System

Requirements

Chapter 1

Introduction

Welcome!

Where to find helpful information

Introduction to the Document WorkCentre 450c

WorkCentre features

Control panel keys

How to navigate the WorkCentre menus

Using the numeric keypad

Understanding the document flow icons

Using the ControlCentre software

Setting the ControlCentre properties

Selecting and Ordering Supplies

WorkCentre 450c Specifications

Keypad Character Assignments

Keypad character assignments for North and South

America

Keypad character assignments for Europe

Welcome!

Thank you for choosing the Xerox Document WorkCentre

450c, the dependable and efficient multi-function device

that handles your office tasks with ease. The WorkCentre

works the way you do, performing more than one job at a

time.

Using the WorkCentre, you can:

• Send and receive paper and electronic faxes

• Print color and black-and-white documents

• Copy, collate, reduce, and enlarge documents

• Scan paper documents and convert them to fully

editable electronic documents

TheWorkCentre CD-ROM includesXerox Pagis™ Pro 97

and TextBridge™ Pro software. Using Pagis Pro you can

scan, organize, and retrieve the documents in your office.

TextBridge optical character recognition software lets you

easily convert your paper documents to electronic

documents, while retaining text formatting and pictures.

Where to find helpful information

Document WorkCentre 450c Quick Installation &

Quick Reference Guide

Step-by-step instructions explain how to set up the

WorkCentre, install the ControlCentre™ software,

and perform frequently used tasks.

Document WorkCentre 450c Guided Tour

An online introduction to the WorkCentre 450c and

its ControlCentre software. To run the guided tour,

click the Help button in the WorkCentre Status

window and then double-click the WorkCentre 450c

Guided Tour.

Document WorkCentre 450c Online Help

Concise explanations and procedures on

WorkCentre tasks and features. To open Help, click

the Help button in the WorkCentre Status window.

Document WorkCentre 450c User Guide

This online guide provides complete instructions on

how to use the WorkCentre, descriptions of

maintenance and troubleshooting tasks, and

reference information.

To obtain a printed version of the guide, use the

order form included with the WorkCentre.

Pagis Pro Multimedia Tutorial

A comprehensive and entertaining summary of the

features and benefits of Pagis Pro 97. To run the

tutorial, insert the WorkCentre 450c CD-ROM,

open the folders (directories):

English\Pagis\Tutorial

Double-click Tutorial.exe. For best results, your PC

should be equipped with a sound card and

multimedia speakers.

http://www.teamxrx.com

Visit the Document WorkCentre 450c Web Site for

product and technical information.

1-800-TEAM XRX

(United States and Canada only)

For technical help, call the Xerox Customer Support

Center.

Introduction to the Document

WorkCentre 450c

The Document WorkCentre 450c features an easy-to-use

control panel that simplifies your routine tasks. With the

press of a few keys, you fax, print, copy, and scan

documents.

Paper tray

Printer output tray

Document tray

Scanner cover

Control panel

Paper tray extension

Document output tray

Using the ControlCentre software, you can efficiently

monitortheWorkCentre’sstatus fromyourPC, changeany

ofthedefault settings, andsetup aPhonebook ofspeeddial

numbers.

WorkCentre features

The WorkCentre 450c’s advanced design lets you easily

access its components. Its compact size allows the

WorkCentre to fit into any office environment.

The control panel includes function keys, a numeric

keypad, document flow icons, and a liquid crystal display

(LCD) that shows menus and system messages.

Control panel keys

Press this ke

To do this

SCAN Automaticallyrun the scanning application on

your PC.

MODE Switch among the print modes: print & fax,

offline, printer only.

FEED Load a single sheet of paper into the printer,

or clear a jammed page from the printer.

CARTRIDGE Switchamong thecartridge maintenance

options: change, clean, replace color head.

COPY Start a copy job.

SIZE Switch among the resize options for copies:

95%, 100% (same size), enlarge 125%,

enlarge 150%, 75%, 80%, 85%, 90%.

JOB STATUS Display the WorkCentre’sactive and pending

jobs.

COVER PAGE Toggle the fax cover page option on and off.

CONFIRM Toggle the fax confirmation report feature on

and off.

CONTRAST Switch among the contrast settings for outgo-

ing faxes and copies: lighten, normal, darken,

photo lighten, photo normal, photo darken.

RESOLUTION Switch among the resolution settings for out-

going faxes: standard, fine, superfine.

LEFT ARROW Display the previousmenu or option,or when

entering text, move the cursor one position to

the left.

RIGHT ARROW Display thenext menu or option, or when

entering text, move the cursor one position to

the right.

Press this ke

To do this

EXIT/CLEAR Display the previous menu. When entering

text, delete the blinking character or, if the

cursor isto the right of the text, delete the last

character.

Clear a document from the scanner.

ENTER Choose a menu and display its submenu or

options, or choose the option or text you

entered.

MENU Display the first top-level menu.

SPEED DIAL Enter a speed dial number from your Phone-

book.

PAUSE Insert a timed interval in the dialing sequence.

REDIAL Redial thelast faxnumber dialed, combine

several numbers during a single dialing

sequence, or add a plus (+) to a speed dial

entry in a Phonebook.

HELP Print theWorkCentre menus and the current

default settings.

STOP Halt a process or exit the menu system.

START Begin the specified job.

Press this ke

To do this

How to navigate the

WorkCentre menus

Using control panel keys and the numeric keypad, you can

easilynavigatetheWorkCentremenus.Asyou navigatethe

menus, the LCD displays the options you can choose and

provides helpful prompts to guide you.

To access the WorkCentre menu system, press the MENU

key. The first top-level menu displays:

Menu (1-6)

1 Fax job

To display the second top-level menu, press the RIGHT

ARROW key or the 2key:

Menu (1-6)

2 Reports

Press the ENTER key to choose the Reports menu and

display the first Reports menu:

Reports (1-2)

1 Print report
