VENTILATION SYSTEMS
Behind the sculpted lines of Wolf ventilation units, there’s a lot of hard-nosed functional thinking. Brilliant halogen lighting
illuminates your cooking surface. Powerful multispeed blowers whisk away smoke and odors. Five-layer mesh filters remove easily
for cleaning.
Wall-mount and island hoods are available in Classic Stainless, downdraft units in Classic Stainless, Carbon and Platinum
finishes.*
Professional heritage shines through in Wolf professional-style ventilation.Exteriors are heavy-duty, welded stainless steel, so
finely hand-finished that they appear seamless. Stainless steel baffle filters and halogen lighting extend the professional look and
back it up with pro-level performance.
*Carbon and Platinum finishes not available on 45”downdraft.
All information is subject to change. Refer to www.wolfappliance.com for current information
WALL AND ISLAND HOODS
Classic Stainless finish
Internal, inline, or remote blower options
Front-mounted controls with LED indicators
Heavy-duty, stainless steel welded seams
Three-speed blower control
Filter clean timer
Delay-off feature
Halogen lighting with three settings
Stainless steel filter cover with dishwasher-safe aluminum mesh filter
Heat sentry to automatically turn unit on when heat is sensed
Transition with built-in backdraft damper
DOWNDRAFT VENTILATION
Classic, *Platinum, and *Carbon
Stainless finishes available on top cover and controls
10’wired remote-mounted controls
Internal, inline, or remote blower options
Three-speed blower control
Filter clean timer
Delay-off feature to automatically turn off unit
Stainless steel filter cover with dishwasher-safe aluminum mesh filter
LED indicators
COOKTOP VENTILATION
COOKTOP WALL HOOD DOWNDRAFT
COOKTOP ISLAND HOOD
All information is subject to change. Refer to www.wolfappliance.com for current information
WALL, ISLAND, CHIMNEY AND LINER
Internal, inline, or remote blower options
Heavy-duty, 16-gauge stainless steel with enclosed liner
Continually welded seams with hemmed edges and sides
Recessed easy-access controls
Infinite-speed ventilator control
Heat sentry to turn unit on when unsafe temp is sensed
Easy-to-clean stainless steel baffle filters
Halogen lighting with two settings
Transition with backdraft damper included (not on low
profile hoods)
ACCESSORIES
Platinum or brass decorative rails with standoffs
38”-high stainless steel backsplash (with or without warming
racks)
6,” 12,” 18,” and 24” duct covers
Internal, inline, or remote blower options from 500 to 1,500 cfm
PRO VENTILATION SYSTEMS
PRO 27” DEEP WALL HOOD PRO ISLAND HOOD
PRO WALL CHIMNEY HOOD LINER
All information is subject to change. Refer to www.wolfappliance.com for current information
PRO LOW-PROFILE HOOD
PRO 24” DEEP WALL HOOD
PRO WALL HOODS
Standard features include heat sentry and dual setting halogen lighting. All Wolf Pro Wall Hoods
have the classic stainless steel finish with the option of a decorative rail. While a classic stainless
steel rail is standard on (R) models, platinum or brass rails are available to match the bezels of
our Dual Fuel Ranges and Sealed Burner Rangetops.
PRO ISLAND HOODS
A Wolf Pro Island Hood is the final touch to complete your stage featuring professional cooking
equipment.This premier ventilation system complements your cooking appliance of choice,
guaranteeing you’ll look the part, no matter what new cooking challenges you take on. Wolf Pro
Island Hoods are recommended for use with all Wolf working appliances.
PRO CHIMNEY HOODS
Wolf Pro Wall Chimney Hoods provide the ultimate in ventilation.With standard elements like heat
sentry and dual setting halogen lighting, Wolf elevates the need for ventilation to an enjoyable
perk.
PRO HOOD LINERS
Whether you prefer French country or modernist, the Wolf Pro Hood Liners allow you to
incorporate superior ventilation within your kitchen design.All you have to do is decide what it will
look like. Sometimes referred to as power packs, these liners bring all of the controls, lighting and
convenience of our Pro ventilation line for those applications with a custom exterior treatment.
