WinFast CarePhone
Quick Installation Guide
Before installing WinFast CarePhone, please make sure the outgoing
network is correctly configured as instructed by your ISP.
We recommend you to use Windows XP SP2 operating system with
Internet Explorer 6.0 or newer version of browser.
This installation guide is only intended for connecting WinFast
CarePhone. For other advanced functions or information related to the
product, please read the complete user manual on the CD. Or you can
visit our website for the detailed product
information.
Thank you for buying WinFast CarePhone. Please read this guide
carefully as the following chapters will take you through the installation
and network configuration of WinFast CarePhone. Please contact our
technical staff if you encounter other problems concerning the
installation.
http://www.leadtek.com.tw
WinFast CarePhone Hardware Installation
Type I
Directly connect WinFast CarePhone and the
computer with a Cross-Over cable. (Fig. 1-1)
Type II (Recmmended)
Connect the Ethernet cables from both the
computer and WinFast CarePhone to the
same subnet.
1. Connect the Ethernet cable from the
computer to the switch or hub.
2. Connect the Ethernet cable from WinFast
CarePhone to the same network device. (Fig.
1-2)
Procedure
Step 1
Connect the included DC 5V power adapter to
the power connector of WinFast CarePhone.
Plug the other end of the power cord into the
wall outlet. (110V-240V) (Fig. 1-3)
Step 2
When the WinFast CarePhone is connected
for power, the yellow indicator on the white
button will light up. 10-20 seconds later, a
blue indicator on WinFast CarePhone will
light, which means the network connection is
working. (Fig. 1-4)
Hardware Connection
Fig. 1-1
Fig. 1-2
Fig. 1-3
Fig. 1-4
Step 3
Right-click the "My Neighborhood" icon on
desktop and choose "Properties". Right-click on
"Local Area Connection" icon, and choose
"Properties". (Fig. 1-5)
Choose "Internet Protocol (TCP/IP)" and click
"Properties". (Fig. 1-6)
192.168.0.139 as the IP address. The Subnet
mask is 255.255.255.0. Click "OK". (Fig 1-7)
If the DNS server addresses are filled, please
clear them.
Return to the previous screen and click "OK" to
complete the TCP/IP configuration.
Step 4
Click "Start" "Run" and type "cmd". Click
"OK" to make sure if the computer has the
correct IP address. (Fig. 1-8)
In the MS-DOS window, type "ipconfig" and press
"ENTER". The command will display the IP
address, Subnet mask and gateway.
Choose "Use the following IP address", and type
Fig. 1-5
Fig. 1-6
FIg. 1-7
Fig. 1-8
The default IP address of WinFast CarePhone is 192.168.0.100, so
you have to type "Ping 192.168.0.100" and press "ENTER". The
"PING" command is used to make sure if the computer and WinFast
CarePhone are correctly connected.
If the computer and WinFast
CarePhone are correctly connected, the
MS-DOS window will look like Fig. 1-8.
If the connection between the computer
and WinFast CarePhone fails, the MS-
DOS window will look like Fig. 1-9.
Step 5 (This program can also be used
if you install the product in a DHCP
environment)
In the same local area network, using
the IIAP program can locate the default
IP address of WinFast CarePhone,
which is a fixed IP address http://192.168.0.100.
The rest of the network information will be
displayed in the IIAP window.
Note: IIAP can only be used to locate WinFast
products. Follow the steps below if you want to
modify the network information of the device.
(Fig. 1-10)
1. Input the MAC address of the device and click "Scan".
2. Modify the network information if necessary.
3. Click "Apply" when done.
Fig. 1-8
Fig. 1-9
Fig. 1-10
Note: To prevent IP conflicts between the product and other devices in
the local area network, we recommend you to use an independent
network connection to connect the computer and WinFast CarePhone
through Switch/Hub.
Step 6
Click "Internet Explorer".
Click the "stop" icon , click "tools", and choose "Internet
Properties".
Click the "Connection" tab, and click "LAN settings".
