Enrich your style of presenting.

Because today’s audiences are accustomed to a different, more

interactive kind of media usage and consumption, Wacom has

developed a contemporary, efﬁcient presentation tool that helps

to simplify any kind of knowledge transfer, whether in business or

education: the PL-720 interactive pen display.

· Enriches presentation methods

The PL-720 allows comments to be written by pen directly

on the screen which makes your presentation more lively.

· Seamless integration

With its 17" LCD screen and compact 4:3 format it can be easily

integrated in existing teaching or presenting environments.

· Optimises interaction with the audience

The PL-720 promotes a motivating and fruitful face-to-face

working atmosphere between presenter and listeners.

· Advanced presentation ergonomics

Enjoy perfect hand-eye coordination and ergonomic posture.

PL-720

The interactive pen display by Wacom.

The perfect choice for seamless integration in existing environments.

The Wacom PL-720 interactive pen display.

210x297_Facsheets_PL720_nwP.indd 1 03.05.2010 16:09:55 Uhr

GENERAL SPECIFICATIONS

Dimensions (W x D x H) 400.0 x 362.0 x 55.5 mm (15.8 x 14.3 x 2.2 in), excluding stand

Weight 6.0 kg (13.2 lb), including stand

Power consumption 37 W (max.)

2 W or less in sleep mode

1 W or less in off mode

Supported operating systems Microsoft®Windows®7, Vista, and XPTM (32 and 64 bit)

Mac OS X 10.4 or later

Certiﬁcation and compliance FCC part 15 class B & Subpart C, Industry Canada Class B, CE,

VCCI class B, EDID 1.3, C-tick, BSMI, MIC, CB, CCC, The European

Union RoHS Directive 2002/95/EC, Chinese RoHS, Korean RoHS

DISPLAY

Screen size 337.9 x 270.3 mm (13.31 x 10.65 in)

Aspect ratio 4 : 3

Resolution 1,280 x 1,024 pixels (SXGA)

Pixel pitch 0.264 x 0.264 mm (0.010 x 0.010 in)

Viewing angles (horizontal/vertical) 70°/65°

Display colours 16.7 million

Contrast ratio 650 : 1

Response time 5 ms (typical)

Luminance (brightness) 300 cd/m2

Plug & Play DDC 2B

TABLET

Reading technology Electromagnetic resonance method

Active area 337.9 x 270.3 mm (13.31 x 10.65 in)

Resolution 0.05 mm/point (508 lpi)

Accuracy ± 0.5 mm (± 0.02 in), center

Reading height 5 mm (0.2 in)

Report rate 100 points/sec., max.

Communication interface Integrated USB hub, USB v2.0 powered hub with two external

ports, 500 mA per port

PEN

Pressure levels 512

Pen tip travel ± 0.2 mm (± 0.008 in)

Physical dimensions (L x D) 146.5 x 12.5 mm (5.77 x 0.49 in)

Weight ± 12 g (± 0.42 oz)

SOFTWARE

Bundle software Uniboard

PL-720 Speciﬁcations.

Wacom and the logo are trademarks or registered

trademarks of

the Wacom Company, Ltd. All other company names and product names are trademarks and/or registered trademarks

of their respective owners. The product contains software protected by copyright. Modifications and errors excepted.

BRO-PL72S3-EN

Wacom Europe GmbH

Europark Fichtenhain A9

47807 Krefeld

Germany

www.wacom.eu
