Xtool IP616 Manual de usuario

Shenzhen Xtooltech Intelligent Co., LTD

User Manual

IP616 Smart Diagnostic System

Please read this user manual carefully before using the IP616 Smart

Diagnostic System. When reading the manual, please pay attention to the

words “Note” or “Caution”, and read them carefully for appropriate

operation.

TRADEMARKS

is a registered trademark of Shenzhen Xtooltech Intelligent

CO., LTD.

In countries where the trademarks, service marks, domain names, logos

and the name of the company are not registered, XTOOL claims that it still

reserves the ownership of the unregistered trademarks, service marks,

domain names, logos and the company name. All other marks for the

other products and the company’s name mentioned in the manual still

belong to the original registered company.

You may not use the trademarks, service marks, domain names, logo and

company name of XTOOL or other companies mentioned without written

permission from the trademark holder.

XTOOL reserves the right to the final interpretation of this manual content.

Without the written consent of Shenzhen Xtooltech Intelligent Co., Ltd.,

any company or individual shall not copy or backup this operation manual

in any form (electronic, mechanical, photocopying, recording, or other

forms).

DECLARATION

This manual is designed for the usage of the IP616 Smart Diagnostic

System and provides operating instructions and product descriptions for

users of the IP616 Smart Diagnostic system.

No part of this manual can be reproduced, stored in a retrieval system, or

transmitted, in any form or by any means (electronic, mechanical,

photocopying, recording, or otherwise), without the prior written

permission of XTOOL.

Use the device only as described in this manual. XTOOL is not

responsible for any consequences of violating the laws and regulations

caused by using the product or its data information

XTOOL shall not be liable for any incidental or consequential damages or

for any economic consequential damages arising from the accidents of

individual users and the third parties, misuse or abuse of the device,

unauthorized change or repair of the device, or the failure made by the

user not to use the product according to the manual.

All information, specifications, and illustrations in this manual are based

on the latest configurations and functions available at the time of printing.

XTOOL reserves the right to make changes at any time without notice.

OPERATION INSTRUCTIONS

For safe operation, please follow the instructions below:

Keep the device away from heat or fumes when you use it.

If the vehicle battery contains acid, please keep your hands and skin

or fire sources away from the battery during testing.

The exhaust gas of the vehicle contains harmful chemicals, please

ensure adequate ventilation.

III

Do not touch the cooling system components or exhaust manifolds

when the engine is running due to the high temperatures reached.

Make sure the car is securely parked, Neutral is selected or the

selector is at P or N position to prevent the vehicle from moving

when the engine starts.

Make sure the (DLC) diagnostic link connector is functioning properly

before starting the test to avoid damage to the Diagnostic Computer.

Do not switch off the power or unplug the connectors during testing,

otherwise, you may damage the ECU and/or the Diagnostic

Computer.

CAUTIONS!

Avoid shaking or dismantling the unit as it may damage the internal

components.

Do not use hard or sharp objects to touch the LCD screen;

Do not use excessive force;

Do not expose the screen to strong sunlight for a long period.

Please keep it away from water, moisture, high temperature or very

low temperature.

If necessary, calibrate the screen before testing to ensure the

accuracy of LCD performance.

Keep the main unit away from strong magnetic fields.

AFTERSALES-SERVICES

E-Mail: [email protected]

[email protected]

Tel: +86 755 21670995 or +86 755 86267858 (China)

Official Website: www.xtooltech.com

CONTENT

TRADEMARKS ................................................................................I

DECLARATION .............................................................................. II

OPERATION INSTRUCTIONS .......................................................II

CAUTIONS! ................................................................................... III

AFTERSALES-SERVICES ............................................................III

CONTENT ......................................................................................IV

1 GENERAL INTRODUCTION ................................................... 1

Tablet .................................................................................................... 1

Front View of Tablet......................................................................................1

Back View of Tablet.......................................................................................2

Host Ports ......................................................................................................... 3

Technical Specifications ....................................................................... 3

Package Kit ...........................................................................................4

2 GETTING STARTED ................................................................5

Activation .............................................................................................. 5

Main Interface ....................................................................................... 7

Operation system...........................................................................................7

Diagnostic system entrance....................................................................... 9

Function Buttons............................................................................................ 9

Navigation Buttons..................................................................................... 10

Notification Bar .............................................................................................11

Factory Reset ......................................................................................12

3 UPDATE ................................................................................. 14

4 DIAGNOSTIC ......................................................................... 15

Vehicle Connection ............................................................................. 15

Diagnostic ........................................................................................... 17

Vehicle Selection..........................................................................................17

Diagnostic functions...................................................................................20

5 SPECIAL FUNCTIONS .......................................................... 28

5.1 OIL RESET ................................................................................... 29

5.2 EPB ...............................................................................................31

5.3 SAS ...............................................................................................33

5.4 DPF ...............................................................................................36

5.5 BMS RESET ................................................................................. 40

5.6 THROTTLE ................................................................................... 43

5.7 INJECTOR CODING .....................................................................44

5.8 GEARBOX MATCH ...................................................................... 47

5.9 GEAR LEARNING ........................................................................ 48

6 SETTINGS ..............................................................................50

Language ............................................................................................ 50

Units ....................................................................................................51

My Workshop Info ............................................................................... 52

Firmware Information .......................................................................... 53

About ...................................................................................................54

7 REPORT ................................................................................. 55

Report ................................................................................................. 55

Replay .................................................................................................58

File Manager ....................................................................................... 59

8 REMOTE ASSISTANCE ........................................................ 59

9 FAQ ........................................................................................ 61

Q1: Failed to generate Diagnostic report ............................................ 61