Make sure no items are checked in the "LAN settings" window. Click
"OK" and click "OK again.
Login to WinFast CarePhone
configuration screen and start setting
up network connection.
Launch Internet Explorer, type
http://192.168.0.100 in the address bar
and press "ENTER". (Fig. 1-11)
Input Username and Password as
follows.
Username admin
Password admin (Fig. 1-12)
Click to enter the configuration window.
Fig. 1-11
Fig. 1-12
IE will ask you to download ActiveX control. Please notice the status
bar (Fig. 1-13) and the message below the address bar. Click the
message below the address bar and choose "Install ActiveX Control".
(Fig. 1-14)
Fig. 1-13
Fig. 1-14
Note: If the firewall in your computer is
enabled, you will see a security alert.
Please choose "Unblock". (Fig. 1-15)
Click "Install" to begin downloading.
(Fig. 1-16)
Fig. 1-15
Fig. 1-16
Downloading ActiveX will take 30 seconds to 1 minute. Do not close
the window when downloading.
(Fig. 1-17)
Step 7
We recommend you to choose "User Management" to modify the
Username and Password after you login for the first time and after you
download ActiveX Control.
Step 8
A. Main Menu
System
Network
Camera
User Management
System Info
System Log
B. Submenu
Choose the related functions
of the items in the main
menu.
C. Settings
Modify the configurations of the functions.
When the installation is completed,
the image will be displayed in the browser.
A
B
C
Fig. 1-17
Other references
To set up the information of the persons to call to, please refer to:
Leadtek_WinFast_CarePhone_PC_UserManual_B5
For the detailed descriptions of all the parameters and functions of the
product, please refer to:
Leadtek_WinFast_CarePhone_PC_UserManual_B5
For troubleshooting (including the problems during installation), please
refer to:
Leadtek_WinFast_CarePhone_PC_UserManual_B5
The following will tell you how to install WinFast CarePhone to your
networl. (Please see the complete document on the CD for the
detailed instructions on how to configure the network settings.)
Please make sure your computer has connected to the Intranet or
Internet through the Router or ADSL/Cable Modem.
WinFast CarePhone Network Connection
Choose the network type for your WinFast CarePhone
Follow the steps below to
directly connect WinFast
CarePhone to the computer.
Network type 1
Direct connection to computer
(Fig. 2-1)
WinFast CarePhone can be
directly connected to the
computer with a Cross-Over
cable. This connection can be
used for testing or initializing
purposes.
Procedure
1. Connect the cross-over cable to WinFast CarePhone.
2. Connect the free end of the cross-over cable to the computer.
3. Connect the power cord to WinFast CarePhone.
4. Plug the power cord into the wall plug (110V-240V).
5. If the network is correctly connected, the LED will light blue.
Fig. 2-1
The router is usually
used in a wired/wireless
network environment in
the house to connect
the private network and
the Internet, and usually works in conjunction with the Hub or the
Switch. Follow the steps below to connect WinFast CarePhone to the
network environment with a router.
Procedure
1. Connect the Ethernet cable to WinFast CarePhone.
2. Connect the free end of the Ethernet cable to the router.
3. Connect the power cord to WinFast CarePhone.
4. Plug the power cord into the wall plug.
5. If the network is correctly connected, the LED will light blue.
Network type 3
Connecting to the ADSL/Cable Modem
(Fig. 2-3)
Follow the steps below to connect
WinFast CarePhone to the xDSL
Modem.
Procedure
1. Connect the Ethernet cable to WinFast CarePhone.
2. Connect the free end of the Ethernet cable to Cable Modem or
xDSL (ADSL Modem).
3. Connect the power cord to WinFast CarePhone.
4. For PPPoE users, please go to the WinFast CarePhone
management page and set up PPPoE username and password.
5. If the network is correctly connected, the LED will light blue.
Network type 2
Connecting to the router (Fig. 2-2)
Fig. 2-3
Fig. 2-2
