Whirlpool PEWETER 3RGSC9400RL0 Manual de usuario

TOP AND CABINET PARTS

For Model: 3RGSC9400RL0

(Pewter)

12−05 Litho in U.S.A. (drd) Part No. 8180799

AUTOMATIC

WASHER

TOP AND CABINET PARTS

For Model: 3RGSC9400RL0

(Pewter)

8180799

Illus. Part

No. No. DESCRIPTION

1 Literature Parts

8318424 Installation

Instructions

8315977 Use & Care Guide

3954736 Wiring Diagram

8315975 Installation &

User Guide

2 3957075 Top

3 62750 Spacer, Cabinet To

Top (4)

4 357213 Nut, Push−In (2)

5 3956112 Cabinet

6 62780 Clip, Top & Cabinet

& Rear Panel (2)

7 8566266 Dispenser, Bleach

8 3351614 Screw, Ground

9 3357011 Screw, 10−16 x 1/2

10 3976348 Sound Dampener,

Cabinet (3)

11 8318084 Switch, Lid

12 21097 Pad, Lid Hinge (2)

13 355274 Screw, Lid Hinge

Mounting (4)

14 3957287 Handle, Lid

15 8559336 Hinge, Lid (L.H.)

16 91770 Hinge, Lid (R.H.)

17 3957286 Insert, Handle

18 8319539 Bearing, Lid

Hinge (2)

19 8577123 Lid

20 9724509 Bumper, Lid (2)

21 3390631 Screw,

10−16 x 3/8 (4)

CONTROLS AND REAR PANEL PARTS

For Model: 3RGSC9400RL0

(Pewter)

8180799

CONTROLS AND REAR PANEL PARTS

For Model: 3RGSC9400RL0

(Pewter)

8180799

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 3349365 Hose, Sensor

(Upper)

2 3952439 Mini−Buzzer

3 Hose, Water Inlet

3949382 Red

3949383 Blue

4 3357027 Nozzle−Drain

Hose

5 8568314 Strap, Console (2)

6 8318405 Panel, Rear

7 62747 Pad, Rear Panel

8 3951609 Hose, Drain

(4 ft.)

661577 Hose, Drain

(9 ft.)

(Not Included)

3357090 Extension,

Drain Hose

(21 Inches.)

(Not Included)

9 3954781 Timer, Control

(50 Hz.)

(Motor Not A

Service Part)

10 3976300 Washer, Water

Inlet Hose (4)

(1−1/16 x 5/8)

11 90767 Screw, 8−18 x 3/8

12 3366845 Switch, Water Level

13 3950194 Bracket, Control

14 8316047 Cord, Power

15 3949468 Strain Relief,

Power Cord

16 8541780 Cap, End (L.H.)

17 3351614 Screw, Ground

18 3360397 Valve, Water

Mixing

19 3951198 Fuse

(In Harness)

20 285750 Kit, Adapter

21 370451 Clamp, Hose

22 3357319 Hose, Vacuum

Break

23 371503 Clamp, Hose

24 387606 Break, Vacuum

25 303294 Edge Protector

26 8317959 Assembly,

Drain Hose

27 3366912 Clamp, Hose

28 3976395 Clamp, Hose

29 3352282 Sensor, Inline

30 3363366 Clamp, Hose

31 8317496 Clamp, Hose

32 3951449 Hose, Pump To Tub

33 8316039 Shield, ATC

34 3407159 Control, ATC

3388228 Screw (2)

35 3952442 Relay (240 VAC)

36 3400818 Screw, Timer

Mounting

37 3179795 Screw, Ground

38 3407160 Transformer

39 8565453 Panel, Console

40 8055003 Clip, Harness

& Pressure Hose

41 357572 Clip, Grounding

42 3398893 Wire, Ground

43 3363920 Adapter,

Drain Hose

44 8544945 Knob, Timer

45 8544947 Dial, Timer

46 8536939 Clip, Knob

47 8544937 Knob, Control

48 356138 Clamp, Hose

49 388326 Screw, 8−18 x 1.25

(Panel to Top)

50 62863 Screw, 10−16 x 3/8

51 8541779 Cap, End (R.H.)

52 8546302 Switch, Clean

Touch (7 Pad)

53 3357397 Adapter, Water

Inlet Hose

54 3976290 Washer, Inlet

Hose Adapter

55 3366913 Clamp, Drain

Hose

56 3352944 Clip, Harness

57 8314879 Shield, Inlet

Valve

58 3957869 Harness, Wiring

(For Detail See

Pages 9 & 10)

FOLLOWING PARTS

NOT ILLUSTRATED

8541754 Miscellaneous

Parts Bag

AGITATOR, BASKET AND TUB PARTS

For Model: 3RGSC9400RL0

(Pewter)

8180799

AGITATOR, BASKET AND TUB PARTS

For Model: 3RGSC9400RL0

(Pewter)

8180799

Illus. Part

No. No. DESCRIPTION

1 63580 Dispenser

2 358237 Screw & Washer

(5/16−24 x 1)

