Watchguard DVR4ENTPACK Manual de usuario

MODEL: DVR4ENTPACK

Professional Surveillance Pack

Digital Video Recorder with 4 Security Cameras

‘QUICK INSTALLATION GUIDE’

DVR 2 x Cameras –30m Infrared range for night operation

- Advanced MPEG4 Video Compression Technology - High Quality CCD Image sensor

- MultiplexOperation - 24xIRLED’s

- Long Recording Duration - 420 TVL Resolution, 520 x 582 Pixels

- Intelligent Video Motion Detection Recording 2 x Cameras –15m Infrared range for night operation

- Remote Network Surveillance & Backup Functions - High Quality CCD Image sensor

- Easy to operate like a VCR - 12 x IR LED’s

- System Auto recovery after power loss (blackout) - 420 TVL Resolution, 520 x 582 Pixels

N517

www.watchguardalarms.com.au

Package Contents (Before commencing installation, please ensure you have all the parts listed below.)

Monitor

* Note: If you wish to connect directly from the DVR to a PC you require a crossover cable (Not Included)

Installation

Before installing this unit, please read through the following points:

• Do not place cords from the AC adapter where they can be pinched or stepped on.

• Do not place heavy objects on cords, or cover cords with rugs or carpet.

• Never immerse any component in water, and do not spray cleaners of solvents on the unit. Unplug

units before cleaning. When cleaning, use a damp, lint-free cloth only.

• Do not expose the DVR or Camera’s to excessive heat, cold, or moisture

• Leave at least a 2” space between the DVR and other objects to allow air circulation around the unit.

• Service should be handled by qualified technicians.

Connection Guide

1. Locate the 4 Cameras as required and connect the supplied combination DC Power and Video

leads. (Yellow to Yellow / Red to Red)

2. Connect the 4 x corresponding camera Video leads (Yellow) into the camera inputs at the rear of

the DVR (Take note of the Camera input 1 – 4, as this will determine the camera channels)

3. Connect the 4 x camera DC Power leads (RED) into the Power Split Cable

4. Connect the Monitor Connection Cable into the BNC Monitor output on the rear of the DVR.

5. Connect the Monitor Connection Cable into the RCA Video input on your TV/Monitor

(TV/Monitor Not Supplied) Note: (Requires composite video input monitor - not VGA)

6. Connect the 2Amp 19VDC Power adaptor to the DVR

7. Connect the 12VDC Power adaptor to the Power Split Cable.

8. Plug both Power adaptors into a 240Volt / AC Power Point and switch power point ON

9. The Power LED at the front of the DVR should now be illuminated Red and the unit will make a

loud beep sound.

WARNING

Please ensure you use

the correct power

supply for each

component.

DO NOT plug the 19V

DVR Power supply into

the cameras as this will

damage them.

Impedance

matching not

required with

this camera

package

Not used with

this camera

package Optional – Input/Output sensing

Not used with this package

Quick Start up Guide

• Make sure your TV/Monitor is ON and set to the appropriate AV channel if required

• Press the Power button located on the front panel of the DVR, the LED will illuminate Green

it takes approximately 10 to 15 seconds to boot the system.

• The images from all 4 cameras should now be displayed on your TV/Monitor

• BEFORE BEGINNING TO RECORD YOU MUST SET the DATE and TIME on your DVR.

Setting the Date and Time

• Press “MENU” button to enter the (OSD) On Screen Display menu list.

The default admin password is 0000.

Enter the default password by pressing “ENTER” 4 times.

(Users can alter the password later. Please refer to the Advanced set up guide CD)

• Use the following buttons to move the cursor for menu settings:

“UP=▲,DOWN=▼,LEFT=◄,RIGHT=►“

• Move the cursor to “DATE” and press, ”ENTER”. The screen will show the following options

(MENU)

RECORD

TIMER

ADVANCE

DATE 12 - MAY - 2006 16:30:00

FORMAT D-M-Y

DAYLIGHT SAVING ON

DOWN

LEFT RIGHT

Setting the Date and Time Cont…..

