IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use
your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to contact us:
For replacement parts and the most up-to-date instruction manuals, visit WENPRODUCTS.COM
MULTIPURPOSE PLANER
MITER SAW STAND
Instruction Manual
MODEL MSA658
2
CONTENTS
WELCOME 3
Introduction ..................................................................................................... 3
Specifications................................................................................................... 3
SAFETY 4
General Safety Rules........................................................................................ 4
Planer-Miter Saw Safety Warnings................................................................... 6
BEFORE OPERATING 7
Unpacking & Packing List.................................................................................7
Know Your Planer-Miter Saw Stand ................................................................. 8
Assembly & Adjustments..................................................................................9
OPERATION & MAINTENANCE 12
Operation ....................................................................................................... 12
Exploded View & Parts List.............................................................................13
Warranty Statement ....................................................................................... 15
3
SPECIFICATIONS
Model Number MSA658
Stand Height 29.3 in.
Tabletop Capacity 220 lbs. (Evenly Distributed)
Tabletop Dimensions 22.7 in. x 22.7 in.
Distance Between Support Arms 24.8 in. - 54.3 in.
Shelf Capacity 55 lbs. (Evenly Distributed)
Shelf Dimensions 22.5 in. x 16.5 in.
Weight 58.8 lbs.
INTRODUCTION
Thanks for purchasing the WEN Planer-Miter Saw Stand. We know you are excited to put your tool to work, but first,
please take a moment to read through the manual. Safe operation of this tool requires that you read and understand
this operator’s manual and all the labels affixed to the tool. This manual provides information regarding potential
safety concerns, as well as helpful assembly and operating instructions for your tool.
NOTE: The following safety information is not meant to cover all possible conditions and situations that may occur.
WEN reserves the right to change this product and specifications at any time without prior notice.
At WEN, we are continuously improving our products. If you find that your tool does not exactly match this manual,
please visit wenproducts.com for the most up-to-date manual or contact our customer service at 1-800-232-1195.
Keep this manual available to all users during the entire life of the tool and review it frequently to maximize
safety for both yourself and others.
SAFETY ALERT SYMBOL: Indicates danger, warning, or caution. The safety symbols and the explanations
with them deserve your careful attention and understanding. Always follow the safety precautions to reduce the
risk of fire, electric shock or personal injury. However, please note that these instructions and warnings are not
substitutes for proper accident prevention measures.
4
GENERAL SAFETY RULES
WORK AREA SAFETY
1. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
2. Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable liquids,
gases or dust. Power tools create sparks which may ig-
nite the dust or fumes.
3. Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
1. Power tool plugs must match the outlet. Never mod-
ify the plug in any way. Do not use any adapter plugs
with earthed (grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric shock.
2. Avoid body contact with earthed or grounded surfac-
es such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body
is earthed or grounded.
3. Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of elec-
tric shock.
4. Do not abuse the cord. Never use the cord for car-
rying, pulling or unplugging the power tool. Keep cord
away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric
shock.
5. When operating a power tool outdoors, use an ex-
tension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric
shock.
6. If operating a power tool in a damp location is un-
avoidable, use a ground fault circuit interrupter (GFCI)
protected supply. Use of a GFCI reduces the risk of elec-
tric shock.
PERSONAL SAFETY
1. Stay alert, watch what you are doing and use com-
mon sense when operating a power tool. Do not use a
power tool while you are tired or under the influence
of drugs, alcohol or medication. A moment of inatten-
tion while operating power tools may result in serious
personal injury.
2. Use personal protective equipment. Always wear
eye protection. Protective equipment such as a respira-
tory mask, non-skid safety shoes and hearing protection
used for appropriate conditions will reduce the risk of
personal injury.
3. Prevent unintentional starting. Ensure the switch is
in the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or
energizing power tools that have the switch on invites
accidents.
4. Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal
injury.
5. Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or jew-
elry. Keep your hair and clothing away from moving
parts. Loose clothes, jewelry or long hair can be caught
in moving parts.
Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool”
in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
SAVE THESE SAFETY INSTRUCTIONS.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
5
GENERAL SAFETY RULES
7. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
POWER TOOL USE AND CARE
1. Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
2. Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
3. Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
4. Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained us-
ers.
5. Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s opera-
tion. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained
power tools.
6. Keep cutting tools sharp and clean. Properly main-
tained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits, etc.
in accordance with these instructions, taking into ac-
count the working conditions and the work to be per-
formed. Use of the power tool for operations different
from those intended could result in a hazardous situa-
tion.
8. Use clamps to secure your workpiece to a stable
surface. Holding a workpiece by hand or using your
body to support it may lead to loss of control.
9. KEEP GUARDS IN PLACE and in working order.
SERVICE
1. Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is main-
tained.
CALIFORNIA PROPOSITION 65 WARNING
Some dust created by power sanding, sawing, grinding,
drilling, and other construction activities may contain
chemicals, including lead, known to the State of Califor-
nia to cause cancer, birth defects, or other reproductive
harm. Wash hands after handling. Some examples of
these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement, and other
masonry products.
• Arsenic and chromium from chemically treated
lumber.