3 3363003 Clothes Mover

4 3951632 Agitator

5 8528150 Tub Ring & Gasket

6 3976308 Gasket, Tub Ring

7 3354845 Clip, Agitator

8 3952374 Bearing, Driven

Cam

9 3951682 Cam Driven

10 3366877 Dog, Agitator

Clutch (4)

11 2219077 Clip, Pressure

Switch Hose

12 21366 Nut, Spanner

13 8526016 Basket & Balance

Ring

14 8519788 Balance Ring

15 8543666 Washer, Agitator

16 63849 Tub

17 389140 Block, Basket

Drive

18 383727 Gasket, Centerpost

19 3347780 Hose, Pressure

Switch

20 3951744 Agitator

(Complete)

22 3951608 Spacer, Thrust

23 3354733 Cap, Barrier

24 3348855 Seal, Inner Cap

26 3949550 Washer

BRAKE, CLUTCH, GEARCASE, MOTOR AND PUMP PARTS

For Model: 3RGSC9400RL0

(Pewter)

8180799

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 388952 Brake & Drive

Tube (Complete)

(Refer to Page 11

For Further

Breakdown)

2 63292 Washer, Spin

Tube Thrust

3 62697 Ring, Spin

Tube Support

4 63283 Ring, Retainer

5 3951311 Clutch (Complete)

6 3951308 Band & Lining,

Clutch (Includes

Items 7 & 8)

7 62646 Cap, Clutch

Spring (2)

8 3946792 Spring, Clutch

9 3949118 Gearcase

(Complete)

(Refer To Page 12

For Further

Breakdown)

10 3357334 Screw, Gearcase

To Base (3)

11 62611 Plate, Motor

Mount To

Gearcase

12 62691 Grommet, Motor (4)

13 285753 Coupling, Motor

& Isolation

14 8577374 Seal

15 3355454 Clip,

Anti−Rattle

16 3400516 Screw

17 3349637 Retainer, Motor (2)

18 3362089 Shield, Tub

To Motor

19 3950297 Motor, Main

Drive

20 8529896 Switch, Main

Drive Motor

21 8546127 Retainer, Pump (2)

22 3363394 Pump (Complete)

23 3387485 Screw, 10−16 x 5/8

24 8316060 Shield, Motor

25 62863 Screw,

10−16 x 5/16

26 8572719 Capacitor

27 3949496 Clamp, Capacitor

MACHINE BASE PARTS

For Model: 3RGSC9400RL0

(Pewter)

8180799

Illus. Part

No. No. DESCRIPTION

1 3400076 Screw, Bracket

Mounting

(10−32 x 5/8)

2 64067 Bracket, Spring

Outer (2)

3 63907 Spring

Suspension,(3)

4 8575214 Support & Brake,

Tub

5 64065 Bracket, Spring

Outer (L.F.)

6 63466 Link, Leveling

Mechanism (2)

7 62597 Spring, Leveling

Mechanism

8 62837 Pin, Knurled

9 62596 Foot, Rear (2)

13 8546455 Bearing,

Centerpost (2)

14 357409 Seal, Centerpost (3)

15 388492 Spring,

Counterweight

16 62568 Pad, Plate

17 3946509 Plate, Suspension

(Includes Item 16)

18 3363660 Pad, Base

19 3946512 Base Assembly

(Includes Items 6,

7, 8, 9, 18 & 26)

20 8544816 Sound Absorber

21 3359452 Nut, Lock (2)

(3/8−16)

22 389102 Foot, Front (2)

23 8577376 Seal, Centerpost

24 285203 Centerpost

Bearing Kit

(Includes Items

13, 14 & 23)

25 63134 Ring, Sound

Deadening

26 63806 Retainer,

Suspension Spring

WIRING HARNESS PARTS

For Model: 3RGSC9400RL0

(Pewter)

8180799

WIRING HARNESS PARTS

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 3349557 Clip, Harness

2 388498 Clip, Harness

3 3347812 Clip, Harness

4 3352501 Clip, Harness

5 90016 Clip, Harness

6 3390496 Clip, Harness

7 389379 Retainer,

(Suds Models)

8 Timer, Block

Disconnect

3948614 White

352089 Black

9 62889 Receptacle,

Terminal

(3−Way)

(Lid Switch)

(Use Term.94613)

Or 94614.)

10 353424 Plug, Terminal

(3−Way)

(Power Cord)

(Use Term.94613)

11 62505 Block, Disconnect

(Motor 2 Speed)

(Use Term.352088)

12 3347243 Block, Disconnect

(Use Term. 352088)

13 63523 Protector

14 717252 Connector

(2−Way)

(Use Term.94614)

15 3352944 Clip, Harness

16 3390423 Block, Disconnect

(12−Way)

(Timer)

(Use Term. 94613)

17 3347730 Receptacle

(6−Way)

(Use Term. 94613)

18 3349494 Connector, Etc

19 3407125 E.T.C. Control

20 3948617 Connector (T.P.A.)

(3−Circuit)

(Lid Switch)

21 3360056 Connector (T.P.A)

(3−Circuit)

(Pressure Switch)

22 Block, Connector

3354925 Cold Valve

3354926 Hot Valve

For Model: 3RGSC9400RL0

(Pewter)

8180799
