OPERATOR MANUAL
WMB-3250
Doc. P/N: WSP-009-004
Version: V1.3
Issue Date: August 2013
Doc. P/N: WSP-009-004
Version: V1.3
Issue Date: August 2013
www.wassp.com
Page 2 of 62
Operator Manual
Revision Date Reason for Change Version
7th May 2012 Initial Revision 1.0
29th August 2012 Imagery Update 1.1
11th December 2012 Numerous updates, corrections and additions for RTM3 1.2
30th July 2013 WMB-3250 Updates 1.3
Document Revision History
Warnings, Cautions, and Notes
Warnings, cautions, and notes are indicated by the following
icons throughout this manual:
A WARNING indicates that if the instruction is
not heeded, the action may result in loss of life
or serious injury.
A CAUTION indicates that if the instruction
is not heeded, the action may result in
equipment damage or software malfunction.
A Note indicates a tip or additional information that could be helpful
while performing a procedure.
Related Documents
Document P/Number Title
WSP-009-005 WMB-3250 Installation Manual
General Notices
WASSP Ltd. reserves the right to change the contents of
Contact WASSP Ltd. regarding copying or reproducing this
manual.
Safety Notices
The installer of the equipment is solely responsible for
the correct installation of the equipment. WASSP Ltd.
assumes no responsibility for any damage associated
with incorrect installation.
Electrical Safety
Fire, electrical shock, or equipment damage may occur if
the transceiver becomes wet.
The equipment is rated for operation at:
• BTxR 24 V DC
• WASSP PC 9 - 36 V DC
(Check the PC power supply to
verify this before connecting an
incorrect voltage!)
Make sure that the power is switched OFF at the main
supply (e.g. switchboard) before beginning the installation.
Fire or electrical shock may occur if the power is left ON.
Do not open equipment covers unless you are totally
familiar with the system’s electrical circuits.
Make sure all safety precautions for electrical equipment
are taken when operating or servicing the equipment.
These to be carried out in accordance with local or na-
tional regulatory body safety regulations.
Make sure that the transducer cannot become loosened or
insecure due to the vessel’s vibration.
Disclaimer
WASSP Ltd. reserve the right to change this manual
without notice. Although WASSP Ltd. has made
every effort to ensure the information in this manual
was correct at publication time, WASSP Ltd. does
not assume and hereby disclaim an legal liability
or responsibility to any party for any direct, indirect,
special or consequential loss, damage or disruption
caused by errors or omissions, whether such errors or
omissions result from negligence, accident or any other
cause.
This document is copyright WASSP Ltd 2013.
Circulation of this document is strictly prohibited without
the written permission of WASSP Ltd.
Doc. P/N: WSP-009-004
Version: V1.3
Issue Date: August 2013
www.wassp.com Page 3 of 62
Operator Manual
Contents
1. Purpose of this Manual
2. Introducing the WASSP System Multibeam Sonar System
2.1 Main Features ............................................................................................................................................................................ 5
2.2 System Conguration............................................................................................................................................................. 7
3. Operating Procedures
4. Menu Task Bar
4.1 Connect Status Icons ............................................................................................................................................................12
4.2 Transmit Mode Button .........................................................................................................................................................13
4.3 Gain Control Knob .................................................................................................................................................................14
4.4 Range Control Knob..............................................................................................................................................................14
4.5 Power Level ..............................................................................................................................................................................15
4.6 Pulse Width...............................................................................................................................................................................15
4.7 System Views ...........................................................................................................................................................................16
4.7.1 Single Screen Layout.......................................................................................................................................16
4.7.2 Vertical Split Screen Layout..........................................................................................................................17
4.7.3 Horizontal Split Screen Layout....................................................................................................................17
4.7.4 Three Split Screen Layout..............................................................................................................................18
4.7.5 Four Screen Layout..........................................................................................................................................19
4.7.6 Window Button.................................................................................................................................................19
4.8 Ship Setup Utility ...................................................................................................................................................................20
4.8.1 General Tab.........................................................................................................................................................21
4.8.2 NMEA....................................................................................................................................................................22
4.8.3 Oset Corrections Tab ....................................................................................................................................22
4.8.4 Sound Speed Tab..............................................................................................................................................23
4.8.5 Sensor Values Tab.............................................................................................................................................24
4.8.6 Power Tab............................................................................................................................................................25
4.8.7 Processing Tab...................................................................................................................................................26
4.9 System Conguration Utility..............................................................................................................................................27
4.9.1 Data Recorder / Replay Controls Window ...............................................................................................28
