Enterprise Hard Drives

Interface

Width/Height

Rotational Speed

Capacities

Model Numbers

3.5-inch/1-inch

250 GB to 1 TB

WD1002FBYS

WD7502ABYS

WD5002ABYS

WD3202ABYS

WD2502ABYS

Note: Not all products

may be available in all

regions of the world.

WD RE3 7200 RPM Enterprise SATA hard drives are packed with

performance and reliability features making them the perfect solution for

servers, video surveillance, and other demanding write-intensive applications.

With a designed, manufactured and demonstrated MTBF of 1.2 million hours

at 100% duty cycle in nominal enterprise conditions, up to 32 MB cache, and

best-in-class vibration tolerance, these drives are the ultimate in Enterprise

SATA storage.

Product Benefits

Massive capacity - WD RE3 Enterprise SATA drives are available in capacities up to 1 TB.

Dual processor - Twice the processing power delivers best-in-class performance for

demanding Enterprise applications.

RAFF™ - Our fourth generation RAFF technology includes sophisticated electronics to

monitor the drive and correct both linear and rotational vibration for up to a 60% performance

improvement in high vibration environments over the previous generation of drives.

IntelliSeek™ - Calculates optimum seek speeds to lower power consumption, noise, and

vibration in active seek modes without degrading performance.

StableTrac™ - The motor shaft is secured at both ends to reduce system-induced vibration

and stabilize platters for accurate tracking during read and write operations. (750 GB and

above)

Multi-axis shock sensor - Automatically detects the subtlest shock events and

compensates to protect the data.

RAID-specific, time-limited error recovery (TLER) - Prevents drive fallout caused by the

extended hard drive error-recovery processes common to desktop drives.

Third generation dynamic fly height - Each read-write head’s fly height is adjusted in real

time for optimum reliability.

Thermal extended burn-in test - Each drive is put through extended burn-in testing with

thermal cycling to ensure reliable operation.

NoTouch™ ramp load technology - The recording head never touches the disk media

ensuring significantly less wear to the recording head and media as well as better drive

protection in transit.

Perpendicular Magnetic Recording (PMR) - WD RE3 Enterprise SATA drives utilize PMR

technology to achieve even greater areal density, reliability, and design margin.

5-year limited warranty

Applications

Ideal for servers, storage arrays, video surveillance, and other demanding applications.

The WD Promise

WD understands the importance of the information you save to your hard

drive and we are committed to protecting that data with exceptionally reliable

products, advanced data protection technology, and superior customer support.

No one does more to safeguard your data than WD.

7200 RPM

SATA

WD RE3

Enterprise Hard Drives

High Performance

24x7 Reliability

1.2 Million Hours MTBF

Enterprise Hard Drives

For service and literature:

support.wdc.com

www.westerndigital.com

Western Digital, WD, and the WD logo are registered

trademarks in the U.S. and other countries; and

IntelliSeek, StableTrac, NoTouch, the FIT Lab logo,

and RAFF are trademarks of Western Digital

Technologies, Inc. Other marks may be mentioned

herein that belong to other companies. Product

specifications subject to change without notice.

Western Digital

20511 Lake Forest Drive

Lake Forest, California 92630

U.S.A

2879-701281-A06 Nov 2008

800.ASK.4WDC North America

800.832.4778 Spanish

+800.6008.6008 Asia Pacific

00800.27549338 Europe

(toll free where available)

+31.880062100 Europe/Middle East/Africa

1 As used for storage capacity, one megabyte (MB) = one million bytes, one gigabyte (GB) = one billion bytes, and one terabyte (TB) = one trillion bytes. Total

accessible capacity varies depending on operating environment. As used for buffer or cache, one megabyte (MB) = 1,048,576 bytes. As used for transfer rate or

interface, megabyte per second (MB/s) = one million bytes per second, and gigabit per second (Gb/s)= one billion bits per second. Effective maximum SATA 3

Gb/s transfer rate calculated according to the Serial ATA specification published by the SATA-IO organization as of the date of this specification sheet. Visit

www.sata-io.org for details.

