WAGO I/O-SYSTEM 750 Manual de usuario

Fieldbus Independent

I/O Modules

4 DO DC 24 V 0.5 A, High-Side

Switching

750-504(/xxx-xxx)

Manual

Version 1.0.5

Downloaded from Elcodis.com electronic components distributor

ii • General

WAGO-I/O-SYSTEM 750

I/O Modules

WAGO Kontakttechnik GmbH & Co. KG

Hansastraße 27

D-32423 Minden

Phone: +49 (0) 571/8 87 – 0

Fax: +49 (0) 571/8 87 – 1 69

E-Mail: [email protected]

Web: http://www.wago.com

Technical Support

Phone: +49 (0) 571/8 87 – 5 55

Fax: +49 (0) 571/8 87 – 85 55

E-Mail: [email protected]

Every conceivable measure has been taken to ensure the correctness and com-

pleteness of this documentation. However, as errors can never be fully ex-

cluded, we would appreciate any information or ideas at any time.

E-Mail: [email protected]

We wish to point out that the software and hardware terms as well as the

trademarks of companies used and/or mentioned in the present manual are

generally trademark or patent protected.

Downloaded from Elcodis.com electronic components distributor

Content • iii

WAGO-I/O-SYSTEM 750

I/O Modules

Content

1Important Comments ................................................................................. 4

1.1 Legal Principles........................................................................................4

1.1.1 Copyright............................................................................................. 4

1.1.2 Personnel Qualification .......................................................................4

1.1.3 Intended Use ........................................................................................4

1.2 Symbols....................................................................................................5

1.3 Number Notation......................................................................................5

1.4 Safety Notes ............................................................................................. 6

1.5 Scope ........................................................................................................6

2I/O Modules ................................................................................................. 7

2.1 Digital Output Module ............................................................................. 7

2.1.1 750-504(/xxx-xxx) [4 DO DC 24 V 0.5 A, High-Side Switching] .....7

2.1.1.1 Variations........................................................................................7

2.1.1.2 View................................................................................................7

2.1.1.3 Description......................................................................................8

2.1.1.4 Display Elements ............................................................................9

2.1.1.5 Schematic Diagram......................................................................... 9

2.1.1.6 Technical Data ..............................................................................10

2.1.1.7 Process Image ...............................................................................11

Downloaded from Elcodis.com electronic components distributor

4 • Important Comments

Legal Principles

WAGO-I/O-SYSTEM 750

I/O Modules

1 Important Comments

To ensure fast installation and start-up of the units described in this manual,

we strongly recommend that the following information and explanations are

carefully read and abided by.

1.1 Legal Principles

1.1.1 Copyright

This manual is copyrighted, together with all figures and illustrations

contained therein. Any use of this manual which infringes the copyright

provisions stipulated herein, is not permitted. Reproduction, translation and

electronic and photo-technical archiving and amendments require the written

consent of WAGO Kontakttechnik GmbH & Co. KG. Non-observance will

entail the right of claims for damages.

WAGO Kontakttechnik GmbH & Co. KG reserves the right to perform

modifications allowed by technical progress. In case of grant of a patent or

legal protection of utility patents all rights are reserved by WAGO

Kontakttechnik GmbH & Co. KG. Products of other manufacturers are always

named without referring to patent rights. The existence of such rights can

therefore not be ruled out.

1.1.2 Personnel Qualification

The use of the product detailed in this manual is exclusively geared to

specialists having qualifications in PLC programming, electrical specialists or

persons instructed by electrical specialists who are also familiar with the valid

standards. WAGO Kontakttechnik GmbH & Co. KG declines all liability

resulting from improper action and damage to WAGO products and third party

products due to non-observance of the information contained in this manual.

1.1.3 Intended Use

For each individual application, the components supplied are to work with a

dedicated hardware and software configuration. Modifications are only

permitted within the framework of the possibilities documented in the

manuals. All other changes to the hardware and/or software and the non-

conforming use of the components entail the exclusion of liability on part of

WAGO Kontakttechnik GmbH & Co. KG.

