Wolf M Series Guía

Design Guide

ICB REVISED 7/2022

Features and speciﬁcations are subject to change at any

time without notice.

Throughout this guide, dimensions may vary by ± 3 mm.

Contents

3M Series Ovens

16 E Series Ovens

24 Convection Steam Ovens

31 Speed Ovens

36 Warming Drawers

41 Induction Cooktops

46 Gas Cooktops

50 Module Cooktops

58 Coee Systems

63 Cup Warming Drawers

67 Vacuum Seal Drawer

71 Dual Fuel Ranges

76 Induction Ranges

80 Sealed Burner Rangetops

84 Outdoor Grills | Modules | Accessories

95 Cooktop Ventilation

102 Downdraft Ventilation

106 Pro Ventilation

110 Ventilation Suggestions

114 Wolf Warranties

Contents

subzero.com | 3

M Series Built-In Ovens

Four striking looks are just the beginning. Superior

performance features include our dual convection fan

system, touch-screen controls, convenient preset cooking

programs, and improved interior lighting. There is more

usable space inside for deliciousness on a grand scale.

M Series Ovens can be installed in a standard or ﬂush inset

application.

M Series Ovens

UPPEROVEN LOWEROVEN

M SERIES OVENS

TRANSITIONAL

ICBSO30PM/S/PH

ICBSO30CM/B

ICBSO30TM/S/TH

ICBDO30PM/S/PH

ICBDO30CM/B

ICBDO30TM/S/TH

PROFESSIONAL

CONTEMPORARY

ICBSO30CM/S

ICBDO30CM/S

4 | English

M Series Built-In Ovens

TRANSITIONAL SINGLE OVEN

TRANSITIONAL DOUBLE OVEN

OPEN OVEN DOOR

584 mm

BEHIND FRAME

723

686

46 mm

543

36 mm

CONDUIT

CHANNEL

218

51 mm

759 mm

724 mm

OPEN OVEN DOOR

584 mm

BEHIND FRAME

1291

1254

46 mm

543

36 mm

CONDUIT

CHANNEL

218

51 mm

759 mm

724 mm

M Series Ovens

subzero.com | 5

M Series Built-In Ovens

PROFESSIONAL SINGLE OVEN

OPEN OVEN DOOR

584 mm

BEHIND FRAME

723

686

46 mm

543

36 mm

CONDUIT

CHANNEL

218

51 mm

759 mm

724 mm

OPEN OVEN DOOR

584 mm

BEHIND FRAME

1291

1254

759 mm

46 mm

543

36 mm

CONDUIT

CHANNEL

218

51 mm

724 mm

PROFESSIONAL DOUBLE OVEN

M Series Ovens

6 | English

OPEN OVEN DOOR

584 mm

BEHIND FRAME

1291

1254

46 mm

543

36 mm

CONDUIT

CHANNEL

218

759 mm

724 mm

OPEN OVEN DOOR

584 mm

BEHIND FRAME

723

686

46 mm

543

36 mm

CONDUIT

CHANNEL

218

759 mm

724 mm

M Series Built-In Ovens

CONTEMPORARY STAINLESS STEEL SINGLE OVEN

CONTEMPORARY STAINLESS STEEL DOUBLE OVEN

M Series Ovens

subzero.com | 7

OPEN OVEN DOOR

584 mm

BEHIND FRAME

1291

1254

46 mm

543

36 mm

CONDUIT

CHANNEL

218

51 mm

759 mm

724 mm

OPEN OVEN DOOR

584 mm

BEHIND FRAME

723

686

46 mm

543

36 mm

CONDUIT

CHANNEL

218

51 mm

759 mm

724 mm

M Series Built-In Ovens

CONTEMPORARY BLACK GLASS SINGLE OVEN

CONTEMPORARY BLACK GLASS DOUBLE OVEN

M Series Ovens

8 | English

Planning Information

The M Series Oven can be installed in a standard or ﬂush

inset application. If a cooktop is installed above an oven, a

minimum of 6 mm is required between the units. Loca-

tion of the electrical supply within the oven opening may

require additional cabinet depth.

Finish the edges of the opening. They may be visible when

the door is open.

For standard installations, the face trim will overlap stiles

and rails. Refer to the chart below.

For ﬂush inset installations, a minimum 3 mm reveal is

required on all sides. To ensure consistent reveals, each

corner of the opening must be exactly 90°.

INSTALLATION REQUIREMENTS

BASE SUPPORT MIN

Single Oven 115 kg

Double Oven 181 kg

TRIM OVERLAP

Top 25 mm

Bottom 0 mm

Sides 18 mm

DUAL INSTALLATION

Two 76 cm single M Series Ovens can be installed side by

side in a standard or ﬂush inset application. A dual instal-

lation kit is required. To maintain appropriate airﬂow, the

ovens must be installed into one opening. Any cosmetic or

structural material placed between the ovens will impede

airﬂow and is not recommended. Refer to the illustrations

on the following pages.

The dual installation kit is available through an authorized

Wolf dealer.

M Series Ovens

subzero.com | 9

M Series Ovens

Planning Information

ELECTRICAL REQUIREMENTS

Installation must comply with all applicable electrical

codes and be properly grounded (earthed).

Locate the electrical supply ﬂush with the back wall and

within the shaded area shown in the illustration for your

speciﬁc installation on the following pages. For ease of

installation, the electrical supply for the oven can be

placed in an adjacent cabinet within reach of the conduit.

Performance may be compromised if the electrical supply

is less than 220 volts.

The oven is supplied with a single phase and 3-phase

convertible power inlet box. The wiring diagram covering

the control circuit is provided with the oven.

ELECTRICAL REQUIREMENTS—SINGLE OVEN

ELECTRICAL SUPPLY

Single Phase 220–240 V AC, 50/60 Hz

3-Phase 380–415 V AC, 50 Hz

MAX CONNECTED LOAD

Single Phase 4.2–4.8 kW

3-Phase 3.0–3.6 kW

ELECTRICAL REQUIREMENTS—DOUBLE OVEN

ELECTRICAL SUPPLY

Single Phase 220–240 V AC, 50/60 Hz

3-Phase 380–415 V AC, 50 Hz

MAX CONNECTED LOAD

Single Phase 8.4–9.6 kW

3-Phase 4.2–4.8 kW

10 | English

M Series Single Oven

STANDARD INSTALLATION

724 mm

OPENING WIDTH

127

102

FRONT VIEW

SIDE VIE

NOTE: Location of electrical supply within opening may require additional cabinet depth.

591 mm

OPENING

DEPTH

TOP VIEW

699 mm

OPENING

HEIGHT

M Series Ovens
