Weider WEMC0943.0 Manual de usuario

CAUTION

Read all precautions and instruc-

tions in this manual before

using this equipment. Save this

manual for future reference.

Model No. WEMC0943.0

Serial No.

Write the serial number in the

space above for future reference.

QUESTIONS?

As a manufacturer, we are com-

mitted to providing complete

customer satisfaction. If you

have questions, or if a part is

damaged or missing, PLEASE

CONTACT OUR CUSTOMER

SERVICE DEPARTMENT

DIRECTLY.

CALL TOLL-FREE:

1-877-992-5999

Mon.–Fri., 6 a.m.–6 p.m. MST

ON THE WEB:

www.weiderservice.com

Visit our website at

www.weiderfitness.com

new products, prizes,

fitness tips, and much more!

USER’S MANUAL

MAX by WEIDER is a trademark of ICON IP, Inc.

IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

PART LIST/EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover

LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover

TABLE OF CONTENTS

WARNING:To reduce the risk of serious injury, read the following important precautions

before using the resistance system.

IMPORTANT PRECAUTIONS

1. Read all instructions in this manual and in the

literature accompanying the resistance sys-

tem before using the resistance system. Use

the resistance system only as described in

the literature.

2. It is the responsibility of the owner to ensure

that all users of the resistance system are

adequately informed of all precautions.

3. Keep children under 12 and pets away from

the resistance system at all times.

4. Keep hands and feet away from moving parts.

5. Use only the resistance included with a MAX

PACK.Do not use other types of weight with

the resistance system.

6. When adding resistance, both ends of the

resistance bar must rest under the two “U”-

channels. Add and remove resistance bars

from the “U”-channels one resistance bar at a

time.

7. Keep clear of the area around the “U”-chan-

nels while the resistance system is in use. Do

not add or remove resistance bars from the

“U”-channels while the end of the long cable

is pulled out.

8. Make sure that all parts are properly tight-

ened each time the resistance system is

used. Replace any worn parts immediately.

9. If you feel pain or dizziness at any time while

exercising, stop immediately and begin cool-

ing down.

WARNING: Before beginning this or any exercise program, consult your physician. This

is especially important for persons over the age of 35 or persons with pre-existing health problems.

Read all instructions before using. ICON assumes no responsibility for personal injury or property

damage sustained by or through the use of this product.

BEFORE YOU BEGIN

Thank you for selecting the MAX by WEIDER™resis-

tance system MAX PACK accessory. The MAX by WEI-

DER uses progressive resistance. As the resistance

bars begin to bend, the amount of resistance will

increase gradually. As the resistance bars bend further,

the resistance will increase rapidly. The MAX PACK is

designed to increase the amount of resistance avail-

able on the MAX by WEIDER resistance system.

For your benefit, read this manual carefully before

using the MAX PACK and the resistance system. If

you have questions after reading this manual, see the

front cover of this manual. To help us assist you,

please note the product model number and serial

number before calling. The model number is

WEMC0943.0. The serial number can be found on the

product packaging. Record the serial number on the

front cover of this manual.

To avoid a registration fee for any service needed

under warranty,you must register the MAX PACK

accessory at www.weiderservice.com/registration.

ASSEMBLY

Attach a Cap (2) to one end of the 200-pound

Resistance Bars (1) with a #8 x 1/2” Flat Head

Screw (3). Repeat with the other Caps.

2. Locate the Tray (B) on the resistance system.

Remove the two indicated Button Head Screws (C)

and the Cover Plate (A) from the Tray. Note: The

resistance bar assembly is shown removed

from the resistance system for clarity.

3. Remove the 80-pound Top Resistance Bar (D)

from the Cover Plate (A) by removing the two

Screws (E).

Before beginning assembly, make sure that

you have read and understand the informa-

tion in the box above.

Before beginning assembly, carefully read the

following information and instructions:

•Assembly requires two persons.

•Tighten all parts as you assemble them, unless

instructed to do otherwise.

•Make sure all parts are oriented as shown in the

drawings.

•Place all parts in a cleared area and remove the

packing materials. Do not dispose of the packing

materials until assembly is completed.

The following tools (not included) are required

for assembly:

• One standard screwdriver

• One Phillips screwdriver

• One Allen wrench (included

with the MAX by WEIDER

resistance system)

6. Make sure that all parts have been properly tightened. To use the MAX PACK to add resistance, refer

to ADJUSTING THE RESISTANCE in the MAX by WEIDER user’s manual.

5. Reattach the Cover Plate (A) to the Tray (B) with

the two Button Head Screws (C) removed in step

2. Note: Make sure the decal is over the

removable resistance bars.

Decal

Removable

Resistance

Bars

4. Attach the 200-pound Resistance Bars (1) to the

Cover Plate (A) with the two Screws (E) removed

instep 3. Make sure the Cover Plate is oriented

with the edges up.

Edges

PART LIST/EXPLODED DRAWING—Model No. WEMC0943.0 R1005A

1 1 200-pound Resistance Bars

24 Cap

3 4 #8 x 1/2” Flat Head Screw

#1 User’s Manual

Key No. Qty. Description Key No. Qty. Description

Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice.

To order replacement parts, see the front cover of this manual. To help us assist you, please be prepared to give

the following information:

• the MODEL NUMBER of the product (WEMC0943.0)

•the NAME of the product (MAX by WEIDER resistance system MAX PACK accessory)

• the SERIAL NUMBER of the product (see the front cover of this manual)

• the KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST and EXPLODED DRAWING on page

6of this manual)

ORDERING REPLACEMENT PARTS

ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and

material, under normal use and service conditions. ICON warrants all parts for five (5) years. This war-

ranty extends only to the original purchaser.ICON's obligation under this warranty is limited to replacing

or repairing, at ICON's option, the product through one of its authorized service centers. All repairs for

which warranty claims are made must be pre-authorized by ICON. If the product is shipped to a service

center, freight charges to and from the service center will be the customer’s responsibility. For in-home

service, the customer will be responsible for a minimal trip charge. This warranty does not extend to any

product or damage to a product caused by or attributable to freight damage, abuse, misuse, improper or

abnormal usage or repairs not provided by an ICON authorized service center; products used for com-

mercial or rental purposes; or products used as store display models. No other warranty beyond that

specifically set forth above is authorized by ICON.

ICON is not responsible or liable for indirect, special or consequential damages arising out of or in con-

nection with the use or performance of the product or damages with respect to any economic loss, loss

of property,loss of revenues or profits, loss of enjoyment or use, costs of removal or installation or other

consequential damages of whatsoever nature. Some states do not allow the exclusion or limitation of inci-

dental or consequential damages. Accordingly, the above limitation may not apply to you.

The warranty extended hereunder is in lieu of any and all other warranties and any implied warranties of

merchantability or fitness for a particular purpose is limited in its scope and duration to the terms set forth

herein. Some states do not allow limitations on how long an implied warranty lasts. Accordingly, the above

limitation may not apply to you.

This warranty gives you specific legal rights. You may also have other rights which vary from state to state.

ICON HEALTH & FITNESS, INC., 1500 S. 1000 W., LOGAN, UT 84321-9813

LIMITED WARRANTY