Please direct any requirements pertaining to a modified and/or new hardware

or software configuration directly to WAGO Kontakttechnik GmbH & Co.

KG.

Downloaded from Elcodis.com electronic components distributor

Important Comments • 5

Symbols

WAGO-I/O-SYSTEM 750

I/O Modules

1.2 Symbols

Danger

Always abide by this information to protect persons from injury.

Warning

Always abide by this information to prevent damage to the device.

Attention

Marginal conditions must always be observed to ensure smooth operation.

ESD (Electrostatic Discharge)

Warning of damage to the components by electrostatic discharge. Observe

the precautionary measure for handling components at risk.

Note

Routines or advice for efficient use of the device and software optimization.

More information

References on additional literature, manuals, data sheets and internet pages.

1.3 Number Notation

Number Code Example Note

Decimal 100 normal notation

Hexadecimal 0x64 C notation

Binary '100'

'0110.0100'

within inverted commas,

nibble separated with dots

Downloaded from Elcodis.com electronic components distributor

6 • Important Comments

Safety Notes

WAGO-I/O-SYSTEM 750

I/O Modules

1.4 Safety Notes

Warning

Switch off the system prior to working on bus modules!

In the event of deformed contacts, the module in question is to be replaced, as

its functionality can no longer be ensured on a long-term basis.

The components are not resistant against materials having seeping and

insulating properties. Belonging to this group of materials is: e.g. aerosols,

silicones, triglycerides (found in some hand creams).

If it cannot be ruled out that these materials appear in the component

environment, then additional measures are to be taken:

- installation of the components into an appropriate enclosure

- handling of the components only with clean tools and materials.

Attention

Cleaning of soiled contacts may only be done with ethyl alcohol and leather

cloths. Thereby, the ESD information is to be regarded.

Do not use any contact spray. The spray may impair the functioning of the

contact area.

The WAGO-I/O-SYSTEM 750 and its components are an open system. It

must only be assembled in housings, cabinets or in electrical operation

rooms. Access must only be given via a key or tool to authorized qualified

personnel.

The relevant valid and applicable standards and guidelines concerning the

installation of switch boxes are to be observed.

ESD (Electrostatic Discharge)

The modules are equipped with electronic components that may be destroyed

by electrostatic discharge. When handling the modules, ensure that the

environment (persons, workplace and packing) is well grounded. Avoid

touching conductive components, e.g. gold contacts.

1.5 Scope

This manual describes the Digital Output Module 750-504(/xxx-xxx)

4 DO DC 24 V 0.5 A, High-Side Switching of the modular WAGO-I/O-

SYSTEM 750.

Handling, assembly and start-up are described in the manual of the Fieldbus

Coupler. Therefore this documentation is valid only in the connection with the

appropriate manual.

Downloaded from Elcodis.com electronic components distributor

750-504(/xxx-xxx) [4 DO DC 24 V 0.5 A, High-Side Switching] • 7

Variations

WAGO-I/O-SYSTEM 750

I/OModules

2 I/O Modules

2.1 Digital Output Module

2.1.1 750-504(/xxx-xxx) [4 DO DC 24 V 0.5 A, High-Side Switching]

4-Channel Digital Output Module DC 24 V 0.5 A,

short-circuit-protected, high-side switching

2.1.1.1 Variations

Item-No. Designation Description

750-504 4 DO DC 24 V 0.5 A

High-Side Switching

4-Channel Digital Output Module DC 24 V

0.5 A,

short-circuit-protected, high-side switching

750-504/025-000 4 DO DC 24 V 0.5 A,

High-Side Switching /T

4-Channel Digital Output Module DC 24 V

0.5 A,short-circuit-protected, high-side

switching extended temperature range from –

20 °C to +60 °C

2.1.1.2 View

13 14

750-504

DO 2

Power jumper contacts

Data contacts

DO 2

Status

24V

DO 4

DO 1

Status

DO 1

DO 4

DO 3

Fig. 2.1.1-1: 4-Channel Digital Output Module 750-504 g050400e

Downloaded from Elcodis.com electronic components distributor

8 • 750-504(/xxx-xxx) [4 DO DC 24 V 0.5 A, High-Side Switching]

Description

WAGO-I/O-SYSTEM 750

I/O Modules

2.1.1.3 Description

The connected load is switched via the digital output from the control system.

