ViviCam 9114 Digital Camera

User Manual

Windows and the Windows logo are registered trademarks of Microsoft Corporation.

All other trademarks are the property of their respective companies.

Table of Contents

Introduction .................................................................................................................................. 2

What‟s Included............................................................................................................................ 2

Parts of the Camera..................................................................................................................... 3

Initial Camera Setup..................................................................................................................... 4

Main Camera Modes.................................................................................................................... 7

Technical Specifications ............................................................................................................... 8

Computer System Requirements ................................................................................................. 9

Powering the Camera On/Off..................................................................................................... 10

Changing Camera Mode .............................................................................................................11

Navigating the Menus................................................................................................................. 12

Photo Capture Mode.................................................................................................................. 13

Photo Playback Mode ................................................................................................................ 31

Video Capture Mode .................................................................................................................. 38

Video Playback Mode................................................................................................................. 51

Installing the Software................................................................................................................ 56

Connecting the Camera to the Computer................................................................................... 57

Getting Photos and Videos from your Camera to Your Computer.............................................. 58

Get Started!................................................................................................................................ 59

Transferring Images from my Camera to my Computer Manually.............................................. 59

Camera Maintenance................................................................................................................. 60

Sakar Warranty Card.................................................................................................................. 61

Technical Support....................................................................................................................... 62

Troubleshooting.......................................................................................................................... 62

Introduction

Thank you for purchasing this camera. Everything you need to take quality digital photos and

videos is included with your camera.

Vivitar makes capturing those special moments as easy as possible.

Please read this manual carefully first in order to get the most out of your digital camera.

Note: Your camera needs an SD Memory card (up to 32GB) for normal use.

SD Memory cards are not included and need to be purchased separately.

What’s Included

1. Digital Camera

2. USB cable

3. Vivitar Experience Image Manager

software Installation CD

4. Wrist Strap

Note: SD Memory Card and batteries not included.

Parts of the Camera

1. Digital Lens

12. Delete / Right Button

2. Flash Light

13. SET button

3. LCD Screen

14. ViviLink / Down Button

4. Power Button

15. Scene / Left Button

5. Shutter Button

16. SD Card Slot

6. Zoom Out

17. MACRO Switch

7. Strap Hole

18. USB Slot

8. LED

19. Tripod Mount

9. Zoom In

20. Battery Door

10.MODE button

21. Microphone

11.Flash / Up / Slide Show

Initial Camera Setup

Installing the Batteries

Installing the Memory Card

Insert 3 AAA (1.5V) batteries. Alkaline

batteries recommended (not included).

SD Memory card (up to 32GB)

needed for normal use.

Turning On the Camera

Using the Camera

Selecting

the modes

Accessing the menu

When powering the camera ON for the first time the camera will take you through the INITIAL

CAMERA SETUP.

Powering the Camera ON

1) Batteries

Make sure the batteries have been inserted properly into your digital camera, according to

the polarity shown inside the battery compartment.

Use 3x AAA (1.5v) batteries. Alkaline batteries are recommended. (Batteries not included.)

Note:

Remove the batteries from the camera when not in use for an extended period.

Do not mix alkaline and non-alkaline batteries.

Some features, such as Flash, will not work if the battery power level is low.

When the battery power is low the battery icon turns red and the camera will

automatically turn off a few seconds later.

The energy status of the power is displayed on LCD as shown below:

Full battery power Medium battery power Low battery power

2) SD Card

Make sure an SD card has been properly inserted into your camera. (SD card not included.)

To properly insert the SD Card:

Push the SD card into the slot in the direction shown on the camera (see SD icon by the SD

card slot). Push the SD card until you hear a slight clicking sound. This indicates the SD

card has been inserted correctly.

Note:

After the camera is powered on, an SD icon will appear on the LCD display. If you do not

see the SD icon on the display, please check if the card was inserted properly.

Make sure the SD card is not locked (check the lock switch on the side of the SD card). If

the SD card is locked this will prevent the camera from saving captured photos to the SD card.

3) Power On

Press the POWER button to turn on the camera.

Setting the Camera Language

1) You will first be prompted to select a language for the camera. The Language selection

menu will appear. Select the language of your choice by pressing the UP and DOWN

direction control buttons. Then press the SET button to confirm the selection.

2) After selecting a language, you will be asked if you would like to continue with the initial

camera setup. A message will appear: “Continue with Camera Setup?”

Select “Yes” to continue or “No” to exit the setup.

Note: If you select “No” and decide to leave the camera setup, the camera will be set toits default

settings.These settings can be adjusted at any time manuallythrough the menus in the camera.

Setting the Date and Time

The next step in the initial camera setup is to set the date and time on the camera.

