6. Suggestions and implementing rules
- X-10 is a professional GSM/G S vehicle tracking system working by external
- power supply, and managing I/O wiring signals. Only professional and expert
- personnel is allowed to install this device.
- In order to get the first G S valid fix, it’s necessary to place the device in a
- good place (better if in open sky) avoiding any metal surface obstructing it.
- This device is not water resistant, it comes with internal rechargeable battery
- for backup power supply and it works in temperature environment from -20°
- to 60°. It is strictly recommended to use it in appropriate environment
- conditions.
- lease strictly follow implementing rules and suggestions reported into this
- manual.
- In order to avoid any warranty restriction please don’t not modify and/or
- dismount the device in any way.
- Use of this device is full responsibility of the user. It is necessary to use it
- carefully and in full compliance with the local legislation and laws.
- X-TraX S.r.l. is not responsible for any damage or disservice due to
- inappropriate installation or improper use of the device.
3. Specifications
- Size: 73 x 54 x 22mm. Weight: 80gr (battery included)
- ower source: DC 8-30V
- Operating temperature: from -20°C to 60°C
- Internal rechargeable backup battery: Li- olymer 850mA/h (3,7V) - more
- than 4h of autonomy in “operating mode”
- ower consumption: in “operating mode” (G S, GSM/G RS, RF and G-Sensor
- ON – except backup battery charging) <30mA @ DC 12V; in “sleep mode”
- (G S, GSM/G RS and RF OFF, G-Sensor ON) <3mA @ DC 12V
- GSM/G RS and G S status LED
- Quectel combined G S/EG RS/2G module (also available with EG RS/4G LTE
- – Cat M1/Cat NB2 modem)
- Embedded GSM antenna
- Embedded G S antenna (external G S antenna available as optional)
- Communication channels: SMS and G RS/TC
- Undelivered events buffer capability: up to 7000 logs
- Unit programming by USB, SMS or G RS
- 5 VI SMS numbers
- Voice wiretapping (only available with 2G modem)
- Mileage Counter (managed by G S)
- Advanced real time Tracking setting
- Daily Timer report (up to 3 pre-defined Timers per day)
- Wake-up on movement & Entering sleep mode reports
- Advanced ower Saving Mode setting
- Tow and Speed limit reports (managed by G S)
- Jamming function
- Driver ID management by remote control (up to 250)
- Driver ID management by wired keypad (up to 1500)
- Driver ID management by i-Button (up to 1500)
- Up to 5 physical Inputs: 2 ositives + 3 settable to ositive or to Negative
- IG function for “Engine On” & “Engine Off” detection
- Up to 4 Analog Inputs (0~30V)
- 4 physical Outputs (Negatives 160mA)
- Up to 12 virtual Outputs (for configuration setting purpose only)
- Up to 100 advanced User-defined reports
- Up to 30 circular Geofences
- Auto-target function
- Up to 100 Time schedules
- Service mode (On/Off)
- 3D G-Sensor (adjustable sensitivity by remote)
- 433,92MHz RF module
- Extension I/O box (optional)
- BLE module (optional)
- 1 TTL 3V Serial port (‘K’) + 1 RS-485 Serial port (‘S’)
- Remote Firmware upgrade OTA (by FT )