4.9.2 Colours Window ...............................................................................................................................................29
4.9.3 Tides Window ....................................................................................................................................................30
4.9.4 Rescan Dongle Button....................................................................................................................................31
4.9.5 Conguration Manager .................................................................................................................................31
4.9.6 Depth & Speed Window ................................................................................................................................32
4.9.7 Movement Control Window.........................................................................................................................32
Doc. P/N: WSP-009-004
Version: V1.3
Issue Date: August 2013
www.wassp.com
Page 4 of 62
Operator Manual
5. Viewing Modes
5.1 Sonar View ................................................................................................................................................................................33
5.1.1 Right-Click Options..........................................................................................................................................34
5.1.2 Advantages and Disadvantages of the Sonar View .............................................................................34
5.2 Single Beam View...................................................................................................................................................................35
5.2.1 Right-Click Options..........................................................................................................................................36
5.2.2 Display Oset (Shifting).................................................................................................................................37
5.2.3 Bottom Colour Intensity ...............................................................................................................................38
5.2.4 Water Column Options...................................................................................................................................39
5.2.5 Advantages and Disadvantages of the Single Beam View................................................................40
5.3 Sidescan View..........................................................................................................................................................................41
5.3.1 Right-Click Options..........................................................................................................................................42
5.3.2 Advantages and Disadvantages of the Sidescan View.......................................................................42
5.4 Waterfall View..........................................................................................................................................................................43
5.4.1 Right-Click Options..........................................................................................................................................44
5.4.2 Waterfall Colour Controls .............................................................................................................................45
5.4.3 Changing the Viewing Angle.......................................................................................................................46
5.4.4 Advantages and Disadvantages of the Waterfall View.......................................................................46
6. Troubleshooting
6.1 Checking Software Installation.........................................................................................................................................47
7. Frequently Asked Questions (FAQs)
7.1 The System is transmitting too slowly, how can I speed it up? .............................................................................50
7.2 The system has stopped transmitting without operator intervention. Why?..................................................50
7.3 When I press the Transmit button, nothing happens and there is no activity on the WASSP display. How
do I x this?...............................................................................................................................................................................50
7.4 When I run WASSP, it displays an error message - what does it mean? Is my WASSP system faulty?......51
7.4.1 GUI MESSAGES ..................................................................................................................................................51
7.4.2 PM MESSAGES ...................................................................................................................................................53
7.5 Why is there a ring displayed just above the seaoor? What causes these ‘ring’ marks? How can I get rid of
them?..........................................................................................................................................................................................54
7.6 What is this constant signal on the sonar/single beam display? ..........................................................................55
7.7 Why is my WASSP System not tracking the seaoor? ...............................................................................................55
7.8 Why doesn’t the seaoor line up when I go over it again? .....................................................................................56
7.9 Why does the seaoor move if the system is Motion Compensated?................................................................57
7.10 The mode button animates as if pinging but nothing happens. What is wrong?..........................................58
8. Appendix A: Restoring the WASSP Processor
9. Product Information for the People’s Republic of China
Doc. P/N: WSP-009-004
Version: V1.3
Issue Date: August 2013
www.wassp.com Page 5 of 62
Operator Manual
This operator manual describes how to operate the WASSP System Multibeam Sonar
System program through its graphical user interface. There may be variations due to on-going
developments and enhancements.
1. Purpose of this Manual
2. Introducing the WASSP System Multibeam Sonar System
and computer processing power which provides you with unparalleled information about the
underwater environment. It gives you a wide 120° port-starboard swath of the water column and
The information is presented in a user-friendly, mouse controlled, Windows-based operating
system. The system can output data to plotting software packages. For optimal performance,
roll, heave, pitch, heading and position inputs are all required.
data. Accurate ship measurements must be taken and the dockside and sea trial commissioning
procedures carried out thoroughly during installation. Even with good sensors, mapping
performance in rough seas will be less accurate than in calm water.
The WASSP System can be applied to a variety of survey methods, as well as search and
rescue, customs, and police applications.
