VWR P2 Series Guía del usuario

Start up Guide

Balances

P2-Series

*The plug type may vary by country.

2. UNPACKING

1 2 3

Keep the packaging should a warranty

claim or service be required.

1. CONTENT

Balance

×1

Balance

×1

Draft shield

×1

Draft shield

×1

Weighing pan

×1

Weighing pan

×1

Power adapter

×1

Power adapter

×1

Models: VWR-203P2

Models: VWR-602P2 | VWR-2002P2 | VWR-3101P2

3. RECOMMENDATIONS AND WARNINGS

+40 °C

+104°F

+10 °C

+50 °F

Operate the device in a room where the temperature ranges between 10–40 °C

(50–104 °F) and where the relative humidity is below 80%.

Place the balance on a solid surface to ensure stability. To obtain stable and

repeatable weighing results, an anti-vibration table is recommended.

Place the balance away from heat

sources. Avoid exposing the balance

to the sunlight.

Avoid air drafts and air movements

at the workstation.

Avoid exposing the balance to amag-

netic ﬁeld. Do not weigh magnetic

substances.

Make sure that the balance is placed

on an even surface.

Do not place the balance in a hazard-

ous area. Do not weigh explosive

materials.

Do not place the balance on an

unstable ground exposed to shocks

and vibrations.

4.1. Grounding spring check

4. ACTIVITIES TO BE DONE PRIOR TO OPERATION

5. COMPONENTS ASSEMBLY

6. PREPARING FOR WORK

6.1. Temperature stabilization time

Prior to switching the device on, let it

reach room temperature (estimated

stabilization time: 1-8 hours).

Connect the power adapter

to DC connector.

Connect the power

adapter to the mains.

1 2 3

6.2. Leveling

To level the balance, turn its feet and

keep turning the feet until an air bubble

takes the central position.

Models: VWR-203P2

1 2

Models: VWR-602P2 | VWR-2002P2 | VWR-3101P2

1 2

6.3. Switch the balance on

To switch the device on, press ON / OFF key.

Your balance is ready to use!

7. PANEL AND SCREEN

7.1. Panel keys

Switching

ON/OFF

7.2. Home screen

Sending weighing

result to a printer

or a computer / ENTER

Weighing result

window and

communication and

information section

Stable result

pictogram

Balance zeroing

pictogram

Navigation

and zeroing

Navigation

and taring

Selecting working

mode / ESC

While “1.1.CA-E” parameter is on, press key.

8. BASIC OPERATIONS

8.1. Adjustment

5 6

Prepare suitable mass standard. Load the weighing pan with the mass standard

and press key.

Prior to adjustment prepare the right mass standard. You

are recommended to use a mass standard of class F1 or F2.

View the table and select the mass standard you need.

External adjustment is carried out using an external mass standard of the

right accuracy and weight value, which value depends on balance type

and capacity.

Balance

model

VWR-203P2 200

VWR-602P2 500

VWR-2002P2

VWR-3101P2

2 000

Mass

standard [g]

1 2

Simultaneously press + keys to enter

home screen.

While “P1.CAL” parameter is on, press key.

3 4

Unload the weighing pan and press key.

With unloaded weighing pan press key.

7 8

Unload the weighing pan. Adjustment completed.

The balance has been zeroed.

1 2

8.2. Zeroing

The balance has been tared.

1 2

With loaded weighing pan, upon result

stabilization, press key.

8.3. Taring

Using key select “YES” value and press

key to conﬁrm.

Using key select “3.1.1.Acc” parameter

and press key.

Using key select “YES” value and press

key to conﬁrm.

Using key select “3.1.1.Acc” parameter

and press key.

8.4. Working modes accessibility

While “3.1.UUGG” parameter is on, press key.

1 2

Simultaneously press + keys to enter

home screen.

Using key select “P3.Func” parameter

and press key.

3 4

In order to enable other

working modes, repeat

the steps: and .

Save working mode

settings - section .

3 4

Using key select working mode

and press .

Using key enter working modes menu.

8.5. Selecting working mode

Using key select “P9.Unit” parameter

and press key.

1 2

8.6. Weighing unit selection

When the main unit is g (gram), the user has the following units:

g (gram), ct (karat), lb (pound).

Using key select weighing unit and press

key to conﬁrm.

3 4

Detailed overview of the settings of

the working modes is to be found in

balance’s main user manual.

•Weighing

•Parts counting

•+/- Control

•Percent Weighing

•Peak Hold

•Totalising

The menu features the following working modes:

Simultaneously press + keys to enter

home screen.

Using key select “9.2.Unin” parameter

and press key.

9. PERIPHERAL DEVICES CONNECTORS
