WatchBot 3.0 Manual de usuario
User Guide
For the latest version of the user guide go to
www.watchbotcamera.com
Please visit www.watchbotcamera.com/guide
Motion Sensor Trigger Areas
for the most up to date information on the latest features
and conguring your WatchBot HD.
You can also download the latest version of the user guide.
Cloud Storage
Push Notications
WatchBot Overview
WatchBot Camera provides peace of mind to both home and
business users; the camera allows you to remotely view, monitor
and protect what’s important to you, even if you are thousands of
miles away.
Simple plug and play technology means you can be up and running
in less than 5 minutes. Connecting wirelessly to your existing net-
work, WatchBot can be placed anywhere in your home or business
environment.
Set up the camera and you can use your smartphone, tablet, laptop
or desktop to view live footage of the WatchBot’s surroundings. The
camera also allows for two-way audio communication and can be
remotely moved left, right, up and down. Use WatchBot to monitor
live video of the camera’s surroundings - or have WatchBot act as
an alarm, notifying you when unauthorised movement has been
detected.
With its night vision capabilities, you have total peace of mind, 24
hours a day, 7 days a week. The camera has an intelligent motion
sensor; if triggered it will send an alert to your smartphone, tablet,
laptop or desktop with screenshots as well as recording footage to
its on-board Micro SD card (not included), or any connected
computers - so you immediately know exactly what’s happening -
and you can have footage for use as evidence, if required.
WatchBot allows for up to 64 cameras to be monitored
simultaneously; view multiple locations around your home or
business premises - or any number of places in the world where you
place a camera.
i
www.watchbotcamera.com/support
ii
What's In The Box
1 WatchBot Camera
1 DC Power Supply
1 Wall Mounting Kit
1 Alarm Connection Adapter
1 RJ45 Ethernet Cable
1 User Guide
www.watchbotcamera.com/support
iii
Day/Night
Sensor
Camera Lens
(Twist to focus)
Pan and Tilt
Motion
Microphone
Ifra-red
LEDs
WiFi
Antenna
Built-in
speaker
I/O Connector
Power Input
Micro SD slot
Reset Button
Audio out
RJ45 Ethernet port
WatchBot Overview
www.watchbotcamera.com/support
iv
Quick Set Up Guide - Mobile Devices
1. Using the power adaptor supplied, plug one end to the power
connection of the WatchBot and the other end into an electrical
socket.
2. Connect your WatchBot camera directly to your router using the
supplied Ethernet cable.
3. Download the ocial WatchBot app for Android and iPhone here:
http://www.watchbotcamera.com/app
Or scan the QR code below
4. Open the app and tap Add New Camera.
5. Click Scan QR Code
6. Scan the QR barcode on the base of the camera.
7. Access and control your WatchBot camera.
It is highly recommended that a password is set as soon as possible
www.watchbotcamera.com/support
v
Quick Set Up Guide - Desktop Application
1. Using the power adaptor supplied, plug one end into the power
connection of the WatchBot and the other end into an electrical
socket.
2. Connect your WatchBot camera directly to your router using the
supplied Ethernet cable.
3. Visit http://www.watchbotcamera.com/app to download and
install the ocial WatchBot Desktop application.
4. Open the WatchBot application and click Preferences at the top
of the screen.
5. Click Camera List at the bottom left of the screen and click Add.
6. Input the username, password and camera ID details located on
the base of the camera and then click OK.
It is highly recommended that a password is set as soon as possible
7. Click Camera at the top left of the screen.
*Note: Linked cameras will be listed at the bottom of the screen.
8. Select the camera you wish to view and then click and drag it on
to the main window.
9. You can now view and control your WatchBot from your
connected device.
www.watchbotcamera.com/support
Quick Set Up Guide - Wireless Set up (Desktop)
This section assumes that you have successfully set up your
WatchBot and you are viewing the camera through the software.
To congure your WatchBot to work wirelessly, you must ensure:
i. The WatchBot is connected to the router with an Ethernet cable;
ii. The WatchBot is linked to the desktop application.
1. Open the desktop application and double click on the camera in
the bottom left corner to open the camera’s settings.
2. Click WiFi on the left hand menu.
3. Click Scan.
4. Select your WiFi network from the list of available WiFi networks
displayed on the right hand side.
5. Input your WiFi password.
6. Click Save and Apply. The WatchBot will take approximately 2
minutes to reboot.
7. Once restarted, disconnect the power and Ethernet cables from
the back of the WatchBot.
8. Reconnect the power cable only. The camera will reboot again
before establishing a connection to the WiFi network. Please
allow up to 5 minutes for the WatchBot to connect.
9. You can now view and control your WatchBot from your
connected device.
vi www.watchbotcamera.com/support
Quick Set Up Guide - Wireless Set up (Mobile)
This Section assumes that you have successfully set up the Watch-
Bot and you are viewing the camera through the mobile app.
To congure your WatchBot to work wirelessly, you must ensure:
i. The WatchBot is connected to the router with an Ethernet cable
ii. The WatchBot is linked to the mobile application.
1. Open the mobile app.
2. Click on the camera settings icon next to the camera.
3. Click WiFi.
4. Click Wireless Access Points to search your network
5. Select your WiFi network
6. Enter your WiFi password
7. Click Done
8. Once restarted, disconnect the power and Ethernet cables from
the back of the WatchBot.
9. Reconnect the power cable only. The camera will reboot again
before establishing a connection to the WiFi network. Please
allow up to 5 minutes for the WatchBot to connect.
10. You can now view and control your WatchBot from your
connected device.
vii
www.watchbotcamera.com/support
SECTION PAGE
WatchBot Overview i
What’s in the box i
Camera Overview ii
Quick set up - Mobile devices iii
Quick set up - Desktop application iv
Quick set up - Wireless v
Introduction and Safety 1
System Requirements 1
Network Requirements 1
PC Requirements 1
Restrictions 1
Maintenance and Protection 2
Product Overview 2
Basic Features 3
1. WatchBot Setup 4
1.1 The WatchBot Camera 4
1.2 WatchBot Software Installation 4
1.3 Connecting WatchBot Components 4
1.4 Connecting WatchBot 5
1.5 WiFi Conguration 11
2. Setting Passwords 13
3. Operator Controls 14
3.1 Directional Controls 16
3.2 WatchBot Patrol 16
3.3 External Alarm Switch 16
3.4 Infrared/Nightvision 16
3.5 Mirroring the Image 16
3.6 On-Screen Display (OSD) 16
3.7 Saving Presets 16
3.8 Audio and Video Features 16
Contents
www.watchbotcamera.com/support