The module has four output channels. Two actuators may be directly

connected to the module.

As an example, two 2-conductor actuators may be directly connected using

connection 0 V and signal output DO 1 or 0 V and signal output DO 2. The

connection of more actuators to signal outputs DO 3 and DO 4 requires a field

side connection module (750-614) for 24V and for 0V, if need be.

Note

For the connection of inductive loads a protected circuit, e. g. a recovery

diode, has to be switched parallel to this load.

The output channels are electrically short-circuit-protected and high-side

switching. Which means that the status of the output channels is "high" if the

output channels switch to the 24 V supply voltage for the field side.

The supply voltage for the field side is derived from an adjacent supply

module by means of power jumper contacts.

The status of the four output channels is indicated via green status LEDs.

An optocoupler is used for electrical isolation between the bus and the field

side.

Any configuration of the output modules is possible when designing the

fieldbus node. Grouping of module types is not necessary.

The field side supply voltage of 24 V for the output module is derived from

adjacent I/O modules or from a supply module.The supply voltage for the

field side is made automatically through the individual I/O modules by means

of power jumper contacts.

Warning

The maximum current of the internal power jumper contacts is 10 A. When

configuring the system it is important not to exceed the maximum/sum

current. However, if such a case should occur, another supply module must be

added.

Attention

In case of overloads a supply module with fuse (750-601) must be connected

on the line side to protect the output modules!

The output module 750-504 can be used with all couplers/controllers of the

WAGO-I/O-SYSTEM 750.

Downloaded from Elcodis.com electronic components distributor

750-504(/xxx-xxx) [4 DO DC 24 V 0.5 A, High-Side Switching] • 9

Display Elements

WAGO-I/O-SYSTEM 750

I/OModules

2.1.1.4 Display Elements

LED Channel Designation State Function

off Output DO 1: not activeA

green

1 Status

DO 1 on Output DO 1: active

off Output DO 2: not activeC

green

2 Status

DO 2 on Output DO 2: active

off Output DO 3: not activeB

green

3 Status

DO 3 on Output DO 3: active

off Output DO 4: not active

13 14

Fig. 2.1.1-2: Display

Elements g050402x

green

4 Status

DO 4 on Output DO 4: active

2.1.1.5 Schematic Diagram

750-504

10nF

DO 1

DO 3

DO 2

DO 4

24V

270pF

10nF

24V

Fig. 2.1.1-3: 4-Channel Digital Output Module 750-504 g050401e

Downloaded from Elcodis.com electronic components distributor

10 • 750-504(/xxx-xxx) [4 DO DC 24 V 0.5 A, High-Side Switching]

Technical Data

WAGO-I/O-SYSTEM 750

I/O Modules

2.1.1.6 Technical Data

Module Specific Data

Number of outputs 4

Current consumption (internal)max. 7 mA

Voltage via power jumper contacts DC 24 V (-15 % / + 20 %)

Type of load resistive, inductive, lamps

Switching rate max. 1 kHz

Reverse voltage protection yes

Output current 0.5 A short-circuit-protected

Energy dissipation Wmax.

