QUICKGUIDE

VOLVO C70

WELCOME TO YOUR NEW VOLVO!

Getting to know your car is an exciting experience.

Browsing through this Quick Guide will further enhance your approval of your

new Volvo. The detailed information is in the Owner’s Manual.

Warning texts and other important information is only in the Owner’s Manual,

not in this folder. The Owner’s Manual contains the most important

information.

Options are marked with an asterisk (*).

COLD START

KEY BLADE

Used to lock/unlock the glovebox or driver’s

door/cargo area, e.g. if car is without electrical

power.

KEY & REMOTE CONTROL

1. Automatic relocking takes place if a door/boot lid is

not opened within 2 minutes after unlocking.

2. The time is adjustable to 30, 60 or 90 seconds, see

Owner’s Manual.

AUTOSTART (applies to 2.4, 2.4i, T5 and D5)

Turn the ignition key/dial to position III and re-

lease. The engine starts automatically.

Diesel engines must always be preheated in

position II before the engine is started.

CONTROL PANEL IN DRIVER’S DOOR

The idling speed may briefly be slightly

higher in order to achieve efficient emission

control.

NOTE

Adjusting the door mirrors, select L

or R. Set with the lever.

Retracting the door mirrors*.

Press L and Rsimultaneously. Press

again to extend.

Manual windows

Automatic windows

All windows open simultaneously with

one press on the right of the button.

Press and hold on the left to close.

L R



WINDOW AUTOMATION

The windows are automatically opened approx.

2 cm when doors are opened/roof is operated.

The windows are closed automatically.

Locks doors, storage compartment in

doors*, boot lid and ski hatch and arms

the alarm. After 30 seconds the doors are

double-locked and cannot be opened

from inside.

Unlocks doors, storage compartment in

doors*, boot lid, ski hatch and steering

lock and disarms the alarm 1.

Unlocks boot lid. (Boot lid does not open.)

Switches on lighting for 30 seconds 2in

side mirrors*, in cabin, by feet and on

number plate. Indicators and parking

lamps illuminate.

"Panic" button. Press and hold for

approx. 3 seconds in an emergency to

trigger the alarm. Switch off the alarm with

the unlock button.

Lock for emergency opening of boot lid.

Headlamp levelling (automatic for

Bi-Xenon lights*)

Automatic dipped beam. Main beam

flash. Main beam cannot be activated.

Parking lamps

Dipped beam. Dipped beam switches

off when the ignition is switched off.

Main beam can be activated.

Display & instrument lighting

Front fog lamps*

Rear fog lamp (one rear lamp)

Main beam flash

Main/dipped beam switching.

Approach lighting.

A. Short sequence, three flashes.

B. Continuous flash sequence.

RAIN SENSOR* AND WINDSCREEN WIPERS

Single sweep

Off

Intermittent wiping. Turn (B) to adjust.

Normal speed

High speed

Windscreen and headlamp washing

WARNING! Adjust the steering wheel before

setting off, never while driving.

DIRECTION INDICATORS ADJUSTING THE STEERING WHEEL

LIGHT SWITCHES

Activates rain sensor. Position D–F deac-

tivates rain sensor.

Adjust sensitivity using the thumbwheel.

Display symbol for rain sensor On.

WINDSCREEN WIPERS

RAIN SENSOR

OPERATING THE ROOF "TOP DOWN & TOP UP"

CARGO SEPARATOR LOADING ASSISTANCE

The cargo separator limits the cargo area to

make space for the folding roof.

1. Raise the cargo separator during loading.

2. Lower the cargo separator fully into the

catches (3) before lowering the roof. See

decal on cargo separator.

Raise/lower the lowered roof to facilitate

Press the button and wait several seconds until

the roof is raised. Raise the cargo separator,

load, and then fold it down fully.

Press the button again to lower.

2,0m

0,2m

PREPARATIONS

• No objects on parcel shelf, roof or boot lid.

• 2 m clearance and 0.2 m behind.

• Level ground.

• Outside temperature above –10 °C.

• Closed cargo separator and boot lid.

• The car must be stationary.

• Pay attention that no individual is close to

the roof’s moving parts during its operation.

The side windows lower several centimetres

when the roof is operated. They then return

automatically.

