Instruction Manual

EN 1004-2 en

Mobile Aluminium Trade

Platform and Tower System

3T - Through the Trapdoor Method

MiniMax®

PN00063300_Minimax_IM_RevD 0522.indd 1PN00063300_Minimax_IM_RevD 0522.indd 1 01/06/2022 10:5401/06/2022 10:54

MiniMax Instruction Manual

PN00063300_Minimax_IM_RevD 0522.indd 2PN00063300_Minimax_IM_RevD 0522.indd 2 01/06/2022 10:5401/06/2022 10:54

minimaxtower.com

Contents

1Safety First

1.1 Introduction 2

1.2 Tower Designation 3

1.3 Maintenance - Storage - Transport 3

2Building the Tower

2.1 Pre-Assembly Checks 4

2.2 Component Diagram 6

2.3 Quantity Schedule 7

2.4 Stabilisers 8

2.5 Adjustable Legs 8

2.6 Assembly 9

2.6.1 Assembly Procedure for 0.6m Tower 10

2.6.2 Assembly Procedure for 1.7m Tower 13

2.6.3 Assembly Procedure for 3.7m Tower 16

2.6.4 Assembly Procedure for 5.8m Tower 22

2.6.5 Fitting Toe Boards 29

2.7 Dismantling 29

3 Using the Tower

3.1 Safety Checklist 30

3.2 Pre-Use Checklist 30

3.3 Use 31

3.4 Movement Of The Assembled Prefabricated Tower Scaffold 34

PN00063300_Minimax_IM_RevD 0522.indd 1PN00063300_Minimax_IM_RevD 0522.indd 1 01/06/2022 10:5401/06/2022 10:54

2MiniMax Instruction Manual

1 Safety First

1.1 Introduction

Please read this instruction manual carefully.

This instruction manual shall be available at the location of use of

this mobile access tower. Instruction manuals are also available to

download at www.minimaxtower.com.

This product shall only be used in accordance with this manual without any

modiﬁcation.

FAILURE TO FOLLOW THESE INSTRUCTIONS MAY LEAD TO

DEATH OR SERIOUS INJURY.

Mobile access towers must always be used in accordance with the national

regulations. If any aspect of these instructions conﬂicts with local regulations please

contact Werner UK Sales & Distribution Ltd. for advice.

Please note that diagrams are for illustrative purposes only.

User training courses are available, but must not be used as a substitute for

familiarity with this manual.

The MiniMax mobile aluminium tower is a light-weight scaffold tower used

throughout the building and construction industry for both indoor and outdoor access

solutions where a stable and secure platform is required. Ideal for maintenance and

installation work or short-term access, the highly versatile towers provide a strong

working platform for a variety of heights.

Veriﬁcation and assessment documentation is held by Werner UK Sales &

Distribution Ltd.

Compliances

The MiniMax mobile tower system has been designed, tested,

approved and certiﬁed to EN 1004-1:2020.

This instruction manual is in compliance with EN 1004-2-en.

PN00063300_Minimax_IM_RevD 0522.indd 2PN00063300_Minimax_IM_RevD 0522.indd 2 01/06/2022 10:5401/06/2022 10:54

minimaxtower.com

1 Safety First

1.2 Tower Designation

Design Code

Load Class (2 = 153kg/m2UDL, 3 = 204kg/m2UDL)

Max. Platform Height Outdoors (m)

Max. Platform Height Indoors (m)

Access Method

A = Stairway, B = Stair ladder, C = Inclined Ladder, D = Vertical Ladder

Clear Height Class (H1 = 1.85m, H2 = 1.90m)

*UDL = Uniformly distributed load

EN 1004 3 6 / 6 XXXD H2

1.3 Maintenance - Storage – Transport

•The MiniMax mobile tower system is robust and requires little maintenance.

•All components and their parts should be regularly inspected to identify

damage, particularly to joints.

•Refer to the MiniMax Inspection Guidance for detailed inspection and

maintenance advice, the guidance is available to download at:

www.minimaxtower.com.

•Threads, hinges, and brace latches may be lubricated with light oil. Ensure oil

does not contaminate climbing or walking surfaces.

•Safety labels should be kept legible. Replacement labels are available from

Werner UK Sales & Distribution Ltd.

•Surfaces should be kept reasonably free of dried paint, plaster etc.

•Use of solvents on wooden platform surfaces and plastic components should

be avoided.

•Components should be stored in clean, dry conditions with due care to prevent

damage.

•During transportation ensure components are not damaged by excessive

strapping forces.

PN00063300_Minimax_IM_RevD 0522.indd 3PN00063300_Minimax_IM_RevD 0522.indd 3 01/06/2022 10:5401/06/2022 10:54

4MiniMax Instruction Manual

2 Building The Tower

2.1 Pre-Assembly Checks

•Check overhead that the area into which the structure is to be erected contains

no obstructions, particularly electrical or radio radiation hazards. The structure is

conductive.

•Ensure the ground on which the mobile access tower is to be erected is capable

of supporting the tower in use.

•Check the surface is level to 0.6°. If not the optional adjustable leg kit must be

used. This allows adjustment up to 210mm.

•Only components speciﬁed in this manual shall be used with MiniMax towers.

Check all required components are onsite and in a suitable working condition.

•Damaged components shall not be used and must

be put beyond use and disposed of according to local

regulations.

•Adjustable legs should only be used for levelling purposes and never to gain

extra height.

•Ensure distance from the ground to ﬁrst climbing rung is less than 400mm.

•Only climb the tower from the inside using the access

method provided.

•This tower provides a work platform. It must not be

used to access other structures.

•Tower scaffolds are not designed to be lifted or suspended.