Set the Date and Time as desired by pressing the RIGHT and LEFT direction control buttons to

choose the specific setting and the UP and DOWN buttons to change each setting.

Once you have completed setting the time and date, press the SET button to confirm the

selection and move to the next part of the camera setup.

Setting the ViviLink Default Option

Once the Date and Time have been set, you will be asked to set the default ViviLink destination

for photos and videos taken with your camera.

The ViviLink technology allows you to quickly and easily upload your camera‟s photos and videos

to the social networks of your choice with the accompanying software application.

1) First you will be asked to choose the default ViviLink social network for Photos. Press the

UP or DOWN buttons to highlight the desired default social network and press the SET

button to confirm the selection.

2) Next you will be asked to choose the default ViviLink social network for Videos. Press the

UP or DOWN buttons to highlight the desired default social network and press the SET

button to confirm the selection.

3) After the ViviLink Video option is confirmed the camera is now ready to use.

Main Camera Modes

Your camera has different modes for the various camera functions.

You can switch modes by pressing the MODE button on your camera after the camera has been

powered ON.

Photo Capture Mode

Use this mode to capture pictures with your camera.

This is the default mode when the camera is powered ON.

To take a picture, aim your camera as desired and press the Shutter button.

The picture will be automatically saved to your camera‟s memory card.

To access the various menus for the Photo Capture mode, press the SET button while in

the Photo Capture mode.

Video Capture Mode

Use this mode to capture videos with your digital camera.

After turning on your camera, press the MODE button once to open the Video Capture

mode. To take a video, aim your camera as desired and press the Shutter button to start

the record. A red record indicator will appear on the LCD screen while record is in progress.

To stop the record, press the Shutter button again. The video will be automatically saved to

your camera‟s memory card.

To access the various menus for the Video Capture mode, press the SET button while in the

Video Capture mode.

Playback Mode (Photos & Videos)

Use this mode to view and manage the photos and videos on your camera.

After turning on your camera, press the MODE button twice to open the Playback mode for

photos and videos. You can scroll through the photos and videos that you‟ve previously

taken to view, edit or delete them as desired.

To access the various menus for the Playback mode for photos and videos, press the SET

button while in the Playback mode.

Technical Specifications

Image Sensor

CMOS Sensor

Image Resolution

3456 x 2592 (9M) / 3648 x 2048 (7M HD) / 2592 x1944 (5M) /

2048 x 1536 (3M) / 1920 x 1080 (2M HD) / 640 x 480 (VGA)

Video Resolution

640X480 pixels VGA (30 fps) / 320X240 pixels QVGA (30 fps)

File Format

JPEG (Photo) /AVI (Video)

Internal Memory

1 Test Photo Use Only

External Memory

SD Card (up to 32GB)

LCD Display

1.8 Inch TFT

Lens

f=7 mm F3.0

Zoom

4X Digital Zoom

Exposure

-3.0EV ~ +3.0EV

White Balance

Auto, Daylight, Cloudy, Fluorescent , Incandescent

ISO

Auto / 100 / 200 / 400

Scene

Auto, Night Portrait, Night Scenery, Portrait, Scenery, Beach, High

Sensitivity

Flash

No Flash, Forced On,Auto Flash, Red Eye Reduction

Self-Timer

2, 5 or 10 second delay

Anti-Shake

Yes (Photo Capture Mode)

Face Detect

Yes

Print Photos

Yes

Microphone

Yes

Macro

Yes, Manual Switch

Interface

USB 2.0

System Requirements

Windows XP (SP 3), Vista (SP1) and 7 ;

Mac OSX v10.5.x and above

Battery

3 * AAA (1.5V) batteries

Working Temperature

0~40C

Computer System Requirements

WINDOWS OS

To be able to download photos and videos to your PC using the Vivitar Experience Image

Manager Software, you will need the following minimum configuration:

Microsoft® Windows XP with Service Pack 3,Windows Vista with Service Pack 1 or Windows 7

Pentium® 4 processor (or above)

512 MB of RAM, with 250 MB of free hard disk space

16-bit Color monitor, 1024 X 768 recommended screen resolution

CD-ROM Drive

QuickTime® 6 or higher

Microsoft® Internet Explorer 7 or higher

Windows Media Player 10 or higher

DirectX 9 or higher

Internet connection required

MACINTOSH OS

To be able to download photos and videos to your Macintosh using the Vivitar Experience Image

Manager Software, you will need the following minimum configuration:

Intel processor running Mac OS X v10.5.x or later

256 MB RAM, 250 MB free hard disk space

Display: 1024 x 768 or higher-resolution monitor

QuickTime® 6 or higher

Internet connection required
