Warwick Blue Cab 15.1 Manual de usuario
OFFICIAL WARWICK
AMP OWNER MANUAL
BLUE CAB 15.1 - BLUE CAB 30.1 - BLUE CAB 60.1
EENNGGLLIISSHH
rotective Circuits 5
Blue Cab 15.1 7
Blue Cab 30.1 8
Blue Cab 60.1 9
Suffix
Technical Data 102
Schematic Diagrams
Blue Cab 15.1 103
Blue Cab 30.1 104
Blue Cab 30.1 105
IINNDDEEXX
Congr tul tions on the purch se of your new W rwick combo. Ple se re d through these instructions be-
fore connecting nd oper ting the device. Following the guidelines you will soon will benefit from your new
W rwick mplifier. Ple se keep this instruction booklet h ndy in c se you need to consult it g in. Ple se
send the PASSPORT to the ddress indic ted therein.
4
EENNGGLLIISSHH
SAFETY HINTS
- Please read these instructions
- Please heed all warnings
Caution: To reduce the risk of electric shock, do
not open the amplifier’s case. Avoid exposure to
rain or moisture. No user serviceable parts inside,
refer all service to a qualified technician. No ves-
sel filled with liquids, such as vases shall be pla-
ced on top of the unit.
This symbol, wherever it appears, alerts you to
the presence of dangerous non-insulated voltage
inside the case. Risk of electric shock!
This symbol, wherever it appears, indicates to
important operating and maintenance instruct-
ions in this user manual. Please read the manual.
This recycling logo informs the end user that it is
forbidden to throw away the product in the trash.
It has to be disposed of accordingly.
!
Weee-Nr.: DE93670540
CB Approved
5
EENNGGLLIISSHH
GENERAL INFORMATION
For safe and reliable operation please follow these instructions:
•DO NOT open the amplifier case! You might receive an electrical shock. For any repair refer to qualified service personnel.
•Avoid dust, excessive moisture, direct sunlight and extremely high or low temperatures.
•Safeguard the device from impact. Always place the unit on a stable and horizontal surface.
•Do not block any of the ventilation openings.
•Avoid leaving the unit near radiators or other heat producing devices.
•Internal components should be adjusted or cleaned by qualified service technicians only. ake sure no object or liquid pene-
trates the device through its cooling vents.
•Fuse must be replaced with one of the same type and value to avoid damaging the amplifier.
•the mains cable or mains switch have been damaged,
•objects or liquids have penetrated the device,
•it has been exposed to excessive moisture,
•malfunctions or abnormal operating conditions have occurred,
•the device has been dropped or the case has been damaged.
Have the device examined by a qualified service technician in the following cases:
- ake sure the unit is plugged into a socket outlet with a protective grounding connection.
- ains plug must be accessible at any time to disconnect it from mains in case of abnormal operation.
- If the device shows any malfunction, immediately disconnect the mains cable from the mains socket.
- Use effects pedals only between the instrument and the amplifier since these devices do not meet the electrical specifications
of the effects loop.
- Unplug the unit whenever changing a fuse.
- Replace fuse only with one of the same type and value. Never bridge defective fuses.
EENNGGLLIISSHH
GETTING STARTED
1. ake sure that the mains lead is connected and all external devices (effects) are properly connected and working.
2. Set the VOLUME control (Blue Cab 15.1, 30.1, 60.1) / MASTER control (Sweet 15.3, 25.2) to zero.
3. Plug your bass guitar into the amplifier's IN UT using a shielded cable.
4. Press the OWER switch to turn the device on.
5. Switch off MUTE - the red LED will turn off. (Sweet 15.3, 25.2)
6. Turn up all volume controls of your bass guitar.
7. Adjust the GAIN control until the clip LED flashes. (Sweet 15.3, 25.2)
8. Set VOLUME control (Blue Cab 15.1, 30.1, 60.1) / MASTER contol (Sweet 15.3, 25.2) to your desired volume.
9. Use the sound controls / switches to adjust the sound as described in the respective chapters FRONT PANEL CONTROLS.
10. If necessary readjust the GAIN. (Sweet 15.3, 25.2)
6
EENNGGLLIISSHH BBLLUUEE CCAABB 1155..11
FRONT PANEL CONTROLS
IN UT socket to plug in a bass guitar.
VOLUME control to determine the main volume level.
BASS control to boost / cut deep frequencies.
MID control to boost / cut mid frequencies.
TREBLE control to boost / cut high frequencies.
HONES socket for connecting headphones (min 200 Ohm).
OWER switch for turning the amplifier on and off.
REAR PANEL
MAINS IN AC terminal with integrated fuse compartment for connecting the amplifier to mains.
EFF. LOO for the insertion of an effects unit.
Connect EFF. SEND with the input and EFF. RETURN with the output of the effects device. The rear stand allows for a 45-degree
tilt of the amplifier.
7
EENNGGLLIISSHH BBLLUUEE CCAABB 3300..11
FRONT PANEL CONTROLS
ASSIVE IN socket to plug in a passive bass guitar.
ACTIVE IN socket to plug in an active bass guitar.
VOLUME control to determine the main volume level.
BASS control to boost / cut deep frequencies.
MID control to boost / cut mid frequencies.
TREBLE control to boost / cut high frequencies.
LINE OUT socket allows connecting additional power amplifiers, active cabinets or a mixing console.
HONES socket for connecting headphones (min 200 Ohm).
OWER switch for turning the amplifier on and off.
REAR PANEL
MAINS IN AC terminal with integrated fuse compartment for connecting the amplifier to mains.
EFF. LOO for the insertion of an effects unit.
Connect EFF. SEND with the input and EFF. RETURN with the output of the effect device. The rear stand allows for a 45-degree tilt
of the amplifier.
8
EENNGGLLIISSHH BBLLUUEE CCAABB 6600..11
9
FRONT PANEL CONTROLS
ASSIVE IN socket to plug in a passive bass guitar.
ACTIVE IN socket to plug in an active bass guitar.
VOLUME control to determine the main volume level.
BASS control to boost / cut deep frequencies.
MID control to boost / cut mid frequencies.
TREBLE control to boost / cut high frequencies.
AUX. LEVEL control determines the level of the sound source which is connected to the AUX IN socket.
AUX. IN Cinch socket (RCA jack) allows connecting auxiliary stereo sound sources with line output level (0 dB),
such as CD players.
LINE OUT socket allows to connect additional power amplifiers, active cabinets or a mixing console.
HONES socket for connecting headphones (min 200 Ohm).
OWER switch for turning the amplifier on and off.
REAR PANEL
MAINS IN AC terminal with integrated fuse compartment for connecting the amplifier to mains.
EFF. LOO for the insertion of an effects unit.
Connect EFF. SEND with the input and EFF. RETURN with the output of the effect device. The rear stand allows for a 45-degree tilt
of the amplifier.
10
TECHNICAL DATA
BLUE CAB 15.1 BLUE CAB 30.1 BLUE CAB 60.1
INPUT 25 mV act. 25 mV
pass. 50 mV
act. 25 mV
pass. 50 mV
PREAMP transistor transistor transistor
PO ER AMP convection coole convection coole fan coole
SPEAKER 8” 10” 12”
EQUALIZER BASS, MID, TREB BASS, MID, TREB BASS, MID, TREB
COMPRESSOR - - -
HEADPHONE min 200 Ohm min 200 Ohm min 200 Ohm
EFFECT LOOP mono serial
sen 0 Bu, 600 Ohm
return 0 Bu, 10 kOhm
mono serial
sen 0 Bu, 600 Ohm
return 0 Bu, 10 kOhm
mono serial
sen 0 Bu, 600 Ohm
return 0 Bu, 10 kOhm
REAR CONTROL
NOMINAL PO ER 50 Watt 100 Watt 150 Watt
THD < 0.1% < 0.1% < 0.1%
EIGHT
(NET / GROSS, kg)
10 / 13 15 / 18.5 19 / 22.5
DIMENSIONS COMBO
(cm)
30 x 25 x 39 34 x 33 x 41 40 x 33 x 51
DIMENSIONS CART.
BOX (cm)
37 x 32 x 50 41 x 40 x 52 46 x 40 x 62
103
CIRCUIT DIAGRAM
BBLLUUEE CCAABB 1155..11