•Ensure the safe working load on the structure is not exceeded.

5mm

PN00063300_Minimax_IM_RevD 0522.indd 4PN00063300_Minimax_IM_RevD 0522.indd 4 01/06/2022 10:5401/06/2022 10:54

minimaxtower.com

•Tools and materials should be lifted using a reliable lifting material (e.g. a strong

rope) employing a reliable knot (e.g. clove hitch) to ensure safe fastening and

always lift within the footprint of the prefabricated tower scaffold (i.e. within the

area bounded by the stabilisers).

•Check this manual is available and its contents familiar to all those involved.

•If assembling outdoors; check the forecast windspeed.

º The assembled tower is certiﬁed to wind forces

equating to 27mph, but handling components under

those conditions would be hazardous.

º Also consider the wind funnelling effect of nearby

buildings.

•This structure is designed to be self-supporting under the loading condition

requirements of EN 1004-1:2020 and does not require tying in. Consideration

should be given to potential wind conditions if the tower is left unattended.

2 Building The Tower

27mph

12m/sec

PN00063300_Minimax_IM_RevD 0522.indd 5PN00063300_Minimax_IM_RevD 0522.indd 5 01/06/2022 10:5401/06/2022 10:54

6MiniMax Instruction Manual

2.2 Component Diagram

2 Building The Tower

2 Rung

Guardrail

Frame

End Toe

Board

8 Rung

Frame

Folding

Base

Frame

Castor Adjustable

Leg

Diagonal

Brace

Side Toe

Board

Horizontal

Brace

Instruction

Manual

Trapdoor

Platform

Stabiliser

PN00063300_Minimax_IM_RevD 0522.indd 6PN00063300_Minimax_IM_RevD 0522.indd 6 01/06/2022 10:5401/06/2022 10:54

minimaxtower.com

Internal or External Use

Composite

Code 38060600 38061700 38063700 38065800

Working

Height 2.6m 3.7m 5.7m 7.8m

Component

Code Component

Description Component

Weight Platform

Height 0.6m 1.7m 3.7m 5.8m

00060000 Folding Base Frame Mk2 17.6kg 1 1 1 1

37751800 Trapdoor Platform 11.8kg 1 1 2 3

00061600 8 Rung Frame 7.0kg - - 2 4

00061800 2 Rung Guardrail Frame 2.6kg - 2 2 2

00061000 Diagonal Brace 1.9kg - 1 3 5

00062100 Horizontal Brace 1.8kg 3 5 9 13

00063700 Side Toe Board 2.5kg 2 2 2 2

00062900 End Toe Board 1.0kg 2 2 2 2

67040100 SP4 Stabiliser* 4.4kg 4 - - -

31751300 SP7 Stabiliser 3.8kg - 4 4 -

31851300 SP10 Stabiliser 8.8kg - - - 4

33551300 Adjustable Leg** 1.1kg 4 4 4 4

*SP4 stabiliser can be substituted for SP7 stabiliser at 1.7m and 3.7m platform heights.

**Adjustable legs only required if ground is uneven or sloping.

2 Building The Tower

2.3 Quantity Schedule

Internal or External Use

Composite Code 38060600 38061700 38063700 38065800

Pack Code Pack Working Height 2.6m 3.7m 5.7m 7.8m

Platform Height 0.6m 1.7m 3.7m 5.8m

37051800 Base Pack Mk2 1 1 1 1

00062100 Horizontal Brace 3 3 3 3

37251800 2 Rung Guardrail Pack Mk2 - 1 1 1

34151800 2m Extension Pack - - 1 2

67040100 SP4 Stabiliser* 4 - - -

31751300 SP7 Stabiliser - 4 4 -

31851300 SP10 Stabiliser - - - 4

37951800 Adjustable Leg Pack** 1 1 1 1

39451800 Toe Board Pack Mk2 1 1 1 1

Tower Total Self-weight 62.6kg 70.9kg 107.7kg 164.5kg

Max. Exerted Leg Load 82.0kg 90.0kg 99.0kg 107.0kg

Quantity Schedule in Packs

Quantity Schedule in Components

PN00063300_Minimax_IM_RevD 0522.indd 7PN00063300_Minimax_IM_RevD 0522.indd 7 01/06/2022 10:5401/06/2022 10:54

8MiniMax Instruction Manual

2.4 Stabilisers

Platform Height X Y

0.6m 2.06m 2.06m

1.7m 2.77m 2.96m

3.7m 2.77m 2.96m

5.8m 4.42m 4.42m

90%

SP4 and SP10 stabilisers must always be fully extended.

Position the lower clamp so that the arm is as close to horizontal as possible. Adjust

the position of the top clamp to ensure the stabiliser foot is in ﬁrm contact with the

ground. Ensure the clamps are secure.

2.5 Adjustable Legs

If the ground is uneven or sloping you will need to ﬁt

adjustable legs. Turn the base unit upside down so

that the wheels are facing upwards. We recommend

that two persons are required to ease the process.

Using a 19mm spanner loosen the ﬁxing bolt and

remove the castor from the base.

Follow the instructions in the adjustable leg pack to

change the large castor spigot to the smaller one supplied in the

pack. Insert the castor into an adjustable leg and then retighten

the ﬁxing bolt with the spanner, following the instructions. Repeat

this process for the other castors and adjustable legs. Insert the

four leg and castor assemblies into the base unit.

Turn the base the correct way up with the wheels on the ground.

Use a spirit level to check the base unit is level.

Adjust the legs as necessary, to level the base unit.

Important - Only use the adjustable legs to level the base

and not to gain extra height.

2 Building The Tower
