Xtool HD900 Manual de usuario
HD900
1
Declaration
1. This manual is designed for the usage of HD900. No
part of this manual can be reproduced, stored in a
retrieval system or transmitted, in any form or by any
means (electronic, mechanical, photocopying,
recording, or otherwise), without the prior written
permission of Xtool.
2. HD900 is just designed for the professional vehicle
repair or maintenance technicians.
3. Use the device only as described in this manual. The
user will be responsible solely for the after-effects of
violating the laws and regulations caused by using the
product or its data information, in this case Xtool will
not bear any legal responsibility.
4. Xtool shall not be liable for any incidental or
consequential damages or for any economic
consequential damages arising from the accidents of
individual users and the third parties, misuse or abuse
of the device, unauthorized change or repair of the
device, or the failure made by the user not to use the
product according to the manual.
5. All information, specifications and illustrations in this
manual are based on the latest configurations and
functions
available at the time of printing. Xtool reserves the right
HD900
2
to make changes at any time without notice.
6. is the registered trademark of SHENZHEN
XTOOLTECH CO.,LTD.
7. In countries that the trademarks, service marks,
domain names, logos and the name of the company are
not registered, Xtool claims that it still reserves the
ownership of the unregistered trademarks, service
marks, domain names, logos and the company name.
All other marks for the other products and the
company’s name mentioned in the manual still belong
to the original registered company.
You may not use the trademarks, service marks, domain
names, logos and company name of Xtool or other
companies mentioned without written permission from
the trademark holder.
8. Please visit www.xtooltech.com for more information
on the HD900.
9. Xtool reserves the right for the final interpretation of
this manual content.
Precautions
1.The HD900 work in 11V~36V voltage, please make
sure the diagnostic socket on your vehicle export
11V~36V voltage.
2.Please pinch the non-slip grooves but not draw the
HD900
3
middle section of the harness when plugging or
pulling out the diagnostic connector. Please plug the
connector vertically to the DLC PORT. Do not plug it
slantly in case terminal damage.
3.Do not test the car with harness that is not from
XTOOLTECH in case of any loss.
4.When HD900 is communicating with the car, do not
take out the connector directly. Please cancel the task
AND go back to main menu, and then take out the
connector.
5.Be gently to avoid vibration or shock when operating
HD900.
6.When you stop using HD900, please take it out from
the diagnosis port of the car.
7.Ensure the temperature of operating environment is -
20℃to 50℃.
8.Avoid damp and corrosive liquids in storage and daily
use of HD900.
HD900
4
Contents
Chapter ⅠAbout HD900................................................5
1. Appearance & Interfaces....................................5
2. Technical Parameters......................................... 7
Chapter ⅡDiagnose.......................................................8
1. Vehicle Connection Diagnosis........................... 8
2. HD900 Main Interface........................................ 8
3. OBDII Diagnosis.................................................. 9
Chapter ⅢSetting....................................................... 11
1. Language Setting.............................................. 11
2. Contrast Adjustment........................................ 12
3. Metric/English Units....................................... 112
4. Recording..........................................................13
5.Information....................................................... 14
Chapter ⅣUpdate....................................................... 15
1. Upgrade Tool Installing..................................15
2. Software Updating......................................... 15
HD900
5
Chapter ⅠAbout HD900
1. Appearance & Interfaces
(1) Appearance
The appearance of product is subject to practicality.
No.
Name
Descriptions
①
Display screen
3.5’’ TFT-LCD, showing
testing options and results
②
Power indicator
After power on, it will turn
to red color and always on.
③
Communication
Indicator
When communicating with
the vehicle, it will turn to
green color.
①
②
③
④
HD900
6
④
Up or Down
Left or Right
Ok
Exit or Back to previous
interface
Special function key,
Retrieve the keyboard and
input the words
Special function key, can be
used as OK.
(2) Top view：
DB15 Port：Connect to the main
test cable
HD900
7
(3) Down view：
Micro USB Port: Connecting PC
USB2.0 port with mini-USB cable to
update SW
2. Technical Parameters
CPU: ARM 32bit CPU 72MHz
RAM: 64K RAM
Program Memory: 512K Flash
Internal Memory: built-in 2GB TF card
Input Voltage: DC 11~36V
External Interface: DB15/ Mini USB
Display: 3.5’’ TFT-LCD Display
Components: Main frame, Test cable, USB cable
Operating Temperature: -20—50℃
Humidity: <90%
Dimension (L*W*H): 7.48’’(L) x 3.94’’(W) x 1.06’’(H)
HD900
8
Chapter ⅡDiagnose
1. Vehicle Connection Diagnosis
(1). Connect the DB15 connector of test cable to the
HD900 main frame and the 6/9 pin connector to the
vehicles DLC port. (Shown as follows)
(2). Switch on the ignition and turn on HD900 to test
vehicles.
① HD900 main frame ② Test cable
③ 6/9 Pin Truck Connectors ④ Vehicle
2. HD900 Main Interface
The main interface is shown as below. Select “Function”
to test vehicles; Select “Options” to enter the settings
menu; Select “About” to check the software version,
serial number, etc.; Select “Selftest” to do HD900 self-
test.
HD900
9
3. OBDII Diagnosis
(1). Select “Function” in the main interface to do OBDII
diagnosis.
HD900
10
(2). Users can choose the protocol according to his
vehicle for diagnosing.
