KCU105 10GBASE-R

Ethernet TRD User Guide

KUCon-TRD04

Vivado Design Suite

UG921 (v2016.3) October 25, 2016

10GBASE-R Ethernet TRD www.xilinx.com 2

UG921 (v2016.3) October 25, 2016

Revision History

The following table shows the revision history for this document.

Date Version Revision

10/25/2016 2016.3 Updated for Vivado Design Suite version 2016.3. Updated Table 1-1. Updated

Appendix E, Additional Resources and Legal Notices.

06/08/2016 2016.2 Updated all references to Vivado Design Suite version 2016.1 to 2016.2. Revised the

resource numbers in Table 1-1.

04/18/2016 2016.1 Updated all references to Vivado Design Suite version 2015.4 to 2016.1. Revised the

resource numbers in Table 1-1.

11/25/2015 2015.4 Updated all references to Vivado Design Suite version 2015.3 to 2015.4. Revised the

resource numbers in Table 1-1.

10/07/2015 2015.3 Updated all references to Vivado Design Suite version 2015.2 to 2015.3. Revised the

resource numbers in Table 1-1.

06/30/2015 2015.2 Updated all references to Vivado Design Suite version 2015.1 to 2015.2.

04/27/2015 2015.1 Updated all references to Vivado Design Suite version 2014.4.1 to 2015.1.

02/25/2015 2014.4.1 Initial Xilinx Release.

Send Feedback

10GBASE-R Ethernet TRD www.xilinx.com 3

UG921 (v2016.3) October 25, 2016

Table of Contents

Chapter 1: Introduction

10GBASE-R TRD Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Chapter 2: Setup

Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Preliminary Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Chapter 3: Bringing Up the Design

Program the Board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Running the Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Chapter 4: Implementing and Simulating the Design

Implementing the Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Simulating the Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Chapter 5: Reference Design Details

Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Appendix A: Directory Structure

Directory Content Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Appendix B: Performance Estimates

Appendix C: User-Space Registers

Control and Status Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Appendix D: Testing with an External Traffic Generator

Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Program the KCU105 Evaluation Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Set Up the Ixia Load Module Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Running the Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Start Traffic Generation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Send Feedback

10GBASE-R Ethernet TRD www.xilinx.com 4

UG921 (v2016.3) October 25, 2016

Appendix E: Additional Resources and Legal Notices

Xilinx Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Solution Centers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Training Resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Please Read: Important Legal Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Send Feedback

10GBASE-R Ethernet TRD www.xilinx.com 5

UG921 (v2016.3) October 25, 2016

Chapter 1

Introduction

This document describes the features and functions, and how to setup, operate, test, and

modify the 10GBASE-R Ethernet targeted reference design (10GBASE-R TRD).

10GBASE-R TRD Overview

The 10GBASE-R TRD targets the Kintex® UltraScale™ XCKU040-2FFVA1156E FPGA running

on the KCU105 evaluation board. It demonstrates 10-Gigabit Ethernet connectivity using

10-Gigabit Ethernet PCS/PMA IP (10GBASE-R) and 10-Gigabit Ethernet MAC IP (10G MAC)

cores on two channels. The data source for these channels can be configured to be either

from an internal or external Traffic Generator. Figure 1-1 shows the 10GBASE-R TRD block

diagram.

X-Ref Target - Figure 1-1

Figure 1-1: The 10GBASE-R TRD Environment

.&8(YDOXDWLRQ%RDUG

&+$11(/

&+$11(/

&+$11(/

&+$11(/

;&.8))9$()3*$

ELWV

;*0,,

ELWVDW0+]

/RRSEDFN

&RQWURO

&RPSXWHU

-

(WKHUQHW&RQWUROOHU

$SSOLFDWLRQ-DYD%DVHG

*8,DQG'ULYHUV

*%$6(5

7UDIILF

*HQHUDWRU

ELWVDW0+]

/RRSEDFN

$;,,QWHUFRQQHFW

86%WR8$57%ULGJH

6L/DEV&3

$;,8$57

/LWH

0LFUR%OD]H3URFHVVRU

6XEV\VWHP

7UDIILF

*HQHUDWRU

6\VWHP0DQDJHPHQW

:L]DUG

6<6021

ELWV

;*0,,

*

0$&

/RRSEDFN

*%$6(5

*7+7UDQVFHLYHU

$;,/,7(

*

0$&

$;,/,7(

/RRSEDFN

8*BFBB

,QWHJUDWHG%ORFNVLQ)3*$

;LOLQ[,3

&XVWRP/RJLF

2Q%RDUG

$;,/LWH

$;,6WUHDP

*7+7UDQVFHLYHU

/RDG0RGXOHRSWLRQDOH[WHUQDOWUDIILFJHQHUDWRU

&RQWURO

&RPSXWHU

Send Feedback

10GBASE-R Ethernet TRD www.xilinx.com 6

UG921 (v2016.3) October 25, 2016

Chapter 1: Introduction

The design has two 10 Gb/s Ethernet channels; channel 0 and channel 1. Data from one

channel is looped to the other as shown in Figure 1-1. Internal generator mode and external

generator mode are supported:

•Internal generator mode. In this mode, the Traffic Generator block generates the

transmit data. The data is looped back on the PHY side using fiber optic cables. The

looped-back data becomes the receive data on the other channel and is verified by the

10-Gigabit Ethernet MAC core.

