Williams Sound PPA VP 37 Guía

Model PPA VP 37

Wide-Band FM Wireless Listening System

Manual and User Guide

Transmitter Model PPA T27

Receiver Model PPA R37

Optional Receiver Model PPA R35-8

MAN 159D

Model PPA VP 37 Wide-Band FM Wireless Listening System

Model PPA VP 37 PERSONAL PA®Value Pack System

Contents

System Overview....................................................................................4

Setting up the PPA VP 37.......................................................................5

Antenna Connection..........................................................................5

Power Connection ............................................................................6

Selecting a Frequency.......................................................................6

Connecting an Audio Source.............................................................6

Adjusting the Audio Source ...............................................................7

Safety Information..................................................................................8

Recycling Instructions ...........................................................................9

Receiver Instructions ......................................................................10-17

PPA R37 Receiver Instructions ........................................................10

PPA R35-8 Receiver Instructions.....................................................12

Receiver Belt Clip Instructions .........................................................14

Using A Receiver With A Hearing Aid .............................................15

Receiver Management Suggestions ................................................15

Battery Information ..............................................................................16

Troubleshooting Guide.........................................................................17

System Specications ....................................................................19-21

Warranty ...............................................................................................22

Repair Services ....................................................................................23

Model PPA VP 37 Wide-Band FM Wireless Listening System

System Overview

Thank you for purchasing the Personal PA Value Pack System from Williams

Sound. The PPA VP 37 System is a Wideband FM Listening System which

operates in the 72-76 MHz frequency band. Designed for hearing assistance

in places of public access, the PPA VP 37 is for those who need help

overcoming background noise, reverberation, or distance from the sound

source. The versatile PPA VP 37 is easily integrated with your existing sound

system or can be used with a microphone as a stand-alone system.

The system has two principal parts: the T27 Transmitter and the PPA

R37 Receiver. Much like a miniature radio station, the Transmitter and

microphone pick up the sounds you want to hear and broadcast them over

an FM radio signal. The receivers are used to pick up the broadcast up to

1000 feet (305 m).

To avoid difculties, please read through these instructions as you begin

to use the system. Then save the manual for questions that arise as you

continue to use your Personal PA Value Pack System.

If you have any problems with this Williams Sound product, please call us

toll-free at 1-800-843-3544.

LOUDSPEAKER

LINE-LEVEL OUTPUT

LINE-LEVEL INPUT

SOUND SYSTEM

AMPLIFIER

MICROPHONES

PPA T27 TRANSMITTER

PPA SELECT™ RECEIVERS

WITH EARPHONES A184

Figure 1: Overall System Diagram

Model PPA VP 37 Wide-Band FM Wireless Listening System

Setting Up the PPA VP 37

Figure 2: PPA T27 Features and Controls

1. Select Location. Position the PPA T27 transmitter near the audio source

(i.e. sound system, mixer) from which it will receive audio.

2. Install the Antenna. Gently thread the ANT 021 rubber duckie antenna

onto the stud recessed in the hole on the top of the transmitter. FCC

rules allow only the use of antennas provided by Williams Sound. To use

a remote antenna supplied by Williams Sound, the antenna cap may be

removed by turning it counter-clockwise with a pliers or wrench. Please

call customer service 800.843.3544 if you have any questions.

A183

MIC INPUT

JACK, 3.5 MM

AUDIO LEVEL

INDICATOR

AUDIO LEVEL

CONTROL

FREQUENCY

DISPLAY (LED)

FREQUENCY

SELECTOR

LOCK/UNLOCK

CONTROL

12VAC POWER

INPUT JACK

75 OHMS ANTENNA CONNECTOR

AUDIO INPUT JACK, RCA-TYPE

(LINE LEVEL,UNBALANCED)

Model PPA VP 37 Wide-Band FM Wireless Listening System

3. Connect the Power. Locate the TFP 036 power supply cord equipped

with the 5-pin DIN connector, then plug the connector into the “Power

In” jack located in the back of the T27. Plug the power supply into the

AC outlet. On power up, the number “8” will scroll across the T27 display

while the system initializes. The system will then display the default

system frequency (72.9 MHz) or the last selected frequency set by the

user.