OPERATION

1. Engine at idling speed.

2. Depress the brake pedal.

3. Press and hold button (A) or (B) until a signal

sounds and the message ROOF CLOSED/

ROOF OPEN is shown in the display.

4. Release the button.

AUTOMATIC CONTROL

In AUTO mode the ECC system controls all

functions automatically making driving simpler

with optimum air quality.

ELECTRONIC CLIMATE CONTROL, ECC*

MANUAL CONTROL

Fan speed

Air distribution

Defroster to quickly remove misting from

the windscreen and side windows.

Air quality system* On (A).

Recirculation On (M).

Air conditioning On/Off

Rear window and door mirror defrosters.

Automatic deactivation 1.

Temperature

Press for individual adjustment of left (L) or

right-hand (R) side. Turn to the required tem-

perature. The set temperature is shown in

the display.

Automatic

Press AUTO for automatic control of tem-

perature and other functions.

PACOS, DEACTIVATING THE AIRBAG*

ON: The airbag is activated.

Passengers taller than 140 cm can sit

in the front seat but never a child on

a booster cushion or child seat.

Incorrect use can endanger life. Consult the

Owner’s Manual in the event of the smallest

uncertainty regarding usage.

OFF: The airbag is deactivated.

PASSENGER AIRBAG OFF is shown

in the warning lamp above the interior

rearview mirror.

A child can sit on a booster cushion or child seat

in the front seat but never passengers taller

than 140 cm.

PACOS (Passenger Airbag Cut Off Switch)

Use the ignition key to switch ON/OFF.

WARNING

1. Rear window 12 minutes. Mirrors 6 minutes.

INDICATOR AND WARNING LAMPS

TRIP COMPUTER AND TRIP METERS

Display shows two independent trip meters,

T1 &T2.

Fuel gauge. The arrow indicates that the fuel

cap is on the right-hand side.

Low fuel level

8 litres petrol (7 litres diesel) remain.

RANGE TO EMPTY FUEL TANK is an esti-

mate based on earlier driving conditions.

Turn to stop and hold to set the clock (6).

Turn to show e.g. RANGE TO EMPTY FUEL

TANK in the display (7).

TRIP COMPUTER

IMPORTANT

Read in information display ABS fault. Stop safely. Restart the

engine 1.

Stop safely. Rectify the fault as per in-

formation display.

Fault in brake system. Stop safely.

Check the brake fluid 2.

Low oil pressure. Stop safely. Check

the oil level 2.

DSTC stability system. Flashes when

the system is operating.

Press to clear a message.

Reset current function. One long press re-

sets all functions.

Switch between T1 & T2 with one short

press. Reset current meter with one long

press.

TRIP METERS

CLOCK

FUEL

1. Contact a Volvo workshop if the symbol illuminates after restart. 2. Have the car towed if the symbol remains

visible.

Remove the antenna to use an automatic car

wash. Turn the antenna anticlockwise to re-

move it.

Diesel cars are equipped with a particle filter,

which results in more efficient emission con-

trol. The particles in the exhaust gases are col-

lected in the filter during normal driving. So-

called "regeneration" is started automatically

in order to burn away the particles and empty

the filter. Engine power may be slightly re-

duced during regeneration.

Open the fuel filler flap, hang up the fuel cap

during refuelling.

REFUELLING DIESEL PARTICLE FILTER

CAR CARE AUTOMATIC CAR WASH

Washing by hand is gentler to the paintwork

than an automatic car wash. The paintwork is

also more sensitive when it is new. Handwash-

ing is recommended during the first few

months.

AUDIO SYSTEM

On/Off and audio volume. Press for On/Off.

Turn to adjust the audio volume. Radio, TP,

handsfree* and RTI volume are stored indi-

vidually.

Sound pattern. Press to select e.g. BASS,

Dolby Pro Logic II* or SUBWOOFER*. Turn

to adjust.

CD or AUX 1

Change CD track using Left/Right arrow or

turn (5).

Select CD disc2 using Up/Down arrow.

Direct selection CD disc2 . Press 1–6.

Select radio station by turning.

Search for station using Left/Right arrow

or SCAN (7). Store up to 20 stations by

holding in 0–9 on FM1 and 0–9 on FM2.

When a station has been stored it is con-

firmed in the display.