2WD products manufactured and sold worldwide after August 1, 2005, meet or exceed Restriction of Hazardous Substances (RoHS) compliance requirements as

mandated by the European Union for electrical and electronic products. The RoHS Directive 2002/95/EC of the European Parliament, which is effective in the EU

beginning July 1, 2006, aims to protect human health and the environment by restricting the use of certain hazardous substances in new equipment, and consists

of restrictions on lead, mercury, cadmium, and other substances.

3Controlled unload at ambient condition.

4The term of the limited warranty may vary by region. Visit support.wdc.com/warranty for details.

5No non-recoverable errors during operating test or after non-operating tests.

6Sound power level.

WD RE3

Enterprise Hard Drives

Specifications11 TB 750 GB 500 GB 320 GB 250 GB

Model number WD1002FBYS WD7502ABYS WD5002ABYS WD3202ABYS WD2502ABYS

Interface SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s

Formatted capacity 1,000,204 MB 750,156 MB 500,107 MB 320,072 MB 251,059 MB

User sectors per drive 1,953,525,168 1,465,149,168 976,773,168 625,142,448 490,350,672

Native command queuing Yes Yes Yes Yes Yes

SATA latching connector Yes Yes Yes Yes Yes

Actuator latch/auto park Yes Yes Yes Yes Yes

Form factor 3.5-inch 3.5-inch 3.5-inch 3.5-inch 3.5-inch

RoHS compliant2Yes Yes Yes Yes Yes

Performance

Data transfer rate (max)

Buffer to host

Host to/from drive (sustained)

3 Gb/s

113 MB/s

3 Gb/s

113 MB/s

3 Gb/s

113 MB/s

3 Gb/s

118 MB/s

3 Gb/s

118 MB/s

Cache (MB) 32 32 16 16 16

Average latency (ms) 4.2 4.2 4.2 4.2 4.2

Rotational speed (RPM) 7200 7200 7200 7200 7200

Average drive ready time (sec) 17 17 11 6.5 6.5

Configuration/Organization

Heads/disks 6/3 5/3 4/2 2/1 2/1

Bytes per sector (STD) 512 512 512 512 512

Reliability/Data Integrity

Load/unload cycles3300,000 300,000 300,000 300,000 300,000

Non-recoverable read errors per bits read <1 in 1015 <1 in 1015 <1 in 1015 <1 in 1015 <1 in 1015

Limited warranty (years)455555

Power Management

12VDC (A, max) 2.1 2.1 2.1 2.1 2.1

Average power requirements (W)

Read/Write

Idle

Standby

Sleep

8.0

7.2

0.85

8.0

7.2

0.85

7.1

6.6

0.85

5.5

5.1

0.85

5.5

5.1

0.85

Environmental Specifications5

Temperature (°C)

Operating

Non-operating

0 to 60

-40 to 70

0 to 60

-40 to 70

0 to 60

-40 to 70

0 to 60

-40 to 65

0 to 60

-40 to 65

Shock (Gs)

Operating (2 ms, read)

Operating (2 ms, read/write)

Non-operating (2 ms)

250

300

350

Average acoustics (dBA)6

Idle mode

Performance seek mode

Quiet seek mode

Physical Dimensions

Height (in./mm, max) 1.028/26.1 1.028/26.1 1.028/26.1 1.028/26.1 1.028/26.1

Length (in./mm, max) 5.787/147 5.787/147 5.787/147 5.787/147 5.787/147

Width (in./mm, ± .01 in.) 4/101.6 4/101.6 4/101.6 4/101.6 4/101.6

Weight (lb./kg, ± 10%) 1.52/0.69 1.52/0.69 1.39/0.63 0.97/0.44 0.97/0.44
