Winix ZERO+ WiFi Manual de usuario

User Manual

Model

Use & Care

Guide

ˍPlease read and follow all safety rules and instructions

in this manual before operating.

ˍThe product warranty is printed on the back of this

guide, so please keep it in a safe place for future use.

WINIX AIR PURIFIER

ZERO+ WiFi (AZPU373-HWE)



ZERO+ WiFiEnglish

CONTENTS

5-STAGE AIR PURIFICATION3

CONTROLS4

WHERE TO USE5

INSTALLING THE FILTERS6

SAFETY AND CAUTIONS8

INITIAL OPERATION9

AUTO AND SLEEP10

MANUAL MODE, TIMER AND PLASMAWAVE

11

CHILD LOCK, AIR QUALITY LED12

WINIX SMART13

FILTER CARE15

PARTICLE SENSOR CARE19

CLEANING CARE20

FREQUENTLY ASKED QUESTIONS21

UNIT SPECIFICATIONS23

PRODUCT WARRANTY 24

▶This product is suitable for 220 ~ 240V only.

French 26

Spanish 51

German 76

Italian 101

Dutch 126

Polish 151



English ZERO+ WiFi

5-STAGE AIR PURIFICATION

PlasmaWave

True HEPA lter

(CD) Coated

Deodorization

Carbon lter

Pre-lter

non-removable

replaceable

washable

replaceable

Cleancel™

(Anti-microbial coated)

Product User Manual

•

WINIX AIR PURIFIER

ZERO+ WiFi (AZPU373-HWE)

UserManual

Model

Use&Care

Guide

Pleaseread and follow all safety rules and instructions

inthis manual before operating.

Theproduct warranty is printed on the back of this

guide,so please keep it in a safe place for future use.

Pre-lter/CD Carbon Filter/

True HEPA lter with Cleancel™

(Included with the product.)

Power cord with

plug



English ZERO+ WiFi

CONTROLS

Air Outlet Vent

Light Sensor

Detects the amount of

ambient light within

the environment, to

adjust the brightness

of the LED indicators.

Mode / Fan Speed Button

Every time the Mode button is

pressed, the Mode LED light will

cycle through the settings. (Auto,

Sleep, Low, Medium, High, Turbo)

Child Lock Indicator

LED light indicates

whether Child Lock mode

is enabled or disabled.

Timer Indicator

If timer has been set,

the LED light Indicates

the set time of operation.

PlasmaWave Indicator

Indicates whether

PlasmaWave is

enabled or disabled.

Timer / Air Quality Button

Press to cycle through and set

desired length of operation (1hr,

4hr, 8hr, [NO TIMER]).

Press and hold for 3 seconds to

enable or disable the Air Quality

light.

Smart Sensor

Automatically

detects indoor air

quality.

Wi-Fi Button

Enables or disables

Wi-Fi function.

Reset Button

After replacing a lter,

press the RESET button

for at least 5 seconds.

Power Button

Turns the unit on

or o.

Check Filter

Indicator

LED light indicates

when it is time to

change the lter.

PlasmaWave /

Child Lock Button

Enables or disables

PlasmaWave .

Press and hold for

3 seconds to enable

or disable the Child

Lock mode.



English ZERO+ WiFi

WHERE TO USE

Allow 30 ~ 46 cm. of space between TVs, radios, and other electronic products

electromagnetic interference from certain electronics may cause product malfunction.

Place indoors away from direct sun light

direct exposure may cause product malfunction or failure.

Only place on hard, flat surfaces

flimsy or slanted surfaces may result in abnormal noise and vibrations.

30~46 cm

WARNING Follow these instructions to reduce the risk of serious injury

or death and to reduce risk of damaging the unit.

Do not use around mist or fumes from

industrial oil or around large quantities of

metallic dust.

Do not place around heating elements.

Do not install in any sort of motor or

transport vehicle (trucks, boats, ships,

etc.).

Do not place in an area with excessive

amounts of noxious gases.

Do not place near any flammable

materials (aerosols, fuel, gases etc.). Do not have unit facing into wind or draft.

Do not place below any electrical outlet. Do not place in excessively humid areas

where unit may become wet.

※This unit is not intended to be used to preserve documents or in art conservation.



