Volvo XC90 2008 Manual de usuario

welcOme TO THe glObAl FAmIly OF vOlvO

OwneRS!

Getting to know your new vehicle is an exciting experience.

Please browse through this Quick Guide to get the full benefits from

your new Volvo. For detailed information, please refer to your Owner´s

Manual.

Warning texts and other important information are only provided in the

Owner’s Manual - not in this folder. The Owner’s Manual contains the

most up-to-date information.

For additional information, contact Customer Service:

U.S.A.: 1-800-458-1552 www.volvocars.us

CANADA: 1-800-663-8255 www.volvocanada.com

Quick Guide

vOLvO XC90

Quick Guide

AUTOSTART

Turn the key/keyless drive start control to

position III and release it. The engine will start

automatically.

COLD START

NOTE

After cold starts, your engine will idle at a

higher speed for a short time.

KEY & REMOTE CONTROL

Locks the doors, fuel filler door, and

tailgate, and arms the alarm.

Unlocks the doors, fuel filler door,

and tailgateA, and disarms the

alarm.

Unlocks the tailgate. (Does not

open the tailgate).

Approach lighting (30 secondsB)

illuminates lights in door mirrors,

cabin, footwells, license plates. Turn

signals and parking lights illuminate.

“Panic” alarm. Press and hold to

sound the alarm. Turn off alarm with

UNLOCK.

A. Automatic relock occurs if no door/tailgate is

opened within 2 minutes after unlock.

B. The time can be set to 30, 60, or 90 seconds.

WIPERS AND RAIN SENSOR (OPTION)

Single wiper sweep

Off

Intermittent wipers. Turn (2) to adjust

interval.

Normal speed

High speed

Windshield and headlight washer

Tailgate washer

Tailgate wiper interval/normal

Activate rain sensor. Positions D-F

deactivate the rain sensor.

Turn to adjust rain sensor sensitivity.

Symbol in display (rain sensor on).

DRIVER’S DOOR CONTROL PANEL

L R

Adjusting the door mirrors. Select

L or R. Adjust with the control.

Open/close a window partially

Open/close a window fully

Locks/unlocks all doors, fuel filler

door, and tailgate.

Lockout switch for rear windows.

LIGHTING PANEL

Automatic headlights. High beam

flash only.

Parking lights

Headlights: turn off when ignition is

switched off, high/low beams.

Display & instrument panel lighting

Front fog lights (option)

Rear fog light (driver’s side only)

High beam flash

Toggle between high/low beams,

home safe lighting.

PARKING BRAKE

Applying the parking brake:

Press firmly on the brake pedal and then

press the parking brake pedal (1).

Release the brake pedal. If the vehicle rolls,

press the parking brake pedal again.

Park – put the gear selector in P.

Releasing the parking brake:

Press firmly on the brake pedal and then pull

the handle (2).

AUDIO SYSTEM

REFUELING

When a low tire pressure warning message

has been displayed and the tire pressure

warning light has come on, one or more tires

has low inflation pressure.

Stop the vehicle in a safe place and check the

inflation pressure of all four tires with a tire

pressure gauge.

TIRE PRESSURE MONITORING SYS-

TEM (TPMS)

On/Off and volume. Press to turn on/off.

Turn to adjust volume. Radio and Volvo

Navigation System (option) volume are

stored individually.

Sound settings. Press to select e.g.,

BASS, TREBLE, etc. Turn to adjust.

SELECTOR knob: turn to choose CD,

Sirius satellite radio (option), AUXA

A. AUX connector for e.g., MP3 player. Set the MP3

player’s volume to medium for best sound quality.

RADIO

Autostore stations

Press AUTO for 2 seconds. The 10 strong-

est stations are stored. Press 0–9 to select

a station.

Automatic/manual station search

A short press starts an automatic search, a

long press starts a manual search. A long

press on 0-9 stores stations. FM1/FM2

store 10 stations each.

CD PLAYERB

CD selectC.Press 1–6 on the keypad.

CD eject. Press to eject current CD.

Press and hold to eject all CDs.C

Change tracks

B. CDs containing files in MP3 and WMA formats can

also be played.

C. CD changer only (option).

Place the fuel filler cap on the hook.

