperatures that exceed the

operating conditions

•Locations that are subject to ambient humidity that exceeds the operat-

ing conditions

•Locations that are subject to rapid temperature changes and condensa-

tion

•Locations that are subject to corrosive or inflammable gas

•Locations that are subject to excessive dust, dirt, salt, or metallic pow-

der

•Locations that are subject to water, oil, or chemicals

•Locations that are subject to vibration or shock

There is a risk of fire, electrical shock, or device damage.

• Never install the product in an atmosphere containing halogen (fluo-

rine, chlorine, bromine, or iodine).

There is a risk of malfunction or damage.

• Do not step on the product or place heavy objects on the product.

There is a risk of injury or an accident.

• Do not block the air exhaust ports on the product. Do not allow foreign

objects to enter the product.

There is a risk of internal element deterioration, malfunction, or fire.

• Always mount the product in the specified orientation.

There is a risk of malfunction.

• Leave the specified amount of space between the product, and the

interior surface of the control panel and other devices.

There is a risk of fire or malfunction.

• Do not subject the product to strong shock.

There is a risk of malfunction.

• Suitable battery installation must be performed and it must be per-

formed only by an experienced technician.

There is a risk of electrical shock, injury, or device damage.

• Do not touch the electrodes when installing the Battery.

Static electricity may damage the electrodes.

E-5



Wiring Precautions

CAUTION

• Check the wiring to be sure it has been performed correctly.

There is a risk of motor run-away, injury, or accidents.

• Always use a power supply of the specified voltage.

There is a risk of fire or accident.

• In places with poor power supply conditions, ensure that the input

power is supplied within the specified voltage range.

There is a risk of device damage.

• Install breakers and other safety measures to provide protection

against shorts in external wiring.

There is a risk of fire.

• Provide sufficient shielding when using the product in the following

locations.

•Locations that are subject to noise, such as from static electricity

•Locations that are subject to strong electromagnetic or magnetic fields

•Locations that are subject to radiation

•Locations that are near power lines

There is a risk of device damage.

• Configure the circuits to turn ON the power supply to the CPU Module

before the 24-V I/O power supply. Refer to the following manual for

details on circuits.

MP3000 Series MP3300 CPU Module Instructions (Manual No.:

TOMP C880725 23)

If the power supply to the CPU Module is turned ON after the external

power supply, e.g., the 24-V I/O power supply, the outputs from the CPU

Module may momentarily turn ON when the power supply to the CPU

Module turns ON. This can result in unexpected operation that may cause

injury or device damage.

• Provide emergency stop circuits, interlock circuits, limit circuits, and

any other required safety measures in control circuits outside of the

product.

There is a risk of injury or device damage.

• If you use MECHATROLINK I/O Modules, use the establishment of

MECHATROLINK communications as an interlock output condition.

There is a risk of device damage.

• Connect the Battery with the correct polarity.

There is a risk of battery damage or explosion.

• Suitable battery replacement must be performed and it must be per-

formed only by an experienced technician.

There is a risk of electrical shock, injury, or device damage.

• Do not touch the electrodes when replacing the Battery.

Static electricity may damage the electrodes.

E-6



Operation Precautions

• Select the I/O signal wires for external wiring to connect the product to

external devices based on the following criteria:

•Mechanical strength

•Noise interference

•Wiring distance

•Signal voltage

• Separate the I/O signal cables for control circuits from the power

cables both inside and outside the control panel to reduce the influ-

ence of noise from the power cables.

If the I/O signal lines and power lines are not separated properly, malfunc-

tion may occur.

CAUTION

• Follow the procedures and instructions in the user’s manuals for the

relevant products to perform normal operation and trial operation.

Operating mistakes while the Servomotor and machine are connected

may damage the machine or even cause accidents resulting in injury or

death.

• Implement interlock signals and other safety circuits external to the

product to ensure safety in the overall system even if the following

conditions occur.

•Product failure or errors caused by external factors

•Shutdown of operation due to product detection of an error in self-diag-

nosis and the subsequent turning OFF or holding of output signals

•Holding of the ON or OFF status of outputs from the product due to fus-

ing or burning of output relays or damage to output transistors

•Voltage drops from overloads or short-circuits in the 24-V output from

the product and the subsequent inability to output signals

•Unexpected outputs due to errors in the power supply, I/O, or memory

that cannot be detected by the product through self-diagnosis

There is a risk of injury, device damage, or burning.

CAUTION

Example of Separated Cables

Power cable I/O signal

cables in

control circuits

Steel separator

E-7



Maintenance and Inspection Precautions



Disposal Precautions



Other General Precautions

CAUTION

• Do not attempt to disassemble or repair the product.