•External generator mode. In this mode, an external generator generates the data.

Appendix D describes using an external Ixia NGY-NP4-01 10-Gigabit application

network processor load module (Ixia load module). The data received by the 10-Gigabit

Ethernet MAC IP core is looped back in the Traffic Generator block and passed as

transmit data to the other 10-Gigabit Ethernet MAC IP core. The Ixia load module

verifies this data when received.

A MicroBlaze™ processor-based subsystem monitors the 10-Gigabit Ethernet MAC IP core

statistics and passes the information to the Ethernet Controller application (GUI) running on

the control computer using the USB-to-UART port on the KCU105 board. This subsystem

also controls the Traffic Generator and monitors Ethernet performance.

Components, Features, and Functions

The 10GBASE-R TRD includes:

• 10-Gigabit Ethernet PCS/PMA IP core:

°Uses a GTH transceiver (GTHE3) running at 10.3125 Gb/s line rate.

°Provides a single data rate (SDR) 10-Gigabit Ethernet Media Independent Interface

(XGMII) which connects to the 10-Gigabit Ethernet MAC IP core. The XGMII interface

runs at 156.25 MHz and the data path is 64-bits wide.

°Serial interface to fiber-optic connections.

• 10-Gigabit Ethernet MAC IP core:

°Connects to the 10-Gigabit Ethernet PCS/PMA IP core using the XGMII interface

°Provides AXI4-Stream protocol support on the user interface running at 156.25 MHz

°Is monitored through an AXI4-Lite interface

• Traffic Generator and Monitor:

°Generates Ethernet traffic or loops back Ethernet traffic selected by user input

°Monitors bandwidth utilization on the transmit and receive AXI4-Stream interfaces

of the 10-Gigabit Ethernet MAC IP core

°Is configured and monitored through an AXI4-Lite interface

Send Feedback

10GBASE-R Ethernet TRD www.xilinx.com 7

UG921 (v2016.3) October 25, 2016

Chapter 1: Introduction

• System Management Wizard:

°Uses the UltraScale™ architecture System Monitor (SYSMON) block to monitor

FPGA temperature, voltages and currents

°Is configured and monitored through an AXI4-Lite interface

•AXIUARTLite:

°Provides the controller interface for asynchronous serial data transfer. This interface

connects to the USB-to-UART port on the KCU105 board, and is used to

communicate with the control computer.

°Provides an AXI4-Lite interface on the other end to communicate with the

MicroBlaze processor subsystem.

• MicroBlaze processor subsystem and AXI Interconnect:

°Communicates with the 10-Gigabit Ethernet MAC IP core, Traffic Generator and

Monitor, System Management wizard, and AXI UART Lite using the AXI4-Lite

protocol.

°Drivers running on the MicroBlaze processor subsystem interpret commands

received from the Ethernet Controller application running on the control computer

and convert them to AXI4-Lite transactions.

• Ethernet Controller application:

°Provides a graphical user interface running on the control computer to pass user

inputs to the 10GBASE-R TRD and to display status through the KCU105 board

USB-to-UART port.

Resource Utilization

Table 1-1 lists the resources used by the 10GBASE-R TRD after synthesis has run. Place and

route can alter these numbers based on placements and routing paths, so use these

numbers as a rough estimate of resource utilization. These numbers might vary based on

the version of the 10GBASE-R TRD and the tools used to regenerate the design.

Table 1-1: 10GBASE-R TRD Resource Utilization

Resource Type Used Available Usage (%)

CLB LUTs 14,275 242,400 5.89

CLB Registers 16,701 484,800 3.44

Block RAM Tiles 35 600 5.83

Global Clock Buffers 8 240 1.67

BUFG_GT_SYNC 4557.27

BUFG_GT 7 120 5.83

GTHE3_CHANNEL 2 20 10.00

Send Feedback

10GBASE-R Ethernet TRD www.xilinx.com 8

UG921 (v2016.3) October 25, 2016

Chapter 1: Introduction

GTHE3_COMMON 1520.00

SYSMONE1 1 1 100.00

Table 1-1: 10GBASE-R TRD Resource Utilization (Cont’d)

Resource Type Used Available Usage (%)

Send Feedback

10GBASE-R Ethernet TRD www.xilinx.com 9

UG921 (v2016.3) October 25, 2016

Chapter 2

Setup

This chapter lists the requirements and describes how to do all preliminary setup of the

KCU105 board, control computer, and software before bringing up the 10GBASE-R TRD.

