Mirror Controls
MIC Brightness LED Volume PWR A/B Switch Hi –Low
Control MIC adjustment
Figure 1: Rear View Mirror
?MIC –Microphone for use with hands free cell phone feature.
?Brightness control –Adjusts the brightness level of the LCD viewing area of
the mirror.
?LED –Power indicator indicating that the mirror is turned on.
?Volume –Adjust the volume level for hands free cell phone use and audio
from rear camera. (Camera must have mic/audio to function)
?PWR –Power button turns Observation and hands free function off and on.
?A/B switch –Toggles between Camera A and Camera B.
?H-Mic-L –Hi and Low level setting for microphone sensitivity. Low setting
helps reduce background noise.
