Warmup W3WT01 Manual de usuario

Colour Touch Thermostats

W3WT01 & W3WT02 (Wi-Fi)

Operating Instructions

Models W3WT01 and W3WT02 (WiFi)

Menu Structure

Turn on the thermostat (you will find

the switch on the left)

Use the easy navigation to set the date

using the buttons to toggle selections.

Confirm each setting with “ “

Use the easy navigation to set the

time using the buttons to toggle

selections. Confirm each setting with

“ “

Select your region and confirm with “ “

It should default to ‘New Zealand’

Startup Wizard

Select your language and confirm

with “ “

Select the type of floor covering –

Tile: floors made of tile or stone

Soft Floor: carpeted, wooden or other

engineered floors

The thermostat comes with pre-programmed schedule for easy and economic heating control

of most homes. Below are the factory settings or the preset schedule.

This schedule can be changed in the Heating Schedule menu.

Wake Up Leave Home Come Home Go to Sleep

5:30 8:00 18:00 21:30

24°C 16°C 24°C 16°C

Pre-programmed schedule

Personalise your settings - Week Type

1. Select the Menu button on the top right to reveal the list of options

2. Start with selecting “Heating Schedule”

3. Then select “Week type”

4. Select “Work days/Home days. Select “All days are different if your heating times are

different for all days of the week.

*In step 4 if you selected ‘All days are different’ – skip steps 5, 6 and 7 and go to Step 8 and

select ‘Event Schedule’

Personalise your settings - Week Type (cntd)

5. Select the right arrow

6. Mark your “Work days” and confirm

7. Then confirm “Home days”.

8. You will now see the Heating Schedule menu

Personalise your settings -

If you have selected ‘All days are different’ you

will have to enter the schedule separately for

each day of the week.

Should there be a break in your routine or you

find that there are days when it may be a little

colder or warmer than usual, you can adjust

these settings manually. When done, close the

screen and your display will update accordingly.

Remember that the temperature on the display is

your current room temperature. It will take some

time for your thermostat to heat up to the new

temperature.

Event Schedule

824°05:30

Work Day: Wake up

16°10

Work Day: Leave Home

24°11

Work Day: Come home

16°12

Work Day: Go to sleep

Personalise your settings - Events per day

1. Menu

2. App Control

3. Wifi Connection

4. Manual

5. Select your network

6. Enter your password

7. Connect to App

8. Select QR code –you will now see

the QR code on the display screen

9. Now go to your mobile and

download the “SWATT” app

https://play.google.com/store/ap

ps/details?id=com.ojelectronics.

ow d5.r1099&hl=en

Open the app

Get started

Accept terms and conditions

Click on “Connect Thermostat”

Scan the QR code on the thermostat

You will now be asked to name the

thermostat and the heating zone Eg

Thermostat : Smith home Heating

Zone –Ensuite

Next.

Create a user name and password

Create Account and then select next

Personalise your settings - WiFi (for Model W3WT02 only)

When there is a drop in temperature and you need to increase the heating temperature,

Select the ‘Other’ button on the bottom right –go to ‘Comfort’. Select the temperature and

duration.

This will temporarily override your programme settings for the period of time selected. Once

that time is up, the thermostat will default to your original setting.

Comfort Mode

In boost mode the heating is activated for one hour. After one hour the thermostat returns

to Scheduled Operation.

Boost Mode