2.1 Main Features
The WASSP System has the following main features:
Simple to use
Improved performance
The use of separate transmit and receive arrays has enabled WASSP Ltd. to optimise both
transmit performance and receive sensitivity, giving improved performance over traditional
sonar and sounders.
High detail picture of the marine environment
The transmit beam spreads over a 120° port-starboard swath and covers 4° fore-aft while
the receive beam covers 10° fore-aft, displaying a highly detailed picture of the marine
environment.
Beam stabilisation
Variable beam width
Unique to the WASSP, the single beam view can not only be stabilised, but the beam width
can be varied from 5° to 40°.
Bottom lock
Bottom lock provides a traditional bottom lock mode where the changes in bottom depth are
Doc. P/N: WSP-009-004
Version: V1.3
Issue Date: August 2013
www.wassp.com
Page 6 of 62
Operator Manual
160 kHz operating frequency
Unique power management system (14 power levels)
depths.
costs and improved accuracy.
Future proof technology
features and methods in software are developed.
Third party integration
Through interfacing, real time to third party software applications and outputting to standard
formats, bathymetric and water column data can be collected and processed using specialist
tools.
Doc. P/N: WSP-009-004
Version: V1.3
Issue Date: August 2013
www.wassp.com Page 7 of 62
Operator Manual
Figure 1. Overview of a fully functional WASSP System
2.2 System Conguration
See Installation Manual for full details.
31.07.13
423.11.11 ADDED USB
JW SR
Doc. P/N: WSP-009-004
Version: V1.3
Issue Date: August 2013
www.wassp.com
Page 8 of 62
Operator Manual
For more details see “5.2 Single
Beam View” on page 35
For more details see “5.1 Sonar
View” on page 33
For more details see
“4. Menu Task Bar”
on page 11
For more details see “5.3
Sidescan View” on page 41
For more details see “5.4
Waterfall View” on page 43
Figure 2. WASSP System User Interface
Doc. P/N: WSP-009-004
Version: V1.3
Issue Date: August 2013
www.wassp.com Page 9 of 62
Operator Manual
3. Operating Procedures
1Start up WASSP Application:
a. The WASSP PC Application software self loads
on system start up.
b. When the WASSP System program starts
up, a Navigation Warning screen similar to
the one shown in “Figure 3. WASSP System
Multibeam Sonar System Navigation Warning”
is displayed.
c. Click on OK to accept the navigation warning
message.
If no dongle is found, a Dongle Error box
appears on the screen.
Ensure a dongle has been plugged into the
computer’s USB port and click Retry.
d. Verify that the BTxR and appropriate sensors
are switched on.
e. Check the connection status for Processing
Module, Transfer Task, BTxR and Navigator.
Connection Status icons will appear green
when connected. See “4.1 Connect Status
Icons” on page 12.
Figure 3. WASSP System Multibeam Sonar
System Navigation Warning
You can click Cancel
2Choose a display mode:
See “4.7 System Views” on page 16.
Note: It is usually easier to select the
display modes after you have started
transmitting, as you can see the actual
modes displayed.
Doc. P/N: WSP-009-004
Version: V1.3
Issue Date: August 2013
www.wassp.com
Page 10 of 62
Operator Manual
3Transmit / Receive:
a. Click the MODE button to switch from STBY
(standby) to TX (transmit) mode.
When transmitting, the MODE button animates
showing a pulse being transmitted. See “4.2 Transmit
Mode Button” on page 13.
4Set up the selected screen layout:
Right-click anywhere in the selected screen layout
window. See “5. Viewing Modes” on page 33 for full details.
Example of right-click options
5Use system as required.
6Quit the WASSP GUI program:
a. Click the Transmit Mode button to set the BTxR to
standby.
b. Click Close on the task bar.
The Exit System box appears.
c. Click OK.
automatically and the program shuts down.
d. Shut down the computer following standard Windows
procedure.
e. Turn the BTxR OFF using the POWER button on the
faceplate.
f. Turn off the sensors according to the manufacturer’s
instructions.
The WASSP system is now shut down.
Note: The MODE button is
disabled while playing back
cannot be played back.
STATUS POWER
procedure in order not to
lose data
The WASSP PC should always be closed down through
the operating system.
Pulling the power can cause unrecoverable corruption.
Otros manuales para WMB-3250
2
Tabla de contenidos
Otros manuales de Sonar de Wassp
