Xerox Regal 5790 Manual de usuario

Revised November 1995

XEROX CUSTOMER SUPPORT CENTER - DOCUMENT #100226

Xerox 5790 (Regal) Digital Color Copier/Printer

COPY VOLUME RANGE

- This product was designed to provide “benchmark”

image quality. To maximize Customer Satisfaction this

product should be operated up to 30,000 copies / prints

per month 80 - 90% of which are color copies. Usage

above this range may result in a higher service

frequency (see chart below).

PERFORMANCE AT MATURITY

SPEED

- 9 copies per minute (cpm) (4 color) for 8.5x11 Long Edge

Feed (LEF)

- 36 cpm (B/W) for 8.5x11LEF

- 18 cpm (B/W) for 8.5x14, 11x17 Short Edge Feed (SEF)

- 4.5 cpm (4 color) for 8.5x11, 8.5x14, 11x17 SEF

- 4.5 cpm (B/W) Transparencies

- 1.8 cpm (4 color) Transparencies

INPUT

- Document Glass Mode - up to 11x17

- Automatic Document Feeder (ADF) is an option

- 50 sheet maximum

- 16 - 28 # paper weight

- 5.5 x 8.5 to 11x17 originals

- Film Projector Mode

- 35mm negative or positive slide in film

holder.

- 35mm negative or positive on platen

- 4 x 5 and 60 x 60 positive films

(60 x 90 mm w/SA adjustment)

- Copies between service calls on a digital color copier is

dependent on customer expectation levels of quality,

volume, applications and thruput materials. Trained

operators can minimize service calls

0 7 14 21 28

A C

v a

g l

S s

e /

r M

v o

i n

c t

e h AMCV/AMPV

Revised November 1995

XEROX CUSTOMER SUPPORT CENTER - DOCUMENT #100226

THRUPUT

* Cassette size is set by the Xerox technical

representative at install and is adjustable by the Xerox

technical representative only .

** 20# paper

- Recommended paper to maximize copy quality is Xerox

Image series LX 24# (smooth bright white paper). This

paper is specifically designed to maximize image quality

and machine performance over a wide range of

environmentalconditions.

- Recommended 90# index or equivalent can be run

satisfactorily. However, it is not to be expected to

match the performance of Xerox Image Series LX 24#

- Attempts to feed greater than 90# index or

recommended equivalent may cause machine damage.

Tray Size* Capacity** Specified

Weights

1 8x10 to

11x17 250 16-24#

2 8x10 to

11x17 250 16-24#

3 8x10 to

11x17 250 16-24#

Bypass 8x10 to

11x17 50 16# bond up

to 90# index

60# coated

Xerox 5790 (Regal) Digital Color Copier/Printer

-Xerox coated stock 32 # bond (3R5093) and 60# bond

(3R5095), which were designed for the xerographic

process, can be run satisfactorily. Coated papers are

not to be expected to match the performance of Image

Series LX paper.

- Sorter option:

- 20 bin sorted or stacked sets of the above thruput

sizes and weights at 50 sheets per bin.

- Sorter top tray will handle all above thruput sizes up

to 99 sheets.

- Output tray will handle all above thruput sizes up to 250

sheets.

Note: For more detailed information on thruput materials, please

refer to the Xerox Materials Usage Guide for Regal.

(700P99701)

COPY QUALITY

- Color Quality is subjective and could be impacted by

lighting.

- Like any color reproduction process there will be some

variances in color quality over time.

- Copy Quality is strongly influenced by paper.

- Key Applications should be copied on the 5790 and

reviewed with the customer.

- Transparencies are non absorbent and may exhibit non

uniform density streaks in large solid areas from the

fuser agent film.

Revised November 1995

XEROX CUSTOMER SUPPORT CENTER - DOCUMENT #100226

CUSTOMER SUPPORT

- The Xerox Customer Support Center Helpline, 1-800-

821-2797, is provided for all service calls and available

for Customer application questions.

- The Supplies Marketing Center is available at 1-800-

822-2200 for order of paper and thruput materials.

- Fee-based training courses or hourly sessions are

available through Xerox Document Management

TrainingRepresentatives.

DUPLEX COPYING

- Regal 5790 is recommended for duplex applications.

- As with any full color copier, duplex performance is not

expected to match the performance for single sided

copying. Paper jam rates will be higher than the rate

you will experience for the same thruput material in

single sided mode. Extensive duplex operation may

have a secondary effect on performance and copy

quality of single sided jobs.

- When running duplex copies, the second side should

be run only from the Paper Tray bypass.

CONFIGURATION LIMITATIONS

- 5790 does not allow for Sorters and Film Projectors to

be placed on the same unit.

INSERTION OF COPIES INTO HIGH

VOLUME COPIERS

- Insertion of Regal 5790 copies in 5090/5390/ DocuTech

135 requires CBU validation.

- Do not use 5790 inserts in 5100 due to incompatibility

with the fuser.

TRANSPARENCIES

- Transparencies for this product are restricted to

3R5765, 3R5775 and 3R3108 and can only be

supported out of the bypass tray if fed in the correct

manner. The 3R5765 premium transparency is

specifically designed to provide optimum copy quality

including more vivid colors.

- Use of other transparencies may cause machine

damage. Continued use of transparencies other than

those recommended may result in customer being

placed on time and materials. Please see the MUG

700P99701 for additional information.

Xerox 5790 (Regal) Digital Color Copier/Printer

Revised November 1995

XEROX CUSTOMER SUPPORT CENTER - DOCUMENT #100226

Reorder # Units / Carton Net Wt./CTN

Dry Ink

- Black 6R718 2 Cartridges 600 g.

- Cyan 6R719 2 Cartridges 600 g.

- Yellow 6R720 2 Cartridges 600 g.

- Magenta 6R721 2 Cartridges 600 g.

Developer

- Black 5R319 1 Pouch 650 g.

- Cyan 5R320 1 Pouch 650 g.

- Yellow 5R321 1 Pouch 650 g.

- Magenta 5R322 1 Pouch 650 g.

Fuser Agent 8R3993 1 Bottle Liter

Waste Toner Bottle 8R7664 2 Bottles -

Note: Dry Ink and Developer consumption will vary depending on actual area coverage.

Xerox 5790 (Regal) Digital Copier / Printer

SUPPLIES

Revised November 1995

XEROX CUSTOMER SUPPORT CENTER - DOCUMENT #100226

Xerox 5790 (Regal) Digital Copier / Printer

ENVIRONMENTAL AND ELECTRICAL REQUIREMENTS

Min Max

Temperature 50 ºF (10 ºC) 90 ºF (32 ºC)

Humidity 15% 85%

Power Consumption Power (VA)

Warm-up 1440

Standby average 288

Run mode (4 Color)

Peak 1200

Average 1020

Specifications:

Ground Fault Interrupter

Single phase - 2 Wire plus ground

Service - 15 AMP or 20 AMP (Sole use not required, but recommended)

Line to neutral - 115 Volts (+6/-10%)

Frequency - 60 HZ (± 2%)

Revised November 1995

XEROX CUSTOMER SUPPORT CENTER - DOCUMENT #100226

Xerox 5790 (Regal) Digital Copier / Printer

Confi

urations for 5790 Moveable Width

(

Inches

)

(

Inches

)

Non Edit /w Catch Tra

or Edit /w Catch Tra

or ADF /w Catch Tra

on a floor Yes 72” 71” Room

86” Hallwa

Non Edit /w Catch Tra

or Edit /w Catch Tra

or ADF /w Catch Tra

on a mobilit

late Yes 72” 71” Room

90” Hallwa

No-Edit /w Catch Tra

or Edit /w Catch Tra

or ADF /w Catch Tra

at a stationar

install No 72” 91” Room

106” Hallwa

Non Edit /w Sorter or Edit /w Sorter or ADF /w Sorter at a stationar

install No 88” 91” Room

106” Hallwa

ADF /w Catch Tra

& Edit Pad O

tion on a floor Yes 103” 91” Room

106” Hallwa

ADF /w Catch Tra

& Edit Pad O

tion on a mobilit

late Yes 103” 91” Room

106” Hallwa

ADF /w Catch Tra

& Edit Pad O

tion at a stationar

install No 103” 91” Room

106” Hallwa

ADF /w Sorter & Edit Pad O

tion at a stationar

install No 119” 91” Room

106” Hallwa

NOTE: Minimum floor to ceiling height requirement for all installations is 78” (2000 mm)

Space Requirements

Revised November 1995

XEROX CUSTOMER SUPPORT CENTER - DOCUMENT #100226

Primary Customer Regal 5790 applications

Special Considerations or performance limitation identified by Xerox and agreed to by the customer.

I have reviewed and understand these product specifications.

Customer

Xerox Sales Representative

Xerox Customer Service Engineer

Xerox 5790 (Regal) Digital Color Copier/Printer

Xerox Color Network Marketing Executive
