Volvo S80 - Manual de usuario

WElCOME TO THE glObal faMIlY Of vOlvO

OWnERs!

Getting to know your new vehicle is an exciting experience.

This Quick Guide provides a brief overview of the most common features and

functions in your Volvo.

However, for the most up-to-date and detailed descriptions and instructions,

as well as important warnings and other information not included in this

folder, please refer to your Owner’s Manual.

An asterisk (*) indicates optional equipment.

For additional information, contact Customer Service:

U.S.A.: 1-800-458-1552 www.volvocars.us

Canada: 1-800-663-8255 www.volvocanada.com

VOLVO S80

Quick Guide

PCC*

Green light: vehicle is locked.

Yellow light: vehicle is unlocked.

Red light: alarm has been triggered.

Alternatively flashing red lights: the alarm

was triggered less than 5 minutes ago.

Locks the doors and trunk and arms

the alarmA.

Unlocks the doors and trunk, and dis-

arms the alarmB

Trunk (press once to unlock; press twice

to open trunk slightly).

Approach lighting illuminates lights in

door mirrors, cabin, footwells, license

plates. Turn signals and parking lights

illuminate.

“Panic” alarm.

– Press and hold to sound the alarm.

Turn off alarm with unlock button.

Information about the vehicle can be

gathered within a range of 65 ft. (20 m).

– Press the button and wait for 7 sec-

onds.

If the vehicle is out of range when the

button is pressed, the most recently

stored status information will be shown.

A The accessory inclination and movement alarm sensors

can be turned off. See the “Alarm” section of your owner’s

manual for information.

B Automatic relock occurs if no door/trunk is opened within 2

minutes after unlock.

REMOTE KEY WITH PCC* – PERSONAL CAR COMMUNICATOR

IGNITION MODES (MODES 0 AND I)

To access the following ignition modes: The

brake pedal must not be depressed.

Mode Active functions

Remote key inserted but not drawn

into ignition slot – audio system and

courtesy lighting.

Remote key drawn into ignition slot

– audio system and courtesy lighting.

Instrument/clock lighting, steering

wheel lock/unlocked.

Remote key drawn into ignition slot

and START pressed briefly – power

moonroof/windows, blower, ECC,

wipers, 12-volt sockets in center

console, Volvo Navigation System*.

To exit ignition modes 0/Iand turn off the

vehicle’s electrical system: Press in the remote

key. It will be partially ejected from the igntion

slot.

The vehicle may be equipped with a number of

other optional systems to help the driver brake

in time, keep a safe distance to the vehicle

ahead or stay in a traffic lane. These include:

Adaptive Cruise Control

Distance Alert

Collision Warning with Auto-brake

Driver Alert System

•

STARTING THE ENGINE

– Insert the remote key as shown in the illus-

tration and push lightly on it – the key will be

drawn into the lock.

COLD START

NOTE

After cold starts, your engine will idle at a

higher speed for a short time.

– Press the START/STOP/ENGINE button

briefly to start the engine.

SWITCHING OFF THE ENGINE AND

REMOVING THE REMOTE KEY

1. Park the vehicle and press the START/STOP

ENGINE button to switch off the engine.

2. Press lightly on the remote key. It will be par-

tially ejected from the ignition slot. The gear

selector must be in the Pposition.

– Press the brake pedal.

DRIVER SUPPORT SYSTEMS

157

FOLDING THE REAR SEAT BACKREST

Pull the respective handles to fold down the

left and/or right sections of the backrest.

1. The rear head restraints must be in the

upright position.

Fold down the backrest.

AUDIO SYSTEM

Press for on/off.

Turn to adjust volume.

Select AM, FM1, FM2, CD, or MODE.

Use MODE to activate Sirius satellite

radio* or the AUX/USB socketsA

Sound settings

Press to select e.g., BASS, TREBLE, etc.

– turn to adjust.

BLUETOOTH®

Make the cell phone searchable/visible.

Press the PHONE button on the audio sys-

tem control panel briefly.

Select “Add phone” in the audio system

display.

Select the cell phone to be connected.

Enter the numbers shown in the audio sys-

tem display using the cell phone’s keypad.

A. AUX/USB sockets for e.g., mp3 player. Set the device’s vol-

ume to medium for best sound quality. An iPod® connected

to the USB socket will also be charged.

