Wirepath WPS-750-BUL-IPH Manual de usuario
CAMERA
IP BULLET
INSTALLATION MANUAL
Review manual thoroughly before installation.
Retain for future reference.
WPS-750-BUL-IPH
2
WPS-750-BUL-IPH Installation Manual
1. Safety Instructions
1. Read and follow all instructions and warnings in this manual. Keep for future reference.
2. Install according to manufacturer’s instructions.
3. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including ampliers)
that produce heat.
4. Only use attachments/accessories specied by the manufacturer.
5. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any
way, such as when the power-supply cord or plug is damaged, does not operate normally, or has been dropped.
6. THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL REMAIN READILY OPERABLE.
CAUTION
CAUTION: TO REDUCE THE RISK OF
ELECTRICAL SHOCK.
DO NOT REMOVE COVER. NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning ash with arrowhead symbol, within an equilateral triangle,
is intended to alert the user to the presence of uninsulated dangerous
voltage within the product’s enclosure that may be of sufcient magnitude to
constitute a risk of electric shock to persons.
The exclamation point, within an equilateral triangle, is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
When viewing this document electronically, references to other sections are formatted to stand out. Click on a reference to navigate
to the section. Table of Contents entries may also be clicked to link to sections for faster navigation.
Example: (Cross-reference in one section to another part of the manual) For more information see section 2. Introduction.
Example: (Hyperlink to a website, will open in a new browser window) Go to www.SnapAV.com.
3
© 2014 Wirepath Surveillance
WPS-750-BUL-IPH Installation Manual
Table of Contents
1. Safety Instructions 2
2. Introduction 7
2.1. Features 7
3. Package Contents 8
4. Required Items for Installation 8
5. How It Works 9
6. Camera Connections 10
6.1. Network Cable Recommendation (PoE and non-PoE) 11
6.2. Choosing the Right Network Equipment 11
6.3. PoE Requirements- IEEE 802.3af 11
7. Camera Installation Instructions 12
7.1. Wiring Installation 12
7.2. Prepare for Installation 12
7.3. Mount the Camera 12
7.3.1. Using Mounting Accessories 12
7.3.2. Surface Mounting 12
7.4. Connecting the Test Adapter 12
7.5. Aiming the Camera 12
7.6. Focus, Zoom, and Position 13
7.7. Closing the Camera 13
7.8. Network Software Setup - IP Installer 14
7.8.1. Running the IP Installer 14
7.9. IP Installer-Conguring Camera IP Settings 15
7.10. Verify Access through the Main Camera Interface 15
8. IP Camera Web Interface - Setup and Use 16
8.1. First Time Access Instructions 16
8.1.1. Recommendations for Best Web Viewing Performance 16
8.2. Camera Web Browser Interface 17
8.2.1. Web Interface Layout - Top Bar 17
8.2.2. Web Interface Layout - Bottom Bar 18
4
WPS-750-BUL-IPH Installation Manual
9. Camera Conguration Menu Setup 19
9.1. Conguration Menu - Access and Navigation 19
9.1.1. Accessing the Menu 19
9.1.2. Conguration Menu Layout 19
9.1.3. Conguration Menu Guidelines 19
9.2. System Information and Settings 20
9.2.1. System Information Menu Settings 20
9.2.1.1. Server Information 20
9.2.1.2. OSD Setting 20
9.2.1.3. Time Setting 21
9.2.1.4. Network LED 21
9.2.2. Camera Time Setup 22
9.2.2.1. NTP Time 22
9.2.2.2. Synchronize with PC’s Time 22
9.2.2.3. Manual 22
9.2.2.4. Internal Clock 22
9.2.2.5. NTP Setup Instructions (For Cameras with Internet Access) 23
9.2.2.6. Time Setup for Cameras without Internet Access 23
9.2.3. User Management 24
9.2.3.1. Anonymous User Login 24