4. Select the Frequency. The T27 has 17 available channels in the 72-76

MHz band. By default, the T27 frequency is set to 72.9 MHz. To change

the frequency on the T27, press and release the down “ ” or up “

” frequency selector button until the desired frequency is displayed. After

3 seconds, the frequency selection will be set, and the audio will begin

transmitting on the new frequency.

NOTE: You can LOCK this selection to prevent others from accidently

changing the frequency.

To LOCK the desired frequency, press and hold both down “ ” and up

“ ” frequency selector buttons for 3 seconds until the word “Loc” appears

on the display. The frequency is now locked. Should the user press the

frequency selector button while in “Lock” mode, the word “Loc” will be

displayed for 2 seconds.

To UNLOCK the desired frequency, press and hold both down “ ” and up

“ ” frequency selector buttons for 3 seconds until the transmitter displays

”Un” then “Loc” on the display. The frequency is now unlocked. The user is

now free to change the frequency on the T27 as needed

5. Connect the Audio Source. On the back of the T27, an RCA-type

“Audio In” jack is available for connecting a line-level, unbalanced audio

source. On the front of the T27, a 3.5 mm “Mic Input” jack is available

to connect a Williams Sound electret microphone. Connect the desired

audio source to the T27 transmitter and proceed to step 6.

Model PPA VP 37 Wide-Band FM Wireless Listening System

6. Adjusting the Audio Source. With the audio source playing, use a small

screwdriver or tuning wand to rotate the “Adjust” control on the front of

the T27:1) clockwise to increase the audio level; or 2) counterclockwise to

decrease the audio level. Refer to the audio “Level” indicator LED on the

front of the T27 as you make your adjustments:

Audio Level Indicator LED

Never On = Audio source is TOO LOW.

Blinks occasionally = Audio source is OPTIMAL.

Always on = Audio source is TOO HIGH.

7. Listen with an FM Receiver.

IMPORTANT: The FM receiver being used with the T27 transmitter will

need to be on the same frequency as the transmitter.

Install the receiver batteries, plug in the earphone, turn on the receiver

and walk around the listening area. The signal should be clear and quite

loud when the volume is turned up. See pages 10-13 for detailed receiver

instructions.

Model PPA VP 37 Wide-Band FM Wireless Listening System

Receiver Safety Information

HEARING SAFETY:

CAUTION!

The receiver is designed to amplify sounds to a high volume level which

could potentially cause hearing damage if used improperly.

To protect your hearing and the hearing of others:

1. Make sure the volume is turned down before putting on the earphone or

headphone before adjusting the volume to a comfortable level.

2. Set the volume level at the minimum setting that you

need to hear.

3. If you experience feedback (a squealing or howling sound), reduce the

volume setting and move the microphone away from the earphone or

headphone.

4. Do not allow children or other unauthorized persons to have access to

this product.

BATTERY SAFETY AND DISPOSAL:

CAUTION!

The receiver may be supplied with alkaline batteries. Do not attempt

to recharge alkaline batteries, which may explode, release dangerous

chemicals, cause burns, or other serious harm to the user or product.

PACEMAKER SAFETY:

CAUTION!

1. Before using the receiver with a pacemaker or other medical device,

consult your physician or the manufacturer of your pacemaker or other

medical device.

2. If you have a pacemaker or other medical device, make sure that you are

using this product in accordance with safety guidelines established by

your physician or the pacemaker manufacturer.

Model PPA VP 37 Wide-Band FM Wireless Listening System

Recycling Instructions

Help Williams Sound protect the environment! Please take the time to

dispose of your equipment properly.

Product Recycling

Please do NOT dispose of your Williams Sound equipment in the

household trash. Please take the equipment to an electronics recycling

center; OR, return the product to the factory for proper disposal.

Battery Recycling

Please do NOT dispose of used batteries in the household trash. Please

take the batteries to a retail or community collection point for recycling.

Model PPA VP 37 Wide-Band FM Wireless Listening System

PPA R37 Receiver Instructions

PPA R37 is a 17-channel receiver operating on the 72-76 MHz bandwidth.

