Western Digital WD15NPVT Instrucciones de instalación

MODEL NUMBERS

WD5000BUDT WD2500BUDT

WD3200BUDT WD1600BUDT

Note: Not all products may

be available in all regions of

the world.

WD AV-25

AV Hard Drives

WD AV-25 2.5-inch SATA hard drives are specially

engineered to offer cool quiet operation while providing

maximum reliability in 24x7 always-on environments.

With support for up to five simultaneous HD video

streams, these drives are perfect for DVRs, set-top

boxes and digital video surveillance.

INTERFACE

SATA

WIDTH/HEIGHT

2.75 in./0.37 in.

(69.85 mm/9.5 mm)

ROTATIONAL SPEED

5400 RPM

CAPACITIES

160 to 500 GB

24x7 reliability

These drives are designed to last in

always-on streaming digital

audio/video environments such as

DVR/PVR, digital video surveillance

and other demanding multimedia

applications.

Advanced Format

Technology

Leading edge technology delivers

improved video quality and AV

performance through enhanced

error correction capability.

SilkStream™technology

Optimized for smooth, continuous

digital video playback of up to five

simultaneous HD streams.

SilkStream is compatible with the

ATA streaming command set so AV

customers can use standard

streaming management and error

recovery options.

Ultra-cool operation

A cool drive is a more reliable drive.

WD continues to develop new and

innovative ways to keep drives cool

while they are operating.

Quiet

Noise levels have been minimized to

less than one sone* - virtually below

the threshold of human hearing.

Low power consumption

The drive draws less than 2 Watts

while operating and a mere 4.75

Watts during spin up.

1 million hours MTBF

Best-in-class reliability for

small-form factor AV storage.**

Preemptive Wear Leveling

(PWL)

The drive arm frequently sweeps

across the disk to reduce uneven

wear on the drive surface common

to audio video streaming

applications.

* A sone is a subjective unit of loudness as perceived by a

person with normal hearing.

** Based upon dual tuner system operating in typical 30°C air

ambient environment.

Product Features

WD AV-25

Western Digital, WD, and the WD logo are

registered trademarks in the U.S. and other

countries; and SilkStream and FIT Lab are

trademarks of Western Digital Technologies,

Inc. Other marks may be mentioned herein

that belong to other companies. Product

specifications subject to change without

notice.

Western Digital

20511 Lake Forest Drive

Lake Forest, California 92630

U.S.A.

2879-771362-A02 May 2010

For service and literature:

support.wdc.com

www.westerndigital.com

800.ASK.4WDC North America

800.832.4778 Spanish

+800.6008.6008 Asia Pacific

00800.27549338 Europe

(toll free where available)

+31.880062100 Europe/Middle East/Africa

1As used for storage capacity, one megabyte (MB) = one million bytes, one gigabyte (GB) = one billion bytes, and one terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on operating environment. As used for buffer or cache, one megabyte (MB) = 1,048,576

bytes. As used for transfer rate or interface, megabyte per second (MB/s) = one million bytes per second, and gigabit per second (Gb/s) = one billion bits per second. Effective maximum SATA 3 Gb/s transfer rate calculated according to the Serial ATA specification published by the SATA-

IO organization as of the date of this specification sheet. Visit www.sata-io.org for details.

2Maximum burst rate running the Mode 5 Ultra ATA transfer mode.

3Controlled unload at ambient condition.

4The term of the limited warranty may vary by region. Visit support.wdc.com/warranty for details.

5No non-recoverable errors during operating tests or after non-operating tests.

6Sound power level.

Specifications 500 GB 320 GB 250 GB 160 GB

Model number WD5000BUDT WD3200BUDT WD2500BUDT WD1600BUDT

Interface SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s

Formatted capacity1500,107 MB 320,072 MB 250,059 MB 160,041 MB

User sectors per drive 976,773,168 625,142,448 488,397,168 312,581,808

Advanced Format Technology Yes Yes Yes Yes

Form factor 2.5-inch 2.5-inch 2.5-inch 2.5-inch

Performance

Data transfer rate (max)2

Buffer to host

Host to/from drive (sustained)

3 Gb/s

108 Mbytes/s

3 Gb/s

108 Mbytes/s

3 Gb/s

108 Mbytes/s

3 Gb/s

108 Mbytes/s

Cache (MB) 32 32 32 32

Average latency (ms) 5.5 5.5 5.5 5.5

Rotational speed (RPM) 5400 5400 5400 5400

Averagedrivereadytime(sec)4444

Reliability/Data Integrity

Load/unload cycles3600,000 600,000 600,000 600,000

Non-recoverable read errors

per bits read

<1 in 1014 <1 in 1014 <1 in 1014 <1 in 1014

Limited warranty (years)43333

Power Management

5VDC ±10% (A, peak) 0.950 0.950 0.950 0.950

Average power requirements (W)

Read/Write

Idle

Standby/Sleep

1.6

0.65

0.20

1.6

0.85

0.20

1.6

0.85

0.20

1.6

0.85

0.20

Environmental Specifications5

Temperature (°C)

Operating

Non-operating

0 to 60

-40 to 65

0 to 60

-40 to 65

0 to 60

-40 to 65

0 to 60

-40 to 65

Shock (Gs)

Operating (2 ms, read)

Non-operating (2 ms)

350

1000

350

1000

350

1000

350

1000

Average acoustics (dBA)6

Idle mode

Average seek mode

Physical Dimensions

Height (in./mm, max)80.374/9.50 0.374/9.50 0.374/9.50 0.374/9.50

Length (in./mm, max) 3.94/100.20 3.94/100.20 3.94/100.20 3.94/100.20

Width (in./mm, ± .01 in.) 2.75/69.85 2.75/69.85 2.75/69.85 2.75/69.85

Weight (lb./kg, ± 10%) 0.22/0.10 0.22/0.10 0.22/0.10 0.22/0.10
