Xerox Phaser 3320 Manual de usuario

haser® 3320 and

WorkCentre® 3315/3325

Service Manual

haser® 3320 and WorkCentre® 3315/3325

Service Manual

roduct hoto

Xerox Internal-Use Only

Updated 10/14/15 DAW

www MK-Electronic de

Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325

Service Manual

5-1

Parts Lists

In this chapter...

•Serial Number Format

•Using the Parts List

•Parts Lists

•Xerox Supplies and Accessories

www MK-Electronic de

Parts Lists

Phaser 3320 and WorkCentre 3315/3325 Xerox Internal Use Only

Service Manual

5-2

Serial Number Format

Changes to Xerox products are made to accommodate improved components. When ordering parts

include this information:

• Component's part number

• Product type or model number

• Serial Number of the printer

The serial number is located on the right-side frame near the Fuser.

The nine-digit serial number uses the format PPPRSSSSS or MMMSSSSSSc.

•PPP = Three digit alphanumeric product code

• MMM = Three digit numeric manufacturing location code

•R= Single digit numeric revision digit, 0-3. To be rolled when the ending serial number is reached

or when a major product change occurs.

•SSSSS(S) = Five or six digit numeric serial number based on the following table. The serial

numbers are reset only when the ending number is reached or when the revision number is rolled.

• c = Check digit (correct number from check digit algorithm)

Product Code Location Code Product

LAO 397 Phaser 3320_DN, 110V Engine

LA1 397 Phaser 3320_DN, 220V Engine

LA2 397 Phaser 3320_DNI, 100V Engine

LA3 397 Phaser 3320_DNI, 220V Engine

LA4 397 WorkCentre 3315_DN, 110V Engine

LA5 397 WorkCentre 3315_DN, 220V Engine

LA6 397 WorkCentre 3325_DN, 110V Engine

LA7 397 WorkCentre 3325_DN, 220V Engine

LA8 397 WorkCentre 3325_DNI, 110V Engine

LA9 397 WorkCentre 3325_DNI, 220V Engine

Product Starting Serial Number Ending Serial Number

Phaser 3320DN 080501 107500

Phaser 3320DN 107501 197500

Phaser 3320DNI 197501 202500

Phaser 3320DNI 202501 217500

WorkCentre 3315DN, 110V Engine 217501 234500

WorkCentre 3315DN, 220V Engine 234501 279500

www MK-Electronic de

Parts Lists

Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325

Service Manual

5-3

Example

LA13970107601: Xerox Serial Number

LA1: Manufacturing Code for Phaser 3320DN, 220V Engine

0: Revision Level

107601: Serial Number for Phaser 3320DN

Using the Parts List

•ID No.: The callout number from the exploded part diagram.

•Name/Description: The name of the part to be ordered and the number of parts supplied per

order.

•Part Number: The material part number used to order that specific part.

• Parts identified throughout this manual are referenced PL#.#.#; For example, PL3.1.10 means the

part is item 10 of Parts List 3.1.

• A Black triangle preceding a number followed by a parenthetical statement in an illustrated parts

list means the item is a parent assembly, made up of the individual parts called out in

parentheses.

• The notation “with X~Y” following a part name indicates an assembly that is made up of

components X through Y. For example, “1 (with 2~4)” means part 1 consists of part 2, part 3, and

part 4.

Note: Only parts with part numbers are available for ordering. Parts without part numbers are

available on the parent assembly.

WorkCentre 3325DN, 110V Engine 279501 326500

WorkCentre 3325DN, 220V Engine 326501 399500

WorkCentre 3325DNI, 110V Engine 411501 419500

WorkCentre 3325DNI, 220V Engine 399501 411500

Product Starting Serial Number Ending Serial Number

www MK-Electronic de

Parts Lists

Phaser 3320 and WorkCentre 3315/3325 Xerox Internal Use Only

Service Manual

5-4

Parts Lists

Parts List 1.0 Phaser 3320 Main

s33 0-001

www MK-Electronic de

Parts Lists

Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325

Service Manual

5-5

Parts List 1.0 Phaser 3320 Main

Item Name Part Number

0 Phaser 3320

1 Left Cover 002N03055

2 Top Cover 002N03056

3 Rear Cover 095N00415

4 Right Cover 002N03057

5 Front Cover 002N03058

6 Control Panel See Parts List 2.1 Phaser 3320

Control Panel

7 Main Frame Parts List 3.1 Frame

8 Duplex Assembly 022N02676

9 Duplex Rear Cover

10 Tray 1 050N00650

11 Main Board (wireless-enabled)

Main Board (non-wireless)

140N63xxx (see note)

12 Print Cartridge See Consumables and

Maintenance Items

13 Wireless Board 140N63633

Main Board (

wireless

-enabled

)

Main Board (

non-wireless

)

(see note)

www MK-Electronic de

Parts Lists

Phaser 3320 and WorkCentre 3315/3325 Xerox Internal Use Only

Service Manual

5-6

Parts List 1.1 Phaser 3320 Covers

3-2

3-3

3-4

2-8

2-5

2-7

2-2

2-7

2-6

2-4

2-7

2-3

s3320-002

www MK-Electronic de

Parts Lists

Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325

Service Manual

5-7

Parts List 1.1 Phaser 3320 Covers

Item Name Part Number

1 Left Cover 002N03055

2 Top Cover Assembly 002N03056

2.1 Top Cover

2.2 Exit Cover

2.3 RX Stacker

2.4 Bin Full Stacker

2.5 Exit Ground

2.6 Sub M Stacker PMO

2.7 Taptype Screw

2.8 531P Antistatic Brush

3 Rear Door Assembly

3.1 Rear Door 095N00415

3.2 Guide Change Dup

3.3 Idle Roller

3.4 Sponge-Guide Change Dup

www MK-Electronic de

Parts Lists

Phaser 3320 and WorkCentre 3315/3325 Xerox Internal Use Only

Service Manual

5-8

Parts List 1.2 Phaser 3320 Right Cover

s3320-003

www MK-Electronic de

Parts Lists

Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325

Service Manual

5-9

Parts List 1.2 Phaser 3320 Right Cover

Item Name Part Number

1 Right Cover 002N03057

2 SCF Cover

3 Sheet-Output_5V

Note: Order this adhesive-backed sheet to cover the 5V

input when replacing the Right Cover.

019N01079