Features: seek-button channel selection, channel-lock capability, battery-

saving sleep mode, on/off volume control, power/low battery indicator,

stereo/mono earphone jack.

Figure 3: PPA R37 Controls

Operating the Receiver

1. Insert two (2) AA batteries ensuring correct polarity. If rechargeable NiMH

batteries are to be used, make sure the Alkaline/NiMH switch inside the

battery compartment is set to NiMH before charging. See Figure 4.

2. Insert headphone, earphone or neckloop into the stereo output jack.

ON/OFF, VOLUME

CONTROL SWITCH

EARPHONE

JACK

"ON" / LOW BATTERY/

FLASH CODE INDICATOR

OFF

A116

ON/OFF, VOLUME

CONTROL SWITCH

EARPHONE

JACK

"ON" / LOW BATTERY/

FLASH CODE INDICATOR

OFF

A116

Otros manuales para PPA VP 37

Tabla de contenidos

Otros manuales de Receptor de Williams Sound

Williams Sound

Williams Sound Digi-Wave DLR 400 ALK Manual de usuario

Williams Sound

Williams Sound Portable FM Listening System TGS 173 Guía

Williams Sound

Williams Sound Digi-Wave DLT 400 Manual de usuario

Williams Sound

Williams Sound PPA T21 Manual de usuario

Williams Sound

Williams Sound T2 863 Manual de usuario

Williams Sound

Williams Sound PPA R37 Instrucciones de montaje

Williams Sound

Williams Sound WIR 135 Manual de usuario

Williams Sound

Williams Sound PPA R35-8 Instrucciones de montaje

Williams Sound

Williams Sound SoundPlus WIR RX22-4 Manual de usuario

Williams Sound

Williams Sound SoundPlus Infrared Receiver WIR RX3 Manual de usuario

Williams Sound

Williams Sound TGS R7 Manual de usuario

Williams Sound

Williams Sound PPA T46 Manual de usuario

Williams Sound

Williams Sound SoundPlus WIR RX22-4 Instrucciones de montaje

Williams Sound

Williams Sound DLR 360 Manual de usuario

Williams Sound

Williams Sound PPA VP Manual de usuario

Williams Sound

Williams Sound SoundPlus WIR RX22-4 Instrucciones de montaje

Williams Sound

Williams Sound TGS 100 Manual de usuario

Williams Sound

Williams Sound WaveCAST WF T5 Manual de usuario

Williams Sound

Williams Sound PPA R35-8 Manual de usuario

Williams Sound

Williams Sound WIR SYS ADV Guía de solución de problemas

Williams Sound

Williams Sound PPA R19 Instrucciones de montaje

Williams Sound

Williams Sound Digi-Wave DLT-100 Manual de usuario

Williams Sound

Williams Sound Whisper R863 Instrucciones de montaje

Williams Sound

Williams Sound IR?RX20 Manual de usuario

Manuales populares de Receptor de otras marcas

Garmin

Garmin GA 23 Manual de usuario

Aiphone

Aiphone PS-12F Manual de usuario

IMES

IMES TCS-01CA-PMI Manual de usuario

BWI Eagle

BWI Eagle AIR-EAGLE SR Manual

AMIMON

AMIMON AMN12310 WHDI Manual de usuario

Dual

Dual DMCPA79BT Instrucciones de funcionamiento

Sound Associates

Sound Associates SA652P Manual de usuario

Sherwood

Sherwood NewCastle R-772 Manual de usuario

Audio

Audio A10-RX Series Manual de usuario

AllSee

AllSee PushShare PSRV1.1 Manual de usuario

DEMAG

DEMAG DRC-DR D2 Manual de usuario

Teleco

Teleco TVRCL868A02 Manual de usuario

Bosch

Bosch RF3222E Manual de usuario

Kramer

Kramer 631R Manual de usuario

Xpress

Xpress xmc10 Manual de usuario

JVC

JVC KD-MR1BTS Manual de usuario

Omega Engineering

Omega Engineering UWTC-REC3 Manual de usuario

e-survey

e-survey E300 Pro Manual de usuario