Your risk from these exposures varies depending on
how often you do this type of work. To reduce your ex-
posure to these chemicals, work in a well-ventilated area
with approved safety equipment such as dust masks
specially designed to filter out microscopic particles.
Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool”
in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
SAVE THESE SAFETY INSTRUCTIONS.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
6
PLANER-MITER SAW STAND SAFETY
1. Place the planer stand on a flat and level surface to
prevent rocking or tipping.
2. Do not climb, sit or stand on the stand.
3. Follow the assembly instructions carefully when in-
stalling the stand.
4. This product is designed to be used as a stand for
bench type power tools. Any misuse or abuse of the
stand can result in product damage or personal injury.
The tabletop will support weight up to 220 pounds and
the shelf will support weight up to 55 pounds. Do not
exceed the capacity of the stand.
4. The height of the power tool mounted to the stand
should not exceed the width of the tool in order to pre-
vent the stand from tipping over. The power tool must
be centered and properly secured to the planer stand.
Always check to make sure the stand and the power tool
are stable before operation.
6. Before attempting to use any tool on the stand, make
sure the stand is resting firmly on the floor in locked
position with the wheel raised.
7. Keep proper footing and balance at all times. Do not
overreach when operating the power tool.
PLANER-MITER SAW SAFETY WARNINGS
WARNING! Do not operate the power tool until you have read and understood the following instructions and
the warning labels.
UNPACKING
With the help of a friend or trustworthy foe, such as one of your in-laws, carefully remove the planer-miter saw stand
from the packaging and place it on a sturdy, flat surface. Make sure to take out all contents and accessories. Do not
discard the packaging until everything is removed. Check the packing list below to make sure you have all of the
parts and accessories. If any part is missing or broken, please contact customer service at 1-800-232-1195 (M-F
PACKING LIST
UNPACKING & PACKING LIST
Components
Tabletop (1)
Roller Supports (2)
Extension Arms (2)
Legs (4)
Shelf Brackets (2)
Pedal Assembly (1)
Shelf (1) Base Assembly (1)
Hardware
Lock Knobs (4)
Carriage Bolts (32)
Washers 8mm (38) Hex Nuts M8 (38)
Bolts M8x60
Partial Thread (2)
Self-Tapping
Screws (2)
Bolts M8x60
Full Thread (4)
7
KNOW YOUR PLANER-MITER SAW STAND
TOOL PURPOSE
Planer-miter saw stands give your planer, miter saw, and other benchtop tools the support, both physical and emo-
tional, they deserve. Refer to the following diagrams to become familiarized with all the parts and controls of your
planer-miter saw stand. The components will be referred to later in the manual for assembly and operation instruc-
tions.
PLANER-MITER STAND
Roller Support
Tabletop
Shelf
Base
Height Adjustment
Lock Knobs
Extension Arm
Foot Pedal
Wheel
8
9
What’s Needed:
What’s Needed:
ASSEMBLY & ADJUSTMENTS
INSTALLING THE LEGS
1. Place the tabletop on the floor, install one leg to a corner
of the table top using four carriage bolts (Fig. 1 - 1), four
M8 washers (Fig. 1 - 2) and four M8 hex nuts (Fig. 1 - 3).
Repeat with all four legs. Be sure to only finger tighten the
bolts to leave room for adjustments when attaching the
base.
INSTALLING THE EXTENSION ARMS
1. Insert the extension arms (Fig. 2 - 1) into the guide
brackets on each side of the table top and secure each with
a locking knob (Fig. 2 - 2). Add a self tapping screw (Fig.
2-3) to each extension arm to act as a stop. This will pre-
vent extending the extension arms too far.
Tabletop (1)
Legs (4)
Carriage
Bolts (16)
Washers (16)
Hex Nuts (16)
Extension Arms (2) Lock Knobs (2)
Self-Tapping
Screws (2)
Fig. 1
1
2
3
Fig. 2
1
1
2
3
What’s Needed:
ASSEMBLY & ADJUSTMENTS
INSTALLING THE PEDAL ASSEMBLY
1. Attach the pedal assembly (Fig. 4 - 1) to the base us-
ing two partially threaded hex bolts (Fig. 4 - 2), two 8mm
washers (Fig. 4 - 3) and two M8 hex nuts (Fig. 4 - 4). The
wheel should be positioned inside the base assembly.
What’s Needed:
INSTALLING THE BASE
1. Attach the table top and leg assembly to the base. Se-
cure each of the four corners with two carriage bolts (Fig.
3 - 1), four 8mm washers (Fig. 3 - 2) and four M8 hex nuts
(Fig. 3 - 3). After setting the position, fully tighten all 24
bolts connecting the legs with the tabletop and the base
assembly.
NOTE: Determine if you plan to primarily use the stand for
a planer or a miter saw. If using stand for a planer, install
the table top such that the arms will be perpendicular to the
wheels. If using stand for a miter saw, install the table top
such that the arms will be parallel to the wheels (Fig. 8).
Carriage
Bolts (8) Washers (8)
Hex Nuts (8)
Base Assembly (1)
Pedal Assembly (1)
Hex Nuts (2)
Bolts M8x60
Partial Thread (2)
Washers (2)
Fig. 3
1
2
3
Fig. 4
1
2
34
10