RADIO

Turn to select a radio station.

Search for stations with the left/right ar-

rows. Store up to 20 stations by holding

in buttons 0–9 in FM1 och 0–9 in FM2,

until the stored station is confirmed in the

display.

Autostore stations by pressing for 2 sec-

onds. AUTOSTORE is displayed during

the search. The 10 strongest stations are

stored. Press 0–9to select a station.

CD PLAYER

Turn to change tracks.

Change tracks with left/right arrows.

Select CDBwith up/down arrows.

Press to eject current CD.

A long press jects all CDsB

CD selectB. Press 1–6.

BOptional CD changer only.

HD RADIO

HD radio reception is subject to coverage limi-

tations. See your Owner’s Manual for details.

ELECTRONIC CLIMATE CONTROL—ECC

MANUAL CONTROL

Driver/front passenger seat ventilation*.

Blower speed.

Heated driver/front passenger seat*.

Air distribution.

Recirculation

Defroster to defog the windshield and

side windows.

Heated rear window and door mirrors.

Air conditioning Off/On to cool the cabin

and defog the windows.

AUTOMATIC CONTROL

In AUTO mode, ECC controls all functions

automatically and makes driving more pleasant

with optimal air quality.

Turn the control to the desired temperatu-

re on the left/right sides of the cabin. The

set temperature is shown in the display.

Press to automatically control the tem-

perature and other functions.

STORAGE SPACES, 12-VOLT SOCKETS & AUX/USB* CONNECTOR

CAUTION

Using the optional 12-volt socket in the trunk

with the engine switched off will drain the

battery.

The 12-volt sockets in the cabin function in

ignition modes Ior II.

The 12-volt socket* in the trunk always func-

tions.

AUX/USB* can be used to connect e.g., an

mp3 player to the vehicle’s audio system.

8 9

Low fuel level indicator

When the symbol illuminates, refuel as

soon as possible.

The trip odometer display shows two

separate trip odometers, T1 & T2.

Fuel gauge

The fuel filler door is on the right, as indi-

cated by the arrow.

Trip computer display. Select function

with (8).

Clock

Adjust with (6).

Multi-function control

Turn the control clockwise or counter-

clockwise to set the clock.

A short press toggles between T1 & T2.

A long press resets the displayed odome-

ter.

TRIP COMPUTER AND ODOMETER

Press to display or erase a message.

Turn to show trip computer information

alternatives.

A short press resets current function.

A long press resets all functions.

STEERING WHEEL ADJUSTMENT REFUELING

WARNING

Never adjust the steering wheel while

driving.

– Press the button to open the fuel filler door.

NOTE

The display text Miles to empty tank is an

approximation, based on recent average fuel

consumption.

LIGHTING PANEL

Single wiper sweep.

Off

Intermittent wipers. Turn (2) to adjust

interval.

Normal wiper speed.

High wiper speed.

Windshield/headlight washers.

Displayed when the rain sensor is

active.

WIPERS AND RAIN SENSOR*

Rain sensor On/Off with the lever in the 0

position.

Turn to adjust intermittent wiper speed or

rain sensor sensitivity where applicable.

EMERGENCY BRAKE ASSIST (EBA) CAR CARE

EBA is designed to provide full brake effect

immediately in the event of sudden, hard

braking. When EBA is activated, the brake

pedal will go down more than usual.

– Press and hold the brake pedal for as long

as necessary – there will be no braking ef-

fect if the pedal is released.

Hand washing is gentler on the paint than an

automatic car wash. Since the paint on a new

vehicle may take several months to harden

completely, we recommend washing the

vehicle by hand during this period. Use clean

water, a suitable car washing detergent and

a sponge. Keep in mind that dirt or grit on the

sponge can scratch the paint.

High beam flash

Toggle between high/low beams. Home

safe lighting.

Display & instrument panel lighting.

Front fog lights.

Rear fog light (driver’s side only).

Automatic headlights. High beam flash

only.

Parking lights.

Headlights: turn off when ignition is

switched off, high/low beams.

Open the fuel filler door.

Press once to unlock the trunk, press

twice to pop open the trunk slightly.

ADJUSTING THE FRONT SEAT

Lumbar support.

Backrest tilt.

Raise/lower the seat.