• Use the following buttons to set the correct Date and Time

(DAY / MONTH / YEAR / HOUR / MIN / SEC)

“▲▼◄► “ to move the cursor.

“＋”, “－” to choose the numbers / selections.

“ ENTER “ to go to the submenu / to confirm the selection

“ MENU “ to go to the menu OSD / to confirm the change / to exit the menu OSD

IMPORTANT NOTE: Please DO NOT change the date or time on your DVR after the recording function is

activated. The recorded data will be disordered and you will not be able to find the recorded file to backup by time

search.

NOTE:If users change the date or time accidentally when the recording function is activated, it’s recommended to

clear all HDD data, and start recording again.

Daylight Saving

• Specify whether to use daylight saving time and time period. (START / END)

• Daylight saving time can be adjusted manually.

• Enter the daylight saving menu mode to set the start time and the end time, and adjust hours of

the daylight saving.

NOTE: The illustrated setting means: During the daylight saving time period (start from the 4th Sunday of October,

end on the 4th Sunday of March), the DVR system time will add one hour.

To Begin Recording

Once you have successfully set the Date and Time, exit the OSD Menu by pressing the

“ MENU “ button until you return to normal viewing.

To begin recording check that you have images from all 4 x cameras and then press the “ REC “ button

located at the front of the DVR.

START 4TH-SUN-OCT 01: 00: 00

END 4TH-SUN-MAR 01: 00: 00

ADJUST 01 : 00

To Stop Recording

In the event you wish to stop recording press the “ MENU “ button located at the front of the DVR.

• Move the cursor to “RECORD” and press, ”ENTER”.

• The screen will show the following

• Select “MANUAL RECORD ENABLE” and press “ENTER”

• The screen will now show the following

• Move the cursor to “YES” and press “ENTER”

• The DVR will now stop recording until the REC button is pressed again

(MENU)

TIMER

DATE

ADVANCE

MANUAL RECORD ENABLE YES

EVENT RECORD ENABLE NO

TIMER RECORD ENABLE NO

OVERWRITE YES

RECORD IMG SIZE CIF

RECORD QUALITY BEST

MANUAL RECORD IPS 012

EVENT RECORD IPS 012

TIMER RECORD IPS 012

TOTAL IPS SHARE FIX

STOP RECORD

ARE YOU SURE ?

ES NO

Recording Options:

Recording Times

• This DVR is factory set to record “CIF Best Quality” at 3 frames per second, per camera, at a

resolution of 352 x 288 pixels. This will provide approximately 4 weeks of recording time on this

setting. Using Video Motion Detection or reducing image quality can achieve much longer record

times if required.

• This unit can be set up to record up to a maximum of 6.25 frames per second per camera in

“Frame Mode, 720 x 576 pixels, High Resolution” (MJPEG Compressoin) or 25 frames per

second per camera in “CIF Mode (Real Time),(MPEG4 Compression) 352 x 288 pixels”

(To alter the recording method please refer to the Advanced set up guide CD)

Recording Modes

The DVR offers three recording modes, MANUAL RECORD, EVENT RECORD and TIMER RECORD.

** This unit is set to “Manual Record” by the factory.

( Please refer to the Advanced set up guide CD for details on how to change the recording mode)

MANUAL RECORDING (continuous recording) :

Recording is initiated by manually pressing the “REC” button, indicated by the sign “ ” on the screen.

EVENT RECORDING (triggered by motion and external alarm) :

When this function is activated, the recording is triggered by motion or external alarms, indicated by the

sign " " (motion) or " " (external alarm) on the screen.

TIMER RECORDING (scheduled time) :

Recording is scheduled by Timer, indicated by the sign “TIMER RECORD”.

Typical Viewing Screen

The image below shows a typical screen shot from an installation

Channel Title

Remaining Available

Capacity of Internal HDD

System Time

** Under HDD

Overwriting Mode

2006-MAY-12

[

FRI

]

16:18:43 78.5 GB

-OW-

●●Under Recording

IMPORTANT NOTE : If power is switched off accidentally or in the case of a black out, recorded video files will

still be still stored in the HDD. The DVR will return to the original recording status after power is turned on again.

** Overwriting View

When the HDD is full under “-OW-”

recording mode, the previous

recorded data may be overwritten

without further warning notice. Your

DVR will clear 8GB from the oldest

data for overwriting.

Unit is pre-set by factory with

Overwriting View Switched to on.

To Play Back Captured Video Footage

Press “ ” / “PLAY” button and the DVR will display the last recorded video.

FAST FORWARD (F.F. ) & FAST REWIND (REW):

You can increase the speed for fast forward and rewind on the DVR in the playback mode,

• Press “►►“ once to get 4X speed forward and press twice to get 8X speed, etc., and the

maximum speed is 32X.

• Press “◄◄“ once to get 4X speed rewind and press twice to get 8X speed, etc., and the

maximum speed is 32X.

SLOW PLAYBACK:

• Press “SLOW” button to get 1/2X speed playback.

PAUSE / IMAGE JOG:

• Press “ II “ button to pause the current image displayed on the screen.

In the Pause mode

• Press “►► “ once to get one frame forward

• Press “◄◄ “ once to get one frame rewind

CHANNEL SHIFT:

Display mode:

• Press MODE “ ” button to 4 channels display.

Full Screen Switch:

• Press “1” “2” “3” “4” buttons to show the full screen channels.

STOP:

• Pressing “ ■“ button under all circumstances will return DVR to live monitoring mode

The image below shows a typical Play-Back screen shot from an installation

●

The type of

recording

image size

(Frame or

CIF)

Play-Back

Time

(Time Of

Actual

Event)

006

-MAY-12

[

FRI

]

:12:

-OW-

●●

●

2006-MAY-12 [FRI] 16:18:43

FRAMEPLAY

Searching for data using Date and Time

You can also use the search function of the DVR to look back though stored data via date and time

• Press “SEARCH” button on the front panel of the DVR to enter the search mode.

• Then the screen will show the following options.

• Select “TIME SEARCH” from the menu,

• Enter the Date and Time (DAY / MONTH / YEAR / HOUR / MIN / SEC) of the event you wish to

view using the following buttons:

“▲▼◄► “ to move the cursor.

“＋”, “－” to choose the numbers / selections.

“ ENTER “ to go to the submenu / to confirm the selection

“ MENU “ to go to the menu OSD / to confirm the change / to exit the menu OSD

• Once you have entered the Date and Time move the cursor to the SELECT button and press

“ENTER”

• The DVR will then start playing back recorded data from the selected period, use the FAST

FORWARD / REWIND / PAUSE / SLOW PLAYBACK and CHANNEL SHIFT buttons on the unit

to navigate through the footage as required

• To finish viewing the playback, press the stop “ ■ ” button to return to the live display

HDD-MASTER-1

FULL LIST

RECORD LIST

SYSTEM LIST

ALARM LIST

MOTION LIST

EVENT SEARCH

TIME SEARCH

Operation

1 “LED LIGHTS”

HDD: HDD is reading or recording

HDD Full: HDD is full.

ALARM: Once the alarm is triggered

TIMER: When timer recording is turned on

PLAY: Under playing status

REC: Under recording status

2 “MENU” Press “MENU” button to enter the main menu.

3 “ENTER” / “SET”

Press “ENTER” button to confirm the setting.

Press “SET” to change the position of the channel display.

Press “▲▼◄►“ to select the channel which you would like to change.

Press “＋” or “－” to select the channel which You would like to show.

4 “REC” Press “REC” button to activate the manual recording.

5 “SEARCH” Press “SEARCH” button to enter the search menu.

6 “SLOW” Under the playback mode, press “SLOW“ button to show slow playback.

7 “ZOOM”

Press “ZOOM” button to enlarge the picture of selected channel (under the live

mode).

“ ” / “ －”

Press “ “ button to show the 4 channel display mode.

Press “ －” button to change the setting in the menu.

9 “SEQ” / “ ＋”

Press “SEQ” button to activate the call monitor function and press “SEQ” button

again to escape the call monitor mode.