All information is subject to change. Refer to www.wolfappliance.com for current information
CHOOSING VENTILATION
Dual Fuel Ranges, Sealed Burner Rangetops (SRT), Gas Ranges, Gas Range Top (GRT)
30” and 36” Appliances
BLOWER AND RECOMMENDED MINIMUM CFMs
PRODUCT HOOD RECOMMENDATION Internal In-Line External/Remote
30” Dual Fuel, 30” Gas Range, 30” SRT
30” PRO Low-Profile Wall Hood 500 600 600
36” PRO Low-Profile Wall Hood 500 600 600
30” PRO Deep Wall Hood (24” or 27”) 600 600 600
36” PRO Deep Wall Hood (24” or 27”) 600 1100 900
36” PRO Wall Chimney Hood 600 1100 900
42” PRO Wall Chimney Hood 600 1100 900
34” PRO Hood Liner 1200 1100 900
40” PRO Hood Liner 1200 1100 900
36” PRO Island Hood 1200 1100 900
42” PRO Island Hood 1200 1100 900
36” Dual Fuel, 36” Gas Range, 36” SRT, 36” GRT
36” PRO Low-Profile Wall Hood 500 600 600
42” PRO Low-Profile Wall Hood n/a 600 600
36” PRO Deep Wall Hood (24” or 27”) 600 1100 900
42” PRO Deep Wall Hood (24” or 27”) 600 1100 900
36” PRO Wall Chimney Hood 600 1100 900
42” PRO Wall Chimney Hood 600 1100 900
34” PRO Hood Liner 1200 1100 900
40” PRO Hood Liner 1200 1100 900
36” PRO Island Hood 1200 1100 900
42” PRO Island Hood 1200 1100 900
All information is subject to change. Refer to www.wolfappliance.com for current information
Dual Fuel Ranges, Sealed Burner Rangetops (SRT), Gas Ranges, Gas Rangetops (GRT)
48” and 60” Appliances
BLOWER AND RECOMMENDED MINIMUM CFMs
PRODUCT HOOD RECOMMENDATION Internal In-Line External/Remote
48” Dual Fuel, 48” Gas Range, 48” SRT, 48” GRT
48” PRO Low-Profile Wall Hood n/a 600 600
48” PRO Deep Wall Hood (24” or 27”) 1200 1100 900
54” PRO Deep Wall Hood (24” or 27”) 1200 1100 900
48” PRO Wall Chimney Hood 1200 1100 900
54” PRO Wall Chimney Hood 1200 1100 900
46” PRO Hood Liner 1200 1100 900
52” PRO Hood Liner 1200 1100 900
54” PRO Island Hood 1200 1100 900
60” Dual Fuel, 60” Gas Range
60” PRO Deep Wall Hood (24” or 27”) 1200 1100 1200
66” PRO Deep Wall Hood (24” or 27”) 1200 1100 1200
58” PRO Hood Liner 1200 1100 900
66” PRO Island Hood 1200 1100 1200
All information is subject to change. Refer to www.wolfappliance.com for current information
Cooktops and Integrated Modules
15”, 30” and 36” Appliances
BLOWER AND RECOMMENDED MINIMUM CFMs
PRODUCT HOOD RECOMMENDATION Internal In-Line External/Remote
15” Induction, 15” Electric Cooktop,
15” Gas Cooktop, 15” Integrated Modules
30” Cooktop Wall Hood 450 600 600
36” Cooktop Wall Hood 600 600 600
42” PRO Island Hood 600 600 600
30” Downdraft included 1100 900
36” Downdraft Included 1100 900
45” Downdraft Included 1100 900
30” Induction, 30” Electric Cooktop, 30” Gas Cooktop
30” Cooktop Wall Hood 450 600 600
36” Cooktop Wall Hood 600 600 600
42” PRO Island Hood 600 600 600
30” Downdraft Included 1100 900
36” Downdraft Included 1100 900
45” Downdraft Included 1100 900
36” Induction, 36” Electric Cooktop, 36” Gas Cooktop
36” Cooktop Wall Hood 600 600 600
42” PRO Island Hood 600 600 600
36” Downdraft Included 1100 900
30” Sealed Burner Rangetop,
36” Sealed Burner Rangetop
30” Downdraft Included 1100 900
36” Downdraft Included 1100 900
CHOOSING VENTILATION
All information is subject to change. Refer to www.wolfappliance.com for current information
VENTILATION MODEL NUMBERS
MODEL # BY CFM
HOOD MODEL #
INTERNAL BLOWER IN-LINE BLOWER EXTERNAL/REMOTE BLOWER
500 600 900 1200 600 1100 600 900 1200 1500
PRO LOW-PROFILE WALL HOODS
30” PW302210 810991 808331 801640 801641
36” PW362210 810991 808331 801640 801641
42” PW422210 808331 801640 801641
48” PW482210 808331 801640 801641
PRO 24” DEEP WALL HOODS
30” PW302418 810559 811131 808331 808332 801640 801641 801642 804701
36” PW362418 810559 811131 808332 801641 801642 804701
42” PW422418 810559 811131 808332 801641 801642 804701
48” PW482418 810316 808332 801641 801642 804701
54” PW542418 810316 808332 801641 801642 804701
60” PW602418 810316 808332 801642 804701
66” PW662418 810316 808332 801642 804701
PRO 27” DEEP WALL HOODS
30” PW302718 810559 811131 808331 808332 801640 801641 801642 804701
36” PW362718 810559 811131 808332 801641 801642 804701
42” PW422718 810559 811131 808332 801641 801642 804701
48” PW482718 810316 808332 801641 801642 804701
54” PW542718 810316 808332 801641 801642 804701
60” PW602718 810316 808332 801641 801642 804701
66” PW662718 810316 808332 801641 801642 804701
PRO WALL CHIMNEY HOODS
36” PWC362418 801644 801645 808332 801641 801642 804701
42” PWC422418 801644 801645 808332 801641 801642 804701
48” PWC482418 804703 808332 801641 801642 804701
54” PWC542418 804703 808332 801641 801642 804701
All information is subject to change. Refer to www.wolfappliance.com for current information
VENTILATION MODEL NUMBERS
MODEL # BY CFM
HOOD MODEL #
INTERNAL BLOWER IN-LINE BLOWER EXTERNAL/REMOTE BLOWER
450 600 900 1200 600 1100 600 900 1200 1500
PRO HOOD LINERS
34” PL342212 805087 808332 801641 801642 804701
40” PL402212 805087 808332 801641 801642 804701
46” PL462212 805087 808332 801641 801642 804701
52” PL522212 805087 808332 801641 801642 804701
58” PL582212 805087 808332 801641 801642 804701
COOKTOP HOODS
30” CTWH30 801643 808331 808332 801640 801641 801642 804701
36” CTWH36 801644 804645 808331 808332 801640 801641 801642 804701
42” IH4227 801644 801645 808331 808332 801640 801641 801642 804701
DOWNDRAFTS
30” PW302718 included
36” PW362718 808332 801641 801642 804701
42” PW422718 Included
48” PW482718 808332 801641 801642 804701
54” PW542718 Included
66” PW662718 808332 801641 801642 804701