(unique switching off)

0.3 J

Lmax. = 2 Wmax. /I²

Isolation 500 V (System/Field)

Current consumption typ.(field side) 30 mA (per module) + load

Internal bit width 4 Bit out

Dimensions (mm) W x H x L 12 x 64* x 100

* from upper edge of 35 DIN rail

Weight ca. 50 g

Standards and Regulations (cf. Chapter 2.2 of the Coupler/Controller Manual)

EMC-Immunity to interference (CE) acc. to EN 61000-6-2 (01)

EMC-Emission of interference (CE) acc. to EN 61000-6-3 (01)

EMC-Immunity to interference (Ship building) acc. to Germanischer Lloyd (01)

EMC-Emission of interference (Ship building) acc. to Germanischer Lloyd (01)

Approvals (cf. Chapter 2.2 of the Coupler/Controller Manual)

CULUS (UL508)

ABS (American Bureau of Shipping)

BV (Bureau Veritas)

DNV (Det Norske Veritas) Cl. B

GL (Germanischer Lloyd) Cat. A, B, C, D

KR (Korean Register of Shipping)

LR (Lloyd's Register) Env. 1, 2, 3, 4

NKK (Nippon Kaiji Kyokai)

RINA (Registro Italiano Navale)

CULUS (UL1604) Class I Div2 ABCD T4A

KEMA II 3 G EEx nA II T4

Conformity Marking

Downloaded from Elcodis.com electronic components distributor

Otros manuales para I/O-SYSTEM 750

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de E/S de WAGO

WAGO

WAGO 50-1418 Manual de usuario

WAGO

WAGO 750-460 Manual de usuario

WAGO

WAGO 753-482 Manual de usuario

WAGO

WAGO I/O-SYSTEM 750 Manual de usuario

WAGO

WAGO Automation WAGO-I/O-SYSTEM 750 Manual de usuario

WAGO

WAGO I/O SYSTEM 750 Manual de servicio

WAGO

WAGO 750-481/003-000 Manual de usuario

WAGO

WAGO WAGO-I/O-SYSTEM 750 XTR Series Manual de usuario

WAGO

WAGO 750 Series Manual de usuario

WAGO

WAGO LONWORKS 750-319 Manual de usuario

WAGO

WAGO 750-312 Manual de usuario

WAGO

WAGO WAGO-I/O-SYSTEM 752 Manual de usuario

WAGO

WAGO WAGO-I/O-SYSTEM 750 XTR Series Manual de usuario

WAGO

WAGO WAGO-I/O-SYSTEM 750 XTR Series Manual de usuario

WAGO

WAGO I/O System 750 750-483 Manual de usuario

WAGO

WAGO I/O SYSTEM 750 Manual de usuario

WAGO

WAGO I/O-SYSTEM 750 Manual de usuario

WAGO

WAGO I/O-SYSTEM 750 510 376 07 Manual de usuario

WAGO

WAGO 750-842 Manual del operador

WAGO

WAGO 750-482/000-001 Manual de usuario

WAGO

WAGO I/O-SYSTEM 750 Manual de usuario

WAGO

WAGO 750-370 Manual de usuario

WAGO

WAGO 750 Series Manual de usuario

WAGO

WAGO 750-402 Manual de usuario

Manuales populares de Sistema de E/S de otras marcas

Teknim

Teknim TWM-1887 Manual de instrucciones

Intelligent Appliance

Intelligent Appliance IA-2662-E Manual de usuario

BERGHOF

BERGHOF ECC DIO 16/16 Manual de instrucciones

Advantech

Advantech PCM-27J3AU Manual de instalación y operación

Festo

Festo CP-E08-M12-CL Manual de usuario

Measurement Computing

Measurement Computing PCI-DAS64/M1/16 Manual de usuario

Hitachi

Hitachi HX-RIO3 Series Manual de usuario

NUUO

NUUO SCB-A08 Manual de usuario

M-system

M-system R3Y-RS8 Manual de usuario

jablotron

jablotron JB-110N Manual de usuario

Omron

Omron SYSMAC C200H Manual de usuario

DOLD

DOLD SAFEMASTER M Manual de usuario

ABB

ABB OPT-MF-001 Manual de usuario

Omron

Omron SYSMAC C2000H Manual de usuario

Helmholz

Helmholz TB20 Manual de usuario

ICP DAS USA

ICP DAS USA tM-AD2 Manual de usuario

Automationdirect.com

Automationdirect.com DL305 Manual de usuario

Contec

Contec PIO-16L(PCI)H Manual de usuario
