Winix AM90 Manual de usuario
•Please read and follow all safety rules and instructions
in this manual before operating.
•The product warranty is printed on the back of this
guide, so please keep it in a safe place for future use.
•This product is manufactured for use only in USA/CA.
WINIX AIR PURIFIER
AM90
User Manual
Model
Use & Care
Guide
AM90English
CONTENTS
This product is suitable for 120V only.
3-STAGE AIR PURIFICATION3
CONTROLS4
WHERE TO USE5
INSTALLING FILTERS6
SAFETY AND CAUTIONS8
INITIAL OPERATION9
AUTO & SLEEP10
MANUAL & PLASMAWAVE
®
11
AIR QUALITY INDICATOR12
FILTER CARE13
CLEANING CARE17
FREQUENTLY ASKED QUESTIONS18
UNIT SPECIFICATIONS20
SAFETY INSTRUCTIONS21
PRODUCT WARRANTY22
English AM90
3-STAGE AIR PURIFICATION
Power cord with plug
Front panel
(This product is suitable
for 120V only.)
PlasmaWave
®
Light sensor
Odor sensor
Odor Absorbing
Carbon Filter
Control Panel
/ Display Panel
Pre-lter
True HEPA lter
1
2
3
User Manual
ㆍ
ㆍ
ㆍ
Pleaseread and follow all safety rules and instructions
inthis manual before operating.
Theproduct warranty is printed on the back of this
guide,so please keep it in a safe place for future use.
Thisproduct is manufactured for use only in USA/CA
WINIX AIR PURIFIER
AM90
UserManual
Model
Use&Care
Guide
Unit Pre-lter/(4) Odor
Absorbing Carbon Filters/
(1) True HEPA Filter
English AM90
CONTROLS
Air
Outlet
Vent
Light Sensor
Detects the
amount of
ambient light
within the
environment,
to adjust the
brightness
of the LED
indicators.
PlasmaWave®
Indicator
Indicates whether
PlasmaWave®
in enabled
or disabled.
PlasmaWave®
Button
Enable or disable
PlasmaWave®.
Power Button
Turns the unit on
or o.
Fan Speed Button
(UP/DOWN)
Enables Manual operation
of the unit. Press to cycle
through and set the desired
fan speed (Auto, Low,
Medium, High, Turbo).
Change Filter Indicator
LED light indicates when it is
time to change the lter.
Wi Button
Enable or disable
the Wi feature.
Sleep Indicator
LED light indicates when
sleep mode is active or disabled.
Fan Speed Indicator
Indicates the current fan speed.
Reset Button
After replacing the lter,
press the RESET button for at
least 5 seconds.
Odor Sensor
When in Auto
Mode, detects the
amount of odor in
the environment
to adjust fan speeds.
Air Quality Indicator
Color-coded LED indicates
one of three levels of air quality.
Wi Indicator
Indicates when
Winix Smart feature is
Enabled or disabled.
English AM90
WHERE TO USE
Allow 12 ~ 18 in. of space between TVs, radios, and other electronic products
electromagnetic interference from certain electronics may cause product malfunction.
Place indoors away from direct sun light
direct exposure may cause product malfunction or failure.
Only place on hard, flat surfaces
flimsy or slanted surfaces may result in abnormal noise and vibrations.
12~18 in 4 in
WARNING Follow these instructions to reduce the risk of serious injury
or death and to reduce risk of damaging the unit.
Do not use around mist or fumes from
industrial oil or around large quantities of
metallic dust
Do not place around heating elements
Do not install in any sort of motor or
transport vehicle (trucks, boats, ships, etc.)
Do not place in an area with excessive
amounts of noxious gases
Do not place near any flammable
materials (aerosols, fuel, gases etc.) Do not have unit facing into wind or draft
Do not place below any electrical outlet Do not place in excessively humid areas
where unit may become wet
This unit is not intended to be used to preserve documents or in art conservation.
English AM90
This product comes with all the required filters. The protective plastic wrap must be
removed from the filters before use.
Operating the unit without removing the plastic wrap may result in product failure.
Unplug and make sure the unit is turned off before installing filters.
•To remove the front panel release the
latch at the lower edge of the panel.
Latch
Press the Pre-filter tabs near the top of the
filter, release and remove.
Remove filters from protective plastic wrap.