Q2: How to print Diagnostic report ......................................................62

Q3: Failed to extract files .................................................................... 63

Q4: Mailbox supported ........................................................................63

Q5: How to make an appointment for remote support ........................ 63

Q6: How to generate and upload diagnostic log files ..........................63

Q7: How to switch languages ............................................................. 64

Q8: Failed to diagnose vehicle ............................................................64

Q9: Failed to activate or register .........................................................64

Q10: Failed to turn on when charging .................................................65

Q11: Failed to open the Diagnostic app ..............................................65

Q12: Why is my device draining battery so fast ..................................65

10 WARRANTY & SERVICES .................................................66

11 COMPLIANCE INFORMATION ..........................................67

FCC Compliance .................................................................................67

CE ....................................................................................................... 68

UKCA .................................................................................................. 68

1 GENERAL INTRODUCTION

The XTOOL IP616 smart diagnostic system is an advanced flatbed

scanning tool based on the Android operating system. It supports multi-

language switching and is suitable for different countries and regions. The

advantage of this obd2 scanner is not only its comprehensive functions,

including complete system Diagnostic, all obd2 functions, various reset

functions (IMMO / EEPROM adapter / EPB (Electronic Parking Brake)

reset / oil light reset / SAS (Steering Angle Sensors) reset / TPS (Throttle

Position Sensor) matching / Injector coding / ABS (Anti-block system)

bleed / gearbox matching / gear learning / electronic pump actuation /

disable transport mode / SRS (Supplemental Restrgint System) reset /

exhaust post-processing / BMS matching / air suspension / cylinder /

TPMS reset / tire refit / headlight adjustment / windows Initialization/seat

matching/DIY mode) can also achieve faster and more accurate

Diagnostic.

TABLET

FRONT VIEW OF TABLET

Fig 1-1 Front View of tablet

①

②

1Grip: this part used to hold the device by hand

2Operation Display: Display basic information such as S/N and model

etc.

The main unit of the IP616 is the tablet, which has a built-in VCI module,

which can be directly connected to the tablet and the car with the test line.

BACK VIEW OF TABLET

Fig 1-2 Back View of Tablet

The product model and S/N are laser-engraved on the back of the display

tablet, and the small hole at the bottom is the Loudspeaker.

1Nameplate: Display basic information such as S/N and model etc.

2Loudspeaker: external sound can be played, supporting the

playback of music, etc.

①

②

HOST PORTS

Fig 1-3 Tablet Host Ports

1USB Port: Data synchronization with PC.

2DB15 Port: This port is used to connect to the main test cable.

3DC charging port: This port is used for charging.

4Power Button: Long press to power on or off. In the power-on state,

short press the button to make the device enter sleep mode.

TECHNICAL SPECIFICATIONS

Table 1-1 Specification

Item

Description

Operating System

Android

Processor

Memory

32GB

Display

7.0-inch touch screen with 1024 ×600

resolution

Connectivity

USB

Wi-Fi

Wired

①

②

③

④

Tabla de contenidos

Otros manuales de Equipo de diagnóstico de Xtool

Xtool

Xtool H6EB Manual de usuario

Xtool

Xtool TP Series Manual de usuario

Xtool

Xtool ASD60 Manual de usuario

Xtool

Xtool IP508S Manual de usuario

Xtool

Xtool PS2 Manual de usuario

Xtool

Xtool KC501 Manual de usuario

Xtool

Xtool TP150 Manual de usuario

Xtool

Xtool H6PRO Manual de usuario

Xtool

Xtool H6 Elite Smart Manual de usuario

Xtool

Xtool H6 EB Manual de usuario

Xtool

Xtool PS70PRO Manual de usuario

Xtool

Xtool PS70PRO Manual de usuario

Xtool

Xtool H6 Elite Manual de usuario

Xtool

Xtool H6PRO Manual de usuario

Xtool

Xtool Anyscan A30D Manual de usuario

Xtool

Xtool AutoProPad Basic Manual de usuario

Xtool

Xtool IP819TP Manual de usuario

Xtool

Xtool H6E Manual de usuario

Xtool

Xtool X100 PAD Manual de usuario

Xtool

Xtool PS70 Pro Manual de usuario

Xtool

Xtool PS70PRO Manual de usuario

Xtool

Xtool D7 Manual de usuario

Xtool

Xtool IP819 Manual de usuario

Xtool

Xtool D1 Pro Manual de usuario

Manuales populares de Equipo de diagnóstico de otras marcas

Mindray

Mindray M7Vet Guía de inicio rápido

Autel

Autel MaxiProgrammer 201 Manual de usuario

TEXA

TEXA TMD2 Manual de usuario

Autel

Autel MaxiIM IM608 Manual de usuario

Sealey

Sealey BT2012 Manual de usuario

Diagnoptics

Diagnoptics Age Reader Manual de usuario

LAUNCH TECH

LAUNCH TECH X-431 PRO5 Manual de usuario

Hella Gutmann

Hella Gutmann Mega macs X Manual de usuario

Foxwell

Foxwell I80TS Manual de usuario

KaVo

KaVo 3D eXam Manual de usuario

ATEQ

ATEQ VT46 Manual de usuario

Hella Gutmann

Hella Gutmann mega macs X Manual de usuario

Autel

Autel MaxiFlash VCMI Manual de usuario

Qiagen

Qiagen QIAcube Connect MDx Manual de usuario

Alber

Alber BDSU Manual de usuario

St. Jude Medical

St. Jude Medical QUANTIEN Manual de usuario

Bosch

Bosch DCU 100 Manual de usuario

Launch

Launch CNC-602A Manual de usuario
