Westomatic Primo Compact Manual de usuario
PRIMO COMPACT
Cleaning Manual
Page 1of 11 P-COM-Cleaning
Primo Compact Fresh Milk
Description
Qty Part Number
1 Litre Milk line clear (Acid based)
1
1053009
Brewer cleaning tablets – 50 tablets
1
1015015
Screen Cleaner 100ml
1
1015014
Microfibre cloth
1
1015012
Primo Compact Instant Milk
Description
Qty Part Number
Microfibre cloth
1
1015012
Screen Cleaner 100ml
1
1015014
Brewer cleaning tablets – 50 tablets
1
1015015
To follow the Primo Compact cleaning guide you will
need the following customer care kit.
FOR PRIMO COMPACT WITH FRESH MILK OPTION
•1 Litre Milk line cleaner (Acid based)
•Brewer cleaning tablets – 50 tablets
•Screen cleaner 100ml
•Microfibre Cloth
FOR PRIMO COMPACT INSTANT ONLY
•Microfibre Cloth
•Screen Cleaner 100ml
•Brewer cleaning tablets – 50 tablets
These kits can be re-ordered on
WestoNET
or
call 01626 323100
PRIMO COMPACT
Cleaning Manual
Page 2of 11 P-COM-Cleaning
DAILY CLEANING
These instructions show the steps for daily cleaning
including:
•Empty and clean the waste container and the trays
•Clean the coffee machine
Before you start, carefully read the “Safety instructions and
environmental information” provided with the machine.
Remove the drip tray
Rinse and clean the drip tray
Remove the cup tray grid
PRIMO COMPACT
Cleaning Manual
Page 3of 11 P-COM-Cleaning
DAILY CLEANING
Clean the cup tray
Open the machine with the key
Remove the waste container
Empty and clean the waste container.
Remove the outlet cover:
1. Lift the tab on the inside of the machine
2. Pull the outlet cover
out from the door
PRIMO COMPACT
Cleaning Manual
Page 4of 11 P-COM-Cleaning
DAILY CLEANING
Clean the outlet
Place all parts back into the machine
Clean the back cover behind the cup tray with a damp
cloth.
If you have accessories like a cup warmer or milk
cooler, then clean them with a damp cloth as well.
The machine is now ready to use
If you have a milk cooler continue with the Fresh Milk system cleaning before refill.
PRIMO COMPACT
Cleaning Manual
Page 5of 11 P-COM-Cleaning
WEEKLY CLEANING
These instructions show the steps for weekly cleaning including:
•Clean the ingredient mixer parts
•Clean the bean supply parts and grinder
Before you start, carefully read the “Safety instructions
and environmental information” provided with the
machine.
On the touchscreen:
Select the machine menu
Select CLEAN MACHINE
The steps on the screen will guide you through the
cleaning procedure.
Open the machine with the key
PRIMO COMPACT
Cleaning Manual
Page 6of 11 P-COM-Cleaning
WEEKLY CLEANING
Open the lid
Turn the canister outlets upwards
Remove the instant canisters by
lifting them and pulling them
forward
Turn the mounting ring
counterclockwise to
unlock the mixer bowl
Remove the mixer bowl
PRIMO COMPACT
Cleaning Manual
Page 7of 11 P-COM-Cleaning
WEEKLY CLEANING
Remove the hose from the mixer bowl
Remove the hose and the coffee
splitter
Remove the coffee hose from the coffee splitter
Remove the mixer fan
1. Turn the mounting ring further clockwise
2. Remove the mounting ring
PRIMO COMPACT
Cleaning Manual
Page 8of 11 P-COM-Cleaning
WEEKLY CLEANING
Remove the dust tray
Clean and rinse the parts
Note: If you have a hygiene kit with duplicate
parts you can place these in the machine and
clean the removed parts later
Clean the canister area using the brush
Note: The cleaning brush is found on left side in
the machine.
Place the dust tray back
1. Carefully re-place the mounting ring
2. Lock the ring by rotating it clockwise
PRIMO COMPACT
Cleaning Manual
Page 9of 11 P-COM-Cleaning
WEEKLY CLEANING
Carefully position the mixer fan and press it firmly
until it fits
1. Attach the hoses to the coffee splitter
2. Re-place the coffee splitter in its holder
Place the instant canister back in the machine
Make sure that the canister connects to the rotor on the back
and falls into the hole on the front
Rotate the canister outlets
downwards into the mixer bowl
Close the lid
