WI-FI 21

User Guide

I

. PRODUCT OVERVIEW

1

. Camera Lens

2

. Micro SD card slot

3

. Reset Button

4

. Power Switch

5

. Mini USB Port

6

. Blue Indicator Light

7

. Red Indicator Light

8

. Battery

I

I. WHAT’S IN THE BOX

-

DC5V 2A Charging Adapter

-

USB Cable

-

Camera

I

II. CHARGING

3

.1. Connect the camera directly to an outlet power socket by using the DC 5V 2A charging adapte

r

a

nd USB cable provided.

3

.2. It will take up to 3 hours to obtain a full charge. The camera is able to record video

s

c

ontinuously for 3.5 hours on a full charge.

[

Note]:

1

). The camera can be charged when it is powered on or off. When the camera is powered off, the indicator light

s

w

ill not glow during the charging process.

2

). If you want the camera to work all the time, please keep it connected to the outlet power socket by using th

e

c

harging adapter and USB cable provided.

I

V. NETWORK SETUP

4

.1. Install the “BVCAM” APP

D

ownload the “BVCAM” APP from App Store or Google Play and install it on your smartphone o

r

t

ablet PC.

(Android) (iOS)

4

.2. P2P or LAN Mode Setup

4

.2.1. Slide the power switch to the position next to the reset button to power on the camera. Th

e

r

ed and blue indicator lights will illuminate for 3 seconds and go out. 15 seconds later, the blu

e

i

ndicator light will stay illuminated and the red one will start blinking, indicating the camera ha

s

e

ntered into P2P mode.

[

Note]:

1

. The camera’s Wi-Fi signal will take 1-2 minutes to appear on your smartphone or tablet PC.

2

. If the camera’s Wi-Fi signal cannot be found on your smartphone or tablet PC, please reset or recharge th

e

c

amera, and then try it again.

Q

: How to reset the camera?

A

: Simply press the Reset Button for 2 seconds to reset the camera. The red and blue indicator lights will go out.

W

ait 15 seconds and the camera will restart automatically.

4

.2.2 Go to Wi-Fi Setting page on your smartphone or tablet PC and connect to the camera’s Wi-F

i

s

ignal. The camera’s Wi-Fi network SSID starts with “KD***********” and will appear on your Wi-F

i

s

etting page as follows:

(Android) (iOS)

4

.2.3. Launch the “BVCAM” APP.

4

.2.4. Add the camera to the “BVCAM” APP.

(

Android): Tap “+” > “Search(Lan)” > the camera icon > “√” or “OK” .

(

iOS): Tap “+” > “Add new online Camera” > “Search(Lan)” > the camera icon > “OK”.

4

.2.5. The camera is added successfully if you see it is “Online”. Tap the camera icon to watch liv

e

v

ideo in the P2P mode.

(Android)

(iOS)

[Note]: See the table below for an explanation of the different functions available:

Button Function Name Function Description

Brightness

T

ap this button to adjust the live video

b

rightness.

Contrast

T

ap this button to adjust the live video contrast

r

atio.

Audio

T

ap this button and the user can listen to the

l

ive audio.

Microphone

T

ap “Microphone” and “Audio” button t

o

r

ecord audio during the remote recordin

g

p

rocess.

Snapshot

T

ap this button to take a screenshot of the live

v

ideo. The pictures will be saved in your

s

martphone or tablet PC.

Remote video

recording

T

ap this button to start or stop recording video.

Horizontal Mirror

T

ap this button to flip the live video image

h

orizontally.

Vertical Mirror

T

ap this button to flip the live video image

v

ertically.

4.3. WAN Mode or Remote View Setup

>> Before the WAN configuration, please confirm that the camera is successfully added to your

smartphone or tablet PC in the P2P mode, and that the P2P connection works well.

4.3.1. Launch the “BVCAM” APP.

4.3.2. In the LAN mode, tap the setting icon > “Advance Config” or “Device Settings” > “WIFI

Config”.

(Android)

(iOS)

4

.3.3. Enroll the camera in a desired Wi-Fi network, then tap “OK” to save the setting.

(Android)

(iOS)

4

.3.4. The camera will reboot automatically.

H

ow to Test the Setting?

1

. Exit the “BVCAM” APP.

2

. Go to Wi-Fi setting page on your smartphone or tablet PC，enroll your smartphone or tablet PC i

n

a

nother Wi-Fi network or cellular which must be different from the current one.

(Android) (iOS)

3

. Launch the “BVCAM” APP again. If you can see the camera is “Online”, it indicates the remot

e

v

iew setup is successful. Tap the camera icon to watch live video remotely.

[

Note]:

1

.If the WAN connection is done, the red indicator light will stay illuminated.

2

. If remote view setup fails, please check your Wi-Fi configuration and bandwidth.