Press “＋” button to change the setting in the menu.

“ “or “Power”

Press this button to turn (On / Off) the DVR.

(Under the recording mode, please stop recording before turning off the DVR).

11 “CH1 ” “CH2 ” “CH3 ” “CH4 ” Press “1” “2” “3” “4” buttons to select the channel to display

“ ”or “PLAY”

UP / PAUSE

DOWN / STOP

LEFT / REWIND

RIGHT / FAST FORWARD

Press “ “ to playback the recorded data.

Press “▲▼◄►“ to move the cursor up / down / left / right.

Under the playback mode, press “ II “ button to pause playback.

Under the playback mode, press “ ■“ button to stop playback.

Under the playback mode, press “►►“ button to fast forward.

Under the playback mode, press “◄◄“ button to fast rewind.

OPT SLOW & ZOOM Press these two buttons to select live or playback sounds of the audio channels.

OPT & SEQ Press these two buttons at the same time to enter / exit the PTZ control mode.

2 3 4 5 6 7 8 9

12 11 1 10

Tabla de contenidos

Otros manuales de Sistema de seguridad de Watchguard

Watchguard

Watchguard DVR4ENTPACK2 Manual de usuario

Watchguard

Watchguard DVR8E(PACK) Manual de usuario

Watchguard

Watchguard WGSIR-500W Manual de usuario

Watchguard

Watchguard DVR8ENTPACK4 Manual de usuario

Watchguard

Watchguard Firebox T35-R Instrucciones de instalación

Watchguard

Watchguard SMS 2010 WGSMS2010 Manual de usuario

Watchguard

Watchguard ALL-SIR2 Manual de usuario

Watchguard

Watchguard DVR4E(PACK) Manual de usuario

Watchguard

Watchguard Firebox III 700 Instrucciones de instalación

Watchguard

Watchguard ALL-PACK1 Manual de usuario

Watchguard

Watchguard Firebox T15 Instrucciones de instalación

Watchguard

Watchguard Firebox T30 Instrucciones de instalación

Watchguard

Watchguard CVRxE Manual de usuario

Watchguard

Watchguard DVR4ENTPACK4 Manual de usuario

Watchguard

Watchguard WGAP864 Manual de usuario

Watchguard

Watchguard DVR4EONPACK Manual de usuario

Watchguard

Watchguard DVR8ENTPACK3 Manual de usuario

Watchguard

Watchguard ALC-CAM2 Manual de usuario

Watchguard

Watchguard DVR4ENTPACK3 Manual de usuario

Watchguard

Watchguard DVR4ENTPACK7 Manual de usuario

Watchguard

Watchguard NVR4ENT(PACK)2 Manual de usuario

Watchguard

Watchguard DIGITAL V2 Manual de usuario

Watchguard

Watchguard DVR4EONPACK Manual de usuario

Watchguard

Watchguard N517Series II Manual de usuario

Manuales populares de Sistema de seguridad de otras marcas

Inner Range

Inner Range Concept 2000 Manual de usuario

Climax

Climax Mobile Lite R32 Instrucciones de montaje

CADDX

CADDX NX-6 Manual de usuario

FBII

FBII XL-31 Series Manual de usuario

Johnson Controls

Johnson Controls PENN Connected PC10 Manual de usuario

Aeotec

Aeotec Siren Gen5 Manual de usuario

Blaupunkt

Blaupunkt SA 2700 Manual de usuario

IDEAL

IDEAL Accenta Manual del propietario

AJAX

AJAX DoubleButton Manual de usuario

Swann

Swann SW-P-MC2 Manual de usuario

Ecolink

Ecolink Siren+Chime Manual de usuario

Digital Monitoring Products

Digital Monitoring Products XR150 Manual de usuario

EDM

EDM Solution 6+6 Wireless-AE Manual de usuario

Highway Safety Group

Highway Safety Group EA401 Manual de usuario

Siren

Siren LED GSM Manual de usuario

Detection Systems

Detection Systems 7090i Instrucciones de montaje

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manual de usuario

Siemens

Siemens FDM273 Manual de usuario