There is a risk of electrical shock, injury, or device damage.

• Do not change any wiring while power is being supplied.

There is a risk of electrical shock, injury, or device damage.

• Do not forget to perform the following tasks when you replace the CPU

Module:

•Back up all programs and parameters from the CPU Module that is

being replaced.

•Transfer all saved programs and parameters to the new CPU Module.

If you operate the CPU Module without transferring this data, unexpected

operation may occur. There is a risk of injury or device damage.

• Dispose of the product as general industrial waste.

• Observe all local laws and ordinances when you dispose of used Bat-

teries.

• The products shown in the illustrations in this manual are sometimes

shown without covers or protective guards. Always replace the cover

or protective guard as specified first, and then operate the products in

accordance with the manual.

• The illustrations that are presented in this manual are typical examples

and may not match the product you received.

• If the manual must be ordered due to loss or damage, inform your

nearest Yaskawa representative or one of the offices listed on the back

of this manual.

E-8

Warranty

Details of Warranty



Warranty Period

The warranty period for a product that was purchased (hereinafter called “deliv-

ered product”) is one year from the time of delivery to the location specified by

the customer or 18 months from the time of shipment from the Yaskawa factory,

whichever is sooner.



Warranty Scope

Yaskawa shall replace or repair a defective product free of charge if a defect

attributable to Yaskawa occurs during the warranty period above. This warranty

does not cover defects caused by the delivered product reaching the end of its

service life and replacement of parts that require replacement or that have a lim-

ited service life.

This warranty does not cover failures that result from any of the following causes.

•Improper handling, abuse, or use in unsuitable conditions or in environments

not described in product catalogs or manuals, or in any separately agreed-

upon specifications

•Causes not attributable to the delivered product itself

•Modifications or repairs not performed by Yaskawa

•Use of the delivered product in a manner in which it was not originally intended

•Causes that were not foreseeable with the scientific and technological under-

standing at the time of shipment from Yaskawa

•Events for which Yaskawa is not responsible, such as natural or human-made

disasters

Limitations of Liability

•Yaskawa shall in no event be responsible for any damage or loss of opportu-

nity to the customer that arises due to failure of the delivered product.

•Yaskawa shall not be responsible for any programs (including parameter set-

tings) or the results of program execution of the programs provided by the user

or by a third party for use with programmable Yaskawa products.

•The information described in product catalogs or manuals is provided for the

purpose of the customer purchasing the appropriate product for the intended

application. The use thereof does not guarantee that there are no infringe-

ments of intellectual property rights or other proprietary rights of Yaskawa or

third parties, nor does it construe a license.

•Yaskawa shall not be responsible for any damage arising from infringements of

intellectual property rights or other proprietary rights of third parties as a result

of using the information described in catalogs or manuals.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Controladores de YASKAWA

YASKAWA

YASKAWA JEPMC-MP2300-Y Series Manual de usuario

YASKAWA

YASKAWA CIMR-JA Series Manual de instalación y operación

YASKAWA

YASKAWA SGD7S series Manual de usuario

YASKAWA

YASKAWA JEPMC-BUB3005-E Manual de usuario

YASKAWA

YASKAWA J1000 CIMR-JC series Manual de usuario

YASKAWA

YASKAWA MP2200 Manual de usuario

YASKAWA

YASKAWA CIMR-V7xx20P1 series Manual de usuario

YASKAWA

YASKAWA VIPA System 300S+ Manual de usuario

YASKAWA

YASKAWA motoman NX100 Manual de usuario

YASKAWA

YASKAWA PG-B2 Manual de usuario

YASKAWA

YASKAWA PROFINET V1000 Manual de usuario

YASKAWA

YASKAWA MP900 Series Manual de usuario

YASKAWA

YASKAWA motoman NX100 Manual de usuario

YASKAWA

YASKAWA Motoman DX200 Manual de usuario

YASKAWA

YASKAWA SI-ET3 Manual de usuario

YASKAWA

YASKAWA FSDrive-MV1000 Series Manual de usuario

YASKAWA

YASKAWA T1000A Manual de usuario

YASKAWA

YASKAWA Z1000U Series Manual de usuario

YASKAWA

YASKAWA SI-EM3 Manual de usuario

YASKAWA

YASKAWA SI-P3V Manual de usuario

YASKAWA

YASKAWA Motoman DX200 Manual de usuario

YASKAWA

YASKAWA V1000 Series Manual de instalación y operación

YASKAWA

YASKAWA YRC1000 Manual de usuario

YASKAWA

YASKAWA SGD7S-xxxDA0 series Manual de usuario

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario

3M MicroTouch EX113 Manual de usuario