English ZERO+ WiFi

This product comes with all of the required filters. The protective plastic wrap must be

removed from the filters before use.

※Operating the unit without removing the plastic wrap may result in product failure.

※Unplug and make sure the unit is turned off before installing filters.

※The unit will automatically power off when front panel is opened.

① Remove the front panel by grasping its

upper edge and gently pulling towards

yourself.

ˍTo remove the front panel, the latch at

the lower edge of the panel must be

released from its position.

Latch

② Remove the filters from the unit, they are

protected inside a plastic wrap.

③ Remove filters from protective plastic wrap.

ˍOperating the unit without removing

filters from plastic may cause abnormal

noise, deformation, or fire as a result of

overheating.

Note

ˍRefer to pages 15 - 18for detailed information on filter care

and how to replace them.

INSTALLING THE FILTERS



English ZERO+ WiFi

INSTALLING THE FILTERS

④ Install the filters until they fit securely in

place.

Filters must be installed in this order:

3 True HEPA filter with Cleancel™ (rear)

2 CD Carbon filter (middle)

1 Pre-filter (front)

ˍTo install the pre-filter, insert bottom tabs

into the slots on either side of the lower part

of the unit, then rotate upward to insert the

upper tabs into the slots at the top part of

the unit until both sides audibly click into

place.

Pre-lter

CD Carbon

lter

True HEPA

lter with

Cleancel™

⑤ Replace the front panel by first inserting

the latch at the bottom edge into the

base of the unit, then rotate the panel

upward toward the top of the unit until it

magnetically snaps closed.

⑥ When to service and replace filters:

Filter Indicator Light When to

service

When to

replace

1 Pre-filter none Clean once every

14days Permanent

2 CD Carbon filter

Can NOT be

WASHED

Lasts up to

6 ~12 months

3 True HEPA filter

with Cleancel™

※Intervals between filter replacement may vary depending on environment.

※For optimal use, Pre-filter can be cleaned every 14days which can extend the life of

other filters.

this unit

is compatible

with this

ﬁlter

FILTER

ITEM: 117130



English ZERO+ WiFi

SAFETY AND CAUTIONS

Before operating this equipment, carefully read and follow these safety cautions and

instructions to avoid damage and ensure safe use.

Ensure filters are inserted before running unit

running unit without filters can shorten the units life and cause electric shock or injury.

Be sure foreign objects are NOT inserted into the vents on the unit

objects can include pins, rods, and coins.

Do not touch any part of the interior of the unit with wet hands

the high voltage may cause electric shock.

Ensure unit intake and outlet vents do not become blocked

blockage may lead to increased internal temperatures causing product failure and

deformation.

Do not use the unit as a step stool or place heavy objects on it

personal injury may occur or product failure and deformation.

WARNING Follow these instructions to reduce the risk of serious

injury or death and to reduce risk of damaging the unit.

Do not pull on the power cord when

unplugging the unit.

Do not tie or knot power cord when unit

is in operation.

If the unit becomes submerged in water,

unplug it and contact customer service.

Do not unplug or move the unit while in

operation.

Do not plug additional appliances into

the same outlet or power supply. Do not touch the plug with wet hands.

Unplug unit when not in operation for

extended periods of time.

Cord can become damaged by forcefully

bending, pulling, twisting, bundling,

pinching or placing heavy objects on it.

※If the supply cord is damaged, it must be replaced by a special cord or assembly

available from the manufacturer or its service agent.

※This appliance is not intended for use by a person (including children) with reduced

physical sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliance by a

person responsible for their safety.

※Children should be supervised to ensure that they do not play with the appliance.



English ZERO+ WiFi

INITIAL OPERATION

① Insert the unit plug into an electrical outlet.

ˍThe Control Panel lights will turn on and

off.

② Press the‘Power’button.

Note

ˍDuring the first 4minutes of power up, the Air Quality light

will flash as the Smart Sensors measure the air quality in the

environment, after which normal operation will begin.

③ By default, when the unit first powers on, the

mode will be set to Auto with PlasmaWave

enabled.

ˍWhen in Auto Mode the fan speed will

be automatically adjusted according to

the environments air quality.

ˍPlasmaWave

works to remove harmful

airborne contaminants.