Autostoring stations

Press AUTO for approx. 2 seconds. Auto-

storing is shown in the display. The ten

strongest stations are stored. Then press

0–9to select a station..

Ejecting a CD disc. One short press ejects

the current disc. One long press ejects all 2.

FM1 , FM2 or AM radio

1. AUX input for e.g. MP3 player.

2. Only CD changer*.

CD PLAYER

RADIO

Activate/deactivate SUBWOOFER* using

STORAGE SPACES, 12 V SOCKET & AUX

Lumber support

ADJUSTING THE FRONT SEAT

12 V socket in centre console front/rear works

in ignition position I or II . 12 V socket on right-

hand side in cargo area is always active.

Using the AUX output the car’s audio system

can playback music from an MP3 player etc.

Using the 12 V socket in the cargo area when

the engine is switched off can discharge the

battery.

IMPORTANT

Raise/lower seat

Seat cushion front edge raise/lower

Forwards/backwards

EASY ENTRY & BELT GUIDE

Manual seat

A. Always remove the seatbelt from the belt-

guide.

B. Pull and move the seat forwards.

Power seat*

A. Always remove the seatbelt from the belt-

guide.

B. Pull the handle and fold up the backrest.

C. Hold the button in while the seat moves for-

wards. Hold the button in again to move the

seat back.

Backrest rake

Otros manuales para C70

Tabla de contenidos

Otros manuales de Automóvil de Volvo

Volvo

Volvo V60 TWIN ENGINE 2018 Manual de usuario

Volvo

Volvo XC90 - ANNEXE 951 Manual de usuario

Volvo

Volvo 2005 S80 PREMIER Manual de usuario

Volvo

Volvo S80 - Manual de usuario

Volvo

Volvo 2004 S80 Manual de usuario

Volvo

Volvo S40 2008 S40 Manual de usuario

Volvo

Volvo V60 Manual de usuario

Volvo

Volvo V90 TWIN ENGINE 2017 Manual de usuario

Volvo

Volvo XC90 - ANNEXE 951 Manual de usuario

Volvo

Volvo C30 - ANNEXE 798 Manual de usuario

Volvo

Volvo V90 CROSS COUNTRY 2021 Manual de usuario

Volvo

Volvo S40 - ANNEXE 244 Guía de inicio rápido

Volvo

Volvo XC90 2020 Manual de usuario

Volvo

Volvo XC90 Twin Engine 2019 Manual de usuario

Volvo

Volvo XC90 Twin Engine 2019 Manual de usuario

Volvo

Volvo 2006 C70 Manual de usuario

Volvo

Volvo C30 - ANNEXE 798 Manual de usuario

Volvo

Volvo S60 - ANNEXE 931 Manual de usuario

Volvo

Volvo S60 - ANNEXE 931 Guía de inicio rápido

Volvo

Volvo XC90 - ANNEXE 951 Manual de usuario

Volvo

Volvo XC90 - ANNEXE 951 Manual de usuario

Volvo

Volvo 2006 S60 Manual de usuario

Volvo

Volvo XC60 - ANNEXE 541 Manual de usuario

Volvo

Volvo 2010 XC90 Manual de usuario

Manuales populares de Automóvil de otras marcas

Toyota

Toyota 2000 Tundra Manual de usuario

CITROËN

CITROËN DS4 DSign Manual de usuario

Lexus

Lexus 2015 CT 200h Manual de usuario

Cadillac

Cadillac CTS 2008 Manual de usuario

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manual de usuario

Porsche

Porsche Boxster S Manual de usuario

GMC

GMC 2010 Savana 1500 Cargo Manual de usuario

KIAM

KIAM SPORTAGE 2014 Manual de lista de piezas

GMC

GMC 2013 Terrain Instrucciones de montaje

GMC

GMC T-Series 1999 Manual de usuario

Mercury

Mercury 1998 Mystique Manual de usuario

Mercury

Mercury 2007 Mariner Manual de usuario

Mazda

Mazda 2007 Mazdaspeed 3 Guía

Mazda

Mazda 2014 CX-5 Manual de usuario

GMC

GMC Chevrolet Express 2022 Manual de usuario

GMC

GMC 1997 Jimmy Manual de usuario

Chevrolet

Chevrolet 2012 Malibu Manual de usuario

Cadillac

Cadillac 2010 Escalade Manual de usuario
