Expectation Setting Document for Fiery X2 V1.01
Digital Front End for 5765, 5790 DocuColor 5750/ 5799
Terms and product names used in this document may be trademarks or registered trademarks of their respective companies and arehereby acknowledged.
Post Launch Version 26 May 1999
Page 1 of 7 X2_Majestik_ced.doc
Customer Support
The Xerox Customer Support Centers are available to provide general information, answer questions and take
service calls. You can reach the Customer Support Center at the following toll-free phone numbers:
United States 1-800-821-2797
Canada 1-800-939-3769
Your Xerox Color Analyst will provide fee-based training upon request.
General Specifications
Physical and Environmental
Server English Units Metric Units
Weight 12 lb. 5.44 kg.
Dimensions 10 x 6 x 14 inches 24 x 14.4 x 33.6 cm
Operating Temperature 50º - 104º F 10º - 40º C
Relative Humidity 5% to 95% (noncondensing) 5% to 95% (noncondensing)
Altitude 0 to 10,000 ft. 0 to 3,048 m
Electrical Requirements and Compliance
Server Line Voltage 100 to 125 / 200 to 240 VAC RMS single phase, automatically configured
Frequency 50 to 60 Hz single phase
Power 150 W maximum
Fiery X2 Optional Kits
•Token Ring Connectivity Kit
•X-Rite DTP32 Densitometer
•BNC Transceiver
Fiery X2 Specifications
•200 MHz R5000 MIPs Processor
•160 MB RAM
•2 GB IDE hard drive
•10/100 BaseT Network capability
Expectation Setting Document for Fiery X2 V1.01
Digital Front End for 5765, 5790 DocuColor 5750/ 5799
Terms and product names used in this document may be trademarks or registered trademarks of their respective companies and arehereby acknowledged.
Post Launch Version 26 May 1999
Page 2 of 7 X2_Majestik_ced.doc
Network Specifications
Protocol Stack Printing
Services Supported Frame Types Platform
Novell IPX / SPX
PServer Ethernet 802.2
Ethernet 802.3
Ethernet_II
Ethernet SNAP
Token Ring 802.2 (option)
Token Ring SNAP (option)
Windows NT
Windows 95
Windows 3.1
TCP / IP LPD Ethernet_II
Token Ring SNAP (option)
Windows NT
Windows 95
Solaris 2.4
SunOS 4.1.x
TCP / IP SMB Ethernet_II
Token Ring SNAP (option)
Windows NT
Windows 95
AppleTalk PAP Ethernet SNAP
(EtherTalk Phase 2 only) Windows NT 4.0
Macintosh
The customer is responsible for supplying one network drop to enable the install.
Printing
STARR Compression
• The Compression efficiency is dependent on file type and complexity. Artifacts may be possible when
compression is selected depending on the file complexity.
• STARR Compression must be selected to support the advanced features in Fiery Options; i.e., collation, reverse
order, etc.
Print Speed / System Performance
• The maximum print speed for the X2 system is limited by the print speed of the 5765, 5790 and DocuColor 5750/
5799.
• The 5765, 5790 and DocuColor 5750/ 5799 are document printers; therefore the print engine will not cycle up until
the entire job is ready. This will impact First Copy Out Time (FCOT) when STARR Compression is in use. The
copier may cycle down between each job depending on job complexity.
• Overall system performance (‘Click to Clunk’ time) is primarily dependent upon the software applications and
network environment being used. Rasterizing (RIP-ing) is only a small fraction of Click to Clunk time.
• Printing with custom software applications may produce unexpected or unknown results.
Expectation Setting Document for Fiery X2 V1.01
Digital Front End for 5765, 5790 DocuColor 5750/ 5799
Terms and product names used in this document may be trademarks or registered trademarks of their respective companies and arehereby acknowledged.
Post Launch Version 26 May 1999
Page 3 of 7 X2_Majestik_ced.doc
Maximum Image Sizes
• The maximum image size from an application is limited to the image size produced by the 5765, 5790 and
DocuColor 5750/ 5799. The application and the 5765, 5790, DocuColor 5750/ 5799 setup controls image position.
• Non-imageable area for the DocuColor 5790/ 5799 is listed as follows:
Leading Edge Trailing Edge Near Edge Far Edge
8mm 3mm 3mm 3mm
• Non-imageable area for the DocuColor 5750 is listed as follows:
Leading Edge Trailing Edge Near Edge Far Edge
5mm 5mm 3mm 3mm
INCLUDE TABLE FOR MAJESTIK
IOTs Supported
• 5765, 5790 and DocuColor 5750/ 5799.
Printer Driver Support
• Adobe 3.0.1 for Windows 3.x
• Adobe 4.2.2 for Windows 95
• Windows NT 4.0 (Microsoft PPDs only are supplied)
• Adobe PSPrinter 8.5.1 for Macintosh
• No driver support for UNIX
• No driver support for DOS applications
Features
ColorWise: Enables the X2 to independently adjust and correct any combination of RGB, CMYK, and Spot Color
data supplied to the X2 controller to provide accurate color rendition when printing with the 5765, 5790 and
DocuColor 5750/ 5799.
NetWise: This architecture supports Appletalk, TCP/IP (Ethernet/Token Ring), Native Novell 4.0 (NDS), Novell 3.x
(bindery), 10/100BaseT standard support, and Native Win 95 printing concurrently. Additionally, this architecture
allows the X2 to bind multiple frame types and protocols to the Ethernet or optional Token Ring card for auto
switching and detection.
PostScript 3: The Fiery X2 is a true Adobe PostScript 3 controller.
Upgrade Strategy
Currently there are no plans for upgrading.
Finishing Options
Sorter
• The Sorter is supported when STARR compression is enabled.
Expectation Setting Document for Fiery X2 V1.01
Digital Front End for 5765, 5790 DocuColor 5750/ 5799
Terms and product names used in this document may be trademarks or registered trademarks of their respective companies and arehereby acknowledged.
Post Launch Version 26 May 1999
Page 4 of 7 X2_Majestik_ced.doc
Utilities
Downloader
• Uses IPX or TCP/IP for Win 95 and Win NT 4.0.
• Supports Win 95 and Win NT only.
• The Downloader utility on Mac requires AppleTalk.
Spooler
• WebSpooler only
WebTools
• Java capable browser platforms only
• Currently, the only fully enabled Java browsers are Win 95, Win NT, and UNIX.
• Mac platforms and Win 3.11 may not fully support WebTools.
Calibration
• AutoCal2 is the primary calibration method.
• An optional X-Rite DTP32 Densitometer is available with the X2 server to enable the printer calibration feature.
Currently the X-Rite DTP32 is the only densitometer approved for the Fiery X2.
• Color monitor calibration is the responsibility of the customer.
• Optimal print quality is achieved by using a densitometer. For RGB emitting applications (PowerPoint, Word, and
Excel), use the 5765, 5790 and DocuColor 5750/ 5799 calibration target. For CMYK applications (Quark,
Pagemaker) use the SWOP target.
Print Quality and Color Management
• The appearance of the document displayed on the monitor screen may not match the output print because the
monitor uses RGB color space parameters.
• For imported RGB images, optimal color is achieved in the EPS format. Other imported file formats may produce
unexpected results.
Separations Support
• For the PC, only QuarkXPress & Pagemaker can be used for separations.
• For the Mac, only QuarkXPress or Pagemaker version 6.0 can be used for separations.
Scanning
• The copier does support the Scan Back feature using a TWAIN plug-in.
• Fiery AutoCal2 calibration is available at the Fiery X2.
Supported Paper Sizes
The following paper sizes are supported by the Fiery X2:
•Letter and SEF Letter •Legal and Legal 13
•8 x 10 •11 x 17
•9 x 12 •A3
•A4, SEF A4 •B4
•B5 •DocuPac
•Oversized (11 X 17 & A3) transparencies •12 x 18 (DocuColor 5750 only)
Expectation Setting Document for Fiery X2 V1.01
Digital Front End for 5765, 5790 DocuColor 5750/ 5799
Terms and product names used in this document may be trademarks or registered trademarks of their respective companies and arehereby acknowledged.
Post Launch Version 26 May 1999
Page 5 of 7 X2_Majestik_ced.doc
Reference Material
The X2 is shipped with a complete set of documentation for the installation and use of the server. This
documentation is in one of two formats and is provided in the Customer Media Package bundled with each server.
The following documentation is available on the User Documentation CD and is in Adobe Acrobat PDF format.
• Setup: How to set-up and configure the Fiery X2 from the LCD interface.
• Installing Software: How to install client software and printer files onto workstations from CD or WebTools.
• Printing: How to print to the Fiery X2 from Macintosh, Windows, and UNIX workstations.
• Utilities: How to use remote utilities and WebTools to spool, download files, and fonts, scan and calibrate.
The following documentation is in hardcopy format.
• Customer Release Notes: Contains customer information about the server and client utility that was not included
in the electronic customer documentation. This information includes caveats and workarounds.
• Quick Start Guide: Quick hardcopy version of Setup Guide from User Documentation
Space Guidelines
356 mm
14 in
50mm
2 in
33.7 in
856 mm
610 mm /
24 in
Minimum Space
Requirements for the
Fiery X2 Server
610 mm /
24 in
33.7 in
856 mm
50 mm
2 in
356 mm
14 in.
25.8 in
655 mm
610 mm /
24 in
25.8 in
655 mm
Customer supplied
work surface
for Fiery X2 5765, 5790 or
DocuColor 5750/ 5799 WS
WS
Customer supplied
work surface
for Fiery X2
Expectation Setting Document for Fiery X2 V1.01
Digital Front End for 5765, 5790 DocuColor 5750/ 5799
Terms and product names used in this document may be trademarks or registered trademarks of their respective companies and arehereby acknowledged.
Post Launch Version 26 May 1999
Page 6 of 7 X2_Majestik_ced.doc
Responsibility Matrix
Action Customer Xerox
Ensure adequate space and power to configure Fiery server to the 5765,
5790 and DocuColor 5750/ 5799 copier/ printer within 12 feet. X
Unpack system / components X
Install server hardware X
Connect all System Components prior to powering up the system X
Install the printer description files, utilities, and printer drivers on client PCs. X
Ensure network configuration X
Confirm network integrity X
Acquire and install client workstation network hardware and software X
Monitor calibration for color matching of color management systems X
Load any additional fonts X
Procure BNC transceiver for network connection (if required) X
Set up and administer client workstations X
Provide Helpline Support (when FSMA is purchased) X1
Provide spared parts (when FSMA is purchased) X1
Provide service (when FSMA is purchased) X1
1Xerox responsability when a Field Service Maintenance Agreement (FSMA) is purchased. If FSMA is not purchased, this
action becomes a customer responsability
Expectation Setting Document for Fiery X2 V1.01
Digital Front End for 5765, 5790 DocuColor 5750/ 5799
Terms and product names used in this document may be trademarks or registered trademarks of their respective companies and arehereby acknowledged.
Post Launch Version 26 May 1999
Page 7 of 7 X2_Majestik_ced.doc
Primary Customer X2 Fiery Applications:
Special Considerations or performance limitations identified by Xerox and agreed to by the customer:
I have reviewed and understand this product information:
Customer
Xerox Sales Representative
Xerox Customer Service Engineer / Representative
Xerox Color Network Marketing Executive / Xerox Color Sales Executive