Note

ˍIn Auto mode, as the indoor air quality improves, the fan

speed will automatically be reduced to Low.

ˍWhen the unit is running, you may hear a chirping or buzzing

sound. The sound is from large particles passing through

PlasmaWave

, it is normal and does not signify product

failure. To disable PlasmaWave

, see page 11.



English ZERO+ WiFi

AUTO AND SLEEP

Every time the Mode button is pressed, the Mode LED light will cycle through the

settings. (Auto, Sleep, Low, Medium, High, Turbo)

1. Auto Mode

Enables Auto operation based on the unit's air quality Smart Sensors.

① Press the Mode button to select Auto mode.

ˍThe mode LED light will indicate when

‘Auto’mode has been selected, and

operation will begin.

ˍEach time the Mode button is pressed,

the modes will be cycled. (Auto, Sleep,

Low, Medium, High, Turbo).

Note

ˍWhen in Auto Mode the fan speed is automatically adjusted

according to the indoor air quality. As the indoor air quality

improves, the fan speed will automatically be reduced. If the

indoor air quality decreases the fan speed will automatically

be increased.

ˍWhen unit is first started, Auto Mode is enabled and set to

Low fan speed.

2. Sleep Mode

① Press the Mode button to select Sleep mode.

ˍThe mode LED light will indicate when

‘Sleep’ mode has been selected, and

operation in that mode will begin.

Note

ˍWhen Sleep mode is selected, the fan speed is automatically

set to Low. Fan speed can be changed by pressing the Fan

Speed (Mode) Button.

ˍWhen Sleep Mode is enabled, the Air Quality light is disabled.

Otros manuales para ZERO+ WiFi

Tabla de contenidos

Otros manuales de Purificador de aire de Winix

Winix

Winix D480 Manual de usuario

Winix

Winix AGN335 Series Manual de usuario

Winix

Winix AW107 Manual de usuario

Winix

Winix Zero AUS-1050AZBU Manual de usuario

Winix

Winix Zero S Hoja de especificaciones

Winix

Winix NK300 Manual de usuario

Winix

Winix FreshHome PlasmaWave WACP150 Manual de usuario

Winix

Winix 5300-2 Manual de usuario

Winix

Winix ZERO Pro Manual de usuario

Winix

Winix NK105 Manual de usuario

Winix

Winix NK300 Manual de usuario

Winix

Winix ZERO Pro Manual de usuario

Winix

Winix HEPA 5500 Manual de usuario

Winix

Winix ZERO AZBU330-HWE Manual de usuario

Winix

Winix HR1000 Manual de usuario

Winix

Winix 2020EU Manual de usuario

Winix

Winix ZERO Pro Manual de usuario

Winix

Winix PlasmaWave WAC-5000 Manual de usuario

Winix

Winix PlasmaWave WAC-9000 Manual de usuario

Winix

Winix T1 Manual de usuario

Winix

Winix AAPU500-JLE Manual de usuario

Winix

Winix 9800 Manual de usuario

Winix

Winix ZERO Manual de usuario

Winix

Winix C535 Manual de usuario

Manuales populares de Purificador de aire de otras marcas

IKEA

IKEA UPPÅTVIND Manual de usuario

Nash

Nash AP-1 PureSmart Manual de usuario

LG PH-U450 Series Manual de usuario

DeLonghi

DeLonghi DDSX 220WFA Manual de usuario

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Manual de usuario

Sharp

Sharp FU-40SE Manual de usuario

Philips

Philips AC2721 Manual de usuario

Hitachi

Hitachi EP-A3000 Manual de usuario

TruSens

TruSens Z-2000 Manual de usuario

Motorola

Motorola MBP87SN Manual de usuario

Beko

Beko ATP 7100I Manual de usuario

Carrier

Carrier INFINITY 1620 Manual de usuario

AtmosAir

AtmosAir P2002 Manual de usuario

Friedrich

Friedrich C-90A Instrucciones de funcionamiento e instalación

Surgically Clean Air

Surgically Clean Air JADE2.0 Manual de usuario

Base aire

Base aire 555 Pro Manual de usuario

Champion

Champion CP25 Manual de usuario

vollara

vollara Air & Surface Pro+ Manual de usuario