IMPORTANT: Perform the procedures described in this chapter before performing the bring up

procedures described in Chapter 3, Bringing Up the Design.

Requirements

Hardware

• KCU105 board with the Kintex® UltraScale™ XCKU040-2FFVA1156E FPGA

• Two USB cables, standard-A plug to micro-B plug

• Power Supply: 100 VAC–240 VAC input, 12 VDC 5.0A output

• Two SFP+ 10GBASE-SR/SW transceiver modules (Avago Technologies)

• One LC-LC duplex 10 Gb multimode 50/125 OM3 fiber optic patch cable, 2 x LC Male to

2 x LC Male, part number FO-10GGBLCX20-001 (Amphenol Corporation)

Computer

One computer is required, and is identified as the control computer throughout this

document. It is required for running the Vivado Design Suite, configuring the FPGA, and

running the Ethernet Controller application to control and monitor the reference design. It

can be a laptop or desktop computer with Microsoft Windows 7 operating system.

Design Tools and Software

• Vivado® Design Suite 2016.3

• USB UART drivers (Silicon Laboratories CP210x VCP drivers)

• Java version 1.7

• Ethernet Controller application (GUI included with the 10GBASE-R TRD)

Send Feedback

10GBASE-R Ethernet TRD www.xilinx.com 10

UG921 (v2016.3) October 25, 2016

Chapter 2: Setup

Download and installation instructions for each required software is described in

Preliminary Setup.

Preliminary Setup

Complete these tasks before bringing up the design described in Chapter 3, Bringing Up

the Design.

Install Vivado Design Suite

Install Vivado Design Suite 2016.3 on the control computer. Follow the installation

instructions provided in Vivado Design Suite User Guide Release Notes, Installation, and

Licensing (UG973) [Ref 1].

Download Targeted Reference Design Files

1. Download the 10GBASE-R TRD ZIP file rdf0308-kcu105-trd04-2016-3.zip from

KCU105 Evaluation Kit Documentation.

2. Unzip the contents of the file to a working directory.

3. The unzipped contents will be located at <working_dir>/kcu105_10gbaser_trd.

The 10GBASE-R TRD directory structure is described in Appendix A, Directory Structure.

Install the USB UART Drivers

Download the CP210x USB to UART Bridge VCP drivers (for Windows 7) from the Silicon

Labs website [Ref 2]. Follow the instructions in Silicon Labs CP210x USB-to-UART Installation

Guide (UG1033)[Ref 3].

Configure the Control Computer COM Port

The 10GBASE-R TRD uses the Ethernet Controller application to communicate between the

control computer and the KCU105 board. To configure the control computer COM ports for

this purpose:

Send Feedback

Otros manuales para KCU105

Tabla de contenidos

Otros manuales de Placa madre de Xilinx

Xilinx

Xilinx SP605 Manual de usuario

Xilinx

Xilinx ML605 Manual de usuario

Xilinx

Xilinx Virtex-6 FPGA Manual de usuario

Xilinx

Xilinx ZCU1285 Manual de usuario

Xilinx

Xilinx KCU105 Manual de usuario

Xilinx

Xilinx VCK5000 Manual de usuario

Xilinx

Xilinx KCU116 Manual de usuario

Xilinx

Xilinx AMS101 Manual de usuario

Xilinx

Xilinx Spartan-3A DSP FPGA Series Manual de usuario

Xilinx

Xilinx Spartan-3A DSP FPGA Series Manual de uso y cuidado

Xilinx

Xilinx ZC702 Manual de usuario

Xilinx

Xilinx ML310 Manual de usuario

Xilinx

Xilinx FMC XM101 LVDS QSE Manual de usuario

Xilinx

Xilinx Virtex-4 RocketIO Manual de usuario

Xilinx

Xilinx VC707 Manual de usuario

Xilinx

Xilinx Virtex-6 FPGA Manual de usuario

Xilinx

Xilinx Zynq UltraScale+ ZCU208 Manual de usuario

Xilinx

Xilinx Zynq UltraScale+ ZCU104 Manual de usuario

Xilinx

Xilinx SP623 Manual de usuario

Xilinx

Xilinx Virtex-II Pro ML324 Manual de usuario

Xilinx

Xilinx VC709 Si570 Manual del propietario

Xilinx

Xilinx Platform Cable USB II Manual de usuario

Xilinx

Xilinx Spartan-6 FPGA Series Manual de usuario

Xilinx

Xilinx Spartan-3 Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario
