Vivo MOUNT-VP01B Manual de usuario
Black Projector Ceiling Mount
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
Instruction Manual
https://vivo-us.com/products/mount-vp01b
SKU: MOUNT-VP01B
Chat live with an agent!
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
2
PACKAGE CONTENTS
WARNING!
A (x1)
Ceiling Mount
B(x1)
Mounting Bracket
M-F (x4)
M4 OD-10 Washer
M-G (x4)
M5 OD-12 Washer
M-E (x4)
M3 OD-10 Washer
M-A (x4)
M3x8 Screw
M-B (x4)
M4x10 Screw
M-C (x4)
M5x10 Screw
M-D (x4)
M6x10 Screw
If you do not understand these directions, or if you have any doubts about the safety of the installation,
please call a qualified technician. Check carefully to make sure there are no missing or defective parts.
Improper installation may cause damage or serious injury. Do not use this product for any purpose that is
not explicitly specified in this manual. Do not exceed weight capacity. We cannot be liable for damage or
injury caused by improper mounting, incorrect assembly or inappropriate use.
NOTE: NOT ALL HARDWARE INCLUDED WILL BE USED
M-H (x4)
M6 OD-12 Washer
M-I (x2)
M5x12 Screw
M-J (x2)
M5 OD-10 Washer
M-K (x2)
M5 OD-10 Plastic Washer
W-A (x4)
ST6x56 Screw
W-B (x4)
Concrete Anchor
W-C (x4)
M6 OD-16 Washer
WARNING: CHOKING HAZARD
SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
T-A (x1)
4mm Allen Wrench
CAUTION!
DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR CEILING CONSTRUCTION. USE WOOD STUDS
TO MOUNT. We include mounting for brick and concrete If unsure, please contact us at vivo-us.com,
WASHER SPECIFICATION KEY
MCompatible Screw Size
Outside DiameterOD
3
ASSEMBLY STEPS
STEP 1
OPTION A: Above Ceiling Cable Management
If cables will be hidden above the ceiling, route cables through large opening in Ceiling Mount (A).
TOOLS NEEDED
30lbs
(13.61kg)
DO NOT EXCEED WEIGHT CAPACITY.
Failure to do so may result in serious injury.
Phillips
Screwdriver
Drill
OPTION B: Below Ceiling Cable Management
If cables are located below ceiling, route cables through the side of Ceiling Mount (A).
A
A
4
STEP 2
OPTION A: Wood Ceiling Joist Installation
Align holes in ceiling plate with wood ceiling joist and mark drilling locations. Use of a stud finder
is recommended for finished ceilings. Drill 55mm (2.2”) deep holes using 4.5mm or 3/16” drill bit.
Secure Ceiling Mount (A) to stud using ST6x56 Screws (W-A) with M6 OD-16 Washers (W-C). Do not use
Concrete Anchors (W-B).
OPTION B: Concrete Ceiling Installation
Mark drilling locations in ceiling. Drill 60mm (2.4”) deep holes using 10mm or 3/8” drill bit. Press
Concrete Anchors (W-B) into drilled holes, and secure Ceiling Mount (A) to ceiling using ST6x56
Screws (W-A) and M6 OD-16 Washers (W-C).
XX
A
A
W-C
W-A
W-C
W-A
W-B
5
STEP 3
Align arms on Mounting Bracket (B) with mounting holes in projector, and secure to projector using
Screws (M-A through M-D) and Washers (M-E through M-H) most appropriate for your projector. If
your projector has 3 mounting holes, simply remove one of the arms.
STEP 4
Hang Mounting Bracket (B) with projector over pre-installed screws on Ceiling Mount (A), making sure
plastic oval washers are between the plate and mount.
B
B
A
B
Plastic Oval Washer
M-A, M-B, M-C, M-D
M-E, M-F, M-G, M-H
6
STEP 5
Secure Mounting Bracket (B) using M5x12 Screws (M-I), M5 OD-10 Washers (M-J) and M5 OD-10
Plastic Washers (M-K). Tighten with 4mm Allen Wrench (T-A).
T-A
B
M-I
M-J
M-K
7
STEP 6
Adjust angle and rotation of projector using 4mm Allen Wrench (T-A).
+15° -15°
-15°
+15°
3
6
0
°
T-A
LAST UPDATED: 09/23/2021
REV2
