Product Safety Data Sheet

Phaser 6140

Page 1 of 3

_________________________________________________________________________

PRODUCT DESCRIPTION

Phaser 6140 Color Printer

MANUFACTURER INFORMATION

XEROX Corporation

P.O. Box 1000

Wilsonville, Oregon 97070-1000

PRODUCT DIMENSIONS

Depth Width Height

Phaser 6140N/DN 457 mm / 18.0 inches 400 mm / 15.8 inches 415 mm / 16.4 inches

WEIGHT

Phaser 6140N 18.35 kg / 40.5 lbs

Phaser 6140DN 19.5 kg / 43.0 lbs

ELECTRICAL INFORMATION

115 V 230 V

Voltage (Volts) 110-127 Vac 220-240 Vac

Frequency (Hertz) 50/60 Hz 50/60 Hz

Current (Amps) 9 A 5 A

PRODUCT SAFETY CERTIFICATION

Standard Certifying Body

Low Voltage Directive •2006/95/EC XEROX Limited

CB Report & Certificate •IEC 60950-1:2005

•EN 60950-1:2006

•IEC 60825-1:1993 +A1:1997 +A2:2001

•EN 60825-1:1994 +A1:2002 +A2:2001

TÜV Rheinland

UL Report •UL 60950-1, 1st Edition

•CAN/CSA C22.2 No. 60950-1-03, 1st

Edition

ELECTROMAGNETIC COMPATIBILITY CERTIFICATION

Standard Certifying Body

EMC Directive •2004/108/EC XEROX Limited

EMC Report •FCC Part 15 Subpart B, Class B

•EN 55022:2006, Class B

•EN 61000-3-2:2006, Class A

•EN 61000-3-3:1995 +A1:2001

+A2:2005

•EN 55024:1998 +A1:2001 +A2:2003

EMC Kashima

Product Safety Data Sheet

Phaser 6140

Page 2 of 3

_______________________________________________________________________________

POWER CONSUMPTION

115 V

Off Mode (Wh/hr) Power Save (Wh/hr) Standby (Wh/hr) Run Mode (Wh/hr)*

0 5 38 333

230 V

Off Mode (Wh/hr) Power Save (Wh/hr) Standby (Wh/hr) Run Mode (Wh/hr)*

0 6 39 335

*color simplex printing

HEAT OUTPUT

115 V

Off Mode (BTU/hr) Power Save (BTU/hr) Standby (BTU/hr) Run Mode (BTU/hr)*

0 17 129 1137

230 V

Off Mode (BTU/hr) Power Save (BTU/hr) Standby (BTU/hr) Run Mode (BTU/hr)*

0 20 134 1143

NOTE: The electrical power information provided should not be used to define the electrical support required for

this product. Consult your Xerox representative if you require detailed information.

*color simplex printing

OPERATING ENVIRONMENT

Ambient Temperature (°C / °F) Relative Humitidy (%)

Operating 10 to 32°C / 50 to 90°F 15 to 85% RH

Non-Operation -20 to 40°C / -4 to 104°F to % RH

LIGHT SOURCE

Laser – FDA/CDRH Accession Number 0831196-000

AUDIBLE NOISE

Declared noise emissions in accordance with ISO 9296:

Model: Phaser 6140N

(Base Configuration) Idling Operating

(Standard Mode 20ppm)

LWAd (1B=10dB)LWAd = 3.7 B LWAd = 6.6 B

Bystander Position (1.0 m) LpA = 22 dB LpA = 51 dB

Product Safety Data Sheet

Phaser 6140

Page 3 of 3

_______________________________________________________________________________

CHEMICAL EMISSIONS

Tested in accordance with RAL-UZ 122:

Emission Rate (mg/h)

(monochrome - Printing Phase)

Ozone <0.076 mg/h

Styrene 0.24 mg/h

Particles (Dust) 0.32 mg/h

TVOC 2.9 mg/h

Benzene <0.0003 mg/h

OZONE FILTER REPLACEMENT

Not applicable
