Whirlpool GB2SHDXTB00 Manual de usuario
1
CABINET PARTS
For Models: GB2SHDXTQ00, GB2SHDXTB00, GB2SHDXTS00
(White) (Black) (Stainless Steel)
5−08 Litho In U.S.A. (tpm) Part No. W10132687 Rev. A
REFRIGERATOR
CABINET PARTS
2
For Models: GB2SHDXTQ00, GB2SHDXTB00, GB2SHDXTS00
(White) (Black) (Stainless Steel)
W10132687
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 Literature Parts
12828178 Use & Care Guide
12863066 Energy Tag
8208183 Tech Sheet
2 Cabinet (Not a
Servicable Part)
3 Plug, Button (3)
4344209 White
4344208 Black
4 8171247 Insulation
5 8170886 Roller Assembly
6 8170869 Clip, Grille
7 67006642 Pin, Center Hinge
8 67006611 Bolt, Adjusting
(Front Roller)
9 67006521 Screw
11 67006380 Screw
12 67006473 Screw
13 8208155 Cover, Water Line
14 67006303 Screw
15 Hinge, Center
67006960 White
67007043 Black
16 67006287 Screw
17 Cover, Corner
8170860 White
8170858 Black
8170859 Biscuit
19 Hinge, Bottom
8171067 White
8171066 Black
20 67006473 Screw
21 4344265 Clip
22 Grille Assembly
(Includes Clips)
67007004 White
67006954 Black
23 4343702 Clip
25 67006425 Screw
27 8170920 Cover, Water Valve
30 8170910 Cover, Unit
31 8208154 Fill Tube Assy.
32 67007121 Power Cord
33 8170924 Insulation, Sound
37 8170861 Tube, Drain
38 8170862 Clip, Drain Tube
41 8170974 Hinge, Top
42 Cover, Hinge
8170977 White
8170975 Black
43 8170878 Plug, Button
46 8171272 Foot Brake
Following Parts Not Illustrated
8170942 Clamp, Tube
FREEZER LINER PARTS
3
For Models: GB2SHDXTQ00, GB2SHDXTB00, GB2SHDXTS00
(White) (Black) (Stainless Steel)
W10132687
FREEZER LINER PARTS
4
For Models: GB2SHDXTQ00, GB2SHDXTB00, GB2SHDXTS00
(White) (Black) (Stainless Steel)
W10132687
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 8170897 Gasket, Foam
3 8171237 Gear (Left)
(Includes Item 7)
4 8208205 Cover, Light
5 8171229 Shaft
6 67002216 Socket, Light
7 8171236 Gear(Right)
(Includes Item 3)
8 67006473 Screw
9 A0282812 Bulb, Light
10 8170838 Housing, Frz. Light
11 8208235 Cover, Evaporator
12 67006425 Screw
13 Bracket, Door
8171232 Left
8171233 Right
14 8208206 Housing, Lighting
15 8208285 Clip, Evap. Motor
16 8208349 Switch, Light
18 Bracket, Basket
8171234 Left
8171235 Right
19 67006607 Slide, Drawer
20 8208203 Gasket, Bottom
21 Bracket, Slide
8208215 Left
8208216 Right
22 13024802 Cover, Fan Shroud
23 8171153 Shroud, Evap.Fan
24 8170544 Blade, Fan
(Evaporator)
25 8171086 Grommet (2)
26 8170894 Motor, Evaporator
27 4344385 Funnel, Drain
(Incl. # 28 & 29)
28 4344311 Seal
29 4344310 Gasket
30 8208196 Thermistor
31 8208202 Cover, Thermistor
32 67006406 Screw
33 67006530 Screw
Following Parts Not Illustrated
67006095 Harness, Lights
(Freezer)
FREEZER DOOR PARTS
5
For Models: GB2SHDXTQ00, GB2SHDXTB00, GB2SHDXTS00
(White) (Black) (Stainless Steel)
W10132687
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 Freezer Door
(w/ Insulation)
W10175552
White
W10175551
White
67007149 Stainless Steel
2 Handle
2319729W White
2319729B Black
