Xantrex MS2000 Manual de usuario

MS2000 Sine Wave Inverter/Charger

Installation Guide

MS2000

MS2000 Sine Wave Inverter/Charger

Installation Guide

About Xantrex

Xantrex Technology Inc. is a world-leading supplier of advanced power electronics and controls with products from

50 watt mobile units to one MW utility-scale systems for wind, solar, batteries, fuel cells, microturbines, and backup

power applications in both grid-connected and stand-alone systems. Xantrex products include inverters, battery

chargers, programmable power supplies, and variable speed drives that convert, supply, control, clean, and distribute

electrical power.

Trademarks

MS2000 Sine Wave Inverter/Charger is a trademark of Xantrex International. Xantrex and Xanbus are registered

trademarks of Xantrex International.

Other trademarks, registered trademarks, and product names are the property of their respective owners and are used

herein for identification purposes only.

Notice of Copyright

Disclaimer

UNLESS SPECIFICALLY AGREED TO IN WRITING, XANTREX TECHNOLOGY INC. (“XANTREX”)

(a) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY

TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION.

(b) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSS OR DAMAGE, WHETHER DIRECT,

INDIRECT, CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE OUT OF THE USE OF SUCH

INFORMATION. THE USE OF ANY SUCH INFORMATION WILL BE ENTIRELY AT THE USER’S RISK.

Date and Revision

August 2004 Rev A

Part Number

975-0126-02-01

Contact nformation

Telephone: 1 800 670 0707 (toll free North America)

1 360 925 5097 (direct)

Fax: 1 800 994 7828 (toll free North America)

1 360 925 5143 (direct)

Email: customerservice@xantrex.com

Web: www.xantrex.com

975-0126-02-01 i

About This Guide

Purpose

The MS2000 Sine Wave Inverter/Charger Installation Guide describes the

procedure for installing the MS2000 Sine Wave Inverter/Charger

(MS2000).

Scope

The Installation Guide provides safety guidelines, detailed planning and

setup information, and procedures for installing the inverter/charger. It

does not provide information on operation, configuration,

troubleshooting, and warranty and product information. Refer to the

MS2000 Sine Wave Inverter/Charger Operation Guide.

This guide does not provide details about particular brands of batteries.

You need to consult individual battery manufacturers for this information.

Audience

The Installation Guide is intended for qualified installers who need to

install the MS2000. Installers should be certified technicians or

electricians.

About This Guide

ii 975-0126-02-01

Conventions Used

The following conventions are used in this guide.

Symbols Used

The following symbols are used on the product labels or in this guide.

Abbreviations and Acronyms

For a listing of abbreviations and acronyms, refer to the MS2000 Sine

Wave Inverter/Charger Operation Guide.

WARNING

Warnings identify conditions or practices that could result in personal injury or

loss of life.

CAUTION

Cautions identify conditions or practices that could result in damage to the unit or

other equipment.

Important:

These notes contain informationthat is importantfor you to know,

but is not as critical as a caution or warning.

In this guide: Important information, warnings or cautions.

On the product: Important information, warnings or cautions

with further explanation in the product guides.



AC –Alternating current

(

DC –Direct current

Warning: Hot surface. Do not touch.



DC ground connection point



AC safety ground connection point from incoming AC source



AC safety ground connection point for AC output (to AC loads)

About This Guide

iii 975-0126-02-01

Related Information

For related materials on this Xanbus-enabled product and its available

accessories, see also:

MS2000 Sine Wave Inverter/Charger Operation Guide (975-0125-02-01)

Automatic Generator Start Owner’s Guide (975-0082-01-01)

System Control Panel Owner’s Guide (975-0083-01-01)

Xanbus System Installation Guide (975-0136-01-01)

More information about Xantrex Technology Inc. as well as its products

and services, including a complete list of Xanbus-enabled devices, is

available at www.xantrex.com

Contact Information

Telephone: 1 800 670 0707 (toll free North America)

1 360 925 5097 (direct)

Fax: 1 800 994 7828 (toll free North America)

1 360 925 5143 (direct)

Email: customerservice@xantrex.com

Web: www.xantrex.com

iv 975-0126-02-01

975-0126-02-01 v

Important Safety Instructions

READ AND SAVE THESE INSTRUCTIONS

The MS2000 Sine Wave Inverter/Charger Installation Guide contains

important safety instructions.

Before you install and use your MS2000 Sine Wave Inverter/Charger, be

sure to read, understand, and save these safety instructions and those in

the other product guides.

Read all cautionary markings on the inverter/charger, the batteries, and all

appropriate sections of this guide.

1. Use of accessories not recommended or sold by Xantrex Technology,

Inc. may result in a risk of fire, electric shock, or injury to persons.

2. The inverter/charger is designed to be permanently connected to your

AC and DC electrical systems. Xantrex recommends that all wiring

be done by a certified technician or electrician to ensure adherence to

the local and national electrical codes applicable in your application.

3. To avoid a risk of fire and electric shock, make sure that the existing

wiring is in good condition and that the wire is not undersized. Do not

operate the inverter/charger with damaged or substandard wiring.

4. To reduce risk of damage and injury, charge only rechargeable

lead-acid batteries: flooded, gel, or absorbed glass mat (AGM) types.

Other types of batteries may burst, causing personal injury and

damage.

5. Do not operate the inverter/charger if it has received a sharp blow,

been dropped, or otherwise damaged in any way. If the unit is

damaged, see the Warranty and Product Information section in the

MS2000 Sine Wave Inverter/Charger Operation Guide.

WARNING: Risk of injury or loss of life

The MS2000 Sine Wave Inverter/Charger shall not be used in connection with

life support systems or other medical equipment or devices.

WARNING

The following warnings identify conditions or practices that could result in

personal injury or loss of life.

Safety

vi 975-0126-02-01

6. Do not disassemble the inverter/charger; it does not contain user-

serviceable parts. Take it to a qualified service personwhen service or

repair is required. Incorrect reassembly may result in a risk of

electrical shock or fire. Internal capacitors remain charged after all

power is disconnected. For instructions on obtaining service, see the

section in the MS2000 Sine Wave Inverter/Charger Operation Guide.

7. Do not expose the inverter/charger to rain, snow, or splashing bilge

water.

8. To reduce the risk of electric shock, disconnect all sources of AC and

DC power from the inverter/charger before attempting any

maintenance or cleaning. Turning off controls will not reduce this

risk.

9. The inverter/charger must be provided with equipment grounding

conductors connected to the AC input ground and chassis ground

terminals.

To reduce the risk of overheating, keep the ventilation openings clear and

do not install the inverter/charger in a compartment with limited airflow

or inadequate clearances around the unit. Refer to “Step 1: Choosing a

Location for the Inverter/Charger”on page 16 for required clearance.

CAUTION

Cautions identify conditions or practices that could result in damage to the unit or

other equipment.
