HANDLING
Before continuing any further with the
installation of this re please read the following:
• One person should be sucient to lift the
re.
• When lifting always keep your back
straight. Bend your legs and not your
back.
• Avoid twisting at the waist. It is better to
reposition your feet.
• Avoid upper body / top heavy bending.
Always bend from the knees rather
than the waist. Do not lean forward or
sideways whilst handling the re.
• Always grip with the palm of your hand.
Do not use the tips of ngers for support.
• Always keep the product as close to the
body as possible to prevent unnecessary
and undue strain on the body.
• Use gloves to provide additional grip.
• Always use assistance if required.
UNPACKING THE PRODUCT
The unit is supplied in a single package
carton. Carefully unpack the product using the
following procedure:
• Ensure that the product is in the correct
position with the carton wording legible.
• Remove the straps and sleeve.
• Carefully lift the replace out of the box.
• Remove the protective packaging and
bag from the suite.
• Locate the xing pack put aside.
• Carefully remove the protective lm
covering the re.
IMPORTANT:
This surround is oor-standing
and must be xed to a wall. Please ensure both
the wall and oor are at before installation, and
there is adequate space for installation. Always
ensure there is enough room to place it.
Please ensure that there is an accessible
electrical socket within the space for
installation. The electrical socket must not be
behind or above the suite.
WARNING!
Ensure supply cord is located
correctly within the notches and cannot be
trapped when the surround is tted to the wall.
1. Route the supply cord through the notch
at the back of the suite.
2. Route the supply cord through the side of
the suite as shown. There will be a notch
located at each side of the suite. Use the
notch nearest to the electrical socket.
SECURING THE SUITE TO THE WALL
(SEE DIAGRAM ON PAGE 11)
1. Attach a mirror clip to the back of each
edge as shown using the 4 x short
screws. Pre-drill the holes to stop the
MDF splitting, (using a 2mm diameter drill
bit).
2. Place the suite to the wall, and mark the
positions of the remaining holes on both
mirror clips.
3. For solid walls, drill the 2 holes
approximately 35mm deep using a 6mm
diameter drill bit. Note: if tting the re to
plaster board with a cavity behind then
propriety wall xings (not supplied) will be
required.
4. Insert the wall plugs, then secure the suite
with 2 x long screws (supplied).
IMPORTANT: Do not connect the appliance
until it is properly xed to the wall and the
instructions have been read fully.
Ensure the minimum distances below are
observed.
Select a location that is not prone to moisture
and is located at least 36” away from any
combustible materials, such as curtain drapes,
furniture, bedding, paper, etc
