VORTEX OPTICS Solo Manual de usuario
MONOCULAR
MANUAL
36 mm Model
manual_mon_solo_36-15.indd 1 12/24/2015 1:22:10 PM
3
2
monocular
manual_mon_solo_36-15.indd 2 12/24/2015 1:22:10 PM
3
2
monocular
The 36 mm Solo monocular delivers bright images, is
compact, easy to handle, and designed for a lifetime of
hard use. Built to withstand use in just about any field
condition, o-ring seals and nitrogen purging make the
Solo a fully waterproof, internally fogproof monocular.
The Solo® 36 mm Monocular
Focus Wheel
Objective
Lens
Twist
Eyecup
Eyepiece
Rubber Armor
with Diamond-Checkered
Grip
Utility Clip
Monoculars are not intended for looking at the sun, or any other
intense light source. Such viewing could damage the retina and cornea
of your eyes—even to the point of causing blindness.
Caution:
manual_mon_solo_36-15.indd 3 12/24/2015 1:22:10 PM
5
4
monocular
Preparing the Solo for Use
Attaching the Lanyard
Attach the lanyard to the Solo monocular in three simple
steps:
1. Push the loop end
of the strap through the
lanyard attachment point
on the monocular.
2. Take the opposite end
of the lanyard and put it
through the loop.
3. Cinch the loop tight.
manual_mon_solo_36-15.indd 4 12/24/2015 1:22:10 PM
5
4
monocular
Focusing the Solo
The focus wheel is found on the eyepiece of the Solo.
Simply turn the wheel until
your subject comes crisply into
view. Turn clockwise to focus on
more distance objects, counter-
clockwise to focus on objects
that are nearer.
The soft case of the Solo slips off for
an easy carry in the field and provides
protection for the monocular when
not in use.
The Case
Carrying with the Utility Clip
This versatile carrying option
allows quick attachment
of the Solo monocular
to pocket edges or other
equipment.
manual_mon_solo_36-15.indd 5 12/24/2015 1:22:10 PM
7
6
monocular
Caring for the Lenses
Maintain the optical brilliance of the Solo monocular by
keeping the lens surfaces free of dirt, dust, and oils.
Protect Lenses While Out in the Field
Store the Solo in its custom carry case.
Keep Lenses Clean
Along with normal use comes the need to clean the
monocular lenses. Follow these guidelines for cleaning:
1. Remove any dust or grit from lenses before wiping.
Use a can of pressurized air or soft camel hair brush
(acrylic optical brushes also work well).
2. Clear lens of smudges, fingerprints, or eyelash oil.
Fog the lenses with your own breath and wipe with
the non-abrasive lens cloth included with the Solo
monocular.
Cleaning fluid and optical paper can also be used.
However, you should never use facial tissue, heavy
cotton, or flannel clothing on lenses—these materials
can scratch the lens surfaces.
Other cleaning options:
manual_mon_solo_36-15.indd 6 12/24/2015 1:22:10 PM
7
6
monocular
the ViP Warranty
We build optics based on our commitment to your
absolute satisfaction. That’s why our products are
unconditionally guaranteed and we make this Very
Important Promise to you—a Very Important Person.
Rest assured that in the event your Solo monocular
becomes damaged or defective, we will repair or replace
the monocular at no charge to you. Call us at 800-426-
0048 for prompt, professional, and friendly service.
2120 West Greenview Drive
Middleton, WI 53562
Visit www.vortexoptics.com for more information.
Canadian customers may visit www.vortexcanada.net for
customer service information.
The VIP Warranty does not cover loss, theft, deliberate
damage or cosmetic damage that does not hinder the
performance of the product.
Lifetime Warranty
Unlimited
Unconditional
manual_mon_solo_36-15.indd 7 12/24/2015 1:22:10 PM
MONOCULAR
#MON-SOLO-36-15/S