2319729S Stainless Steel
3 Door Gasket,
Magnetic
8171163 White
8171162 Black
4 8171220 Stud, Handle
5 8170956 Screw
6 Plug, Button (2)
8208212 White
8208213 Black
7 67006408 Screw
REFRIGERATOR LINER PARTS
6
For Models: GB2SHDXTQ00, GB2SHDXTB00, GB2SHDXTS00
(White) (Black) (Stainless Steel)
W10132687
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 8208184 Bracket, Control
and Lights
3 8208185 Overlay
4 8208186 Housing,
Electronic Control
5 67006740 Electronic Control
6 4344571 Switch, Light
7 8208188 Cover, Light
8 8208189 Housing, Light
9 A0282812 Bulb, Light (2)
10 67002216 Socket, Light (2)
11 8208191 Insert,
Damper Cover
12 67006602 Screw
13 8208193 Cover, Damper
14 8208194 Insulation
15 8208195 Control, Damper
16 8208196 Thermistor
Following Parts Not Illustrated
8208197 Harness,
Damper Control
8208198 Harness, Controls
(Refrigerator)
(Includes # 16)
REFRIGERATOR DOOR PARTS
7
For Models: GB2SHDXTQ00, GB2SHDXTB00, GB2SHDXTS00
(White) (Black) (Stainless Steel)
W10132687
REFRIGERATOR DOOR PARTS
8
For Models: GB2SHDXTQ00, GB2SHDXTB00, GB2SHDXTS00
(White) (Black) (Stainless Steel)
W10132687
Illus. Part
No. No. DESCRIPTION
1 Refrigerator Door
(w/Liner)
12658565W
White
12658565B
Black
12658566S
Stainless Steel
2 8170956 Screw
3 8171204 Door, Compartment
4 8170793 Tray, Dairy
5 8171166 Shelf Bin
(Medium)(4)
6 Plug, Handle Hole
8170791 White
8170792 Black
7 Plug, Button
8208212 White
8208213 Black
8 Door Gasket,
Magnetic
8171197 White
8170758 Black
9 Door Handle
2319729W White
2319729B Black
2319729S Stainless Steel
11 Door Closure
8171245 White
8171246 Black
13 8171220 Stud, Handle
14 8170795 Shelf, Bin (Large)
15 67006287 Screw
17 Stop, Door
8171205 White
8171214 Black
18 Bushing
8208208 White
8171213 Black
19 8170797 Nameplate
UNIT PARTS
9
For Models: GB2SHDXTQ00, GB2SHDXTB00, GB2SHDXTS00
(White) (Black) (Stainless Steel)
W10132687
UNIT PARTS
10
For Models: GB2SHDXTQ00, GB2SHDXTB00, GB2SHDXTS00
(White) (Black) (Stainless Steel)
W10132687
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 67006433 Screw
2 8208223 Blade, Fan
3 8208371 Base
4 67006425 Screw
7 12870501 Harness, Evap.
Heater
8 8170911 Drain Pan
9 8171209 Grommet (3)
10 8171152 Evaporator Heater
11 67007052 Strap
12 67005560 Overload
(Includes Relay &
Capacitor)
13 8170914 Gasket
14 8208287 Bi−Metal
15 8208321 Grommet
17 8208368 Capacitor
18 67006132 Condenser
20 8170882 Tray, Drip
22 8170889 Evaporator
23 Dam
8171155 Right Side
8171154 Left Side
24 8208221 Motor, Fan
25 4343918 Clip, Heater
26 8208233 Harness, Unit
27 2317845 Drier (Service)
28 8208289 Compressor
(Includes Items
11, 12, 15,
17 & 27)
31 12575305 Shroud
32 8208222 Bracket, Fan Motor
34 10547003 Clip, Drier
36 67005149 Roller
39 4343845 Grommet (4)
40 8208234 Screw
41 67006434 Axle, Roller
42 4344219 Clip, Evaporator
43 67006737 Screw
44 67006432 Screw
53 67006573 Screw
55 8171240 Tube, Drain
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.00 Ozs.
(R−134A)