9.2.3.2. Add User (Guest Account only) 24
9.2.3.3. User List 24
9.2.3.4. User Account Levels 24
9.2.3.5. Administrator Account Setup 25
9.2.3.6. Add, Edit, or Remove a Guest Account 25
9.2.4. System Update 26
9.2.4.1. Firmware Upgrade 26
9.2.4.2. Reboot System 26
9.2.4.3. Setting Management 26
9.2.4.4. How to Back up Camera Settings 27
9.2.4.5. Load Backup Settings to the Camera 27
9.2.4.6. Upgrade the Firmware 28
9.3. Network IP Settings 29
9.3.1. Basic IP Settings 29
9.3.1.1. IP Assignment 29
9.3.1.2. Port Assignment 30
9.3.1.3. UPnP 30
9.3.1.4. RTSP Setting 31
9.3.1.5. Multicast Setting (Based on RTSP Server) 31
9.3.1.6. ONVIF 32
9.3.1.7. Bonjour 32
9.3.1.8. Link Layer Topological Discovery (LLTD) 32
9.3.2. Advanced IP Settings - HTTPS Access Setup 33
9.3.2.1. Created Request 33
9.3.2.2. Installed Certicate 33
5
© 2014 Wirepath Surveillance
WPS-750-BUL-IPH Installation Manual
9.3.2.3. Connection Types 33
9.3.3. Advanced IP Settings - SNMP 34
9.3.4. Advanced IP Settings - Access List (IP Filter) 35
9.3.4.1. IP Address Filter Setting 35
9.3.4.2. Add or Remove IP Addresses or Ranges 36
9.3.4.3. Controlling Administrator Access 36
9.3.5. Advanced IP Settings - QoS/DSCP 37
9.3.5.1. QoS / DSCP Setting 37
9.3.6. PPPoE Setup 38
9.3.6.1. PPPoE Overview 38
9.3.6.2. PPPoE Settings 38
9.3.6.3. Send Mail after PPoE Dialed 38
9.3.7. DDNS Setup 39
9.3.7.1. DDNS Overview 39
9.3.7.2. DDNS Settings 39
9.3.7.3. State (DDNS) 39
9.3.7.4. Setting Up a DDNS Address – WirepathDNS 40
9.3.8. Server Settings 41
9.3.8.1. Email Notications 41
9.3.8.2. Mail Settings 41
9.3.8.3. FTP Settings 42
9.3.8.4. Network Share Settings 43
9.4. Camera A/V Settings 44
9.4.1. Image Settings Menu 44
9.4.1.1. Tips for Getting the Best Camera Image 45
9.4.2. How to Congure Day & Night Settings (Color Modes) 46
9.4.2.1. Day & Night Modes 46
9.4.2.2. Day & Night Modes 47
9.4.2.3. Light Sensor Mode (Default Mode) 47
9.4.2.4. Day & Night Times Mode 47
9.4.2.5. How to Congure Privacy Masks 48
9.4.3. Video Settings Menu Overview 49
9.4.3.1. Video Setting (For BNC Test Adapter Output) 49
9.4.3.2. Streaming 1 and 2 Setting 49
9.4.3.3. Streaming 3 (JPG/MJPEG) 49
9.4.3.4. Streaming 4 (3GPP) 49
9.4.4. Video Streaming 1 and 2 Setup 50
9.4.5. Streaming 3 and 4 Setup 52
9.4.5.1. Streaming 3 52
9.4.5.2. Streaming 4 52
9.4.6. Audio Settings 53
9.4.7. Camera Audio Technology Overview 54
9.5. Event Record Setup and Scheduling 55
9.5.1. Event Settings Menu 55
9.5.1.1. Record File 56
6
WPS-750-BUL-IPH Installation Manual
9.5.1.2. Record Time Setting 56
9.5.1.3. Network Disconnected 56
9.5.1.4. Network IP Check 56
9.5.2. Conguring Motion Detection Areas 57
9.5.2.1. Motion Detection Settings Overview 57
9.5.2.2. Adding a New Motion Detection Area 58
9.5.2.3. Removing a Motion Detection Area 58
9.5.3. Schedule Menu 59
9.5.3.1. Snapshot Menu 59
9.5.3.2. How to Set Up Scheduling for Events 60
9.5.3.3. Set up Snapshot 60
9.5.4. I/O Settings 61
9.5.4.1. Input Settings 61
9.5.4.2. Output Settings 61
9.6. Log List 62
9.6.4.1. Motion Detection Log 62
9.6.4.2. All Logs 62
9.7. SD Card Menu 63
9.7.1. Playback 63
9.7.2. SD Management 63
10.Internal Heater Overview 64
10.1. Safe Operating Range 64
11. Reset Procedure 65
12. Mobile App Access 65
13. Specications 66
14.Dimensions 68
15.Warranty 69
16.Contacting Technical Support 69
7
© 2014 Wirepath Surveillance
WPS-750-BUL-IPH Installation Manual
2. Introduction
Thank you for purchasing a Wirepath™ IP Surveillance camera. The WPS-750-BUL-IPH is an indoor/outdoor camera designed for
mounting to any wall, ceiling or surface, for easy monitoring over a web or smartphone interface.
We recommend that this document be read in its entirety before proceeding with system design, installation, or operation of the
camera.
2.1. Features
• 1/2.7" 2MP CMOS Sensor
Advanced CMOS sensor provides improved picture quality over a typical CCD sensor. Supports full Full 1080p HD
(1920x1080) at 30FPS.
• Varifocal Lens
This camera features a varifocal lens with a focal length of 2.8-12 mm.
• H.264/ MJPEG Quadruple Stream Optimization
Supports up to 4 simultaneous streams of compression typically used for the following situations:
• High Res stream optimized for NVR Record or Local Network viewing
• Lower Res stream optimized for Remote viewing
• Lower Res stream optimized for Control Systems (same res as Stream 2)
• Low Res stream for Mobile Viewing
• Low Temperature Operation
A heater is included that automatically turns on and off to ensure the camera operates within an optimum temperature range,
and helps to minimize condensation inside the housing at low temperatures. The heater activates automatically at 50°F and
deactivates at 60°F.
• IR up to 65 ft
• True Day/Night (IR Cut Filter)
For more accurate, vivid color reproduction during daytime use, an IR Cut lter is automatically moved over the lens to block
unwanted IR. At night, the lter is removed to deliver maximum visibility and clear IR illumination.
• Advanced Image Processing
Advanced DSP (Digital Signal Processor) to improve image quality including:
• Sense Up: Automatically slows the shutter speed to improve image quality in low light.
• D-WDR (Digital Wide Dynamic Range): Provides clearer images and even lighting in applications that are
simultaneously bright and dark. This is particularly useful in areas with windows and lots of natural light.
• 2D and 3D Digital Noise Reduction (DNR): Intelligently scans the image and reduces noise in low-lux conditions for a
cleaner, crisper image.
• Privacy Mask
Block out sensitive or privileged areas by placing rectangular blocks or “masks” over up to three installer-dened areas.
• Power Over Ethernet (PoE IEEE 802.3af)
Camera can be powered by PoE using the same Cat5e/Cat6 cable that connects to the network. No need to pull a 2nd power
cable to the location. Compatible with all PoE network switches that support PoE IEEE 802.3af and PoE power injectors.
• Edge Storage
The camera supports microSD cards (up to 32GB, card NOT included). Images, short recordings and logs can be stored on a
microSD installed into the camera. This is useful as a backup if the network connection to the NVR is lost.
• Test Port for Quick Setup during Install
• Analog Video Out
• Local 12V DC Power for Camera
• IP-66 Weatherproof Rating
With an IP-66 rating, this camera is protected from dust and water, making it effective for indoor and outdoor installations.
• ONVIF
8
WPS-750-BUL-IPH Installation Manual
3. Package Contents
NOTE: A POWER SUPPLY IS NOT INCLUDED WITH THIS CAMERA. The PS-12DC-1A, WPS-PS multiple output power supply
or a Power over Ethernet (PoE) switch is recommended.
4. Required Items for Installation
The following items are required during the installation of a Wirepath™ IP camera. Prepare all parts and tools in advance to ensure
that the installation can be performed smoothly.
• Local Ethernet network installed
• All cameras to be installed in the system
• PoE Ethernet equipment or power supplies and wiring to power cameras
• Network connection at each camera location
• Access to a PC connected to the local network
• Static IP address to assign to the camera
• Additional access information for network equipment:
• Router / Switch Details – Contact the network admin to obtain access to equipment settings
• Admin Rights – Required to setup the network and port forwarding for remote access
• Default Gateway
• Subnet Mask
• DNS Address
• Recommended for mounting cameras and wiring:
• Hand tools
• Drill (may be needed for mounting the camera)
• Extra connectors for terminating cables on the job
• (1) WPS-750-BUL-IPH Camera
• (1) WPS-ACC-PWR Power Adapter
• (1) BNC Test Adapter
• (1) Female to Female RJ45 Adapter
• (1) 3mm Allen Key
• (4) Screws
• (4) Wall Fasteners
• (1) Spare Silica Pack
• (1) Quick Start Guide
9
© 2014 Wirepath Surveillance
WPS-750-BUL-IPH Installation Manual
How Does IP Video Surveillance Work?
Wirepath™ IP cameras use a digital image processor to capture video in a stream of packets that are broadcast using a standard
Ethernet network. These packets can be received by several devices at once, including local PCs, mobile devices, and recorders
(NVRs) on the same network, or even off the network (with the correct setup and web access).
Users can see the camera feed through the interface of their choice, or see recorded footage from a storage device like an NVR.
Wirepath Surveillance offers apps for iOS® devices, Android® smartphones, Windows PC, and Mac computers. Drivers for various
popular control systems are also available for integration with a control system.
Access and Use
For local network (LAN) access, a static IP address is assigned to the camera in the network router. The user enters this address
into a PC, smartphone, or other device connected to the LAN, and logs in using a customizable username and password.
For access outside the LAN, a port is forwarded to the camera in the network router settings and a DDNS address is set up in the
camera. This enables the same streams from the camera to be broadcast anywhere in the world over an Internet connection.
In systems where the camera stream must be recorded, a network video recorder (NVR) is connected to the LAN. The address and
login credentials for the camera are entered and the stream can be captured as needed for later viewing.
5. How It Works
Streaming audio/
video
Access from IP
interface
Power from PoE or
power supply
WPS-IP Mobile App
Streaming
Browser Interface
Streaming & setup
Browser Interface
Streaming, Setup
Video streams to
NVR for recording
Port Forwarding and DDNS allows camera to be
accessed from the Internet
Gigabit router and switch
Wirepath™ NVR
LAN-Based Computer
Smartphone/Tablet Web-Based Computer
IP Camera
10
WPS-750-BUL-IPH Installation Manual
6. Camera Connections
Wirepath™ Surveillance IP Cameras can be powered by Power over Ethernet (PoE) through the Cat5e/Cat6 Ethernet connection.
This method is recommended because it limits the amount of wiring required, reducing installation cost and time. The camera must
be connected to a compatible PoE-equipped router/switch or a PoE injector for this method to work.
2. 12V DC In
(Black)
3. Audio In
(Pink)
4. Audio Out
(Green)
5. Contact
& Relay
1. Ethernet
7. Ethernet Connection (RJ45)
Connect to network switch for communication to and from the camera. Pin out follows EIA standard 568-B.
8. 12V DC Power In (Barrel Connector)
Connect to a 12V DC power supply. The camera is not supplied with a power supply. No power supply is needed if PoE is
being used to power the camera via the Ethernet connection.
Warning! Use only a 12V DC power supply with this camera. Higher voltages or AC current will cause permanent damage
that is not covered by the warranty.
9. Audio In (1/8" / 3.5mm Stereo)
Connect a microphone to receive audio at the cameras location.
10. Audio Out (1/8" / 3.5mm Stereo)
Connect to an amplier and speakers to allow for communication between the viewer and the cameras location.
11. Contact & Relay (Spring Loaded Terminal)
Connect to devices with contact closure output to trigger recording, or activate devices like lights or sirens at the camera
location.
Tabla de contenidos
Otros manuales de Cámara de seguridad de Wirepath
Wirepath
Wirepath WPS-365-DOM-A Manual de usuario
Wirepath
Wirepath WPS-300-CUB-IP-WH Manual de usuario
Wirepath
Wirepath WPS-750-DOM-IP Manual de usuario
Wirepath
Wirepath WPS-350-DOM-A-WH Manual de usuario
Wirepath
Wirepath WPS-100-BUL-A-SL Manual de usuario
Wirepath
Wirepath WPS-500-BUL-A-WH Manual de usuario
Wirepath
Wirepath Surveillance WPS-550-BUL-IP Manual de usuario
Wirepath
Wirepath WPS-100-DOM-A-WH Manual de usuario
Wirepath
Wirepath WPS-700-DOM-A-WH Manual de usuario
Wirepath
Wirepath WPS-565-BUL-A Manual de usuario