•Operating the unit without removing
filters from plastic wrap may cause
abnormal noise, deformation, or fire as a
result of overheating.
INSTALLING FILTERS
NOTE •Refer to pages 13 - 15 for details on how to replace filters.
English AM90
INSTALLING FILTERS
Install the filters until they fit securely in
place.
Filters must be installed in this order:
3 True HEPA filter (rear)
2 Carbon filter (middle)
1 Pre-filter (front)
•To install the Pre-filter, insert bottom tabs
into the slots on either side of the lower part
of the unit, then rotate upward to insert the
upper tabs into the slots at the top part of
the unit until sides audibly click into place.
Pre-lter
Carbon
Filter
True HEPA
Filter
Replace the front panel by first inserting
the latch at the bottom edge into the base
of the unit, then rotate the panel upward
toward the top of the unit until the magnets
pull the lid closed.
Latch
When to service and replace filters:
Filter Indicator Light When to
service When to replace
1 Pre-filter none Clean once every
14days Permanent
2 Carbon filter none
Can NOT be
WASHED
Replace every
3 months
3 True HEPA filter Lasts up to
12 months
Intervals between filter replacement may vary depending on environment.
For optimal use, Pre-filter can be cleaned once every 14 days which can extend the
life of other filters.
To purchase replacement
Winix filters:
(877)-699-4649
www.winixamerica.com
This unit
is compatible
with this
filter
ITEM: 115115
FILTER
A
English AM90
SAFETY AND CAUTIONS
Before operating this equipment, carefully read and follow these safety cautions
Ensure filters are inserted before running unit
running unit without filters can shorten the units life and cause electric shock or injury.
Be sure foreign objects are NOT inserted into the vents on the unit
objects can include pins, rods, and coins.
Do not touch any part of the interior of the unit with wet hands
the high voltage may cause electric shock.
Ensure unit intake and outlet vents do not become blocked
blockage may lead to increased internal termperatures causing product failure and derformation.
Do not use the unit as a step stool or place heavy objects on it
personal injury may occur or product failure and deformation.
WARNING Follow these instructions to reduce the risk of serious
injury or death and to reduce risk of damaging the unit.
Do not pull on the power cord when
unplugging the unit
Do not tie or knot power cord when unit
is in operation
If the unit becomes submerged in water,
unplug it and contact customer service
Do not unplug or move the unit while in
operation
Do not plug additional appliances into
the same outlet or power supply Do not touch the plug with wet hands
Unplug unit when not in operation for
extended periods of time
Cord can become damaged by forcefully
bending, pulling, twisting, bundling,
pinching or placing heavy objects on it
English AM90
INITIAL OPERATION
Insert the power cord into an electrical
outlet.
Press the‘Power’ button.
NOTE •During the first 4 minutes of power up, the Air Quality
Indicator will flash as the Smart Sensors measure the air
quality in the environment, after which normal operation will
begin.
By default, when the unit first powers on, the
mode will be set to Auto with PlasmaWave
®
enabled.
•When in Auto mode, the fan speed will
be automatically adjusted according to
the environments air quality.
•PlasmaWave® works to remove harmful
airborne contaminants.
NOTE •In Auto mode, as the indoor air quality improves, the fan
speed will automatically be reduced to Low.
•When the unit is running, you may hear a chirping or buzzing
sound. The sound is from large particles passing through
PlasmaWave®, it is normal and does not signify product
failure. To disable PlasmaWave®, see page 12.
English AM90
AUTO & SLEEP
1. Auto Mode
Enables auto operation based on the unit's air quality Smart Sensors.
Press the Mode button to select Auto mode.
•The LED 'Auto' light will indicate when
Auto mode is activated, and operation
will begin.
NOTE •When in Auto mode the fan speed is automatically adjusted
according to the indoor air quality. As the indoor air quality
improves, the fan speed will automatically be reduced. If the
indoor air quality decreases, the fan speed will automatically
increase.
2. Sleep Mode
Press the Mode button to select Sleep mode.
•The LED 'Sleep' light will indicate when
Sleep mode is activated, and operation
will begin.
NOTE •When Sleep mode is selected, the fan speed is automatically
set to Low. The fan speed can be manually changed by
pressing the Fan Speed button, changing the unit into
manual mode.
•When Sleep Mode is activated, the Air Quality Indicator LED
light is disabled.