Raise/lower the front edge of the seat

cushion.

Forward/rearward.

Folding down the passenger’s seat back-

rest.

When a low tire pressure warning message

(Low tire press. check tires or Very low tire

pressure) has been displayed and the tire

pressure warning light ( )has illuminated,

one or more tires has low inflation pressure.

Check the inflation pressure of all four tires

with a tire pressure gauge as soon as pos-

sible and pump the tire(s) with low pressure

to the recommended inflation pressure.

Refer to the inflation pressure tables in the

section “Wheels and tires” in the Owner’s

Manual.

If the BLIS indicator lights illuminate even

when there are no vehicles in the blind area,

this may be due to light reflected from a

wet road surface, the vehicle’s own shadow

against a large, light, smooth surface, or

sunlight directly in the camera when the sun is

low on the horizon.

In the event of a fault, Blind spot syst.

service required will be displayed. See the

Owner’s Manual for other BLIS-related mes-

sages.

ELECTRIC PARKING BRAKE

Setting

– Press the button. The light flashes until the

parking brake is fully applied, then glows

continuously.

Releasing

Ignition mode 0or higher.

Press the brake pedal and pull out the but-

ton.

Release automatically

– Select a gear and begin driving. The parking

brake will release automatically (the driver’s

seat belt must be fastened).

TIRE PRESSURE MONITORING

SYSTEM (TPMS)

BLIND SPOT INFORMATION

SYSTEM (BLIS)*

Otros manuales para S80 -

Tabla de contenidos

Otros manuales de Automóvil de Volvo

Volvo

Volvo XC90 S Manual de instrucciones

Volvo

Volvo XC60 2013 Manual

Volvo

Volvo V70 SPORT Manual de usuario

Volvo

Volvo S60 - ANNEXE 931 Manual de usuario

Volvo

Volvo 120 Manual de instrucciones y seguridad

Volvo

Volvo XC90 RECHARGE Manual de usuario

Volvo

Volvo V70 SPORT Guía de inicio rápido

Volvo

Volvo C70 convertible Manual del propietario

Volvo

Volvo XC90 2019 Manual de usuario

Volvo

Volvo XC90 2018 Manual de usuario

Volvo

Volvo S60 - ANNEXE 931 Manual de usuario

Volvo

Volvo 2011 V40 Manual de usuario

Volvo

Volvo C30 2012 Guía de inicio rápido

Volvo

Volvo XC60 - ANNEXE 541 Manual de usuario

Volvo

Volvo V70 SPORT Manual de usuario

Volvo

Volvo S40 - ANNEXE 244 Manual de usuario

Volvo

Volvo S60 - ANNEXE 931 Manual de usuario

Volvo

Volvo V90 CROSS COUNTRY Manual de usuario

Volvo

Volvo XC90 2008 Manual de usuario

Volvo

Volvo S60 2013 Guía de inicio rápido

Volvo

Volvo XC 90 Manual de usuario

Volvo

Volvo 2008 C30 Manual de usuario

Volvo

Volvo 2007 S80 Manual de usuario

Volvo

Volvo V70 2014 Guía de inicio rápido

Manuales populares de Automóvil de otras marcas

Toyota

Toyota 2000 Tundra Manual de usuario

CITROËN

CITROËN DS4 DSign Manual de usuario

Lexus

Lexus 2015 CT 200h Manual de usuario

Cadillac

Cadillac CTS 2008 Manual de usuario

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manual de usuario

Porsche

Porsche Boxster S Manual de usuario

GMC

GMC 2010 Savana 1500 Cargo Manual de usuario

KIAM

KIAM SPORTAGE 2014 Manual de lista de piezas

GMC

GMC 2013 Terrain Instrucciones de montaje

GMC

GMC T-Series 1999 Manual de usuario

Mercury

Mercury 1998 Mystique Manual de usuario

Mercury

Mercury 2007 Mariner Manual de usuario

Mazda

Mazda 2007 Mazdaspeed 3 Guía

Mazda

Mazda 2014 CX-5 Manual de usuario

GMC

GMC Chevrolet Express 2022 Manual de usuario

GMC

GMC 1997 Jimmy Manual de usuario

Chevrolet

Chevrolet 2012 Malibu Manual de usuario

Cadillac

Cadillac 2010 Escalade Manual de usuario