AUTOMATIC CONTROL

In AUTO mode, ECC controls all functions

automatically and makes driving more pleasant

with optimal air quality.

Temperature

Turn to the desired temperature.

Automatic mode

Press AUTO to maintain cabin temperature

balanced airflow, and other settings.

ELECTRONIC CLIMATE CONTROL—ECC (OPTION)

MANUAL CONTROL

Blower speed

Air distribution

Defroster quickly removes mist from

the windshield and front, side windows.

Recirculation

Air conditioning on/off.

Heated rear window and door mir-

rors. Timer functionA.

A. Rear window 12 minutes. Mirrors 6 minutes.

We do not recommend washing your car in

an automatic wash during the first six months

because the paint will not have hardened suf-

ficiently.

Leather upholstery requires regular care. Treat

the leather with protectant cream, one to four

times a year as necessary. Consult your Volvo

retailer for leather care products.

CAR CARE

910

Trip computer display, select trip com-

puter information with (9).

Press to erase a displayed message.

Turn to show trip computer information

such as MILES TO EMPTY TANK in the

trip computer display.

Reset current function

ODOMETER AND TRIP COMPUTER

See the information in the display. Brake failure warning light, stop

safely. Check brake fluid levelA.

Stop safely and take the action

shown in the display.

DSTC stability system, flashes

when the system is working.

Low oil pressure, stop safely and

check the oil levelA.

A. Have the vehicle towed if the symbol remains illuminated.

Fuel gauge

Low fuel level indicator

When the symbol illuminates, refuel as

soon as possible.

TRIP ODOMETER

The display shows two separate trip

odometers, T1 & T2.

Press quickly to toggle between T1 &

T2. Press and hold to reset the displayed

odometer.

CLOCK

Turn as far as possible and hold to set

the clock (4).

TRIP COMPUTER

NOTE

MILES TO EMPTY TANK is an approxima-

tion, based on recent average fuel consump-

tion.

FUEL

INDICATOR AND WARNING LIGHTS

FOLDING THE REAR SEAT BACKRESTS

Third row of seats (seven-seat model)

Move the second row of seats as far forward as

possible.

A. Pull the handle up.

B. Push the seat cushion as far rearward as

possible and fold in the load eyelets.

C. Fold down the backrest.

Second row of seats

Move the seats as far rearward as possible (ap-

plies to seven-seat models only).

A. Pull the loop.

B. Fold down the head restraint.

C. Pull the handle to unlock the backrest.

D. Fold down the backrest and press to lock it

in the folded position.

The front passenger’s seat backrest can also

be folded down. See point 6 of “Adjusting the

front seat.”

EMERGENCY BRAKE ASSIST (EBA)

TURN SIGNALS

A. Lane-change sequence, three flashes.

B. Full turn sequence.

WARNING! Never adjust the steering wheel

while driving.

STEERING WHEEL ADJUSTMENT

BLIS – BLIND SPOT INFORMATION

SYSTEM (OPTION)

EBA is designed to provide full brake effect

immediately in the event of sudden, hard

braking. When EBA is activated, the brake

pedal will go down more than usual. Press

and hold the brake pedal for as long as

necessary. There will be no braking effect if

the pedal is released.

If the BLIS indicator lights illuminate occasion-

ally even when there are no other vehicles in

the blind area, this may be caused by light re-

flected from a wet road surface, the vehicle’s

own shadow against a large, light, smooth

surface, or sunlight directly in the camera

when the sun is low on the horizon.

In the event of a fault, Blind spot syst. ser-

vice required will be displayed.

ADJUSTING THE FRONT SEAT

STORAGE SPACES, 12-VOLT SOCKET & AUX CONNECTOR (OPTION)

Lumbar support

Backrest tilt

Raise/lower the rear edge of the seat

Raise/lower the front edge of the seat

Forward/rearward

Folding the passenger’s seat backrest

CAUTION

Using the 12-volt socket in the cargo area

with the engine switched off will drain the

battery.

The center console’s front and rear 12-volt

sockets function in ignition position Ior

higher.

The 12-volt socket on the right side of the

cargo area always functions.

The AUX connector (behind the cup holder in

the center console) makes it possible to con-

nect a portable music player’s headphones to

your audio system. Use a 3.5 mm stereo mini

plug.

GROCERY BAG HOLDER
